QuadPAR 7 & QuadPAR 18
1
User’s Manual
QuadPAR 7 & QuadPAR 18
www.showtech.com.au

QuadPAR 7 & QuadPAR 18
2
Table of Contents
1. Safety instructions…………………………………………………………3
1.1 Overhead rigging …………………………………………………….4
1.2 Power Connection …………………………………………………..6
1.3 Cleaning and Maintenance ……………………………………..6
2. Menu Setting …….………………………………………………………….7
3. DMX Allocation….………………………………………………………….8
4. Technical Specifications ………………………………………………10

QuadPAR 7 & QuadPAR 18
3
1. Safety Instructions
FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature.
Avoid exposing it to direct rays of sun near a heating appliance.
Do not put it in a temperature below 41°F/5°C, or exceeding 95°F/35°C.
Keep away from humidity, water and dust.
Do not place the set in a location with a high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
NO USER SERVICABLE PARTS INSIDE.
If unit is out of service please contact your point of purchase.
If any troubles arise, remove the power plug and contact your Pro Shop
representative for repair. Do not open the cabinet by yourself, it might result a
danger of electric shock.

QuadPAR 7 & QuadPAR 18
4
Take care with the power cable. Never pull the power cable to remove the plug from
the receptacle, be sure to hold the plug.
When not using the unit for an extended period of time be sure to disconnect the
plug form the receptacle.
1.1 Overhead Rigging
This item must be built in a way that it can hold 10 times more of its weight for 1
hour without causing any damages. The installation must be secured with a
secondary safety attachment. The Safety attachment has to be constructed in a way
that no part of the installation can fall down. When rigging, de-rigging or servicing
the fixture staying in the area below the installation place, on bridges, under high
working places and other endangered areas us forbidden. Before taking the device in
operation, the installation must be approved by an expert. The operator has to make
sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE.
Including (but not limited to) calculating working load limits, installation material
being used, and periodic safety inspection of all installation material and the
projector. If you lack these qualifications, do not attempt the installations yourself,
but instead use a professional structural rigger. Improper installation can result in
bodily injury and/or damage to property.
Use only professional trussing system if the item shall be lowered from the ceiling or
high joists. Never let the device swing freely in a room.

QuadPAR 7 & QuadPAR 18
5
CAUTION: Overhead Items may cause serious injuries when crashing down!! If there
is concern about the safety then DO NOT INSTALL the device.
DANGER OF FIRE!
When installing the device, make sure there is no highly-flammable material
(decoration articles, etc) within a distance of min. 0.5m.
Mount the projector with the mounting bracket to your trussing system using an
appropriate clamp.
For overhead use, always install a safety-rope that can hold at least 10 times the
weight of the fixture. You must only use safety –ropes with quick links with screw
cap. Pull the safety-rope through the hole in the mounting bracket and over the
trussing system or a safe fixation spot. Insert the end in the quick link and tighten the
safety screw. The maximum drop distance must never exceed 20cm
A safety rope which already held the strain of a crash or which is defective must not
be used again.
DANGER TO LIFE!
Before taking into operation for the first time, the installation has to be approved by
an expert.

QuadPAR 7 & QuadPAR 18
6
1.2. Power Connection
!! CAUTION !!
Never leave this device running unattended!! Every person that is involved with this
item has to be qualified!!
Connect item with main plug. The voltage and frequency must exactly be the same as
stated on the device. The power plug must always be inserted without force.
1.3. Cleaning and Maintenance
Please make sure that safety-relating and machine-technical installations are
inspected by a skilled person once a year.
1. Make sure before installing that all screws are tightly connected and not corroded.
2. There must be no deformations on the housings, fixations and installations spots
3. No damages must be showed on the power supply cables, material fatigue and
sediments
If the exterior of the unit is going to be cleaned, please use moist, lint free cloths.
Never use alcohol or solvents.
The Cooling fan must be cleaned monthly and check to ensure it is free of
obstructions.
To clean the interior of the device please use a vacuum cleaner or an air jet, however
we recommend cleaning the lenses weekly to ensure the best output from your unit.

QuadPAR 7 & QuadPAR 18
7
2.0 Menu Navigation
Menu
Level 2
Level 3
Auto
Auto 1
Speed (0-100)
Auto 2
Speed (0-100)
Auto 3
Speed (0-100)
Auto 4
Speed (0-100)
Auto 5
Speed (0-100)
Static
FIX c
RGBW
Manu C
R (0-255), G (0-255), B (0-255), W (0-
255)
Dim mode
DIM 1
DIM 2
DIM 3
Back Lite
ON
10S
20S
30S
Info
TEST
Fix
Hours
Version
Address (DMX
address)
1-512
Channel (personality)
10 ch
(set max dmx address to 502)
5 ch
(set max dmx address to 507)
4 ch
(set max dmx address to 508)
Master/Slave
Master
Slaver

QuadPAR 7 & QuadPAR 18
8
3.0 DMX Allocation
4CH MODE:
CHANNEL
VALUES
FUNCTION
1
000-255
Red 0~100%
2
000-255
Green 0~100%
3
000-255
Blue 0~100%
4
000-255
White 0~100%
5CH MODE:
CHANNEL
VALUES
FUNCTION
1
000-255
Master Dimmer 0~100%
2
000-255
Red 0~100%
3
000-255
Green 0~100%
4
000-255
Blue 0~100%
5
000-255
White 0~100%
10CH MODE:
CHANNEL
VALUES
FUNCTION
1
000-255
Master Dimmer 0~100%
2
000-255
Red 0~100%
3
000-255
Green 0~100%
4
000-255
Blue 0~100%
5
000-255
White 0~100%
000-010
No function
011-030
R100% G 0~100% B 0
031-050
R0~100% G100% B 0
051-070
R 0 G100% B 0~100%
071-090
R 0 G100~0% B 100%
091-110
R0~100% G 0 B100%
111-130
R100% G 0 B 100~0%
131-150
R100% G0~100% B 0~100%
151-170
R100~0% G100~0% B100% W 0~100%
6
171-200
R100% G100% B100% W100%

QuadPAR 7 & QuadPAR 18
9
201-205
Colour Temperature 1 Warm Warm
206-210
Colour Temperature 2
211-225
Colour Temperature 3
216-220
Colour Temperature 4
221-225
Colour Temperature 5
226-230
Colour Temperature 6
231-235
Colour Temperature 7
236-240
Colour Temperature 8
241-245
Colour Temperature 9
246-250
Colour Temperature 10
251-255
Colour Temperature 11 Cool Cool
7
000-009
No function
010-255
Strobe Slow ~ Fast
8
000-051
No function
052-101
Show 1 (Auto program 1)
102-152
Show 2 (Auto program 2)
153-203
Show 3 (Auto program 3)
204-254
Show 4 (Auto program 4)
255-255
Show 5 (Auto program 5)
9
000-255
Show Speed 0~100% (CH8@ 052-255)
000-051
Built-in Dimmer
10
052-152
Dimmer 1
153-203
Dimmer 2
204-255
Dimmer 3

QuadPAR 7 & QuadPAR 18
10
4.0 Technical Specifications
QuadPAR 7
QuadPAR 18
Light source: 12 x 8W (500mA x 4)
Light source: 18 x 8W (500mA x 3)
Quad-colour RGBWLEDs 50,000hrs
Quad-colour RGBW LED 50,000hrs
Beam angle: 25°
Beam angle: 25°
Power consumption:
120W
Power consumption: 200W
Equipped with Neutrik PowerCon
in/out
Equipped with Neutrik PowerCon in/out
AC power: 100V –240V 50/60Hz
AC power: 100V –240V 50/60Hz
Weight: 3kg
Weight: 5kg
