ProCurve J8452A User manual

61195863L1-13D, May 2006 www.procurve.com Copyright 2006 Hewlett-Packard Development Company, LP
Quick Start Guide 5990-8893
ProCurve Secure Router dl 1xT1 + DSX-1 Module
J8452A
INSTALLATION INSTRUCTIONS
Warning For ProCurve Secure Router modules with outside plant
connections, ensure that all cables are removed from the
module before installing or removing it from the router
chassis.
1. Remove power from the unit.
2. Slide the ProCurve Secure Router dl 1xT1 + DSX-1 Module into the
option slot until the module is firmly seated against the chassis.
3. Secure the screws at both edges of the module.
4. Connect the cables to the associated device(s).
5. Complete the installation of the base unit.
6. Restore power to the unit.
Note For safety information for the routers and all modules, please
refer to the safety and ESD precautions in the ProCurve
Secure Router Installation Guide included in your router
shipment.
T1 NETWORK (RJ-48C) CONNECTION PINOUT
Pin Name Description
1 R1 Receive data from the network
2 T1 Receive data from the network
3 — Unused
4 R Transmit data toward the network
5 T Transmit data toward the network
6-8 — Unused
DSX-1 NETWORK (RJ-48C) CONNECTION PINOUT
Pin Name Description
1 R Transmit data toward the DTE
2 T Transmit data toward the DTE
3 — Unused
4 R1 Receive data from the DTE
5 T1 Receive data from the DTE
6-8 — Unused
SPECIFICATIONS
Operating
Modes
T1/FT1 Frame Relay, T1/FT1 PPP, T1/FT1 Multilink PPP,
T1/FT1 Multilink Frame Relay, T1/FT1 HDLC
T1/FT1
Interface
Supported Standards: AT&T TR 62411, AT&T TR 54016,
Bellcore TR 194, ANSI T1.403
Line Rate: 1.544 Mbps ±75 bps
Line Code: AMI or B8ZS
Framing: D4 (SF) or ESF
FT1 Line Rate: DS0 channelized (multiples of 56/64 kbps)
Input Signal: 0 to -36 dB (DS1)
Line Build-Out: 0, -7.5, -15, -22.5 dB (long), 0 to 655 ft (short)
Connector: RJ-48C
DS0 Assignment: Programmable
DSX-1
Interface
Supported standards: DSX-1 per ANSI T1.102
Line Rate: 1.544 Mbps
DSX Receiver Input Range: -10 dBdsx to +6 dBdsx
Capacity: 1 to 24 DS0s
Line Codes: AMI, B8ZS
DSX-1 interface to PBX
Framing: D4 (SF) or ESF
Line Length: 0 to 655 ft and -7.5 dB
Connector: RJ-48C
Clock Source Network, internal, and through
Diagnostics Test Pattern Generation and Detection: QRSS, 511,
all ones, all zeros
Network loopbacks (local and remote); responds to both
inband and FDL loop codes (T1 interface only)
Alarm generation and detection
Network and user sets of performance data (15 minutes
and 24 hours)
Compliance FCC Part 15 Class A, EN 55022 Class A
ACTA/FCC Part 68, IC CS-03, UL/CUL 60950, IEC 60950
Physical Dimensions: 6.99 cm (2.75 in) W x 10.80 cm (4.25 in) D
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Relative Humidity: Up to 95 percent, noncondensing at
30°C (86°F)
Non-Operating Temperature: -20°C to 70°C (-4°F to 158°F)
Non-Operating Relative Humidity: Up to 95 percent,
noncondensing at 30°C (86°F)
Altitude: Up to 3.05 km (10,000 ft)

61195863L1-13D, May 2006 Printed in the USA Copyright 2006 Hewlett-Packard Development Company, LP
Quick Start Guide 5990-8893
ProCurve Secure Router dl 1xT1 + DSX-1 Module
J8452A
loopback remote payload
Sends a loopback code to the remote unit to initiate a payload loopback. Use the no
form of this command to deactivate the loopback.
remote-alarm rai
Selects the alarm signaling type to be sent when a loss of frame is detected on the T1
receive signal. Use the no form of this command to disable all transmitted alarms.
rai* Sends a remote alarm indication (RAI) in response to a loss of
frame. Also prevents a received RAI from causing a change in
interface operational status.
remote-loopback
Configures the interface to respond to loopbacks initiated by a remote unit (or service
provider). Use the no version of this command to disable this feature.
show test-pattern
Displays the results (including error count) from active test patterns.
shutdown
Disables the interface (both physical and virtual) so that no data will be passed through.
Use the no form of this command to turn on the interface and allow it to pass data. By
default, all interfaces are disabled.
signaling mode [message-oriented | none | robbed-bit*]
Configures the signaling mode for the DS0s mapped to the DSX-1 port.
message-oriented Clears channel signaling on Channel 24 only.
none Clears channel signaling on all DS0s.
robbed-bit* Specifies robbed-bit signaling on all DS0s.
snmp trap link-status
Controls the SNMP variable, ifLinkUpDownTrapEnable (RFC2863) to enable the
interface to send SNMP traps when there is an interface status change. Use the no form
of this command to disable this trap.
tdm-group <group#> timeslot <1-24> speed [56 | 64*]
Creates a group of contiguous DS0s on this interface to be used
during the bind process.
<group#> Number label (1 to 255) to identify this TDM group.
timeslot <1-24> Specifies the timeslots used in the TDM group. Enter as a single
number (representing one of the 24 T1 channel timeslots) or as a
contiguous group of channels. (For example, 1-10 specifies the
first ten channels of the T1.)
56 | 64* (Optional) Specifies a DS0 rate of 56 kbps or 64 kbps.
test-pattern [clear | insert | ones | p511 | qrss | zeros]
Activates the built-in pattern generator and begins sending the specified test pattern.
Can be used to verify a data path when used in conjunction with an active loopback. Use
the no form of this command to cease pattern generation.
clear Clears the test pattern error count. Display the error count using
the show test-pattern command.
insert Inserts an error into currently active test pattern. Display the
injected error result using the show test-pattern command.
ones Generates a pattern of continuous ones.
p511 Generates a repeating pattern of ones and zeros.
qrss Generates a random pattern of ones and zeros.
zeros Generates a pattern of continuous zeros.
* Indicates default values
1XT1 + DSX-1 MODULE COMMANDS
clock source [line* | internal | through]
Configures the source of the clock for the module. The 1xT1 + DSX-1 module supports
a single clock source for both T1 interfaces. Use the no form of this command to return
to the default value.
line* Recovers clock from the T1 circuit.
internal Provides clocking using the internal oscillator.
through Recovers clock from the circuit connected to the
DSX-1 interface.
coding [ami | b8zs*]
Configures the line coding for the T1 physical interface. The settings must match the
line coding supplied on the circuit by the service provider (or external equipment).
ami Configures the line coding for alternate mark
inversion.
b8zs* Configures the line coding for bipolar eight zero
substitution.
fdl [ansi* | att | none]
Configures the format of the facility data link (FDL) channel on the T1 circuit.
ansi* Configures the FDL for ANSI T1.403 standard.
att Configures the FDL for AT&T TR 54016 standard.
none No FDL standard configured.
framing [d4 | esf*]
Configures the framing format of theT1 interface. This setting must match the framing
format supplied on the circuit by the service provider or external device. Use the no
form of this command to return to the default value.
d4 Specifies D4 superframe (SF) T1 framing.
esf* Specifies extended SF T1 framing.
lbo [long <0*| -7.5 | -15 | -22.5> | short <0 to 655>]
Sets the line build out (in dB or feet) for the T1 Interface. Use the lbo long command
for T1 interfaces with a cable length greater than 655 feet. Use the lbo short command
for T1 interfaces with a cable length less than 655 feet.
line-length [0 – 655 ft | -7.5 dB]
Defines the cable length (in feet) between the DSX-1 interface and the attached
equipment. Use the -7.5 dB setting for maximum attenuation.
loopback network [line | payload]
Initiates a loopback on the interface toward the network. Use the no form of this
command to deactivate the loopback.
line Initiates a metallic loopback of the physical T1
network interface.
payload Initiates a loopback of the T1 framer (CSU portion) of
the T1 network interface.
loopback remote line [fdl | inband]
Sends a loopback code to the remote unit to initiate a line loopback. Use the no form of
this command to send a loopdown code to the remote unit to deactivate the loopback.
fdl Uses the facility data link (FDL) to initiate a full 1.544
Mbps physical (metallic) loopback of the signal
received by the remote unit from the network.
inband Uses the inband channel to initiate a full 1.544 Mbps
physical (metallic) loopback of the signal received by
the remote unit from the network.
