  9. ProCurve J8451A User manual

ProCurve J8451A User manual

61195862L1-13D, May 2006 www.procurve.com Copyright 2006 Hewlett-Packard Development Company, LP
Quick Start Guide 5990-8885
ProCurve Secure Router dl 1xT1 Module
J8451A
SPECIFICATIONS
Operating
Modes
T1/FT1 Frame Relay, T1/FT1 PPP, T1/FT1 HDLC,
T1/FT1 Multilink Frame Relay, T1/FT1 Multilink PPP
T1/FT1
Interface
Supported Standards: AT&T TR 62411, AT&T TR 54016,
ANSI T1.403, Bellcore TR 194
Line Rate: 1.544 Mbps ±75 bps
Line Code: AMI or B8ZS
Framing: D4 (SF) or ESF
FT1 Line Rate: DS0 channelized
Input Signal: 0 to -36 dB (DS1)
Line Build-Out: 0, -7.5, -15, -22.5 dB or 0 to 655 feet
Connector: RJ-48C
DS0 Assignment: Programmable
Clock Source Network, internal
Diagnostics Test Pattern Generation and Detection: QRSS, 511,
all ones, all zeros
Network loopbacks (local and remote); responds to both
inband and FDL loop codes
Alarm generation and detection
Network and user sets of performance data
(15 minutes and 24 hours)
Compliance FCC Part 15 Class A, EN 55022 Class A
ACTA/FCC Part 68, IC CS-03
UL/CUL 60950, IEC 60950
Physical Dimensions: 6.99 cm (2.75 in) W x 10.80 cm (4.25 in) D
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Relative Humidity: Up to 95 percent, noncondensing at
30°C (86°F)
Non-Operating Temperature: -20°C to 70°C (-4°F to 158°F)
Non-Operating Relative Humidity: Up to 95 percent,
noncondensing at 30°C (86°F)
Altitude: Up to 3.048 km (10,000 ft)
INSTALLATION INSTRUCTIONS
Warning For ProCurve Secure Router modules with outside plant
connections, ensure that all cables are removed from the
module before installing or removing it from the router
chassis.
1. Remove power from the unit.
2. Slide the ProCurve Secure Router dl 1xT1 Module into the option slot
until the module is firmly seated against the chassis.
3. Secure the screws at both edges of the module.
4. Connect the cables to the associated device(s).
5. Complete the installation of the base unit.
6. Restore power to the unit.
Note For safety information for the routers and all modules,
please refer to the safety and ESD precautions in the
ProCurve Secure Router Installation Guide included
in your router shipment.
T1 NETWORK (RJ-48C) CONNECTION PINOUT
Pin Name Description
1 R1 Receive data from the network
2 T1 Receive data from the network
3 — Unused
4 R Transmit data toward the network
5 T Transmit data toward the network
6-8 — Unused
Note An optional backup module is required for backup
applications.
For a description of the backup connection pinouts,
refer to the Quick Start Guide included with your
backup module
61195862L1-13D, May 2006 Printed in the USA Copyright 2006 Hewlett-Packard Development Company, LP
Quick Start Guide 5990-8885
ProCurve Secure Router dl 1xT1 Module
J8451A
1XT1 MODULE COMMANDS
clock source [line* | internal]
Configures the source of the clock for the module. Use the no form of the command
to return to the default value.
line*Recovers clock from the T1 circuit.
internal Provides clocking using the internal oscillator.
coding [ami | b8zs*]
Configures the line coding for the T1 physical interface.
ami Configures the line coding for alternate mark inversion.
b8zs*Configures the line coding for bipolar eight zero
substitution.
fdl [ansi* | att | none]
Configures the format of the facility data link (FDL) channel on the T1circuit.
ansi* Configures the FDL for ANSI T1.403 standard.
att Configures the FDL for ATT TR 54016 standard.
none No FDL standard configured.
framing [d4 | esf*]
Configures the framing format of theT1 interface. This setting must match the framing
format provided by the service provider or external device. Use the no form of this
command to return to the default value.
d4 Specifies D4 superframe (SF) T1 framing.
esf* Specifies extended SF T1 framing.
lbo [long <0*| -7.5 | -15 | -22.5> | short <0 to 655>]
Sets the line build out (in dB or feet) for the T1 Interface. Use the lbo long command
for T1 interfaces with a cable length greater than 655 feet. Use the lbo short
command for T1 interfaces with a cable length less than 655 feet.
loopback network [line | payload]
Initiates a loopback on the interface toward the network. Use the no form of this
command to deactivate the loopback.
line Initiates a metallic loopback of the physical T1 network
interface.
payload Initiates a loopback of the T1 framer (CSU portion) of the T1
network interface.
loopback remote line [fdl | inband]
Sends a loopback code to the remote unit to initiate a line loopback. Use the no form
of this command to send a loopdown code to the remote unit to deactivate the
loopback.
fdl Uses the facility data link (FDL) to initiate a full 1.544 Mbps
physical (metallic) loopback of the signal received by the
remote unit from the network.
inband Uses the inband channel to initiate a full 1.544 Mbps
physical (metallic) loopback of the signal received by the
remote unit from the network.
loopback remote payload
Sends a loopback code to the remote unit to initiate a payload loopback. Use the no
form of this command to deactivate the loopback.
remote-alarm rai
Selects the alarm signaling type to be sent when a loss of frame is detected on the T1
receive signal. Use the no form of this command to disable all transmitted alarms.
rai* Sends a remote alarm indication (RAI) in response to a loss of
frame. Also prevents a received RAI from causing a change in
interface operational status.
remote-loopback
Configures the interface to respond to loopbacks initiated by a remote unit (or service
provider). Use the no version of this command to disable this feature.
show test-pattern
Displays the results (including error count) from active test patterns.
shutdown
Disables the interface (both physical and virtual) so that no data will be passed
through. Use the no form of this command to turn on the interface and allow it to pass
data. By default, all interfaces are disabled.
snmp trap link-status
Controls the SNMP variable, ifLinkUpDownTrapEnable (RFC2863) to enable the
interface to send SNMP traps when there is an interface status change. Use the no
form of this command to disable this trap.
tdm-group <group#> timeslot <1-24> speed [64]
Creates a group of contiguous DS0s on this interface to be used during the bind
process.
<group#> Number label (1 to 255) to identify this TDM group.
timeslot <1-24> Specifies the timeslots used in the TDM group. Enter as a single
number (representing one of the 24 T1 channel timeslots) or as
a contiguous group of channels. (For example, 1-10 specifies
the first ten channels of the T1.)
64 (Optional) Specifies a DS0 rate of 64 kbps.
test-pattern [clear | insert | ones | p511 | qrss | zeros]
Activates the built-in pattern generator and begins sending the specified test pattern.
Can be used to verify a data path when used in conjunction with an active loopback.
Use the no form of this command to cease pattern generation.
clear Clears the test pattern error count. Display the error count using
the show test-pattern command.
insert Inserts an error into currently active test pattern. Display the
injected error result using the show test-pattern command.
ones Generates a pattern of continuous ones.
p511 Generates a repeating pattern of ones and zeros.
qrss Generates a random pattern of ones and zeros.
zeros Generates a pattern of continuous zeros.
* Indicates default values.
Note This command list is an illustration of available commands.
For complete command descriptions and default values, refer
to the SROS Command Line Interface Reference Guide
provided on your ProCurve SROS Documentation CD.
