INSTRUCTIONS
MANUAL
RC04
Step-Down Transformer
+ Reciever
IMPORTANT: This manual includes essential
information on the safety measures to be
implemented for installation and start-up. Therefore,
the installer, as well as the user, must read these
instructions before beginning installation and start-up.
To achieve optimum performance, follow the
instructions indicated below:
1. VERIFY THE CONTENTS OF THE PACKING:
The following items are included inside the box:
• Transformer x1
• Remote control x1
2. GENERAL CHARACTERISTICS AND INFORMATION:
• This is a single-phase 220W step-down transformer
that is used to lower voltage from 220V to 12V.
• This transformer is designed primarily for
underwater pool and fountain lights.
• This transformer can be xed for both, new and
old pools.
• It is possible to operate the underwater lights
using a remote control that is included.
• It is also possible to operate two additional
electrical items (garden lights, fountain pump,
etc) using the remote control which will function
as an on/off switch.
• There is a safety fuse inside.
• It is recommended not to install this unit more
than 15 meters away from the pool.
• The manufacturer is not responsible in any
circumstances for assembly, installation or start-
up of any electric components that have been
inserted or handled at locations other than its
own premises.
3. MAINTENANCE & REPLACEMENT:
FUSE: In case the lamps suddenly stop working,
check incoming and outgoing voltage. If there is
220V going into the transformer and no 12V coming
out, check the fuse and replace if necessary. This is
an indication that there was a spike in voltage that
damaged the fuse.
SPARKING: In case of sparking and/or blackness
around the connection terminals, scrape off all soot,
reconnect cables and tighten as much as possible.
REMOTE: In case the remote control stops working
or is replaced, there is a small button on the remote
module inside the transformer, press this button for
1 second, and then immediately press one of the 4
buttons on the remote to pair both devices.
The battery inside the remote may require
replacement.
4. AUX CONNECTIONS:
The auxiliary connections are to be used similar to an
on/off switch. Do not connect the live and neutral
wires into the terminals, as this will damage the
unit. Simply connect the live wire of any electrical
item (such as pump, light, etc) into one terminal
and carry on the same wire out into the unit. This
will enable the on and off action upon pressing the
respective buttons. If you have any doubts, email us
for assistance.
5. SAFETY WARNINGS:
• The persons who are in charge of installation
should have the required qualications for this
type of work.
• Avoid making contact with the electric voltage.
• Comply with the current standards regarding
accident prevention.
• IEC 364-7-702 standards must be observed:
WIRING IN BUILDINGS, SPECIAL WIRING,
SWIMMING POOLS.
• Any maintenance works must be performed
with the 220V incoming wire disconnected or
switched off at the main supply.
• Do not handle any electrical components with
wet feet.
6. TECH SPECS:
Housing Protection: IP65
Housing Size: 160mm x 160mm x 90mm
Weight: 1.8kgs
Input Voltage: 220V
Output Voltage: 12V
Maximum Power Output at 12V Terminal: 220W
Maximum Power Connected to Aux Terminals:
1500W/240V
7. MORE INFORMATION:
For more information on this product, installation
guides and maintenance procedures, please visit
www.propoolpro.com
Professional Pool Products reserves the right to alter this document as
and when necessary, without prior notice.
