Flash LED NEW EFFECT LIGHT User manual

www.flash-butrym.pl Page 1
LED NEW EFFECT LIGHT
User’s manual

www.flash-butrym.pl Page 2
1. Products introduction
To congratulate you order 2pcs*10W LED New Effect Light, features as the following:
LED lamp-house :2pcs*10W LED(RGBW)
Automatic mode
Sound controller mode
Master slave mode
Standard DMX control signal: 7 DMX channels.
Power supply: AC220V/240V-50/60HZ
Rated Power Consumption: 25W
Work Environment: indoor 200C-400C
Inner box Size : 460×400×390 mm
N/W: 2KG G/W: 3KG
2. Installation
1、Fix up it at any place ,but the distance between the magic light and other objects and person
should be at least 1m.and ensure fastness well .do safety measure well .the light should
earthing safety .
2、DMX512 connections :
Use the signal line DMX512 to connect all the LED controller, through 3-pin XLR “input”
and ”output” socket Controller DMX512 signal (1earth,2-,3+)connect as follow. (Note : please
exchange and connect signal 2 and 3、if it can’t by control, generic controller don’t use this,
signal line should be within 100 meter，prevent others equipment to be disturbed as excess
line。
3、Ensure the voltage and frequency of the factory enactment are suit your locate .You can open
it after connect it well
3. Operation Display Panel
After starting up, press MANU to enter the main menu, press UP (a) DOWN ( under) select sub menu, then
press ENTER to determine

www.flash-butrym.pl Page 3
Red Color bright all time mode
Green Color bright all time mode
Blue Color bright all time mode
White Color bright all time mode
Four Color Jump Change mode
Seven Color Jump Change mode
Change Gradually mode
Strobe mode
Sound Control mode
Sound Control Color Jump Change
A001 A511
AXXX A1 X
A2 X
A3 X
A4 X
A5 X
A6 X
A7 X
A8 X
S1 X
S2 X
4. Master & Slave Setting
Do not connect DMX, arbitrarily set 1 master machine for automatic or sound control status,
other lights set a start address for the 1
5.Channel List
7 Channels Table
channel
Value
Function
CH1
0
No Strobe Effect
1-255
LED Strobe, Speed from slow to fast
CH2
0
Turn Off the Red Color
1-255
Red LED Dimming,bright from dark gradually bright
CH3
0
Turn Off the Green Color
1-255
Green LED Dimming,bright from dark gradually bright
CH4
0
Turn Off the Blue Color
1-255
Blue LED Dimming,bright from dark gradually bright
CH5
0
Turn Off the White Color
1-255
White LED Dimming,bright from dark gradually bright
CH6
0-127
Motor Position
128-191
Motor positive rotation, speed from fast to slow

www.flash-butrym.pl Page 4
192-255
Motor reverse rotation, speed from fast to slow
CH7
0
CH1-CH5
10-37
Au01
38-65
Au02
66-93
Au03
………..
S2 X
6. Cleaning and Repairing
To confirm the power supply have cut off before disconnect the light or repair it ,it is very
important to keep the light cleaning .not only can keep the light maximum brightness output but
also can prolong their use life . Please use the high quality professional glass and soft cloth to
clear up the equipment not permission to use the alcohol and organic liquid clean at least once
each year use vacuum dust collector.
7. Warning
Never dismantle and refit the light
Please keep the light don’t contact water or other kind liquid and metal.
Please keep the light away from the water, liquid metal products
Please don’t put beam of light on the tinder, the distance between the magic light and tinder
should be at least 2m the distance between the magic light and other objects should be at least
0.5m
Please don’t orthoptic beam of the magic light, or it will be hurt your eyes.
To confirm the power supply have cut off the light before you open and repair the light.
