Configuring EVI
Overview
Ethernet Virtual Interconnect (EVI) is a MAC-in-IP technology that provides Layer 2 connectivity
between distant Layer 2 network sites across an IP routed network. It is used for connecting
geographically dispersed sites of a virtualized large-scale data center that requires Layer 2
adjacency (see Figure 1).
EVI enables long-distance virtual machine workload mobility and data mobility, disaster recovery,
and business continuity. For example, virtual machines can move between data center sites without
changing their IP addresses, so their movements are transparent to users and do not disrupt traffic.
Figure 1 Virtual machine migration
Layer 2 connectivity extension issues
EVI resolves the following Layer 2 connectivity extension issues:
•Site independence—EVI keeps protocol failures, such as broadcast storms, from propagating
across sites.
•Transport independence—EVI has no special requirements for site location or transport
network type, except that the transport network can forward IP packets.
•High availability—EVI supports redundant edge devices and has a loop-free mechanism to
prevent loops for a multihomed network site.
•Link efficiency—EVI optimizes the inter-site multicast and broadcast transmission mechanism
and implements load-sharing on redundant links.
•Site and transport transparency—EVI is both site and transport network transparent. It has
no special site or transport network topology requirements.

2
•Easy management and maintenance—EVI requires deployment only on edge devices and
does not introduce any topology change or configuration within sites or the transport network.
Network topologies
As shown in Figure 2, an EVI network has one or multiple edge devices at each site. These sites are
connected through virtual links and run the EVI IS-IS protocol to advertise their MAC address entries
to each other. EVI maintains MAC routing information on the edge devices without changing the
forwarding or routing information within the sites or the transport network.
Figure 2 EVI network
EVI supports multiple EVI networks on an edge device for extending different VLANs across the
Layer 3 network. One EVI network can convey multiple VLANs, but one VLAN can map to only one
EVI network. Each EVI network has separate network parameters and independently forwards
traffic.
As shown in Figure 3, EVI network 1 extends VLAN 100 and VLAN 101 to Site 2, Site 3, and Site 4
for Web access traffic. EVI network 2 extends VLAN 4000 (the management VLAN) to all sites, and
EVI network 3 extends VLANs 50 to 80 between Site 1 and Site 4 for database traffic.
Transport network Site network
Edge
device
EVI link
EVI
Site network
Edge
device
Site
network
Edge
device
EVI link EVI link VLAN 10
VLAN 10
VLAN 10
Site 1
Site 2
Site 3

3
Figure 3 Multiple EVI networks
Terminology
Edge device
An edge device performs typical Layer 2 learning and forwarding on the site-facing interfaces
(internal interfaces) and performs tunneling and routing on the transport-facing interfaces.
EVI network ID
An edge device can belong to multiple EVI networks. Each EVI network is uniquely identified by a
network ID.
EVI link
An EVI link is a bidirectional virtual Ethernet channel between a pair of edge devices in an EVI
network. EVI links are conveyed on EVI tunnels. Each EVI link is uniquely identified by a pair of
source and destination EVI tunnel IP addresses.
EVI tunnel
An EVI tunnel is a point-to-many automatic GRE tunnel that conveys EVI links for an EVI network.
One EVI tunnel can provide services only for one EVI network.
EVI neighbor
All edge devices in an EVI network are EVI neighbors to one other.
ENDP
EVI Neighbor Discovery Protocol uses the client/server model to dynamically discover sites and
edge devices, establish and maintain EVI links, and exchange network membership information in
an EVI network.
ENDS
An EVI neighbor discovery server maintains all neighbor information in an EVI network. An EVI
network can have up to two ENDSs.
Site 1
Site 2
Site 4
Site 5
EVI 1
VLANs 100-101
EVI 2
VLAN 4000
EVI 3
VLANs 50-80
Site 3

4
ENDC
An EVI neighbor discovery client works with an ENDS to learn neighbor information and triggers EVI
link setup between neighbors.
EVI IS-IS
EVI IS-IS establishes adjacencies and advertises MAC reachability information among edge devices
at different sites in an EVI network. It also maps VLANs to redundant edge devices at a multihomed
site to avoid loops and balance traffic.
EVI IS-IS runs independently of the Layer 3 routing protocols on the transport network and sites.
DED
Designated edge devices (DEDs) include inter-site DEDs and site DED.
An inter-site DED is elected from between the edge devices on each EVI link to send CSNP packets
for LSDB synchronization.
A site DED is elected from among the redundant edge devices at a multihomed site to distribute
extended VLANs among them so the traffic of a VLAN always enters or leaves the site from the same
edge device.
Appointed edge forwarder
If an edge device is assigned by DED to forward and receive traffic for an extended VLAN, this edge
device is the appointed edge forwarder for the extended VLAN. This extended VLAN is an active
VLAN on the edge device.
Internal interface
Internal interfaces are site-facing Layer 2 interfaces that connect an edge device to switches or
routers in the site.
Working mechanism
An edge device uses the following process to set up an EVI network and forward traffic at Layer 2 to
remote sites:
1. Runs ENDP to discover EVI neighbors and set up EVI links between neighbors.
2. Runs EVI IS-IS to advertise MAC reachability information over EVI links in the EVI network.
3. Forwards traffic based on MAC reachability information that has been received from other sites.
This section describes this process in detail.
Neighbor discovery
An EVI network runs ENDP to discover all its edge devices and establishes adjacencies among the
edge devices in the following process:
1. ENDS is enabled on one edge device, and ENDC is enabled on all other edge devices.
2. The ENDCs register their IP addresses and other data with the ENDS.
3. The ENDS updates its ENDC database with received data and sends the updated database to
each ENDC.
4. After receiving the register reply, the ENDCs establish an EVI link with each other.
For high availability, you can configure up to two ENDSs for an EVI network.
MAC address learning
MAC reachability information on an EVI edge device comes from the following sources:
•MAC entries configured or learned in the data plane—The edge devices use the typical
source-MAC-based learning mechanism to learn unicast MAC addresses in their local sites
(called local MAC addresses).

5
•MAC entries learned through EVI IS-IS—After completing neighbor discovery, the edge
devices run EVI IS-IS in the control plane to establish adjacencies and advertise MAC
reachability information that has been learned or configured in the data plane to each other over
EVI links.
NOTE:
The mac-address max-mac-count command and the mac-address mac-learning enable
command take effect only on local MAC addresses, which are learned in the data plane. They do
not take effect on remote MAC addresses, which are learned in the control plane.
Unicast flow
For intra-site unicast flows, an edge device performs the typical MAC address table lookup, as
shown in Figure 4.
Figure 4 Layer 2 forwarding in a site
The following forwarding process (see Figure 5) takes place for unicast flows between sites:
1. The source edge device learns the source MAC address of the incoming Ethernet frame, and
looks up the destination MAC address in its MAC table for the outgoing interface.
2. If the outgoing interface is an EVI-Link interface instead of a physical port, the source edge
device encapsulates the frame in a GRE header, and then adds an IP header and a link layer
protocol header.
In the outer IP header, the source IP address is the source edge device's tunnel source IP
address, and the destination IP address is the destination edge device's tunnel source IP
address.
3. The source edge device forwards the encapsulated packet out of the EVI link to the destination
edge device across the IP transport network.
4. The destination edge device removes the headers of the original Ethernet frame, looks up the
destination MAC address in the MAC address table, and sends the frame out of the matching
outgoing interface.
Site 1 Site 2
MAC Table
VLAN MAC Interface
200 MAC1 GE1/0/1
200 MAC2 GE1/0/2
MAC1 MAC2
EVI
Transport network
GE1/0/1 GE1/0/2
Host A Host B
EVI EVI

6
Figure 5 Layer 2 forwarding between sites
Multicast flow
Edge devices run IPv4 IGMP snooping on each extended VLAN and learn multicast router port and
multicast member port information on EVI-Link interfaces for Layer 2 multicast forwarding as if they
were Ethernet interfaces. In an extended VLAN, each edge device tunnels IGMP, MLD, and PIM
protocol packets to all its remote edge devices, and the remote edge devices floodthe packets in the
VLAN.
For a site-to-site multicast data frame in an extended VLAN, the following process (see Figure 6)
takes place:
1. The DR in a site sends out a multicast frame.
2. The source edge device copies the frame and encapsulates one copy on each multicast
member EVI-Link interface.
3. The source edge device unicasts the encapsulated frames to the destination edge devices over
the EVI links.
4. Each destination edge device removes the headers of the multicast frame and copies the
multicast frame on each multicast member interface.
5. Each destination edge device sends the multicast frame out of all member interfaces to the
destination hosts.
Transport network
Site 1 Site 2
MAC1
EVI MAC Table
VLAN MAC Interface
200 MAC1
200 MAC3
200 MAC2
EVI-Link0
GE1/0/1
EVI-Link0
MAC Table
VLAN MAC Interface
200 MAC1 GE1/0/1
200 MAC3 EVI-Link0
200 MAC2 GE1/0/2
Host A MAC2 Host B MAC3
Host C
GE1/0/1
Device A Device B
a
b
c
d
e
EVI EVI

7
Figure 6 Multicast data frame forwarding process
Flooding flow
An edge device handles flooding by frame type, as follows:
•Broadcast frame—Floods the frame to all interfaces in the VLAN where the frame has been
received, including internal interfaces and EVI-Link interfaces. ForARP packets, you can use
the ARP flood suppression feature (see "ARP flood suppression") to reduce ARP broadcasts.
•Destination-unknown unicast or multicast frame—Floods the frame to all internal interfaces
in the VLAN where the frame has been received. The edge device typically does not forward
destination-unknown frames to other sites. If a site-to-site flooding is desirable for a special
MAC address, use the selective flood feature (see "Selective flood").
To flood a frame to remote sites, an EVI edge device must replicate the frame, encapsulate each
replica in one unicast frame for each destination site, and send the unicast frames to the remote
edge devices.
Placement of Layer 3 gateways
For the hosts in an extended VLAN at a site, their Layer 3 gateway must beon the edge device at the
local site rather than a remote site.
ARP flood suppression
ARP flood suppression reduces ARP request broadcasts on the EVI network by enabling edge
devices to reply to ARP requests on behalf of remote-site hosts.
As shown in Figure 7, this feature snoops ARP replies on an EVI tunnel interface to populate the
ARP flood suppression table with remote MAC addresses. If an ARP request has a matching entry,
the local edge device replies to the request on behalf of the remote-site host. If no match is found, the
edge device floods the request to the EVI network.
ARP flood suppression uses the following workflow:
1. Host IP1 in site A sends an ARP request to obtain the MAC address of IP2.
2. Site A's edge device floods the ARP requests out of all interfaces, including the EVI tunnel
interfaces.
(1) Multicast stream
(2) Replicate & encapsulate (3) Unicast (4) Decapsulate & replicate
(5) Multicast stream
DR
Source
Receiver
Receiver
EVI
(3) Unicast GE1/0/1
EVI-Link1
EVI-Link2
GE1/0/1
EVI-Link1
GE1/0/1
(4) Decapsulate
& replicate
(5) Multicast
stream
EVI-Link1
VLAN R-port H-port
100 GE1/0/1 EVI-Link1
EVI-Link2
VLAN R-port H-port
100 EVI-Link1 GE1/0/1
VLAN R-port H-port
100 EVI-Link1 GE1/0/1
Site 1
Site 2
Site 3
EVI EVI
EVI

8
3. Site B's edge device de-encapsulates the ARP request and broadcasts the request.
4. IP2 sends an ARP reply back to site A's edge device over the EVI link.
5. Site A's edge device creates an ARP cache entry for the remote MAC address and forwards the
reply to the requesting host.
6. Site A's edge device replies to all subsequent requests for the MAC address of IP2.
Figure 7 ARP flood suppression
Selective flood
Selective flood enables an edge device to send an unknown unicast or multicast frame out of an EVI
tunnel interface.
This feature is designed for special multicast addresses that require flooding across sites but cannot
be added to a multicast forwarding table by IGMP snooping.
For example, you must configure selective flood for PIM hellos, IGMP general query packets, and
Microsoft NLBS cluster traffic to be sent out of an EVI tunnel interface.
Multihoming
EVI supports deploying two or more EVI edge devices to provide Layer 2 connectivity extension for a
site. Deployment of redundant edge devices creates the risk of loops because EVI edge devices do
not transmit spanning tree BPDUs across the transport network.
To remove loops in a multihomed network (see Figure 8), you can use IRF to virtualize multiple edge
devices into one device, as shown in Figure 9. If IRF is not used, EVI IS-IS runs among the
redundant edge devices to automatically designate each edge device as the traffic forwarder for a
particular set of extended VLANs, as shown in Figure 10.
The redundant edge devices exchange EVI IS-IS hello packets in a designated site VLAN to elect a
DED for exchanging extended VLAN information and assigning active VLANs among them. All edge

9
devices have a user-configurable DED priority. The one with the highest DED priority is elected as
the DED. The DED uses the following rules to assign active VLANs:
1. If an extended VLAN is configured only on one edge device, the edge device is the appointed
edge forwarder for the VLAN.
2. If a set of extended VLANs is configured on at least two edge devices, the DED distributes the
extended VLANs equally among the edge devices.
3. When reassigning VLANs, the DED preferably assigns an edge device the active VLANs that
were assigned to it in the previous assignment.
The traffic forwarder designation mechanism of EVI IS-IS makes sure an extended VLAN is active
only on one edge device. For example, VLAN 1000 in Figure 10 is active only on site 1's Device B
and site 2's Device D. Only these two edge devices can receive or forward VLAN 1000 traffic
between the two sites.
Figure 8 Looped dual-homed EVI network

10
Figure 9 Edge devices in an IRF fabric
Figure 10 Active VLAN on an edge device
Transport
network
Site 1 Site 2
IRFIRF
EVI
EVI EVI

11
Path MTU
When encapsulating an Ethernet frame in EVI, the edge device does not modify the Ethernet frame,
but it sets the DF bit in the IP header. For an Ethernet transport network, the total size of an EVI
protocol packet increases by 46 bytes, and the total size of a data packet increases by 38 bytes.
Because EVI does not support path MTU discovery, your EVI deployment must make sure the path
MTU of the transport network is higher than the maximum size of EVI tunneled frames.
Licensing requirements
EVI requires a license. For information about feature licensing, see Fundamentals Configuration
Guide.
EVI configuration task list
Perform the following tasks on all edge devices of an EVI network:
Tasks at a glance Remarks
Configuring EVI basic features:
•(Required.) Configuring a site ID
•(Required.) Configuring an EVI tunnel:
{(Required.) Assigning a network ID to the EVI tunnel
{(Required.) Specifying extended VLANs on the EVI tunnel
{(Required.) Configuring ENDP
An EVI tunnel can provide services
for only one EVI network.
All edge devices in an EVI network
must have the same network ID.
The edge devices at the same site
must have the same site ID, and
the edge devices at different sites
must have different site IDs.
An extended VLAN can be
assigned only to one EVI network.
(Optional.) Tuning EVI IS-IS parameters
EVI IS-IS automatically runs on an
EVI tunnel interface immediately
after the interface is created.
You can tune EVI IS-IS
parameters for optimizing network
performance.
(Optional.) Configuring VLAN mappings N/A
(Optional.) Enabling EVI ARP flood suppression Perform this task to reduce ARP
request broadcasts on an EVI
network.
(Optional.) Enabling EVI flooding for all destination-unknown frames Perform this task to flood frames with unknown MAC addresses to
the EVI tunnel interface.
(Optional.) Enabling selective flood for a MAC address
Perform this task for special
multicast MAC addresses that
require Layer 2 inter-site
forwarding but cannot be learned
into the MAC address table.
Configuring EVI basic features
All tasks in this section are required for setting up an EVI network.

12
Configuring a site ID
A site ID uniquely identifies a site in an EVI network. Edge devices at the same site must use the
same site ID, and edge devices at different sites must use different site IDs.
A site ID conflict occurs in the following situations:
•The devices at the same site are assigned different site IDs.
•The devices at two different sites are assigned the same site ID.
When the site IDs of two devices conflict, EVI IS-IS isolates the device with the lower MAC address.
The isolated device can only receive EVI IS-IS hello packets. It cannot exchange EVI IS-IS packets
with other neighbors. To identify isolated devices, use the display evi isis brief command or the
display evi isis peer command.
To assign a site ID to the device:
Step Command Remarks
1. Enter system view. system-view N/A
2. Assign a site ID to the
device. evi site-id site-id The default site ID is 0.
Configuring an EVI tunnel
Step Command Remarks
1. Enter system view. system-view N/A
2. Create an EVI tunnel
interface and enter tunnel
interface view. interface tunnel number mode
evi
By default, no tunnel interface
exists.
The endpoints of a tunnel must use
the same tunnel mode.
For more information about this
command, see tunneling
commands in Layer 3—IP Services
Command Reference.

13
Step Command Remarks
3. Specify a source IP
address or interface for the
tunnel. source { ipv4-address |
interface-type interface-number }
By default, no source IP address or
source interface is specified for any
tunnel.
The source interface can be a Layer
3 Ethernet interface, Layer 3
aggregate interface, VLAN
interface, or Layer 3 loopback
interface. For more information
about the source command, see
tunneling commands in Layer 3—IP
Services Command Reference.
EVI uses the specified address or
the primary IP address of the
specified source interface as the
source IP address of tunneled
packets on the transport network.
EVI networks can share a tunnel
source IP address or interface.
IMPORTANT:
To avoid forwarding failure, do not
use a GRE tunnel interface or its IP
address (configure with the ip
address command in tunnel
interface view) as the source
interface or IP address of an EVI
tunnel. For more information about
GRE, see Layer 3—IP Services
Configuration Guide.
4. Configure the EVI link
keepalive interval and the
maximum number of
keepalive transmissions. keepalive [ seconds [ times ] ]
By default, a keepalive packet is
sent every five seconds and the
maximum number of transmissions
is two.
If no reply is received from the
remote end on an EVI link after the
maximum number of keepalive
transmissions is reached, the local
end considers the EVI link as having
failed.
5. (Optional.) Generate a
GRE key for tunneled
packets based on their
VLAN IDs. gre key vlan-id
By default, EVI tunneled packets do
not contain a GRE key.
The GRE key setting must be the
same across an EVI network.
Perform this step if any remote edge
devices generate VLAN ID-based
GRE keys for EVI tunneled packets.
NOTE:
In addition to the EVI-specific commands described in this section, you can configure generic tunnel
interface commands on an EVI tunnel interface. These tunnel commands and tunneling basics are
described in the tunneling configuration in Layer 3—IP Services Configuration Guide.
Assigning a network ID to the EVI tunnel
Assign the same network ID to the EVI tunnels of all edge devices in an EVI network.

14
On an edge device, the network ID assigned to an EVI tunnel must be unique.
To assign a network ID to an EVI tunnel:
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter tunnel interface view. interface tunnel number
[ mode evi ] N/A
3. Specify a network ID. evi network-id number By default, no network ID is specified.
Specifying extended VLANs on the EVI tunnel
When configuring extended VLANs, follow these guidelines:
•You can specify an extended VLAN on only one EVI tunnel.
•To avoid loops, do not assign transport-facing ports to extended VLANs.
•To avoid data breach, make sure all edge devices in an EVI network maintain the same list of
extended VLANs.
To assign extended VLANs to an EVI tunnel:
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter EVI tunnel interface
view. interface tunnel number
[ mode evi ] N/A
3. Specify extended VLANs. evi extend-vlan vlan-list
By default, no VLANs are specified as
extended VLANs on any EVI tunnel.
To specify more extended VLANs, repeat
this step.
Configuring ENDP
ENDP enables the edge devices in an EVI network to discovery each other.
Configure an edge device as an ENDS to provide registration services or as an ENDC to register
with an ENDS.
Configuration guidelines
•For redundancy, you can configure up to two ENDSs on an EVI tunnel interface. These two
ENDSs work independently. The failure of one ENDS does not affect the neighbor discovery
and EVI link maintenance in the EVI network.
•When you enable ENDS on an EVI tunnel interface, an ENDC is automatically enabled. This
ENDC uses the source address of the EVI tunnel as the ENDS address.As a result, you can
use the evi neighbor-discovery client enable command to add only one ENDS address on an
ENDS-enabled EVI tunnel interface.
•To guarantee that each edge device can obtain the addresses of all its EVI neighbors, make
sure the ENDSs are the same across the EVI network.
•To improve security, enable ENDP authentication.
{Make sure all authentication-enabled ENDCs and ENDSs in an EVI network use the same
authentication key.

15
{If authentication is disabled on an ENDS, all ENDCs, including authentication-enabled
ENDCs, can register with the ENDS without authentication.
{If authentication is enabled on an ENDS, only authentication-enabled ENDCs that use the
same authentication key as the ENDS can register with the ENDS.
Configuring the edge device as an ENDS on the EVI tunnel
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter EVI tunnel
interface view. interface tunnel number
[ mode evi ] N/A
3. Enable ENDS. evi neighbor-discovery
server enable
By default, ENDS is disabled.
On an ENDS-enabled tunnel interface,
you can use the evi neighbor-discovery
client enable command to add one more
ENDS, and use the evi
neighbor-discovery client
register-interval command to modify the
ENDC registration interval.
4. (Optional.) Enable
ENDP authentication. evi neighbor-discovery
authentication { cipher |
simple } password
By default, ENDP authentication is
disabled.
Configuring the edge device as an ENDC on the EVI tunnel
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter EVI tunnel interface
view. interface tunnel number
[ mode evi ] N/A
3. Configure the edge device
as the ENDC of an ENDS. evi neighbor-discovery client
enable server-ip
By default, ENDC is disabled.
If ENDS is enabled on the EVI tunnel
interface, you can use this command
to specify only one more ENDS.
If ENDS is disabled, you can repeat
this command to specify up to two
ENDSs.
ENDS address is the tunnel source
address configured on an
ENDS-enabled EVI tunnel interface.
4. (Optional.) Enable ENDP
authentication. evi neighbor-discovery
authentication { cipher |
simple } password
By default, ENDP authentication is
disabled.
All ENDSs and ENDCs in an EVI
network must use the same
authentication key.
5. Configure the interval at
which the ENDC updates
its registration with ENDSs. evi neighbor-discovery client
register-interval time-value
By default, an ENDC update its
registration with an ENDS every 15
seconds.
Tuning EVI IS-IS parameters
EVI IS-IS automatically runs on an EVI link immediately after the link is set up. You can tune EVI
IS-IS parameters to optimize the protocol performance.

16
EVI IS-IS configuration task list
All EVI IS-IS configuration tasks are optional.
Tasks at a glance Remarks
Creating an EVI IS-IS process N/A
Changing the designated site VLAN
The redundant edge devices at a site use the
designated site VLAN to exchange EVI IS-IS
hello packets for DED election and
extended-VLAN assignment.
Optimizing an EVI IS-IS network:
•Configuring the EVI IS-IS hello interval
•Configuring the hello multiplier for calculating the
adjacency hold time
•Configuring the DED priority
•Configuring the CSNP packet transmit interval
•Configuring the minimum LSP transmit interval and
the maximum number of LSPs sent at each interval
•Configuring the maximum LSP lifetime
•Configuring the LSP refresh interval
•Associating an EVI tunnel interface with a track entry
•Configuring preferred VLANs
Perform the EVI IS-IS network optimization
tasks to enable fast EVI link failure detection,
set appropriate MAC reachability information
update interval, and control the volume of LSP
and CSNP traffic on an EVI network.
Specifying a routing policy for an EVI IS-IS process Perform this task to advertise a subset of MAC
addresses instead of all local MAC addresses
to remote sites.
Enabling adjacency change logging N/A
Configuring SNMP notifications and context for EVI IS-IS N/A
Configuring Graceful Restart for an EVI IS-IS process Perform this task for providing nonstop
services.
Increasing the maximum number of MAC entries in an
LSP for an EVI IS-IS process Perform this task depending on the MAC address table size on the edge device.
Creating an EVI IS-IS process
Each EVI network has one EVI IS-IS process. Before you can configure settings in EVI IS-IS process
view, you must create the process.
An EVI IS-IS process is created automatically when you perform any one of the following tasks on a
tunnel interface:
•Specify extended VLANs.
•Perform network optimization tasks (see "Optimizing an EVI IS-IS network") except configuring
the LSP refresh interval and the maximum LSP lifetime.
•Configure VLAN mappings.
The ID of an automatically created process is the same as the EVI tunnel interface number.
Alternatively, you can use the evi-isis command to create an EVI IS-IS process manually.
To delete a manually created EVI IS-IS process, you must use the undo evi-isis command.
•If EVI IS-IS settings exist on the EVI tunnel interface, the undo evi-isis command only deletes
settings configured in EVI IS-IS process view.

17
•If no EVI IS-IS settings exist on the EVI tunnel interface, the undo evi-isis command deletes
both the EVI IS-IS process and all settings configured in EVI IS-IS process view.
An automatically created EVI IS-IS process is automatically deleted when you delete all EVI IS-IS
settings from the EVI tunnel interface.
To create an EVI IS-IS process or enter its view:
Step Command Remarks
1. Enter system view. system-view N/A
2. Create an EVI IS-IS process
or enter EVI IS-IS process
view. evi-isis process-id
By default, no EVI IS-IS process is
configured.
The process ID you specify must be the
same as the EVI tunnel interface number.
The EVI IS-IS process takes effect after you
configure extended VLANs on the tunnel
interface.
Changing the designated site VLAN
EVI IS-IS uses the designated site VLAN to exchange hello packets within a site to discover
redundant edge devices and map extended VLANs to edge devices.
This designated site VLAN must not be extended across any EVI network.
To change the designated site VLAN for EVI IS-IS:
Step Command Remarks
1. Enter system view. system-view N/A
2. Specify a designated site
VLAN. evi designated-vlan vlan-id The default designated site
VLAN is VLAN 1.
Optimizing an EVI IS-IS network
Perform the tasks in this section to optimize an EVI IS-IS network for bandwidth efficiency and high
performance.
Configuring the EVI IS-IS hello interval
EVI edge devices send EVI IS-IS hellos over EVI links to establish and maintain adjacencies and
elect the inter-site DED on each EVI link.
EVI edge devices at a multihomed site also exchange EVI IS-IS hellos to elect the site DED for
distributing extended VLANs among them.
Set the hello interval depending on the network convergence requirement and system resources.
•To increase the speed of network convergence, decrease the hello interval.
•To conserve resources, increase the hello interval.
NOTE:
The hello interval of a DED is one-third of the hello interval set with the evi isis timer hello
command.
To configure the EVI IS-IS hello interval on an EVI tunnel interface:
