Schwinn Daytripper User manual

Daytripper
OWNER’S MANUAL
This manual contains safety, assembly, use and maintenance
instrucons. Read these instrucons carefully before use and keep
them for future reference. Your safety may be aected if you do
not follow these instrucons. The Schwinn Bicycle Trailer must be
assembled by an adult who has read and understands the
instrucons in this manual. Keep the packaging away from children
and dispose all packaging before use.
Do not return to store. Call toll free 1-800-242-6110 for assistance
and replacement parts. Keep instrucons for future reference.
CARGO TRAILER
13-SC320

Thank You
ii Schwinn Cargo Trailer • model 13-SC320
For purchasing the Schwinn Cargo Trailer. If you have any quesons
or comments our customer service hours are:
8:00 AM - 5:00 PM Monday through Friday CST.
You may also reach us through the following:
Web: www.pacic-cycle.com
Email: customerservice@pacic-cycle.com
Mail: P. O. Box 344
4730 E. Radio Tower Lane
Olney, IL 62450
Important!
Do not return the product to the store. Please contact customer
service at 1-800-242-6110 for assistance and replacement parts.

Contents
Schwinn Cargo Trailer • model 13-SC320 iii
1 SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Assembly ......................................... 1
Safe Riding Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Trailer Use Warnings................................ 2
Care, Tips, Guidelines ............................... 2
2 PARTS AND FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3 ASSEMBLY ........................................4
Extend and Secure the Tow Bar....................... 4
Aach the Wheels.................................. 5
Unfold the Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Insert the Safety Flag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 TRAILER ATTACHMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Aach the Safety Strap............................. 16
5 USING THE CARGO TRAILER . . . . . . . . . . . . . . . . . . . . . . . .17
6 DISASSEMBLY AND STORAGE.......................19
7 MAINTENANCE AND PARTS . . . . . . . . . . . . . . . . . . . . . . . .22
Care ............................................22
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

1 Safety
WARNING!
FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW
MAY RESULT IN SERIOUS INJURY OR DEATH. Always read and
understand the informaon and warnings in this manual before
using the Bicycle Trailer.
If you are unsure of any informaon in this manual or have a
queson regarding assembly or use please call customer service.
Always keep this manual for reference and include it with resale
of the Bicycle Trailer.
ASSEMBLY
• An adult who has read and understands the informaon and
warnings in the manual shall assemble this product according
to manufacturer’s instrucons.
• Do not use the product if there are any missing or damaged
parts. Do not return the product to the store. Please contact
customer service at 1-800-242-6110 for assistance and
replacement parts.
• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury. Fold or unfold the trailer
slowly using cauon.
• Dispose of all plasc bags and wrapping material immediately.
SAFE RIDING WARNINGS
• Weight limit is 100 lbs. Do not carry loads exceeding 100 lbs,
as the extra weight and height will increase the center of
gravity, increasing the risk of p over
• Do not carry items that exceed the trailer’s frame by more
than 8” (high). Carrying taller loads will increase the trailers
center of gravity and increase the risk of p over. Be sure to
always keep the center of gravity as low as possible
• Do not carry humans or pets in this trailer
• Do not ride bicycle at excessive speeds as it increases the risk
of the trailer pping
• Avoid riding with the trailer on icy or slippery terrain, or when
inclement weather makes bicycling unsafe
• Avoid riding on sloped terrain, with wheels perpendicular
to the slope. Doing so will increase the likelihood of the
trailer pping
• Never tow trailer with any motorized vehicle
• Riding with this trailer increases your turning radius. Be sure
to allow for extra clearance around curbs, signs, cars, and
other obstacles.
• Make sure tow bar safety strap is properly secured, for
addional safety
1 Schwinn Cargo Trailer • model 13-SC320

WARNING!
TRAILER USE WARNINGS
• The canopy must be properly fastened in open or closed
posions (aached with buckles and secured by elasc straps)
to avoid interference with the bicycle or ground
• We do not recommend carrying loads that extend past the
back of the trailer’s frame. This can create a hazard by
interfering with the bicycle, ground, or other obstacles such
as curbs, signs, cars, etc.)
• Tires must be properly inated prior to use. Please refer to
the PSI recommendaons on the re for proper inaon
levels
• Over inaon of res may result in re failure and risk of
serious injury. Do not exceed the maximum inaon pressure
shown on the re
• Inspect and maintain the bicycle trailer regularly, before each
use. Ensure trailer hitch is properly aached and secure prior
to riding
• Do not leave trailer outside aer use. Inclement weather and
harsh elements may stress the fabric on the trailer
• Never leave your cargo unaended
• Do not transport ammable, explosive, poisonous, or other
hazardous material in your trailer
CARE/TIPS/GUIDELINES
• The canopy and side wall material is not weather resistant.
The contents of the trailer may get wet during inclement weather
• Riding with a trailer will increase your normal braking distance.
Pracce braking with the trailer in areas with less trac.
• Load heavier items in the front of the trailer bed to increase
stability
• Be sure to secure all loads with properly sized fasteners, ropes,
or straps
Schwinn Cargo Trailer • model 13-SC320 2

2 Parts and Features
3 Schwinn Cargo Trailer • model 13-SC320
Canopy
Wheels (2)
Safety Flag with pole
Tow bar
Tow bar locking pin
Bicycle coupler
Safety strap
Rear canopy buckle (2)
Flagpole sleeve
Front canopy buckle (2)
D-rings (4) for bungy
cord aachment Elasc bands (2) for
canopy buckles
Flag pole elasc band
Reector

• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury. Fold or unfold the trailer
slowly using cauon.
• Keep children clear when folding or unfolding the trailer.
• Ensure that all locking devices are engaged before use.
TIP! Start assembly with the tow bar side facing up.
❶ Unlock the tow bar by removing the safety loop on the end of
the locking pin. Remove the locking pin from the tow bar
bracket. Figure 3.1
❷ Rotate the tow bar out and away from the trailer. The tow bar
should rest on the front of the frame. Figure 3.1
3Assembly
EXTEND AND SECURE THE TOW BAR
WARNING!
Schwinn Cargo Trailer • model 13-SC320 4
Figure 3.1
1
Tow bar bracket
Locking
pin
2

❸ Re-insert the locking pin through the tow bracket, and lock it
by inserting the end of the safety loop onto the end of the
locking pin. Figure 3.2
❶ Remove the caps from the ends of the wheels axles.
❷ Insert the axle of the wheel completely into the hole located
on the side of the wheel bracket. Figure 3.3
ATTACH THE WHEELS
5 Schwinn Cargo Trailer • model 13-SC320
Figure 3.2 Figure 3.3
Wheels that are not securely locked in place may fall o the
trailer and cause serious injury or death. Always check the
wheels are securely locked in place before use.
WARNING!
3
2
1

❸ Insert the locking pin into the hole on the end of the axle and
slide the end of the safety loop over the end of the locking pin.
Check that the locking pin is securely in place. Figure 3.4
❹ Repeat steps 2 and 3 for the remaining wheel. Figure 3.5
Schwinn Cargo Trailer • model 13-SC320 6
Figure 3.4 Figure 3.5
34

• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury. Fold or unfold the trailer
slowly using cauon.
• Keep children clear when folding or unfolding the trailer.
• Ensure that all locking devices are engaged before use.
❶ Holding the end of the tow bar, li the tow bar and rotate the
bar up and around unl the trailer is right side up. Figure 3.6
UNFOLD THE FRAME
WARNING!
❷ Li the Right side wall up into a vercal posion. Figure 3.7
7 Schwinn Cargo Trailer • model 13-SC320
Figure 3.7Figure 3.6
1
2

❸ Li the le side wall up into a vercal posion. Figure 3.8 ❹ Rotate the back crossbar unl it locks into the back crossbar
latch. Figure 3.9
Schwinn Cargo Trailer • model 13-SC320 8
Figure 3.8 Figure 3.9
Release buon
Lock
4
3
4
Crossbar latch

❺ Rotate the front crossbar unl it locks into the front crossbar
latch. Figure 3.10 ❻ Pull the canopy over the back end of the trailer. Figure 3.11
❼ Secure the canopy by fastening the buckles on the sides of the
trailer. Figure 3.11
9 Schwinn Cargo Trailer • model 13-SC320
Figure 3.10 Figure 3.11
Release buon
Lock
5
5
Crossbar latch
7
6

INSERT THE SAFETY FLAG
Important! The safety ag is an important safety feature that
warns others that a trailer is present and on the bicycle.
Always have the safety ag on the trailer when in use.
❶ Insert the top half of the pole into the opening of the boom
half of the pole.
❷ Insert the ag pole through the elasc loop on the back of the
trailer and into the ag pole sleeve. Figure 3.13
❽ Fold the remaining secon of the canopy over the back
crossbar, and tuck the buckles of the canopy into the elasc
bands inside the boom corners of the trailer bed. Figure 3.12
Schwinn Cargo Trailer • model 13-SC320 10
Figure 3.12 Figure 3.13
1
2
8
Elasc
loop

4 Trailer Aachment
Use of the trailer without the safety strap aached to the bicycle
may result in serious injury or death. Always aach the safety
strap to the bicycle when using the trailer.
Important! This secon provides instrucons for aaching the
trailer coupler to the bicycle’s REAR WHEEL with a hub nut or quick
release lever. The coupler aaches to most bicycles.
❶ To ensure secure aachment of the coupler to the bicycle, be
sure the thread of the rear axle extends at least 2 mm’s from
the hub nut before proceeding to the next step. Figure 4.1
❷ Using a wrench, remove the hub nut and washer from the
bicycle’s back wheel. Figure 4.2
❸ Place the tab washer on the axle. Fit the tab into the slot on
the bicycle frame dropout. Note: If your bicycle frame doesn’t
have a slot in the drop out, rotate the tab to t into the axle
slot. Figure 4.3
Washer
Hub nut
3
2
Slot
Tab
washer
1
Figure 4.1
Figure 4.2
Figure 4.3
2 mm
2 mm
2 mm
WARNING!
11 Schwinn Cargo Trailer • model 13-SC320

❸ Remove the safety loop from the end of the locking pin on the
end of the coupler. Figure 4.4
❹ Remove the locking pin from the coupler and slide the coupler
o the end of the tow bar.
Figure 4.4
3
4
❺ Insert the coupler plate onto the wheel axle. Place the coupler
in a horizontal posion so that it is in line with the tow bar.
❻ Place the hub nut and washer back onto the axle and ghten.
Figure 4.5
Figure 4.5
Coupler
Incorrect
coupler
placement
Washer Hub nut
5
6
Schwinn Cargo Trailer • model 13-SC320 12

ATTACHMENT WITH QUICK RELEASE
❶ Release the quick release lever, skewer and remove the nut
and spring from the opposite side of the wheel.
❷ Remove the axle skewer and spring. Leave the wheel in place.
Figure 4.7
❼ Slide the tow bar into the open end of the coupler.
Important! Ensure the coupler is completely in line with the
tow bar. This reduces stress on the tow bar.
❽ Insert the locking pin into the hole on the top of the coupler.
Slide the safety loop over the end of the lock pin.
Important! Ensure the loop of the safety pin is facing away
from the wheel to prevent possible fricon against the wheel
and spokes of the bicycle. Figure 4.6
Figure 4.6
8
Figure 4.7
Skewer
Inner
Spring
Quick
release lever
Nut
Outer
spring
2
Quick release
lever and spring
8
7
13 Schwinn Cargo Trailer • model 13-SC320

❸ Place the tab washer on the axle. Fit the tab into the slot on
the bicycle frame dropout. Note: If your bicycle frame doesn’t
have a slot in the drop out, rotate the tab to t into the axle
slot. Figure 4.8
❹ Insert the coupler plate onto the wheel axle. Figure 4.9
❺ Insert the quick release lever, spring and nut that were
removed in step 1 through the wheel.
❻ Rotate the quick release lever up and ghten. When properly
tightened, the quick release lever should leave an imprint in
your hand. The pressure should be firm but not excessive.
Figure 4.9
Quick
release lever
and spring
Figure 4.8
Tab
washer
Slot 4
5
Schwinn Cargo Trailer • model 13-SC320 14

❼ Slide the tow bar into the open end of the coupler.
Important! Ensure the coupler is completely in line with the
tow bar. This reduces stress on the tow bar. Figure 4.10
❽ Insert the locking pin into the hole on the top of the coupler.
❾ Slide the safety loop over the end of the lock pin. Figure 4.11
Important! Ensure the loop of the safety pin is facing away
from the wheel to prevent possible fricon against the wheel
and spokes of the bicycle.
Figure 4.10 Figure 4.11
7
8
9
9
15 Schwinn Cargo Trailer • model 13-SC320

ATTACH THE SAFETY STRAP
Use of the trailer without the safety strap aached to the bicycle
may result in serious injury or death. Always aach the tow bar
safety strap to the bicycle when using the trailer.
❶ Wrap the tow bar safety strap around the bicycle frame.
Figure 4.12
❷ Clip the safety strap to the tow bar ring on the end of the tow
bar. Be sure the tow bar safety strap is securely aached
before using the trailer. Figure 4.13
Safety strap
Figure 4.12 Figure 4.13
Bicycle frame
Safety strap
Tow bar ring
WARNING!
Schwinn Cargo Trailer • model 13-SC320 16

❶ Load Limits: loads should be no higher than 8” above the
trailer top, and should not extend beyond the end of the
trailer. Figure 5.1
We recommend:
• That loads do not extend past the back of the trailer’s frame.
This can create a hazard by interfering with the bicycle, ground,
or other obstacles such as curbs, signs, cars, etc.)
• Storing the trailer inside aer use. Inclement weather and harsh
elements may stress the fabric on the trailer
17 Schwinn Cargo Trailer • model 13-SC320
5 Using the Cargo Trailer
Figure 5.1
• Weight limit is 100 lbs. Do not carry loads exceeding 100 lbs,
as the extra weight and height will increase the center of
gravity, increasing the risk of p over
• Do not carry items that exceed the trailer’s frame by more
than 8” (high). Carrying taller loads will increase the trailers
center of gravity and increase the risk of p over
WARNING!
No more than 8” inches
1
