Griven Powershine MK2 S User manual

Powershine K2 S
Manuale di istruzioni
Instructions manual

INDEX
1.0 Introduction .................................................................................................................................................................18
1.1 Safety information.......................................................................................................................................................18
1.1.1 Protecting against electric shock ..........................................................................................................................18
1.1.2 Installation ................................................................................................................................................................18
1.1.3 Protection against burns and fire ...........................................................................................................................18
1.1.4 Weather protection..................................................................................................................................................18
1.2 Compliance ................................................................................................................................................................18
2.0 Size ...............................................................................................................................................................................19
3.0 Packaging and transport ...........................................................................................................................................19
3.1 Packaging ...................................................................................................................................................................19
3.2 Transport ......................................................................................................................................................................19
4.0 Installation ...................................................................................................................................................................20
4.1 Fixing ............................................................................................................................................................................20
4.2 Adjusting light beam direction..................................................................................................................................20
4.3 Connection to mains power ......................................................................................................................................21
4.4 Connection to DM signal .........................................................................................................................................21
5.0 Use of the unit..............................................................................................................................................................22
5.1 Setting operating mode .............................................................................................................................................22
5.2 Unit control panel........................................................................................................................................................22
5.2.1 Reading the display and using controls ................................................................................................................22
6.0 D X function mode....................................................................................................................................................23
6.1 Setting DM channels ................................................................................................................................................23
6.2 Setting DM address...................................................................................................................................................23
6.3 DM functions RGBW ..................................................................................................................................................23
6.3.1 DM functions with DM MODE = 4 channels.......................................................................................................23
6.3.2 DM functions with DM MODE = 5 channels.......................................................................................................23
6.3.3 DM functions with DM MODE = 6 channels.......................................................................................................24
6.4 DM functions DW ......................................................................................................................................................24
6.4.1 DM functions with DM MODE = 2 channels.......................................................................................................24
6.4.2 DM functions with DM MODE = 3 channels.......................................................................................................24
6.5 DM functions monochrome.....................................................................................................................................25
7.0 aster-Slave and Automatic function (only RGBW and DW).................................................................................25
7.1 AUTOMATIC configuration .........................................................................................................................................25
7.2 MASTER configuration.................................................................................................................................................26
7.3 SLAVE configuration....................................................................................................................................................26
8.0 FIXED COLOURS mode (only RGBW and DW)...........................................................................................................26
8.1 RGBW MASTER configuration......................................................................................................................................26
8.2 Dynamic white MASTER configuration ......................................................................................................................26
8.3 SLAVE configuration....................................................................................................................................................27
9.0 Dimmer ( onochromatic ) .......................................................................................................................................27
10.0 Led temperature .......................................................................................................................................................27
11.0 Temperature of led drivers ......................................................................................................................................27
12.0 Body Temperature ( only Polar versions)................................................................................................................27
13.0 Heating Power ( only Polar versions ) .....................................................................................................................27
14.0 Default setting ...........................................................................................................................................................28
15.0 RD functions............................................................................................................................................................28
16.0 Thermal protection....................................................................................................................................................28
17.0 No frost glass .............................................................................................................................................................28
18.0 aintenance.............................................................................................................................................................28
18.1 Cleaning the unit ......................................................................................................................................................28
18.2 Regular checks .........................................................................................................................................................29
19.0 Spare parts ................................................................................................................................................................29
20.0 Disposal......................................................................................................................................................................29
21.0 Troubleshooting.........................................................................................................................................................30
22.0 Technical specifications ..........................................................................................................................................30

18 English
1.1 Safety information
1.1.1 Protecting against electric shock
• Disconnect the unit from mains supply before servicing it or performing any other action.
• Always ground/earth the unit electrically.
• Before connecting the unit to power supplies, verify that operating voltage and frequency are compatible.
• Do not handle the unit with wet hands or in the presence of water.
• Check regularly that the power supply cable is not damaged or crushed.
• Apply to a qualified technician for any regular maintenance action not described in this manual.
1.1.2 Installation
• Fix the unit with screws, hooks or any other support able to bear the weight of the unit itself.
• The unit installation actions must be performed by a qualified staff.
1.1.3 Protection against burns and fire
• Suitable to be installed onto normally inflammable surfaces.
• The unit is not to be installed in places where the ambient temperature exceeds 50° (122°F).
1.1.4 Weather protection
The unit is classified as device with an IP66 weather protection rate.
1.2 Compliance
• Product in compliance with EN60598-1 EN60598-2-17.
• Product in compliance with 2002/95/CE (RoHS).
1.0 Introduction
Warning!
This unit is suitable for professional use only, not for domestic use.

English 19
3.1 Packaging
Check carefully the content of the box and, in case of damage, contact your forwarder immediately. The fol-
lowing items are included in the box of this unit:
n° 1 Powershine K2 S unit
n° 1 owner’s manual
n° 2 connection kit
3.2 Transport
The carton box has not been designed to be used more than once, therefore, it is recommended to use one of
our flight cases to transport the unit.
2.0 Size
363mm
14,29”
546mm
21,48”
12,5mm
0,49”
300mm
11,81”
190mm
7,46”
336mm
13,23”
3.0 Packaging and transport
Warning!
• Griven S.r.l. liability will cease upon consignment of goods to the forwarder: claims for damage due to trans-
port must be addressed directly to the forwarder.
• Griven S.r.l. will accept claims for broken or missing goods only within seven days of receipt of the goods.
• Returns of equipment will not be accepted without prior authorization granted by Griven S.r.l. and if not duly ac-
companied by relevant shipping documents.

20 English
4.1 Fixing
The unit can be used both rested on floor and fixed onto a structure. The unit can operate in any position.
Use the holes Ø16 (0.6”) or Ø6.5 (1/4”) in the bracket to fix the
unit.
4.2 Adjusting light beam direction
1. Untighten the lateral screw “1”.
2. Rotate the bodies of the unit towards desired direction and
tighten the screw “1”.
4.0 Installation
12,5mm
0,49”
300mm
11,81”
1

English 21
4.3 Connection to mains power
The unit can operate with voltage from 100-277Vac and with frequency of 50 and 60Hz.
For the connection use main cable in the side of the rear boxl of the fixture and connect as shown below.
4.4 Connection to D X signal
The DMX signal is to be connected by using a shielded cable designed for devices RS-485.
The signal cable must be connected according to the following table:
ND = Shield
DATA - = Black
DATA + = Red
The projector is fitted with butt connectors and heat shrink tube which allow to perform IP67 connections.
To make the connection follow these instructions.
Warning!
• Before connecting the unit, verify that power supplies features are compatible with the unit features.
• The unit must never be installed if not grounded electrically.
• It is suggested to use a magnetothermic switch along the power supply line, as prescribed by in force rules.
• The unit must not be powered up through a dimmer power device.
• Wiring and connection actions are to be performed by a qualified staff.
Live
Ground
Neutral
Brown
Yellow Green
Blue
Main supply
Warning!
Follow the instructions provided along with the connection kit to perform the connections.
Warning!
All data wires must be isolated one from another and from the shield.
The GND of the D X signal is not to be connected to the electric ground of the unit.
Insert a terminal plug with a 120 Ω resistor connected to DATA- and DATA+ in the last unit.
Warning!
Follow the instructions provided along with the connection kit to perform the connections.

22 English
5.1 Setting operating mode
By the control panel it is possible to select one of the following operating modes:
• using D X512 signal control mode
Each fixture is controlled from DMX512 signal control.
(see chapter 8.0 D X function)
• ASTER-SLAVE or AUTO ATIC mode (only RGBW and DW)
The projector operates independently, without DMX512 signal control.
(see chapter ASTER/SLAVE and AUTO ATIC function)
• using FIXED COLOURS mode (only RGBW and DW)
The projector operates independently, without DMX512 signal control.
(see chapter FIXED COLOURS function)
The unit NORMALLY works in DMX mode and, on turning on, the display will read the number of DMX address (e.g.
012).
If on turning on the display will read “AUT”, it will mean that the unit is working in AUTOMATIC mode.
Disable this function to go back to the DMX mode.
If on turning on, the display will read “COL”, it will mean that the unit is working in FIXED COLOURS mode.
Disable this function to go back to the DMX mode.
5.2 Unit control panel
The display of the unit is programmed to turn off
automatically after 10 seconds of non working.
To activate it just press any key.
In the presence of the DMX signal the red led will steadily
be on while in the absence of DMX signal the led will flash.
The SET led is on during:
• DMX address is setting
• menu setting
5.2.1 Reading the display and using controls
ENU button:
By pushing the “MENU” button the display will show the main menu or you can exit from function and go back to
main menu.
By pushing the “MENU” button when is show the DMX address, you will enter in the main menu.
• Address setting ADR
• Channels number setting CHN (only R BW and DW)
• MASTER/SLAVE and AUTOMATIC mode AUT (only R BW and DW)
• FIXED COLOURS mode COL (only R BW and DW)
• Dimmer whitout DMX DIM ( only monochrome)
• LED temperature LET
• Driver temperature DRT
• Body temperature BOT (only polar version)
• Heating Power HEP (only Polar version)
• Default settings DEF
• Release software REL
UP and DOWN buttons:
By pushing the “UP” and “DOWN” buttons, values of the function which is shown in the display can be changed.
ENTER button:
Keep the “ENTER” button pushed, until the display and the SET led flash, in order to memorize the function which
is shown on the display.
5.0 Use of the unit

English 23
6.1 Setting D X channels
The number of DMX channels used by the unit to operate will depend from the selected operating mode.
Each R BW unit will use 4, 5 or 6 DMX channels.
Each DW unit will use 2 or 3 DMX channels.
Each monochrome unit will use 1DMX channel.
Follow this description to modify the DMX channels setting: press the “MENU” button, select “CHN” and press
“ENTER” button to activate the function. Then select the desired value (1C/../6C) through the “UP” and “DOWN”
keys. Press “ENTER” to confirm.
6.2 Setting D X address
Follow this description to modify the address: press once the “MENU” button, select “ADR” and press “ENTER” but-
ton to activate the function. Then select the desired value (between 1 and 512 ) through the “UP” and “DOWN”
keys. Press “ENTER” to confirm.
6.3 D X functions RGBW
6.3.1 DM functions with DM MODE = 4 channels
6.3.2 DM functions with DM MODE = 5 channels
6.0 D X function mode
Warning!
In absence of D X signal the led will remain OFF.
Channel Function Value Description
1 Red 0-255 Proportional control 0-100% of the Red color
2 reen 0-255 Proportional control 0-100% of the reen color
3 Blue 0-255 Proportional control 0-100% of the Blue color
4 White 0-255 Proportional control 0-100% of the White color
Channel Function Value Description
1 Red 0-255 Proportional control 0-100% of the Red color
2 reen 0-255 Proportional control 0-100% of the reen color
3 Blue 0-255 Proportional control 0-100% of the Blue color
4 White 0-255 Proportional control 0-100% of the White color
5Dimmer
Strobe
0-15 Luminous output intensity 100%
16-150 Proportional control of the luminous output intensity 100-0%
151-160 Luminous output intensity 0%
161-255 Proportional control of the strobe effect 0-100% (255=max)

24 English
6.3.3 DM functions with DM MODE = 6 channels
6.4 D X functions DW
6.4.1 DM functions with DM MODE = 2 channels
6.4.2 DM functions with DM MODE = 3 channels
Channel Function Value Description
1 Red 0-255 Proportional control 0-100% of the Red color
2 reen 0-255 Proportional control 0-100% of the reen color
3 Blue 0-255 Proportional control 0-100% of the Blue color
4 White 0-255 Proportional control 0-100% of the White color
5 Dimmer
0-5 Luminous output intensity 0%
6-250 Proportional control of the luminous output intensity 0-100%
251-255 Luminous output intensity 100%
6 Strobe
0-15 No strobe
6-250 Proportional control of the strobe effect 0-100%
251-255 Strobe effect 100%
Warning!
In absence of D X signal the led will remain ON.
Channel Function Value Description
1Dynamic
white
0-3 Warm white 100% - Cold white 0%
4-122 Warm white 100% - Cold white from 0% to 100%
123-132 Warm white 100% - Cold white 100%
133-251 Warm white 100% to 0% - Cold white 00%
252-255 Warm white 0% - Cold white 100%%
2Dimmer
Strobe
0-15 Luminous output intensity 100%
16-150 Proportional control of the luminous output intensity 100-0%
151-160 Luminous output intensity 0%
161-255 Proportional control of the strobe effect 0-100% (255=max)
Channel Function Value Description
1Warm
white 0-255 Proportional control 0¬-100% of the warm white
2Cold
white 0-255 Proportional control 0¬-100% of the cold white
3Dimmer
Strobo
0-15 Luminous output intensity 100%
16-150 Proportional control of the luminous output intensity 100-0%
151-160 Luminous output intensity 0%
161-255 Proportional control of the strobe effect 0-100% (255=max)

English 25
6.5 D X functions monochrome
Powershine K2 S can operate without DMX signal (in AUTOMATIC mode) and can be set so that a single MAS-
TER unit will command a series of SLAVE units. This function is particularly useful when more units are desired to ex-
ecute the same programme in synchrony.
The following picture shows an example of a Master-Slave layout.
7.1 AUTO ATIC configuration
RGBW - The AUTO ATIC mode ONLY works when set to operate with 5 D X channels.
DW - The AUTO ATIC mode ONLY works when set to operate with 3 D X channels.
Follow this description to modify the DMX channels setting: press the “MENU” button, select “CHN” and press
“ENTER” button to activate the function. Then select 5C through the “UP” and “DOWN” keys. Press “ENTER” to
confirm.
To activate the AUTOMATIC mode, press the “MENU” button up to visualize “ADR”. Through the “UP” and “DOWN”
keys select “AUT”. Press “ENTER” to confirm.
Through the “UP” and “DOWN” keys select “ACT”. Through the “UP” and “DOWN” keys select “ON” or “OFF” to
activate or deactivate the AUTOMATIC mode. Press “ENTER” to confirm.
It is possible to adjust the length of time of the scenes of the programmes.
Through the “UP” and “DOWN” keys select “TI” and press “ENTER” to confirm. Through the “UP” and “DOWN” keys
select the length of time desired (5-10-20-40 seconds) and press “ENTER” to confirm.
Now, through the “UP” and “DOWN” keys, it is possible to scroll the 8 preset programmes (P1-P8). Once positioned
Attention!
In absence of D X signal the led will remain ON.
Channel Function Value Description
1Dimmer
Strobe
0-15 Luminous output intensity 100%
16-150 Proportional control of the luminous output intensity 100-0%
151-160 Luminous output intensity 0%
161-255 Proportional control of the strobe effect 0-100% (255=max)
7.0 aster-Slave and Automatic function (only RGBW and DW)
MASTER SLAVE 1 SLAVE N
INOUTINOUT
SLAVE 2
INOUT OUT
Terminal resistor
(R=120 ƺnot included!)

English 26
onto the desired programme, press “ENTER” to confirm. By the keys “UP”and “DOWN” select “ON” or “OFF”. It is
possible to activate or disactivate the programme. Press ENTER to confirm.
Now the unit is in AUTOMATIC mode and the diplay will keep reading “AUT”.
To exit from the AUTOMATIC mode, press the “MENU” button, select “ACT” and press “ENTER” to confirm.
Select “OFF” to deactivate the AUTOMATIC mode. Press ENTER to confirm.
The following table shows the light output colour effect according to the programme (only R BW).
7.2 ASTER configuration
To set up the unit as MASTER the same instructions for the set up as AUTOMATICR must be followed (see paragraph
9.1 AUTOMATIC configuration).
7.3 SLAVE configuration
To set up the unit as SLAVE set the 5 channels (R BW) or 3 channels (DW) DMX mode with address 001.
In the FIXED COLOURS mode, it is possible to manually turn on the LEDs, without the use of a DMX.
In this mode, the projector also behaves as a master and can control a number of projectors SLAVE.
8.1 RGBW ASTER configuration
The FIXED COLOURS mode ONLY works when 5 channels D X mode is set.
To activate the FIXED COLOUR mode, press the “MENU” button up to visualize “ADR”. Through the “UP” and
“DOWN” keys select “COL”. Press “ENTER” to confirm.
Through the “UP” and “DOWN” keys select “ACT”. Through the “UP” and “DOWN” keys select “ON” or “OFF” to
activate or deactivate the FIXED COLOUR mode. Press “ENTER” to confirm.
Now, through the “UP” and “DOWN” keys, it is possible scroll the colours.
1. Red RED
2. reen RE
3. Blue BLU
4. White UHT
Once positioned onto the desired colour, press “ENTER” to confirm. By the keys “UP”and “DOWN” select “ON” or
“OFF”. It is possible to activate or disactivate the colours. Press ENTER to confirm.
Now the unit is in FIXED COLOURS mode and the diplay will keep reading “COL”.
To exit from the FIXED COLOURS mode, press the “MENU” button, select “ACT” and press “ENTER” to confirm.
Select “OFF” to deactivate the FIXED COLOURS mode. Press ENTER to confirm.
8.2 Dynamic white ASTER configuration
The FIXED COLOURS mode ONLY works when 3 channels D X mode is set.
To activate the FIXED COLOUR mode, press the “MENU” button up to visualize “ADR”. Through the “UP” and
Warning!
It is possible to select more programmes which will be executed in sequence.
If ASTER-SLAVE mode is being used, the fixture cannot be controlled by a D X control device and no other
D X control device must be present along the line!!
Program N° Effect
1 Red - Magenta - Yellow
2 Red - Magenta - Yellow - White
3 reen - Cyan - Yellow
4 reen - Cyan - Yellow - White
5 Blue - Cyan - Magenta
6 Blue - Cyan - Magenta - White
7 reen - Cyan - Blue - Magenta - Red - Yellow
8 reen - Cyan - Blue - Magenta - Red - Yellow - White
8.0 FIXED COLOURS mode (only RGBW and DW)

“DOWN” keys select “COL”. Press “ENTER” to confirm.
Through the “UP” and “DOWN” keys select “ACT”. Through the “UP” and “DOWN” keys select “ON” or “OFF” to
activate or deactivate the FIXED COLOUR mode. Press “ENTER” to confirm.
Now, through the “UP” and “DOWN” keys, it is possible scroll the colours.
1. Cold white CW
2. Warm white WW
Once positioned onto the desired colour, press “ENTER” to confirm. By the keys “UP”and “DOWN” select “ON” or
“OFF”. It is possible to activate or disactivate the colours. Press ENTER to confirm.
Now the unit is in FIXED COLOURS mode and the diplay will keep reading “COL”.
To exit from the FIXED COLOURS mode, press the “MENU” button, select “ACT” and press “ENTER” to confirm.
Select “OFF” to deactivate the FIXED COLOURS mode. Press ENTER to confirm.
8.3 SLAVE configuration
To set up the unit as SLAVE set the 5 channels (R BW) or 3 channels (DW) DMX mode with address 001.
This function controls the LED brightness.
Press the “MENU” button up to visualize “ADR”. Through the “UP” and “DOWN” keys select “DIM”. Press “ENTER”
to confirm. The DMX value of the dimmer function will be thus displayed. Press the buttons “UP” or “DOWN” until
the required value appears, then press “ENTER”.
With this operation the working temperature of Leds can be checked.
Press the “MENU” button up to visualize “ADR”. Through the “UP” and “DOWN” keys select “LET”. Press “ENTER” to
confirm.
The value of the operating temperature of LED, which should never be higher than 75°C, will appear. A higher
value indicates a malfunction of the fixture.
With this operation the working temperature of Led Drivers can be checked.
Press the “MENU” button up to visualize “DRT”. Through the “UP” and “DOWN” keys select “DRT”. Press “ENTER” to
confirm.
The value of the operating temperature of led drivers, which should never be higher than 70°C, will appear.
A higher value indicates a malfunction of the fixture.
With this operation the working temperature of Body can be checked.
Press the “MENU” button up to visualize “DRT”. Through the “UP” and “DOWN” keys select “BOT”. Press “ENTER” to
confirm.
With this operation the percentage of power that is supplied of the heater can be checked.
Press the “MENU” button up to visualize “DRT”. Through the “UP” and “DOWN” keys select “HEP”. Press “ENTER” to
confirm.
9.0 Dimmer ( onochromatic )
10.0 Led temperature
11.0 Temperature of led drivers
12.0 Body Temperature ( only Polar versions)
13.0 Heating Power ( only Polar versions )
English 27
English 27

With this operation ALL the parameters can be set to the default values.
Press the “MENU” button up to visualize “ADR”. Through the “UP” and “DOWN” keys select “DEF”. Press “ENTER”
to confirm. Select “RES” or “CAN” to reset value or cancel operation.
Following parameters will be set to default values: dmx address, number of dmx channels, automatic mode, co-
lour mode.
When operating in DMX mode, the projector can accept the following RDM commands:
• discovery
Upon request of the RDM controller, the projector adverts its own presence (the RDM controller will display the
projector between a list).
• DMX address reading and setting.
• Channels number reading and setting.
• On / Off identification
This command is used to identify the projector you want to get access to (the identification happens by swit-
ching on at full intensity all the LEDs).
• Manufacturer
The name of the manufacturer ( riven) is displayed.
• Model description
The projector model is displayed.
• Software version description
The version of the firmware in use on the projector is displayed.
• Temperature
The LEDs operating temperature value is displayed.
An internal temperature sensor prevents the unit from overheating. The temperature sensor will limit the current
to leds, protecting their integrity, if the ambient temperature exceeds the one allowed.
The POLAR Edition of the projector is fitted with a thermal glass which is particularly useful for outdoor applications.
In fact, by warming up the glass melts ice and snow which might interfere with the projection.
When the projector is on, if required by the weather conditions, the glass is automatically warmed up.
If the projection is to be started at a definite time, take care to defrost the glass in advance so that the leds can
be lit at the time required.
With very cold temperatures (below -20° C), we recommend you to let the projector always powered and switch
on the LEDs when needed.
15.0 RD functions
16.0 Thermal protection
17.0 No frost glass
14.0 Default setting
28 English

To ensure maximum functionality and light output it is recommended to follow these instructions:
18.1 Cleaning the unit
The unit must be cleaned regularly. Cleaning regularity will depend especially on the environment where the unit
will operate: deposits of dust, smokes or other wastes will reduce the light output performances.
• Clean regularly the glass of the unit.
• Be careful when cleaning the components. Operate in a clean, properly illuminated environment.
• Do not use solvents which could damage painted surfaces.
• Remove left particles by a cotton towel dampened with a glass-cleaning liquid or distilled water.
• Remove smoke and other wastes by a cotton towel dampened with isopropyl alcohol.
• Dry out by a clean, soft, non-scratching towel or by compressed air.
18.2 Regular checks
• Check electrical connections, especially the ground wiring and the power supply cable.
• Check that the unit is not damaged mechanically. Replace those components which have got deteriorated.
All components of the unit are available as spare parts at Griven dealers.
Exploded views, wiring diagrams, electronic layouts and advertising brochures are available on request.
To make the job of assistance centres easier, specify serial number and model of the unit which spare parts are
requested for.
The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old
lighting fixtures must not be disposed of the normal unsorted municipal waste stream. Old appliances must be
collected separately in order to optimise the recovery and recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you
dispose of the appliance it the must be separately collected.
Consumer should contact their local authority or retailer for information concerning the correct disposal of their
old appliance.
19.0 Spare parts
20.0 Disposal
18.0 aintenance
Attention!
Always remove mains power prior to opening up the fixture.
English 29

echanical features
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .363mm (14.3”)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .548mm (21.6”)
Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190mm (7.5”)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20Kg (44Lbs)
Thermal features
Maximum ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50°C (122°F)
Minimum ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C (-104°F)
Maximum surface temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <70°C ( <158°F)
Electrical features
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100-277 Vac 50/60Hz
Nominal current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3A @ 230V
Maximum power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281W
Thermal protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electronic
Light output source
Type of light output source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Leds
Optics
Optical system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lenses
Control
Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USITT DMX-512
R BW control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5 - 6 DMX channels
Dynamic white control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3 DMX channels
Monochromatic control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 DMX channels
Construction
Unit body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Iron/Aluminium
Treatment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Scratch resistant paint
Weather protection rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP66
21.0 Troubleshooting
Inconvenience Possibile Cause Action
The unit does not
respond properly
to the DMX control.
Incorrect DMX cable
connection.
Check connections and wires. Rectify inefficient connec-
tions. Repair or replace damaged wires.
Unfinished data connection.
Insert a terminal plug in the output jack of the last
unit of the connection.
Incorrect address
assignment to the units. Check the addresses of the units and the protocol settings.
One of the unit is faulty and
it is affecting the data
transmission along the
connection.
Short-circuit units singularly, one by one,
since regular working is restored.
It has been set up an oper-
ating mode different from
the DMX mode used.
Check the operating mode set up.
The unit is set to Master or
Automatic, but is not run-
ning any programs.
In addition to setting the
Master dip-switch to ON, it is
necessary to also select a
program number.
Select a program number.
Check the corresponding DMX functons table.
The unit is set to Slave,
but does not
respond properly
to the Master.
There more than a unit is set
to Master.
Check that amongst the interconnected fixtures, only one
has been set to Master.
Conflict in signals. Ensure that there is no incoming DMX signal.
22.0 Technical specifications
30 English

NOTE
English 31

Via Bulgaria, 16 - 46042 CASTEL OFFREDO (MN) - Italy
Telefono 0376/779483 - Fax [phone]
http://www.griven.com/ e-mail [email protected]
http://www.griven.it/ e-mail [email protected]
User’s manual rel. 2.30
