Steiner SS244 Setup guide

WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
OWNER/OPERATOR’SMANUAL
& ILLUSTRATED PARTS LIST
09-205A REV B
MODELS:
75-70625 SLIP SCOOP 44” SS244
75-70630 SLIP SCOOP 48” SS248

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2003, TEXTRON INC

1
SLIP
SCOOP
IMPORTANTMESSAGE
Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best
designed and built anywhere.
This product comes with an Owner/Operator's Manual / Illustrated Parts List. The useful life and good service
you receive from this product depends to a large extent on how well you read and understand this manual. Treat
this product properly and adjust it as instructed, and it will give you many years of reliable service.
See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive
the best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest
life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and
instructions. You'll always be glad you did.
Jacobsen, a Textron Company
One Bob Cat Lane
Johnson Creek, WI 53038-0469
11-2004
TABLE OF CONTENTS FIGURES PAGE
INTRODUCTION/SPECIFICATIONS............................................................................................................. 2
SAFETY ..................................................................................................................................................... 3, 4
ASSEMBLY INSTRUCTIONS ........................................................................................................................ 5
INSTALLATION/OPERATION ........................................................................................................................ 6
PARTS SECTION .......................................................................................................................................... 7
HYDRAULIC SLIP SCOOP PARTS ................... FIGURE 1 ..................................................................... 8, 9

2
SLIP
SCOOP
INTRODUCTION/SPECIFICATIONS
SPECIFICATIONS
Model 75-70625 75-70630
Overall width: ............................48" ............................................ 52"
Overall height:...........................16" ............................................ 16"
Overall length:...........................33" ............................................ 33"
Width of bucket:........................44" ............................................ 48"
Bucket Capacity:.......................3.25 cubic ft. ............................. 3.5 cubic ft.
Dumping: ..................................Hydraulic................................... Hydraulic
Ground Clearance (transport): .12" on Model 430 ..................... 12" on Model 430
Ground Clearance (dumped):...9" on Model 430 ....................... 9" on Model 430
Weight.......................................135 lbs. ..................................... 170 lbs.
NOTE: Specifications are subject to change without notice.
DESCRIPTION
The Slip Scoop attachment mounts on the quick hitch front lift of the power unit. On or off in a
minute or less, it is a quick, inexpensive way to relocate loose materials. Use it for landscaping, light
excavating and many tasks where you would normally use a wheelbarrow. Twin hydraulic cylinders control
the bucket position on hydraulic operated slip scoops.

3
SLIP
SCOOP SAFETY
NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Jacobsen, a Textron Company strongly warns
against, rejects and disclaims any modifications,
add-on accessories or product alterations that are
not designed, developed, tested and approved by
Jacobsen Engineering Department. Any Jacobsen
product that is altered, modified or changed in any
manner not specifically authorized after original
manufacture–includingtheadditionof“after-market”
accessories or component parts not specifically
approved by Jacobsen–will result in the Jacobsen
Warranty being voided.
Anyandallliabilityforpersonalinjuryand/orproperty
damagecausedbyanyunauthorizedmodifications,
add-on accessories or products not approved by
Jacobsen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Jacobsen will vigorously
pursuefull indemnification andcosts from anyparty
responsibleforsuchunauthorizedpost-manufacture
modifications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manual and on the safety labels attached to
Jacobsenmachines.Foryoursafetyandthesafety
ofothers,readandfollowtheinformationgivenwith
thesesignalwordsand/orthesymbolshownabove.
DANGER indicates an imminently hazardous
situationwhich, ifnot avoided, WILL resultin death
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, MAY result in minor
or moderate injury. It may also be used to alert
against unsafe practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage
MODEL NUMBER: This number appears on
sales literature, technical manuals and price
lists.
SERIAL NUMBER: This number appears only
on your mower. It contains the model number
followed consecutively by the serial number.
Use this number when ordering parts or seeking
warranty information.

4
SLIP
SCOOP
SAFETY
1. Read and understand the Owner’s Manual before attempting to operate this machine.
2. Operate all controls from the operator’s seat. NO RIDERS.
3. Keep all shields in place and safety switches adjusted properly.
4. Do not leave equipment unattended. STOP the engine and remove the key.
5. Do not allow minors or the inexperienced to operate this machine.
6. Keep people and pets a safe distance away from machine using power driven attachments. Injury
could result from flying debris.
GENERALSAFETY
OPERATINGSAFETY
1. Do not attempt to work on unit or any
attachments with engine running. STOP
ENGINE!
2. WARNING! The tractor may coast when the
engine stops.
3. Before leaving the tractor seat:
• Set Parking brake.
• Stop Engine.
CARRY LOADS LOW AND AVOID HIGH SPEEDS
OR QUICK, SHARP TURNS. A REAR WEIGHT
BAR SHOULD BE ADDED WITH WEIGHT EQUAL
TO THE SCOOP LOAD.

5
SLIP
SCOOP ASSEMBLY INSTRUCTIONS
Refer to Pages 8 & 9 for Parts
Identification
Assembly Instructions 75-70625
1. Unfasten the bucket (Fig. 1, Item 16) and the
sub-frame (Fig. 1, Item 15) from the sides of the
crate and remove.
2. Remove the hardware package from the crate
and open.
3. Loosen all ball joints prior to connecting them to
the bucket.
4. Place the bucket between the frame arms so
that the holes at the ends of the arms line up
with the lower set of holes on each side of the
bucket.
5. Insert a 5/8 X 2-1/2 bolt (Fig. 1, Item 19) through
the end of each arm and place three 5/8 flat
washers (Fig. 1, Item 12) on each bolt. Insert
the bolts through the lower holes on each side
of the bucket. Place a 5/8 lockwasher
(Fig. 1, Item 17) and 5/8 nut (Fig. 1, Item 18) on
each bolt and tighten.
6. Insert a 5/8 X 2-3/4 bolt (Fig. 1, Item 3) through
the rod end of each cylinder (Fig. 1, Item 4) and
place a bushing (Fig. 1, Item 5) on each bolt.
Insert the bolts through the upper holes on each
side of the bucket. Place a 5/8 lockwasher (Fig.
1, Item 17) and a 5/8 nut (Fig. 1, Item 18) on
each bolt and tighten.
Assembly Instructions 75-70630
1. Unfasten the bucket (Fig. 1, Item 16) and the
sub-frame (Fig. 1, Item 15) from the sides of the
crate and remove.
2. Remove the hardware package from the crate
and open.
3. Loosen all ball joints prior to connecting them to
the bucket.
4. Place the bucket between the frame arms so
that the holes at the ends of the arms line up
with the lower set of holes on each side of the
bucket.
5. Insert a 5/8 X 2-3/4 bolt (Fig. 1, Item 3) through
the lower hole on each side of the bucket.
(Through the outer bracket only.) Insert bolts
through the end of each arm and place one
bushing (Fig. 1, Item 5) on each bolt. Push the
bolts through the bucket. Place a 5/8 stover
locknut (Fig. 1, Item 18) on each bolt and
tighten.
6. Insert a 5/8 X 2-3/4 bolt (Fig. 1, Item 3) through
the upper hole on each side of the bucket.
(Through the outer bracket only.) Insert bolts
through the rod end of each cylinder
(Fig. 1, Item 4) and place a bushing
(Fig. 1, Item 5) on each bolt. Push the bolts
through the bucket. Place a 5/8 stover locknut
(Fig. 1, Item 18) on each bolt and tighten.

6
SLIP
SCOOP
INSTALLATION/OPERATION
HYDRAULIC SLIP SCOOP OPERATION
1. Use “Low” (1) range for operating scoop.
2. Level the scoop, for loading materials, by moving the auxiliary hydraulic lever. To dig into the surface,
the front edge of the scoop must be lower than the rear.
3. When the scoop is loaded, move the auxiliary hydraulic lever to roll back the scoop to contain the load.
4. To dump the load, move the auxiliary hydraulic lever.
NOTE: A rear weight bar is recommended to use with the Slip Scoop. Add weights equal to the load
carried in the scoop. Remove weights when the Slip Scoop is removed.
HINTS FOR OPERATION OF HYDRAULIC SLIP SCOOP
A. Use “FLOAT” position for loading loose materials on a firm surface.
B. Use DOWN PRESSURE to dig into firm surfaces.
C. To level loose materials, roll the bucket to the extreme dump position. Lower the scoop and move
backward to get a back blade leveling effect. Use a little down pressure.
HYDRAULIC SLIP SCOOP INSTALLATION
1. Attach the slip scoop to the front lift.
2. Attach the hydraulic hoses to the auxillary couplers. Route the hoses in a place where they will not be
damaged. If the hydraulic lever movement seems backward, reverse the hoses at the quick couplers..

7
SLIP
SCOOP PARTS SECTION
PARTS
SECTION

8
SLIP
SCOOP
HYDRAULIC SLIP SCOOP PARTS
FIGURE 1

9
SLIP
SCOOP
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
HYDRAULIC SLIP SCOOP PARTS
FIGURE 1
1-1 25-2103-4-6 FITTING-90 DEG. 4
1-2 20-217 HOSE-1/4 X 20 2
(USED ON 44" ONLY)
20-027 HOSE-1/4 2
(USED ON 48" ONLY)
1-3 90-1022 BOLT-5/8 X 2-3/4
(USE QTY 4 ON 44")
(USE QTY 6 ON 48")
1-4 23-058 CYLINDER-1-1/2 X 5 2
21-0A009066 SEAL KIT-CYLINDER 1
1-5 64163-12 .635/.640X1.0X.25 WASH
(USE QTY 10 ON 44")
(USE QTY 12 ON 48")
1-6 25-033T-6-6 FITTING-TEE 2
1-7 20-074 HOSE-1/4 X 31 2
1-8 25-0103-4-6 FITTING 2
1-9 23-004 QUICK COUPLER-MALE 2
1-10 20-029 HOSE-1/4 2
(USED ON 44" ONLY)
20-022 HOSE-1/4 2
(USED ON 48" ONLY)
1-11 64025-29 NUT-HEX #8-32 KEPS
(USE QTY 3 ON 44")
(USE QTY 4 ON 48")
1-12 64163-73 WASHER 6
1-13 4134161 CLAMP-HOSE RETAINER
(USE QTY 3 ON 44")
(USE QTY 4 ON 48")
1-14 01-014 SCREW, MACHINE 8-32 X 1
(USE QTY 3 ON 44")
(USE QTY 4 ON 48")
1-15 62-734.7 FRAME 1
(USED ON 44" ONLY)
64-985.7 FRAME 1
(USED ON 48" ONLY)
1-16 62-735.17 BUCKET 1
(USED ON 44" ONLY)
64-984.17 BUCKET 1
(USED ON 48" ONLY)
1-17 64006-04 LOCKWSHR-HELICAL 5/8 6
(USED ON 44" ONLY)
1-18 64025-21 NUT-HEX 5/8-11 6
(USED ON 44" ONLY)
99-A10 LOCKNUT-5/8 STOVER 6
(USED ON 48" ONLY)
1-19 90-1020 BOLT-5/8 X 2-1/2 2
(USED ON 44" ONLY)
1-20 F5012 NUT-JAM NYL INSERT 1/2 1
(SN 1001-1300)
(USED ON 48" ONLY)
43067A COLLAR, SET, PLATE 1
(SN1301 & UP)
1-21 02-PP0313 PRESTO PIN-3/32 X 1-5/8 1
(USED ON 48" ONLY)
1-22 64-986 KICKSTAND-(SN 1001-1300) 1
(USED ON 44" ONLY)
64-999.7 KICKSTAND-(SN 1301 & UP)
(USED ON 48" ONLY)
1-23 29-010 GREASE FITTING 2
(USED ON 48" ONLY)
* 4116761 DECAL-MADE IN THE USA 1
* 4128363 DECAL-STEINER 1
*NOT ILLUSTRATED

BOB-CAT BROUWER BUNTON CUSHMAN RYAN STEINER
Equipment from Jacobsen, a Textron company,
is built to exacting standards ensured by
ISO 9001 and ISO 14001 registration at all our
manufacturing locations.
A worldwide dealer network and factory-trained
technicians backed by Textron Parts Xpress
provide reliable, high-quality product support.
