Profile PAC-106 User manual

Videophone Profile EN - 1
PAC-106
We thank you for the purchase of this Profile product.
Note: It is important that you read this manual carefully
before using the product Then keep this manual in a
safe place.
Technical data Monitor
Supply voltage adapter: 230VAC/15VDC 1.5A
Working current: +/- 300 mA
Operating temperature: -10°C to 60°C
Max relative humidity: 85%
Number of pixels: 480 horizontal X 240 vertical
Screen size: 2.36 Inches (diagonal)
Video system: PAL/NTSC
Total dimensions: 265(L) x 94(B) x 45(H) mm
Technical data Camera
Working current: <300mA
Temperature for use: -20°C/+50°C
Type:pinhole camera
Focus/image angle: 50°
Total dimensions:120(L)x41(W)x45(H)mm
Technical requirements for connections
Use either the 10-metre cable supplied or wiring
measuring 0.6 - 0.8 mm² with a max. length of 30
metres.
You need a plug socket that is max. 1.5 m from the
monitor.
Required wires without door lock: 4
Required wires with door lock: 6
Parts
Monitor with receiver
Camera
Protective cover for external unit
Mounting bracket for monitor
Spacer bushes for camera
Fixing screws
Connecting cable 10 m
Safety instructions
The monitor and camera may never be cleaned
with detergents. Only use soap and a damp cloth.
The adapter's power wiring may never be cut
through nor extended; this renders the guarantee
invalid!
The monitor may not be placed close to magnetic
fields such as next to a TV or thick power cables.
Water may never be poured over the camera or
monitor. The outside camera is only splashproof.
Assembly instructions
1. If there is not yet any wiring:
The position of the monitor is determined as
follows: the height is approximately 165 cm, and is
max. 150 cm from the plug socket into which the
adapter will be plugged. The connecting cable
between monitor and camera must therefore come
from the wall behind the monitor. Tubing must be
provided to contain the cable so the cable can
move freely. If possible also provide tubing with a
sufficiently large diameter, 20-25mm.
Determine the position of the camera outside at
the door. The ideal installation height is 155 to
165 cm. Then smaller and larger persons remain
in picture.
Bring the camera cable to the monitor from outside
to inside; the cable is moulded.
Connect the wiring according to diagram below.
We again emphasise that the power supply wiring
may not be extended or cut through: this causes
the appliance to work poorly and invalidates the
guarantee.
Cut off the cables with 2 cores without door lock.
If a door lock is to be connected, its connection
must be from the outside camera as shown on the
diagram below. The lock may consume no more
than 300 mA and must have a memory function
(the lock remains in position “free” until just before
the door is pushed open). The 2 wires are already
provided in a moulded cable (4m)
2. if there is already existing wiring (max.30m):
The wire diameter must be between 0,6 and 0,8
mm².
Shorten the moulded cables to the desired length
and strip the wires approximately 1cm. If an
electrical door lock is used: also strip the 2-core
cable over a length of 1cm.
The door lock is connected from the camera with
the moulded cable with two wires.
The lock may consume no more than 300 mA and
must have a memory function (the lock remains in
a free position as long as the door is not pushed
open).
If a recess can be provided behind the camera in
the wall or door frame, connect the wiring through
the connecting blocks and work it away in the
recess. If you cannot do this the wires must be
twisted together and insulated with insulation tape.

Videophone Profile EN - 2
PAC-106
Use:
A. Having a normal conversation
1. Ringing on the external unit
2. The image automatically appears on the
monitor inside.
3. Take the receiver and speak to the visitor.
4. The door lock can be operated with the key for
that purpose.
5. Replace the receiver after the conversation.
B. Making a visual check
1. You can press the picture key without picking
up the receiver.
2. The picture appears without any noise being
heard outside.
3. You can pick up the receiver and have a
conversation if you wish.
4. If you do not have a conversation you can stop
the picture by pressing the picture button
again. If you do have a conversation just
replace the receiver after the conversation.
C. Changing functions
1. The luminosity can be changed using the
luminosity key; the light intensity increases by
a value of 1 each time the button is pressed.
There are 7 levels. After the last level one
returns to the first or lowest position.
2. The contrast can be changed with the contrast
button. This happens in the reverse direction,
from less to more contrast. Here also there are
7 levels.
3. The colour intensity is changed with the colour
key. There are 7 different colour intensities
changed by pressing the button once.
4. The volume can be adjusted using the slider
button. The volume is continuously adaptable.
Guarantee conditions
The guarantee period for the PAC-106 amounts to 2
years and commences on the date of purchase.
During this guarantee period Eltra nv will repair any
defects attributable to material or production faults.
Eltra nv may choose to either repair or replace a
defective appliance.
Eltra nv is not obliged to repair or replace appliances if
they have become defective as a result of damage,
inappropriate use, or modifications or adaptations
made after the purchase date.
Take any defective appliance together with the original
receipt back to the shop where the appliance was sold.
Always add a note with a description of the problem.
Damage
Eltra nv can under no circumstances whatsoever be
held responsible for damage of whatever nature if the
appliance was not correctly installed according to the
specified installation instructions, nor for damage as a
result of unforeseen circumstances such as natural
disasters, lightening strike, etc. All such resulting costs
are consequently at the expense of the buyer and are
not covered by the guarantee conditions.
