procontrol IP STECKER Operating manual

PROCONTROL®
Plug-in socket from the Internet
User and Installation Manual
IP Stecker V12
August 2018

© 2012 Procontrol Electronics Ltd.
All rights reserved.
Worktime, Workstar, WtKomm, ProxerNet are all Procontrol Electronics Ltd.’s official product names.
Trademarks in the document are the property of the registered owner.
Procontrol Electronics Ltd maintains the copyrights of this document: the document can only be
reproduced, modified, published –whether in whole or in part –by the prior written permission of the
author. Procontrol Electronics Ltd can change the document and software at any time without giving any
notice Procontrol Electronics Ltd. takes no responsibility for the accuracy of the software or
documentation for its suitability or usability for a particular application.

Contents
IP Stecker............................................................................................................5
Welcome.................................................................................................................. 5
Safety Precautions.................................................................................................... 6
Introduction.............................................................................................................. 7
Types:..............................................................................................................................................................7
Plans for Product Enhancement.......................................................................................................................7
Features............................................................................................................................................................8
Factory reset...................................................................................................................................................10
1. Reset factory settings for IPStecker4 type:.................................................................................................10
2. Reset factory settings for IPStecker Industial:............................................................................................10
What kind of Ethernet network we have? ...............................................12
1. In Case of Established Computer Network........................................................ 12
2. Directly Wired Connection between Terminal and PC...................................... 13
Ethernet data connection establishment.................................................14
Product setup.......................................................................................................... 14
IPStecker remote control function ..................................................................15
Testing the IPStecker connection........................................................................... 16
1. Web browser / IP Stecker Online....................................................................... 17
1. Plugs –Remote access of powers sockets...................................................................................................18
2. Events –User operations log......................................................................................................................18
3. User –User settings....................................................................................................................................19
4. Connection –Connection settings ..............................................................................................................20
5. Security –Security settings.........................................................................................................................20
6. Date time –Date and time settings.............................................................................................................21
7. Delays –Plug power on delay settings.......................................................................................................21
8. Save settings –Saving settings of plugs......................................................................................................22
9. Ping settings –Automatic plug restart (automatic restart of crashed systems e.g., RESET)......................23
10. System –Language settings and device restart/logout.............................................................................23
2. Telnet ................................................................................................................. 25
3. Command line remote control through user developed program (SDK)........... 26
4. Command line control through USB connection............................................... 26
Contact to the manufacturer.......................................................................30

IP Stecker
Welcome
Thank you for choosing a Procontrol product.
Procontrol Electronics Ltd has grown to an important national company of developing and
manufacturing software, hardware, electronic devices, access control, time-attendance
systems, queue control, client caller and access protection systems since 1981.
Thousands of satisfied customers have experienced the security ensured by our long time
period planning, reliable work and the world trademarks standing behind us. Our qualified
staff does its best to satisfy your requirements in the electrical development.

Safety Precautions
Please read this guide before installing
and using the device. Please use the
device properly and as described in the
following manual.
The authors are NOT liable for any claim,
damages or other liability out of:
using not the proper way
incorrect installation
connecting to inappropriate electronic
network
incorrect maintenance
not approved modifications, interventions
using non-original elements
Do not attempt to disassemble or modify
any part of this product.
Do not store at temperatures outside the
specified range and do not operate in an
environment outside the specified range
as it will reduce the life of the product or
cause product malfunction.
Maximum number of connectable devices
using switching power supply is 2/socket!
Never allow water or any other foreign
matter to get into the unit. The unit
contains sensitive electronic parts, so
water and foreign matter not only can
cause malfunction, they also create the
risk of overheating due to short circuiting
and insulation failure, fire and smoke,
combustion, and electric shock. Ne
helyezze a terméket hőforrás közelébe,
illetve ne tegye ki az eszközt közvetlen
láng vagy hő hatásának, mivel az eszköz
olyankor felrobbanhat.
Only use the product for it’s intended
purpose!
Safety
Keep the device in operation only from
electric sources defined in this user
manual. Do not open the device, there are
no user serviceable parts inside!
Attention! Connect the product exclusively
to a grounded power outlet with relay
contact protection network.
To avoid fire and risk of electronic shock:
Beware that your children do not throw or
push objects through the slots of the
device.
Do not mount accessories or attachments
on the device that are not designed for
this device. If you do not use the device
for longer time or in case of lightning, you
shall unplug the power cord.
Risks at Installation
Do not store anything on the power cord.
Do not place the device, where the power
cord can be damaged. Do not use the
device under wet circumstances or in
humid premises.
Cleaning
Switch off the device before cleaning. Use
slightly wet mop. Excessive humidity may
cause electric shock
General rights and responsibility
Manufacturing rights of this device are
reserved by Procontrol Electronics Ltd.
Modifying or copying of this device or
parts is prohibited!
Procontrol Ltd. is not liable for using of this
device and the consequences of the
application.

Introduction
IP Stecker is an Ethernet plug-in bar, which can control 230V sockets on an Ethernet
network.
Types:
•IPStecker 4 –indoor use
IPStecker 4
•IP Stecker 3 Industrial –IP54 casing
IP Stecker 3 Industrial
Plans for Product Enhancement
From the current R9D series, the above type is available with Ethernet and USB connectivity.
As advanced option you will be able to connect external thermometer sensors (TS-05 or
THS-05) through the USB (I2C) port, for applications e.g. emergency stop at a certain
temperature, i.e. the user sets a threshold value, when exceeded, the device stops operating.
This „Smart Metering” will be available, when the manufacturing of next series has been
launched, which is at present in the process of development.
A built in current and voltage meter function is planned, this „Smart Metering” will be available
similarly, when the manufacturing of next series has been launched, which is at present in
the process of development.
In case of any requested modification and enhancement please do not hesitate to contact us,
any individual request is highly appreciated. Please contact our colleagues for details and
prices!

Features
Type
IPStecker 4
Revision
0802-03-R9C
Part number
141106
Number of remotable switched sockets
4 sockets
Ethernet interface
10/100BaseT
Remote abilities
o Web /internet browser
o Telnet
o Command prompt remote control, Perl script, PHP script
o PCSW protokoll
Compatibility
Can be used in all operation system, with all browsers: Microsoft
Internet Explorer, Opera, Mozilla Firefox, Netscape,
Windows 98SE / 2000 / XP / XP SP1-SP2, Server 2003 / Vista / Linux /
Me / Mac OS
Language
english, hungarian
Mounting
19 "rack mountable with included metal fixing brackets
Connectors
RJ45, USB B
Socket standard
F (Hungary)
Power supply
AC 230V, 50Hz
Power consumption
max: 3 VA
Capacity
max: 230V, Σ16A total, max: 230V 8A / socket at continuous load.
Maximum number of devices using switching power supply is 2/socket.
Needed cable type
CAT5, CAT6
Support / feedback on hardware
- 1 hidden reset button
- 3+2 pcs status LED
- Ethernet status leds for , a LINK signal and 10/100Mbit mode
- Built-in clock, and memory protection batteries
Casing
Indoor durable case, compact, distinguished
Dimensions
Without fixing brackets: 430x60x45mm
With fixing brackets: 480x60x45mm
Weight
Net 1000g, gross 1140g
Operating temperature
-25 - +50 °C
Storage temperature
-40 - +60 °C
Operating relative humidity
max. 80%
Storage relative humidity
max. 90%
Standards
Ethernet IEE802

USB (I2C) - prepared for later developments
x
Smart Metering: current and voltage
measurement functions
under development
Types
IP Stecker 3 Industrial
Revision
0802-03-R9D
Part number
141010
Number of remotable switched sockets
3 sockets
Ethernet interface
10/100BaseT
Remote abilities
• Web /internet browser
• Telnet
• Command prompt remote control, Perl script, PHP script
• PCSW* protocol
Compatibility
Can be used in all operation system, with all browsers: Microsoft Internet
Explorer, Opera, Mozilla Firefox, Netscape,
Windows 98SE / 2000 / XP / XP SP1-SP2, Server 2003 / Vista / Linux / Me
/ Mac OS etc.
Language
english, hungarian
Szerelhetőség
Wall mounted
Connectors
Swinging RJ45, Power 3x2.5 MT cabel
Socket standard
F (Hungary) (Swinging, stripped, with end ferrules)
Power supply:
AC 110..230V, 50Hz
Power consumption:
max: 3 VA
Capacity:
max: 230V, Σ16A total, max: 230V 8A / socket at continuous load.
Maximum number of devices using switching power supply is 2/socket.
Supporting on hardware :
- 1 hidden reset button
- 3 operating status LEDs
- Built-in clock and memory protection
Housing
IP55
Sizes:
Net, without mounting ears: 430x60x45mm
Weight
Net 1995g
Operating temperature:
-25 - +50 °C
Storage temperature:
-40 - +60 °C
Operating relative humidity:
max. 80%
Storage relative humidity:
max. 90%
Standards
Ethernet IEE802
USB (I2C) - prepared for later developments
x
Smart Metering: current and voltage
measurement functions
under development

* A Special communication protocol developed by Procontrol, which allows the implementation and communication of IPStecker with other Procontrol
manufactured products and systems.
Attention! Maximum number of devices using switching power supply is 2/socket.
Factory reset
The device has a hidden reset button to reset the factory settings.
1. Reset factory settings for IPStecker4 type:
Located below the USB socket there is a tiny hole.
To reset to factory settings, press and hold the reset button for 5 seconds. The restarting in
indicated with fast blinking of the red status led. If restart finished, the blinking became again
the normal mode. The unit will restart with the factory settings.
2. Reset factory settings for IPStecker Industial:
The following figure shows the position of the screws with an arrow:
Located next to the USB socket hidden behind a tiny hole.

Press and hold the button for at least 5 seconds. If this is done, you will be running
the original factory settings after restarting the device.
To reset to factory settings, press and hold the reset button for 5 seconds. After restarting the
unit will start with the factory settings.

What kind of Ethernet network we have?
(Estimation of Ethernet network topology)
Connect the device to a free end point (or directly to your PC) of an established Ethernet
network as following.
Ethernet on PC network is not everywhere accessible, therefore we suggest two solutions for
testing your device:
1. In Case of Established Computer Network
Connect a free end point of the PC network with a straight patch cable (Straight-Trough) to
the device. We recommend this solution, if possible. Test the device with a patch cable
(Straight-Trough, attached to the customer package) on an Ethernet socket of a network-
connected PC. Connect the Ethernet cable to the SWITCH or HUB of your PC network
(Ethernet).
o

2. Directly Wired Connection between Terminal and PC
If a network SWITCH is not available, but you want to connect it directly to the Ethernet
socket of your PC, you need a special Cross-Over wire. Connect the device to your PC’s built
in connector through the Cross-Over patch cable.

Ethernet data connection establishment
Product setup
Connect the socket strip to a 230V mains socket outlet. Use a grounded outlet only. Connect
the Ethernet network cable, then turn on the power switch of the device (I O labeled rocker
switch). After about 10 seconds the device is available on the computer network with default
connection settings.
IP address: 192.168.0.250
Subnet Mask: 255.255.255.0
Web port: 80
You can now connect the remotely switched 230V powered devices as you wish.
The product is supplied with the relays switched on, so after switching on the first time, all
four sockets will be powered with 1-2-3-4 seconds delay.

IPStecker remote control function
The remote control modes of the IPStecker were developed according to different customer
needs and requests. Controlling the power supply of the connected devices is available
through the following channels:
•Web browser port 80 / internet browser (IPStecker Online)
Most of the user's choice, the simplest plausible method for remote control via
an Internet Browser with graphic interface. Most parameters of the unit are
accessible through this default interface. The following browsers were tested:
a. Internet Explorer 5,6,7,8
b. Mozilla
c. Opera
•Telnet port 23 / command line
a. Microsoft Telnet
b. Debian linux –telnet
•PCSW protocol, port 1001
Secret internal protocol of Procontrol Ltd., used to edit system parameters and
for firmware upgrades. Only for system administration purposes.
•Through web port 80 instead of web browser, even scheduled, or command line
remote control, Perl script, PHP script. (sample script is available on the product’s
website)
Power supply control of the connected devices is even possible scheduled through
web port 80 (instead of web browser), or controlled by program code. Tested under
the following environment:
•Microsoft Windows 2000, Windows XP, Windows Vista, Windows 2003 Server,
Windows 2008 Server, Windows 7

Testing the IPStecker connection
•Ping test: enter following command into the command line: PING 192.168.0.250
•If you receive a reply, you can try with your browser according to description below. If
you do not receive any reply, check as follows.
FIREWALL DIFFICULTIES: A well operating firewall may prevent the program from running
correctly

1. Web browser / IP Stecker Online
Power of the IPStecker’s sockets can be individually switched on and off through a web
browser. Access to the control page can be password protected.
FIREWALL DIFFICULTIES: A well operating firewall may prevent the program from running
correctly.
Enter the default IP address into the browser: 192.168.0.250
If the user interface is not displayed, please check:
•Whether you established all connections properly?
•Whether at least one of the IPStecker’s status LEDs is lit?
•Whether your PC’s IP address is in the same network: 192.168.0.xxx?
•After displaying the user interface you can enter a new IP address into the IP field of
connection preferences.
A belépéshez írja be a megfelelő jelszót:

Sections of the web interface:
1. Plugs –Remote access of powers sockets
•The first section of the IPStecker’s user interface displays the current status of power
socket strip. A powered plug is marked green (ON), an unpowered plug is marked red
(OFF).
With a single click on the buttons in the On/Off column, power can be switched ON or
OFF in each plug (R1, R2, R3).
Restarting of each plug is also possible, they remain unpowered till the time delay set in
section Delays. After the time period expires, the plug automatically switches on, and the
web page is being refreshed. Each plug can be renamed by the user for easier
identification in the User section of the web interface. The names given there are
displayed in the User name column.
ATTENTION! ALWAYS USE THE SAVE BUTTON AFTER SETTINGS
MODIFICATION AND DATA ENTRY!
2. Events –User operations log
The device logs each user operation and stores the last 128 events

3. User –User settings
(Operation of the IPStecker is not affected by the settings in this section)
Each plug can be renamed (according to the connected devices e.g.) by the user for
easier identification in this section. The names given here are displayed in the User
name column of the first section. A maximum 10 characters long name can be given to
each plug with contents of the English alphabet.

4. Connection –Connection settings
Parameters of the connection with the IPStecker can be changed here: IP address, default
gateway, subnet mask, TCP/IP port.
5. Security –Security settings
A password can be set here to access the IPStecker’s web interface. The password can be
changed any time inside the control page. If you set and save a password here, the device
asks for it the next time you want to log in. The default password is “admin”. (Recommended
to change it after the first login)
