ProcureLED Twinspot LED Configuration guide

59.5
227.3
51.7
27.8
20.5
226
144
35.2
3 hour
IP
65
Self
Test
Installation/maintenance/servicing notes:
Twinspot variations:
Thank you for purchasing our Twinspot Emergency LED. Be assure that our products have been designed according to
the relevant standards below and if installed and maintained correctly they will provide long life service. If a self-test
version ispurchased please follow the table in the reverse and choose the right remote control if required.
• Ensure that the mains supply is switched off before installing, maintaining or servicing
the emergency luminaire.
• Luminaires should only be installed by qualified personnel.
• This product is configured as non-maintained.
• The LED light source and control gear are non-replaceable. Once end-of-life is reached,
the whole luminaire will need to be replaced.
• In case of mains supply failure, the batterywillautomatically energise the emergency
lightforaminimum of 3 hoursperiod. After3hr5m theluminairewill enterinto stand-by
mode to prevent battery over-discharge. The battery must be re-charged again no later
than 6 months after mains supply’s failure.
• Self-test emergency luminaires are programmed to carry out functional and full duration
tests according to BS EN 50172:2004.
• First battery charge takes up to 16 hrs.
• Battery re-charge takes up to 8hrs. Note that full cycle (discharge and recharge) takes
up to 12 hours.
• Contact ProcureLED Safety if a battery replacement is required.
• This product is subject to ProcureLED Safety’s Warranty Policy.
This luminaire needs to be tested by a competent person according to BS EN 50172:2004.
This luminaire can be used in conjunction with the Advanced Remote Control (ARC). ARC
is an optional tool that adds new features to AST and MT emergency luminaires.
If functional test or full duration test is initiated via ARC the MT luminaire will automatically
switch to mains mode after the functional or full duration test is completed.
This is a self-test luminaire. Functional test is carried out automatically once a week and runs
for 30seconds. Full duration test is carried out automatically every 52 weeks. First full duration
test is carried out automatically within the first 4 weeks after the luminaire being connected to
mains voltage. This luminaire can be used in conjunction with the Advanced Remote Control
(ARC). ARC is an optional tool thataddsextrafeatures to ASTemergencyluminaires. Please
refer to the ARC's user guide.
This is a programmable self-test luminaire. It must be used in conjunction with a Programmable
Remote Control (PRC). Please refer to PRC’s user guide.
MT (Manual Test)
AST (Advanced Self-Test)
PST (Programmable Self-Test)
Ensure this product is disposed
responsibly according to WEEE
directive 2002/96/EC
BS EN 60598-1 / BS EN 60598-2-22 / BS EN 50172 / BS EN 1838 / BS EN 62034
Please refer to the variation purchased
Twinspot LED
ProcureLED
Twinspot LED www.procureled.com
“LED indicator status” coding
Normal flash = 1Hz (about once/second)
Fast flash = 2Hz (about twice/second)
Solid ON
Normal Flash
OFF
Fast Flash
Normal Flash
OFF
Fast Flash
OFF
OFF
Solid ON
OFF
Normal Flash
Normal Flash
Fast Flash
OK
Charging
Battery disconnected /
Duration test failure
Functional/Duration test in progress
Battery Temperature
Light source fault
PST clock unsync
-
-
Connect battery /
Replace battery
-
Consult with Z10 safety
Replace Luminaire
Refer to PRC’s user guide
GREEN LED RED LED G R STATUS ACTION REQUIRED

Twinspot LED
ProcureLED
Twinspot LED www.procureled.com
Twinspot Emergency range:
* Advance Remote Control (ARC) allows the competent installer to carry out functional tests and/or full duration tests at any time and to check system’s status.
Please refer to ARC’s user guide. In addition to ARC functions the Programmable Remote Control (PRC) allows the competent installer to programme the
testing schedule of each emergency luminaire. Please refer to PRC’s user guide.
TWIN350NM3
TWIN350NM3AST
TWIN350NM3PST
IP65 LED Twin Spot 2x1.5W 350lm MT
IP65 LED Twin Spot 2x1.5W 350lm Self Test AST
IP65 LED Twin Spot 2x1.5W 350lm Self Test PST
Manual Test (MT)
Advanced Self-Test (AST)
Programmable Self-Test (PST)
ARC
ARC
PRC
0°C ~ 40°C 0.72 kg
Part
number Description Operating temperature
Net
weight
Remote control
part number *
Testing facility
STEP 6
Restrain mains cables
STEP 3
STEP 2
Remove cover
STEP 5
STEP 9
Secure cover
Ensure that the mains supply is switched off
before installing, maintaining or servicing
the emergency luminaire.
STEP 1
Switch mains supply off
IP65
IP65
Blue
(Permanent)
0.75 -2.5mm28+1mm
Brown
N
L
STEP 4
Cable size and strip length
Use the supplied IP65 cable
gland where required. Connect Live and Neutral to
the terminal block
Remove
knock-out
Drill where indicated and use wall plugs+screws*
*Supplied screws and wall plugs are suitable for masonery
only. Please purchase other fixing set if required.
3-4mm
0.5Nm
1.5Nm
Silicone coil
Installation Guide:
STEP 11
Switch mains supply on
220-240V AC 50Hz
X 0 180
Part No.:
Installation date:
__/__/____
STEP 8
STEP 7
Connect the indicator
electronic board
Complete luminaire
and ba�ery labels
Part No.: Secondary Li-ion Battery Pack Li18650-5000mAh 3.6V 5000mAh 18Wh 1ICR19/66-2 Mfg date: Installation date: / /
- Write in on date
- Write the appropriate character/s in the “Facility” segment
STEP 10
Max
80°
Max
±75°
Adjust spot lights
Secure mains cable using cable clip and
screws supplied in the box
