probst VM-301-KJ-GREENLINE User manual

51500024
V2
GB
Operating Instructions
Translation of original operating instructions
Installation Machine VM-301-KJ-GREENLINE
VM-301-KJ-GREENLINE

Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht
eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine
Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der
EU / EFTA senden wir Ihnen diese kostenlos nach. Für Länder außerhalb der EU / EFTA erstellen wir
Ihnen gerne ein Angebot für eine Betriebsanleitung in Landessprache, falls die Übersetzung nicht
durch den Händler/Importeur organisiert werden kann.
Please note that the product may not be used / put into operation without these operating
instructions in the national language. If you did not receive operating instructions in your national
language with the delivery of the product, please contact us. In countries of the EU / EFTA we will
send them to you free of charge. For countries outside the EU / EFTA, we will be pleased to provide
you with an offer for an operating manual in the national language if the translation cannot be
organised by the dealer/importer.

Contents
2 / 43
51500024
V2
GB
Contents
1EC-Declaration of Conformity ............................................................................................................................... 4
2Safety...................................................................................................................................................................... 5
2.1 Safety symbols................................................................................................................................................ 5
2.2 Definition skilled worker / specialist .............................................................................................................. 5
2.3 Safety Marking................................................................................................................................................ 5
2.4 Personal safety requirements ........................................................................................................................9
2.5 Protective equipment.....................................................................................................................................9
2.6 Accident prevention .......................................................................................................................................9
2.7 Function Control........................................................................................................................................... 10
2.7.1 General ..................................................................................................................................................... 10
2.7.2 Hydraulic................................................................................................................................................... 10
2.8 Safety procedures ......................................................................................................................................... 11
2.8.1 Equipment attachments........................................................................................................................... 11
2.8.2 Installation machine ................................................................................................................................. 11
2.8.3 Safety in the operation of the laying machine ........................................................................................ 11
2.8.4 Stability......................................................................................................................................................12
3General................................................................................................................................................................... 13
3.1 Authorized use...............................................................................................................................................13
3.1.1 Optional Accessories .....................................................................................................................................14
3.2 Survey and construction ...............................................................................................................................15
3.3 Technical data............................................................................................................................................... 16
4Operation .............................................................................................................................................................. 17
4.1 Charging the Lithium Ion Batteries...............................................................................................................17
4.2 Daily checks................................................................................................................................................... 18
4.2.1 Open cover............................................................................................................................................... 18
4.2.2 hydraulic oil check.................................................................................................................................... 19
4.2.2.1 Refill hydraulic oil .............................................................................................................................. 19
4.2.2.1.1 Folding the driver's seat down....................................................................................................20
4.2.3 Windscreen wiper water control (windscreen washer system - optional)........................................... 20
4.2.4 Control displays / Function checks...........................................................................................................21
4.3 Display - Overview of functions ................................................................................................................... 22
4.4 System start .................................................................................................................................................. 24
4.5 Driving with the installation machine.......................................................................................................... 25
4.6 Driver seat adjustment ................................................................................................................................. 25
4.7 Operating elements......................................................................................................................................26
4.7.1 System start / foot pedals (driving brakes) ............................................................................................ 26
4.7.2 Driving speeds.......................................................................................................................................... 27
4.7.3 Electronic Joystick ................................................................................................................................... 28
4.7.4 Ventilation / Heating ................................................................................................................................ 29
4.8 Mounting additional equipment..................................................................................................................30
5Transport ...............................................................................................................................................................31
5.1 Transport of the installation machine ..........................................................................................................31
5.2 Lifting the machine with a crane ................................................................................................................. 33
5.3 Towing the installation machine.................................................................................................................. 33

EC-Declaration of Conformity
3 / 43
51500024
V2
GB
6Storage ................................................................................................................................................................. 34
7Maintenance and care ......................................................................................................................................... 35
7.1 maintenance ................................................................................................................................................. 35
7.1.1 Mechanical .................................................................................................................................................... 35
7.1.2 Electrics ....................................................................................................................................................36
7.1.3 Fuse assignment (dash panel)................................................................................................................. 37
7.1.4 Hydraulic...................................................................................................................................................38
7.2 Lubrication plan ............................................................................................................................................40
7.3 Trouble shooting .......................................................................................................................................... 42
7.4 Repairs .......................................................................................................................................................... 42
7.5 Safety procedures ........................................................................................................................................ 42
7.6 Hints to the type plate..................................................................................................................................43
7.7 Hints to the renting/leasing of PROBST devices ......................................................................................... 43

EC-Declaration of Conformity
4 / 43
51500024
V2
GB
1EC-Declaration of Conformity
Description:
Type:
Order number:
Installation Machine VM-301-KJ-GREENLINE
VM-301-KJ-GREENLINE
51500024
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[email protected]om
www.probst-handling.com
The machine described above complies with the relevant requirements of the following EU directives:
EC-machinery directive 2006/42/EC
2014/30/EU (Electromagnetic compatibility)
The following standards and technical specifications were used:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction (ISO 12100:2010)
DIN EN ISO 13857
Safety of machinery - safety distances to prevent hazard zones being reached by upper and lower limbs (ISO 13857:2008)
DIN EN 60204-1 (IEC 60204-1)
Safety of machinery, electrical equipment of industrial machines. Part 1: General requirements.
Authorized person for EC-documentation:
Name: J. Holderied
Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany
Signature, information to the subscriber:
Erdmannhausen, 07.01.2020..........................................................................
(Eric Wilhelm, Managing director)

Safety
5 / 43
51500024
V2
GB
2Safety
2.1 Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property
can result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
Important informations or useful tips for use.
2.2 Definition skilled worker / specialist
Only skilled workers or specialists is it allowed to carry out the installation,- maintenance, - and repair work on these
device!
Skilled workers or specialists must have for the following points (if it applies for
these device), the necessary professional knowledge.
•for mechanic
•for hydraulics
•for pneumatics
•for electrics
2.3 Safety Marking
PROHIBITION SIGN
Symbol
Meaning
Order-No.
Size
It is not allowed to stand under hanging loads. Danger to life!
2904.0210
2904.0209
2904.0204
Ø 30 mm
Ø 50 mm
Ø 80 mm
It is forbidden to ride on the installation machine!°
2904.0762
Ø 80 mm
Do not open the tool cover while the engine/system is running!
2904.0259
70 x 115 mm

Safety
6 / 43
51500024
V2
GB
Cleaning with a high pressure cleaner or water in the area of the
cover is prohibited. Danger of short-circuit/electric shock to
electronic components.
29040839
70x55 mm
WARNING SIGN
Symbol
Meaning
Order-No.
Size
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30 x 30 mm
50 x 50 mm
80 x 80 mm
Do not reach into the fan with your hands -
Risk of injury to the hands
29040838
60 x30 mm
Warning of electric voltage
2904.0397
31 x 27 mm
Warning of battery acid.
2904.0551
31 x 27 mm
Danger: Keep distance to the machine..
2904.0756
64 x 103 mm
REGULATORY SIGN
Symbol
Meaning
Order-No.
Size
Each operator must have read and understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
Ø 30 mm
Ø 50 mm
Seat belt duty
On every drive with the machine the seat belt must always be worn.
2904.0450
Ø 52 mm
Pull hand brake in idle machine time. To drive release handbrake.
2904.0267
45 x 80 mm

Safety
7 / 43
51500024
V2
GB
Drive forward and backward with the right foot pedal.
The pedal must not only be operated with the tips of the shoes!
To be able to react quickly in dangerous situations, the shoe must be
fully positioned on the control pedal.
2904.0760
68 x 43 mm
Lifting and lowering boom arm with left foot pedal.
2904.0759
48 x 43 mm
Suspension point for transport goods for lifting (recovering) the
laying machine
2904.0370
23 x 60 mm
Lashing eyelet for securing the laying machine to the transport vehicle
by means of chains or tension belts
2904.0755
Ø 60 mm
The steering of the machine must be locked before transport!
2904.0818
90 x 55 mm
OPERATING INFORMATIONS
Symbol
Meaning
Order-No.
Size
Max. 600 kg (1,320 lbs)→VM-301
Maximum weight paver load 320 kg (710 lbs)
with counterbalance 380 kg (840 lbs)
2904.0616
40 x 160 mm
Max. 650 kg (1,430 lbs)→VM-301-K
Maximum weight paver load 380 kg (840 lbs) (837,8 lbs) with
counterbalance 440 kg (970 lbs)
2904.0623
40 x 160 mm
Button for horn / reset button:
Press reset button each time for the driving, when the machine will be
started and when the driving was stopped caused by the standing up
of the diver from the driver´s seat (triggered by the seat switch).
The reset button only works (and the driving of the machine), when
the driver is sitting in the s seat.
2904.0716
90 x 23 mm
Open cover hood
2904.0253
28 x 85 mm
After approx. 40 days of machine idle the 12 V battery for operating
voltage (radio, lighting etc.) must be charged, otherwise no system
start is possible.
29040837
45x45 mm

Safety
8 / 43
51500024
V2
GB
Joystick / control lever:
Movement directions for the Control / operation of attachments (e.g.
for opening and closing the main and side clamping at a HVZ)
2904.0260
50 x 50 mm
Electronic joystick with function controls as well as activations of
additional functions.
Function controls: for controlling of a hydraulic installation clamp
(HVZ) →opening and closing of the main and side clamping.
Additional functions:
- Rotating movement of a hydraulic rotator
- Vacuum operation (suction and release of load)
- Horn/reset button (reset button for releasing the seat switch)
Reset button for driving must be pressed each time the laying
machine is started, or the driving was stopped due to the driver
getting up from the driver's seat (triggered by the seat switch).
The reset button (and driving the machine) only works when the
driver is in the driver's seat.
29040836
70x55 mm
Press and hold the button (in the driver's cabin next to the ignition
switch) for at least 2 seconds to start the system.
29040835
50 x12 mm
Release the parking brake when the LED (in the driver's cab next to
the fuses) lights up red.
29040834
40 x33 mm
Fuses (symbols and ampere rating) in driver's cabin.
29040808
125 x45 mm

Safety
9 / 43
51500024
V2
GB
2.4 Personal safety requirements
Each operator must have read and understood the operating instructions (and all safety instructions).
Only qualified, authorized personal is allowed to operate the device and all devices which are connected
(lifting device/carrier).
The manual guiding is only allowed for devices with handles.
IMPORTANT INFORMATION REGARDING SAFETY, STORAGE, HANDLING AND THE LIKE MUST BE OBSERVED
AND CAN BE FOUND IN THE ENCLOSED PRODUCT DATA SHEET OF THE LITHIUM-ION BATTERIES.
2.5 Protective equipment
The protective equipment must consist, according to the safety regulations
of the following parts:
•Protective clothing
•Safety gloves
•Safety shoes
2.6 Accident prevention
•The workplace has to be covered for unauthorized persons, especially children.
•Take care in case of thunderstorm!
•The workplace must be sufficiently illuminated.
•Take care with handling wet, dirty and not solidified components.
•The working with the device in case of atmospheric editions under 3° C(37,5° F) is forbidden!
Because the goods could be fall down caused by dampness or freezing.
Caution during operation, dismantling and maintenance work on the laying machine!
There is a risk of electric shock, etching and burns from battery acid and various engine fluids.
Appropriate protective measures must be taken and protective equipment worn in order to avoid serious
injuries or even death!

Safety
10 / 43
51500024
V2
GB
2.7 Function Control
2.7.1 General
•Before every usage of the device check the functions and the working condition.
•Maintenance and lubrication are only permitted when device is shut down!
•Do not use the device, until all faults which can cause safety hazards are removed.
•If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
•The operating instructions must be available at the workplace every time.
•Do not remove the type plate of the machine.
•Unrecognisable information signs (such as regulatory or prohibition signs) must be replaced.
2.7.2 Hydraulic
Check all hydraulic hoses and connection for tightness before every operation. Only experts are allowed to
replace faulty parts (depressurized).
Ensure a clean working environment before opening the hydraulic connection.
The hydraulic hoses must be free of breaks and abrasion. Take care that there are no outstanding edges,
where the hoses could hook in.
The operator of the device is responsible for a constant line pressure, which is necessary for the working
with this device.
Only under these conditions is a safety gripping, lifting and transporting of the gripping goods with this
device ensured.

Safety
11 / 43
51500024
V2
GB
2.8 Safety procedures
2.8.1 Equipment attachments
During all adjustments on equipment attachments (e.g. HVZ-UNI) it must be ensured that the attachment
cannot close unintentionally. Risk of injury!
All adjustments may only be made when the laying machine is shut down (pull handbrake) and the engine is
switched off!
2.8.2 Installation machine
•The installation machine has to be in good, safe working condition.
•Never exceed the maximum capacity/working load limit (WLL) of the installation machine!
•Only authorized and qualified persons are allowed to operate the installation machine.
•The operator must have all the necessary qualifications.
2.8.3 Safety in the operation of the laying machine
•The entry and exit may only be done from the left side (in the direction of travel) in order to avoid
unintentional activation of the controls.
•The operation of the laying machine is generally only permitted under optimum visibility conditions and
enough lighting (e.g. daylight)!
•By retrofitting appropriate headlamps (light package VM-301), work is also permitted in the dark.
•Always lower the load to approx. 20 cm above the ground when moving!
•The maximum load of the laying machine, its attachments (e.g. HVZ-UNI) and the loads attached to
them must not be exceeded!
•When leaving the laying machine, the driver must pull the handbrake and ensure that the laying
machine is on a horizontal surface. If necessary, use wheel chocks or the like to prevent the laying
machine from rolling away unintentionally.
•Unattended parking of the laying machine on inclined and sloping surfaces is not permitted!
•During operation of the machine, the operator must always ensure that the machine is in a safe
operating condition.
•Always disconnect the battery when working on the electrical system. Risk of electrical shock!

Safety
12 / 43
51500024
V2
GB
It is forbidden for persons to ride on the laying machine (by hanging on from the outside)!
Accident/life hazard!
•It is generally forbidden for persons to stand in the working and travel area of the installation
machine during installation work.
A minimum safety distance of 1.5 m between the person and the machine must be observed!
Exception: It is essential due to the type of use of the implement, e.g. by manually guiding a implement
at the handles.
•It is generally forbidden to stand under a suspended load!
•It is strictly forbidden to stand in the steering area/kink area of the machine! Risk of crushing the
feet/legs between the front wheels and the chassis.
•The driver must not leave the control position if the attachments of the laying machine are loaded
with laying material and the system is in operation.
•Never let the control lever valve (joystick) for operating the attachments, the control pedal for forward
and reverse travel or the control pedal for up and down movement of the boom spring back.
Otherwise there will be pressure surges in the forward and return lines! The laying material may fall
down and the hydraulic motors may be damaged!
2.8.4 Stability
Danger of overturning!
Only drive at walking speed and with the boom lowered (with and without load) if the following applies:
•No attachment equipment (e.g. HVZ-UNI) mounted on boom
•Driving curves
•Driving in unpaved and uneven terrain
•Terrain with slope
•Machine slope of more than 10° (~ 18 %)
Driving faster than step speed allowed if the following applies:
•Drive straight ahead (with and without attachment equipment and stone position)
•Driving in paved and level terrain
•Check terrain in advance for sufficient surface condition (such as large holes or broken ground).
•When using the laying machine on roofs, parking decks or other soft ground, the load capacity of the
ground must be checked in advance.
•In the event of accidents or when the laying machine tilts over, load-bearing parts must be inspected by
a specialist workshop before the machine is put back into operation.

General
13 / 43
51500024
V2
GB
3General
3.1 Authorized use
•The machine is only designed for the use specified in this documentation.
•Every other use is not authorized and is forbidden!
•All relevant safety regulations, especially regulations of the declaration of conformity, and additional
local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
•the machine is suited to the intended operation, the functioning and the working condition of the
equipment is examined and the loads are suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
•The installation machine VM-301-KJ-GREENLINE in connection with the hydraulic installation clamp HVZ/HVZ-UNI is
used for laying interlocking paving stones in connection with the kerb stone laying clamp VZ-H-UNI (for laying kerb
stones).
•Only attachment equipment from Probst may be attached to the installation machine VM-301-KJ-GREENLINE, such
as:
-VZ-H-UNI, HVZ-STANDARD, HVZ-UNI, HVZ-UNI-II, HVZ-LIGHT.
- On request also Probst vacuum attachment equipment like SH-1000-MINI-H.
When using third-party attachment equipment on the Probst installation machine, the relevant safety
regulations and the technically necessary prerequisites (performance data) of the respective attachment
must be observed. In addition, all technical requirements of the Probst installation machine must
correspond to those of the third-party attachment equipment. The responsibility for this lies solely with
the operator of the installation machine!
•The installation machine is no lifting equipment!
•All instructions in the instructions handed over with the installation machine must be observed.
It is not allowed to use the installation machine in public traffic –only construction sites or private
ground!
NOT ALLOWED ACTIVITIES:
Unauthorized alterations of the device and the use of any self-made additional equipment could cause
danger and are therefore forbidden!
Use of the machine after substantial modification, as well as after improper troubleshooting/maintenance
Never exceed the carrying capacity/working load limit (WLL) and the nominal width/nominal size of the
device.
All unauthorized transportations with the device are not allowed:
•Transportation of people and animals.
•Transportation of other loads and materials than described in this manual.
•Never suspend any goods with ropes, chains or similar at the device.

General
14 / 43
51500024
V2
GB
3.1.1 Optional Accessories
Type
Description
LED light package:
combination headlights (close/distance), 1 rear spotlight
LED- rotating beacon:
with fold-down stand incl. mounting material
VM-RFW:
reversing alarm VM-301
Exterior mirror:
retrofit kit
Mounting:
for light and/or mirror (only needed once
Additional weight:
for increasing the load capacity by 60 kg 1)
Windscreen washer system:
without wiping interval. Retrofit kit for VM-301-K
Additional battery:
for 50% more battery lifetime
1) with adjusted forward speed and lowered load. Max. Weight of the stone layer see technical data.

General
15 / 43
51500024
V2
GB
3.2 Survey and construction

General
16 / 43
51500024
V2
GB
3.3 Technical data
Traction drive:
8 kW
Hydraulic drive:
5 kW
Effective value of the acceleration to which the body is exposed:
< 0.5 m/s²
Landing gear:
Double articulated steering
Driving speeds:
Drivingstage I: approx. 11 km/h
Speed stage II: approx. 6 km/h
Dimensions and weights:
Total height / total width / total length:
1,980 mm / 1,220 mm / 3,610 mm
Total weight:
1,565 kg ①
Load capacity:
650 kg *
Max. Weight of attachments with attached loads:
320 kg (with additional weight 380 kg) *
380 kg (with additional weight 440 kg) *
maximum height of acceptance:
1.600 mm
Turning radius on the front inner wheel / outer wheel:
700 mm / 1,900 mm
Turning radius (above all):
2.450 mm
Ground clearance:
180 mm
Operating voltage (travel drive / working hydraulics):
48 V
Operating voltage (lighting, radio etc.)
12 V
Battery technology (basic version):
2x lithium-ion battery, 48 V each, 105 Ah, (total 210 Ah)
-Charging technology:
2x on-board chargers, à 48V, 50 A (total 100 A)
-Charging time at 230 V mains:
0% →100% = approx. 4.6 h
-Charging time at 400 V mains:
0% →100% = approx. 2.3 h
-Battery life (100 % →0 %):
approx. 6 h (depending on operating mode)
-starter battery
12 V
Battery technology (optional additional battery):
3x lithium-ion battery, 48 V each, 105 Ah, (total 315 Ah)
-charging technology
2x on-board chargers, à 48V, 50 A (total 100 A)
-Charging time at 230 V mains:
0% →100% = approx. 7 h
-Charging time at 400 V mains:
0% →100% = approx. 3.5 h
Battery life (100 % →0 %):
approx. 9 h (depending on operating mode)
Working hydraulics:
180 bar, 20 l/min
fill quantities
hydraulic oil
18 l
HLP 46
Sit:
height adjustable in 3 steps or infinitely variable, back and forth, backrest adjustable, spring strength
adjustable
* With adapted travel speed and lowered load.
① Total weight increases e.g. by retrofitting the optional (third) battery.

Operation
17 / 43
51500024
V2
GB
4Operation
4.1 Charging the Lithium Ion Batteries
Before the daily use of the machine, it is recommended to charge the lithium-ion batteries completely!
The lithium-ion batteries may only be recharged by suitably qualified persons.
Due to electrical voltage (230 v /400V) there is a danger to life if used improperly.
•Check the battery charging capacity in the display (in the driver's cab) →see the following chapter "Operation" or
"Display - Function overview".
•Open cover (see following chapter "Opening the cover")
There are two ways to charge the two lithium-ion batteries:
-with 230 V →Charging time approx. 4.6 h (from 0 to 100% charging capacity)
-with 440 V →Charging time approx. 2.3 h (from 0 to 100% charging capacity)
After the start, the digital instrument displays the string of the following
parameters:
•BATTERY VOLTAGE (two-colour red upper LED).
•Current supplied by the charger (two-colour red lower LED).
•TIME in hours missing until the end of charging (two-colour green
upper LED).
•Ah (two-colour green lower LED).
By pressing the MODE key, the sequence of the parameters is locked and
the last displayed value is retained. Press the MODE button again to
restart the parameter sequence.
Charging socket for
charging cable for 400V
Charge and for charging
cable with adapter plug
for 230V charge

Operation
18 / 43
51500024
V2
GB
Color:
Description
red
Constant or maximum current phase (IUIa).
Flashing red (4s ON - 1s OFF)
Voltage regulation phase (IUIa).
Red and flashing green (4s ON - 1s OFF)
Overloading phase (IUIa).
Flashing green (4s ON - 1s OFF)
Waiting phase (for equalization) (IUIa).
green
Loading finished (with CU1 BA2)
Flashing green (4s ON - 1s OFF)
Equalizing pulse and floating
Green and red flash together.
Connection with CanConsolle or S/S HW-SW.
Before putting the installation machine into operation, the safety regulations must be observed and the
maintenance work carried out.
To ensure safe and trouble-free operation of the installation machine, the following daily checks must be
carried out in particular.
4.2 Daily checks
Before the initial start-up and generally before each start-up, all liquid levels (hydraulic oil, wiping water
(optional)) must be checked and refilled if necessary!
4.2.1 Open cover
•In order to open the cover ②, the unlocking button ①
on the cover ② must first be actuated.
①
②

Operation
19 / 43
51500024
V2
GB
4.2.2 hydraulic oil check
•The installation machine must stand on absolutely level
ground.
•To check the hydraulic oil, the hydraulic ram of the
boom must be fully retracted and the boom at the
bottom of the ground.
•The oil level must be in the middle to the upper third of
the sight glass ③. If this is not the case, the
corresponding hydraulic oil must be refilled!
As soon as the boom is moved all the way up,
the oil level drops to the lower part of the
sight glass.
4.2.2.1 Refill hydraulic oil
The installation machine must be placed on an
absolutely level surface.
To top up the hydraulic oil, the hydraulic ram
of the boom must be completely retracted or
the boom must be at the bottom of the
ground.
Otherwise the wrong oil level will be
displayed.
Switch off traction drive (ignition to 0)
The oil filler neck ④ is located under the
driver's seat. For this the driver's seat must be
folded down (see following chapter "Folding
the driver's seat down").
Open oil cap ④ and first fill in only a small
amount of hydraulic oil (HLP 46).
Observe oil level in sight glass ③!
Fill in hydraulic oil until the oil level is in the
upper third of the sight glass ③ . Then close
oil filler neck ④ again.
③
④
