FormNo.3407-632RevB
SteelFlatBedKit
Workman®GTXSeriesUtilityVehicle
ModelNo.07148
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Nopartsrequired–Preparethemachine.
Nopartsrequired–Removetheplasticcargobed.
Steelcargobed1
Flange-headscrew(5/16x3/4inch)3
ProprodUbracket1
Proprod1
Flange-headscrew(1/2x4-1/2inches)2
Locknut(1/2inch)2
Thandle1
Installthesteelcargobed.
Nopartsrequired–Installstakesidestothesteelatbed(optional).
PreparingtheMachine
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekeyfromthekeyswitch.
Figure1
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3407-632*B

RemovingthePlasticCargo
Bed
1.Usinganoverheadhoist,raisetheplasticcargobed.
2.Removethe3ange-headscrews(5/16x3/4inch)
andproprodUbracketfromtheproprod(Figure2).
Note:Retainthehardwareifyouwanttoinstallthe
plasticcargobedinthefuture.
Figure2
1.ProprodUbracket3.Proprod
2.Flange-headscrew(5/16
x3/4inch)
3.Slidetheproprodforwardoutofthedetentslotand
removetheproprod(Figure3).
Figure3
1.Detentslot2.Proprod
4.Usinganoverheadhoist,lowerthecargobed.
5.Removethe2pivotbolts(1/2x4-1/2inches)and2
locknuts(1/2inch)fromthepivotbracketlocatedat
therearofthemachine(Figure4).
Note:Retainthehardwareifyouwanttoinstallthe
plasticcargobedinthefuture.
Figure4
1.Pivotbolt(1/2x4-1/2
inches)
3.Locknut(1/2inch)
2.Pivotbracket
6.Releasethecargo-bedleverandraisethecargobed
usinganoverheadhoist.
2

InstallingtheSteelCargoBed
1.Removethe3ange-headscrews(5/16x3/4inch),
proprodUbracket,andproprodfromthebottomof
thesteelcargobed(Figure5).
Important:Retainthehardware.
Figure5
1.Proprod3.ProprodUbracket
2.Flange-headscrew(5/16
x3/4inch)
2.Usinganoverheadhoist,lowerthesteelcargobed
ontothemachine.
3.Alignthesteelcargobedwiththeholesattherear
ofthemachinewherethe2pivotbolts(1/2x4-1/2
inches)and2locknuts(1/2inch)werepreviously
removed.
4.Installthe2ange-headscrews(1/2x4-1/2inches)
throughthepivotbracketandsecurethemwiththe2
locknuts(1/2inch)asshowninFigure6.
Figure6
1.Flange-headscrew(1/2x
4-1/2inches)
3.Locknut(1/2inch)
2.Pivotbracket
5.Releasethecargo-bedleverandraisethecargobed
usinganoverheadhoist.
6.Slidetheshortendoftheproprodintothedetent
slot(Figure7).
Figure7
1.Detentslot2.Proprod
7.InstalltheproprodUbracketandproprodtothesteel
cargobedusingthe3ange-headscrews(5/16x3/4
inch)asshowninFigure8.
Figure8
1.Proprod3.ProprodUbracket
2.Flange-headscrew(5/16
x3/4inch)
3

8.InstalltheThandleontothebutton-headscrew(Figure
9).
Figure9
1.Button-headscrew2.Thandle
9.Tightenthejamnut(3/8inch)fullyagainsttheT
handle(Figure10).
Figure10
1.Jamnut(3/8inch)2.Thandle
4

InstallingStakeSides
Optional
Toinstalltheoptionalstakesides,youneedthefollowingmeasurementsandquantitiesofwood:
WoodDimensionsTotalLengthofEachBoardQuantityNeeded
38x89mm(2x4inch)36cm(14inches)8
29x140mm(5/4x6inch)117cm(46inches)8
Youalsoneedthefollowinghardware:
HardwareUseQuantityNeeded
Button-headbolt(5/16-18x3inches)Mountingthe29x140mm(5/4x6inch)
boardstothe38x89mm(2x4inch)
boards
32
Button-headbolt(5/16-18x2-1/2inches)Mountingthe38x89mm(2x4inch)
boardstothebed
16
Flangednylocnut(5/16-18inch)Securingthehardware48
Yourstructureshouldappearasfollows:
Figure11
1.29x140mm(5/4x6inch)board3.38x89mm(2x4inch)board
2.Frontofthestructure—ensurethattheboardsareoriented
asshown.
5

Notes:

Notes:

DeclarationofIncorporation
ModelNo.SerialNo.ProductDescriptionInvoiceDescriptionGeneralDescriptionDirective
07148NoneandUp
SteelCargoBedKit,
WorkmanGTXSeries
UtilityVehicle
STEELCARGOBEDKIT
[WORKMAN]UtilityVehicle2006/42/EC, 2004/108/EC
RelevanttechnicaldocumentationhasbeencompiledasrequiredperPartBofAnnexVIIof2006/42/EC.
Wewillundertaketotransmit,inresponsetorequestsbynationalauthorities,relevantinformationonthispartly
completedmachinery.Themethodoftransmissionshallbeelectronictransmittal.
ThismachineryshallnotbeputintoserviceuntilincorporatedintoapprovedT oromodelsasindicatedonthe
associatedDeclarationofConformityandinaccordancewithallinstructions,wherebyitcanbedeclaredin
conformitywithallrelevantDirectives.
Certied:EUT echnicalContact:
MarcVermeiren
ToroEuropeNV
B-2260Oevel-Westerloo
Belgium
DavidKlisTel.003214562960
Sr.EngineeringManagerFax003214581911
8111LyndaleAve.South
Bloomington,MN55420,USA
August11,2016
