profluid HPC PFMF 120-10 User manual

High Pressure Coolant System Packages
Installation & Operation Manual
HPC Model PFMF 120-10
PFMF 70-20
PFMF 70-15
PFMF 30-20
PFMF 20-20
Rev.20161107 V5.0E
The contents of the manual is subject to change without notice for improving quality.
* The products in the photos may be different from the actual products.
1156, Dudong-ro, Dudong-myeon, Ulju-gun, Ulsan, Korea.
TEL : [phone] FAX : [phone] www.kemtech.co.kr

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 2
◆ Foreword
We appreciate you for your purchase of the HPC System of KEMTECH.
Please read this operation manual to fully understand the details for correct operation of the system.
Keep the operation manual at a place for easy reach. When you lose the operation manual, please contract
KEMTECH.
Cautions
◇It is prohibited of duplicate whole or part of the operation manual.
◇The operation manual is subject to change to reflect modification of the
Specifications without notice in advance.
◇The description in this manual is to providing safe and convenient use of the system.
Please contact KEMTECH if you find any omission or inconvenience.
◇KEMTECH provides you with new manual if the manual contains wrong information or is
missed of pages.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 3
◇Contents ◇
Chapter 1 Precautions for Safety ·······························································································4
Attachment 1. Special Notes on Model PFMF 000-00 ········································································7
Chapter 2 Quality Warranty Certificate of HPC Systems of KEMTECH ····················································8
Chapter 3 Nomenclature of Each Component and Basic Specifications of HPC Model PFMF 000-00 ···············8
3-1. Nomenclature of components on the front panel ·······························································8
3-2. Nomenclature of components on the rear panel ································································8
3-3. Nomenclature of components of the pump ······································································8
Chapter 4 Cautions before Installation························································································ 10
Chapter 5 Installation············································································································ 12
Chapter 6 Electric Wiring ······································································································· 13
6-1. When the standard level switches (FS1 and FS2) are only mounted ······································ 13
6-2. When all of the standard and the optional level switches (FS1, FS2, FS3 and FS4) are mounted ···· 13
6-3. System Mounted with Control Box·············································································· 16
6-4. Operation Sequence Chart of System Mounted with Full Options·········································· 18
Chapter 7 Trial Run·············································································································· 20
Chapter 8 Pressure Setting and Operation of Pressure Control Valve ··················································· 20
Chapter 9 Relationship between Discharge Pressure and Discharge Diameter········································· 21
Chapter 10 Filter Replacement ································································································ 22
Chapter 11 Maintenance and Repair·························································································· 24
Chapter 12 Troubleshooting···································································································· 25

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 4
Chapter 1 Precautions for Safety
◇ This chapter describes the provisions to be observed for protecting customers or users of the HPC system from
KEMTECH, and the assets from damage.
◇ The symbols of safety in this manual are as follows:
Risk of death or serious injury of human being
Probability of death or serious injury of human being
Probability of injury of human being or damage to assets
《Immunity 》
1. The company shall be responsible for damage from any of the following sub paragraphs:
- Acts of God such as earthquake and flood
- Fire or action of third party, which the company is not responsible for
- Damage from intentional or incidental misuse of the system by user
- Loss from abnormal operation of the system deviated from the description in the manual
2. The company shall not be responsible for any consequential loss (e.g., commercial benefits, and shutdown
hours) from use or non-availability of the system.
3. The company shall be responsible for loss from non-compliance with the description in the manual.
4. The company shall not be responsible for any loss from malfunction of the system due to combination of the
system with other systems that the company is not responsible.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 5
●Do not install or use the system in the vicinity of source of high temperature
(e.g., frame or heating apparatus).
- Excessive heat, smoke, frame or explosion may take place.
●Do not place any object on the system, do not violently shake, or do not allow significant to the system.
- Overturn may take place.
●Use the standard peripheral equipments.
- Otherwise, failure or accident may take place.
●Install the system indoor, if possible.
- Otherwise, failure or capability degradation may take place.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 6
Attachment 1. Special Notes on Model PFMF 000-00
1. Unlike other model, it is allowed of switching the voltage of PFMF 000-00 from 220V to 380V with
simple modification inside the control box. (Refer to the electric wiring diagram.)
- The factory default is 220V.
- When you desire to switch the voltage to 380V, remove the short bar on the power supply. (Please
not that the voltage of the control box is fixed to 220V, and not allowed of changing.)
- Change the wiring (U1, V1, W1, X1, Y1 and Z1) of the high-pressure pump appropriate for 380V.
(Changing at the terminal block)
- The voltage of the coolant supply pump (U2, V2 and W2) will also be switched to 380V. The motor
shall be replaced with a pump of 380V, or change the wiring accordingly.
●The voltage shall first be checked before operating the system. The company shall not be responsible for
any failure or fire caused by connecting power of 380V to the system set to 220V.
In such a case, service charge will be billed even in the warranty period.
- Electric shock or damage to the system may take place.
●Make sure the correct rotation direction of the motor when operating the pump.
Repair of failure caused by rotation of the pump in wrong direction will be billed even in the warranty
period.
- Operating the pump in wrong direction for one or two minutes may damage the seal.
●Voltage switching shall be performed by qualified electric engineer.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 7
High Pressure Coolant System Packages
Chapter 2 Quality Warranty Certificate of HPC Systems of KEMTECH
Warranty scope
The warranty by KEMTECH for the quality warranty certificate supplied with the system is made pursuant to the
specifications of the manufacturer, and KEMTECH is not responsible for warranty of technical or material defects
after one year from the date of purchase.
Non-warranty scope
This warranty certificate shall not be applied to defects caused by incidental or erroneous actions of the purchaser
(the user) or third party. KEMTECH shall not be responsible for warranty of abnormal operation of the system due to
failure of routine maintenance; misuse, abuse and excessive use; unauthorized modification and repair; erroneous
installation, wrong electric wiring; or improper transportation of the system. Warranty does not cover damage from
acts of God such as fire, flood, earthquake and lightning, or defects notified after the expiry date of warranty. The
warranty certificate shall not be applied to common dispensable parts (e.g., valve, valve seat, o-ring, diaphragm,
spring, spring retainer, spacer and seal), or abrasive or dispensable parts of the functional components. KEMTECH
shall not be responsible for any expenses incurred from transfer, installation and transportation of the items relevant
to the warranty responsibilities of KEMTECH.
Procedure of applying warranty
When detecting defect of the system withinthe warranty period, immediately notify the defect to the local dealer or
the company with the purchase date or the serial number. The dealer or KEMTECH may ask to return the system
in the original packing materials or other appropriate packing materials, if required. KEMTECH will repair or replace
the system with a new system free dependent upon the conditions of the system. Purchase order shall be sent to
KEMTECH if quotation is required for the warranty services. Customer shall bear and be responsible for expenses
incurred for the KEMTECH product such as postage, insurance premium, and transportation. KEMTECH will return
the repaired or replacement system to the customer only upon transportation prepaid (freight of vessel or air
excluded). Customer shall bear expenses for transportation taking more than one day, or special transportation.
Requirements
Conditions of operation
- The pump shall operate within the conditions described in the HPC system manual; discharge pressure,
supply pressure and rotation speed. The pressure control valve shall properly adjusted within the range not
exceeding the maximum operation pressure of the high-pressure system.
Cutting oil
- There shall be no warranty responsibility if the pump operates with sufficient quantity cutting oil.
- Operate the pump only after supplying sufficient quantity of cutting oil into the pump. Never operate the
pump filled with unfiltered cutting oil or oil inappropriate for the rubber seals.
If the conditions are not satisfied, the warranty responsibility shall be void. Neither KEMTECH nor its affiliate shall
not be responsible for warranty any loss or inconveniency of customer caused by improper use of the system from
KEMTECH, including loss beyond the warranty period specified on the written warranty certificate, and direct,
special, prone and consequential losses.
The HPC system is valuable asset of yours.
KEMTECH and HPC Systems will support you for use of the system in optimal conditions.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 8
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
Chapter 3
Nomenclature of Each Component and Basic Specifications of HPC Model PFMF 000-00
Components
Make sure all of the system and the accessories listed below are delivered. Contact KEMTECH or HPC System for any omitted or
abnormal components . TEL : [phone] FAX : [phone]
Quantity Item
1 HPC MODEL PFMF 00-00
1 Orificeforpressureadjustment(Seepage18)
1 Cautionlabelstobeattachedtothesystem (Seepage4)
1 Installationand operationmanualwiththequalitywarrantycertificateattached
3-1. Nomenclature of components on the front panel
①Inlet Port
②Filter choice V/V
③Sol V/V
④Gauge (토출압력)
⑤Discharge Port (고압 토출구)
⑥Unloader (압력조절기)
⑦Eye Bolt (이동용)
⑧Control Box
⑨Level S/W (Low/Mid/Hi)
⑩Level Gauge
⑪Clean Tank Drain V/V
⑫Caster
⑬Clean Tank Overflow Port
⑭Dirty Tank Drain
⑮Bypass Line
⑯Pump in V/V (상시열림)
⑰PUMP & MOTOR

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 9
①
⑬
⑭
⑤
⑮
⑯
⑰
3-1. Nomenclature of components on the rear panel 3-2. Nomenclature of components of the pump
3-3. Part List
No.
PARTS No.
PARTS NAME
SPECIFICATIONS
RK.
1
D00SM000020
MOTOR
1.5Kw,4P,3∅,200/220V,50/60Hz
PFMF 30-20/20-20
D00HY000420
4Kw,4P,3∅,220/380V,50/60Hz
PFMF 70-15(20)/120-10
2
M10NP000180
PUMP
TOP-212HWM
PFMF 30-20/20-20
M10SU000260
QT32-12.5-A
PFMF 70-20
M10SU000300
QT32-10-A
PFMF 70-15/120-10
3
M42HZ000230
COUPLING
CR2035-A
4
D40ZZ000110
SOL V/V
HSEVK047-DC24
5
M70WI000030
토출압력 Gauge
63mm, 60bar, Pole 형
M70WI000040
63mm, 100bar, Pole 형
M70WI000050
63mm, 150bar, Pole 형
6
M35ZZ000271
압력조절기(Unloader)
UL180/200
7
M71MP000040
Level Gauge
LVA30SVP
8
D20ZZ000120
Level S/W
Low/Mid/Hi/Dirty Tank
DM-SP26,Φ8,STS304
9
M22ZZ000030
SUCTION FILTER
FILTER SH-SF-06-PL(SS40 #100)
10
M72ZZ000100
CASTER
WI-60FP

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 10
<Table1>
Specifications
Unit
PFMF 120-10,S
PFMF 70-20,S
PFMF 70-15,S
PFMF 30-20,S
PFMF 20-20
Discharge volume
liters/min (gallons/min)
10 / (2.6)
21 / (5.5)
14 / (3.7)
30 / 7.9
20 / 5.3
Motor
HP (kW)
5(4.0)
5(4.0)
5(4.0)
2(1.5)
2(1.5)
Voltage
[ V ]
3Ph 220/380V
200/220V
Current
A (220/380)
14.7/8.51
18.1/8.9
18.1/8.9
7.0/7.0
7.6/4.3
Oil volume at
the inlet
liters/min /
(gallons/min)
15 / 4.0
20 / 5.3
15 / 4.0
20 / 5.3
20 / 5.3
Max. discharge
pressure
Bar (psi)
120 (1,740)
70 (1015)
70 (1015)
30 (435)
20 (290)
High-pressure
discharge outlet
male
R 3/8" JIS
Orifice
mm(Hole diameter)
1.0
2.0
1.5
1.5
1.5
Inlet tube
Female
Rc 1/2"
Overflow
Female
Rc 1-1/4"
Size
mm(D x W x H)
470 x 944 x 1326
Weight
Kgs
173
Coating
Powder coating
Standard (Light Grey : R7035)
** Note
1. The rotation speed of the motor and the discharge volume vary dependent upon the power frequency.
2. The Discharge volume is sum of flow rate at the high-pressure discharge outlet and the bypass at the top pressure.
Chapter 4 Cautions before Installation
Preparation for safety:
1. Read and fully understand the description and the cautions for safety in the installation and operation manual prior to
installing and operating the HPC system.
2. Always wear the protective goggles when operating the system at high pressure.
3. Install every protective device on the system prior to operating the system at high pressure.
4. Do not expose the body to the discharge outlet of the high-pressure coolant system.
5. Do not operate the pressure control valve to increase the pressure when the orifice for proper adjustment of pressure
(Refer to Table 1) is not installed.
6. Adjust the nozzle only when the high-pressure coolant system is standstill.
7. Never allow spraying the high-pressure coolant to the operator (fatal injury may take place).
8. Pay special attention when moving the system with a forklift truck or a crane not to damage the system. Prevent any
person from walking under the system during movement. Fatal injury or death accident may take place when the system
drops.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 11
Inspection in advance
Safety valve: The HPC system is a strong pressurizing system.
The bypass pressure control valve is mounted on the system to play the role of a safety valve, adjust the maximum
pressure of the system, and prevent discharge with pressure exceeding the defined setting. Improper operation may make
the quality warranty void, and cause injury to the body. Improper operation may also cause damage to the pump or the
system.
Do not remove the pressure control valve from the system. (Fatal injury may take place.)
The manufacturer shall not be responsible for failure due to erroneous or improper operation of the user.
Flow rate at the inlet: The coolant shall be supplied with proper flow rate for operating the HPC system at the optimal
conditions. A coolant pump for supplying the coolant to the inlet of the HPC system is demanded. Make sure that the
flow rate of the coolant supply pump is appropriate before install the pump. The maximum flow rate of the high-
pressure pump installed on the HPC system is (Refer to Table 1). The minimum flow rate of the coolant supply pump
is (Refer to Table 1). Adjust the pressure for the flow rate. When fine particles accumulated on the filter, the flow rate
of the coolant supply pump decreases, and air is introduced into the high-pressure pump installed on the HPC system to
cause problem.
Filtering: You can select the filtration grade from three types; 50-, 25, and 10-micron.
Viscosity of coolant: It is recommended to use coolant or oil with viscosity lower than 125 SUS (cSt 26).
(The higher the viscosity of the coolant grows, the lower the life cycle of the filer gets.)
Considerations before Installation
a. Make sure that the coolant supply systems (the hose, the valve, the tube, and the coolant coupling) are appropriate for
the operation pressure prior to installing the HPC system.
b. Replace contaminated coolant with fresh coolant, and remove chips and iron particles from the coolant tank of the
system to maximize the effects.
c. Tubing materials of PT/NPT and coolant tubing material of 37° JIS are used on the HPC system. The JIS tubing material
is designed to prevent leakage under high pressure and in vacuum without pipe seal. The PT/NPT tubing material shall
be wrapped with the pipe sealant (e.g., Loctite 585), or Teflon tape. The Teflon tape shall carefully handled to prevent the
tape from being introduced inside the tubing.
※Contact KEMTECH or HPC Systems if you have questions or need support:
TEL : [phone] FAX : [phone]

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 12
Chapter 5 Installation
Fixing the system
1. Operate the HPC system only after fixing the system on a flat floor.
2. There are bolts and devices on the bottom of the HPC system for fixing the system.
3. When the system not fixed moves or falls due to external impact during operation, the system is damaged
and causes fatal injury to the operator.
Tubing
1. It is recommended to keep the tubing on the HPC system and the system body as short as possible.
Consider the distance to the system body from the tubing or wiring supplied together with the HPC system.
2. Consider the situations of the filter replacement, adjusting the discharge pressure, and checking and
replacing the pump oil, and install the HPC system at a place with sufficient and appropriate space for the
situations.
3. It is recommended to install partition on the coolant tank of the system body to separate the pump
supplying coolant to the HPC system, and the area where coolant is recovered from the system body is
introduced. This design reduces air introduced when supplying the coolant to the HPC system.
Tubing at the inlet (coolant supply inlet)
1. Use the tubing at the inlet (e.g., hose and tubing materials) with inner diameter larger than 9.52 mm(3/8").
2. If it is inevitable to use the elbow tubes, it is recommended to use the elbow or 45° rather than 90° angle.
Do not use elbow of 90° angle as possible.
3. Use sealing materials (sealant or Teflon tape) on the PT/NPT tubing at the inlet of the HPC system. If there
is slight leakage on the tubing, air is introduced into the system to generate vacuum.
Please note that the JIS 37° tubing materials does not demand sealing materials.
4. When using a shutoff valve, use a valve with inner diameter of 9.52 mm(3/8") of full-open mode.
5. Do not directly connect solid tubing such as steel pipes to the HPC system. Use tubing materials such as
flexible hose to absorb effects from vibration.
6. Install the tubing in such a way to minimize vibration and load on the tubing.
Caution: Do not installed a shutoff valve on the bypass.
Rapid increase of pressure damages the HPC system, and causes fatal injury to the body.
Overflow tubing
1. It is recommended to use overflow hose with inner diameter of 1-1/2" or larger. If coolant flow is blocked,
the clean coolant tank may be overflowed. Keep sufficient inclination and elevation level from the coolant tank.
2. If the clean coolant tank is overflowed yet, adjust the flow rate of the coolant supply pump. (Adjust the
operation duration with a timer, or install a valve to adjust the supply flow rate.)
3. The overflow hose connected to the coolant tank of the system shall be located at a position farthest from
the inlet of the coolant supply pump. Introduction of air affects capabilities of the coolant supply pump.
4. Task appropriate action to prevent removal of the overflow hose from the coolant tank.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 13
High-pressure tubing (discharge)
1. Use a flexible hose longer than 0.9 meter for connecting the high-pressure discharge outlet of the HPC
system to the connection port (or tubing material such as a pipe) fixed on the machine.
2. The flexible hose is demanded to reducing vibration of the tubing for coolant. Pulsation dampening assembly
is more effective for dampening pulsation generated from high pressure.
3. Make sure that the coolant tubing on the machine is appropriate for the minimum operation pressed of 150
bar (2100 psi) prior to installing the HPC model. If not, replace with the appropriate tubing.
4. It is recommended to use a hose with inner diameter of 9.52 mm (3/8"). Do not use a hose with inner
diameter smaller than 3.17 mm (1/8"). If it is inevitable to use the hose smaller than the size, please contact
KEMTECH for advise.
5. The tubing at the high-pressure outlet of the HPC system is 3/8" (-12) 37° JIS male hydraulic tubing.
Label indication cautions for operator
1. Affix the caution label as illustrated on the figure
on the door of the system body at height of the
eyes of operator.
2. Operate the HPC system only after fully
understanding the installation procedures.
Then, check the cautions prior to installation again.
Chapter 6 Electric Wiring
Caution: Electric wiring and circuit configuration shall be performed by qualified electric engineer.
Never fail in making sure that the power is turned off prior to operation.
Caution: Pay special attention to how to operate and shut down the high-pressure pump motor before
operating the HPC system. Frequent turning-on and turning-off generates overheating, and may cause
damage to the motor, the magnetic connector and the shaft of the high-pressure pump, and malfunction of the
motor.
If it is required of operation at high pressure for a short period (i.e., several turning-on and-off operations are
required in a few minutes), install the 3-way solenoid valve for high pressure. It is desirable to operate the

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 14
motor with a single control signal. Use a separate signal on the solenoid valve for high pressure to selectively
operate discharge and drain of the valve.
Power connection
The factory default of the HPC model is low voltage wiring (220V, 50/60 Hz, 3-phases). The rotation direction
may be switched dependent upon the wiring of the main power. In such a case, the motor or the pump may
seriously be damaged. Immediately shut off operation, and correct the wiring for right rotation direction.
When changing the wiring to 380V, correct the wirings of the high-pressure pump, the control box, and
the coolant supply pump also. Supplying power of 380V without correcting the wiring may cause
significant failure to the system.
The system connector cable of five meters is provided to the power supply and the controller respectively in default.
(The cable length may vary, or no cable is demanded upon request of the customer.)
Make sure of grounding.
Alarm control circuit (Refer to the electric diagram)
The following level switches are installed on the HPC system for monitoring flow rate of coolant supplied to the inlet of
the high-pressure pump:
FS1- CLEAN TANK LOW S/W(Standard) : Used for the signal of turning on/off signal of the coolant supply pump,
or control of the level alarm. (Location at height of approx. 50 liter of
flow rate)
FS2- DIRTY TANK HIGH S/W(Standard) : Used for the signal of the bag filter (Location at height of approx. 2.5
liter of flow rate)
FS3- CLEAN TANK MID S/W(Option) : Used for the turning-on signal of the coolant supply pump (Location at
height of approx. 60 liter of flow rate)
FS4- CLEAN TANK HIGH S/W(Option) : Used for the turning-off signal of the coolant supply pump (Location at
height of approx. 80 liter of flow rate)

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 15
Controlling the coolant supply pump
6-1. When the standard level switches (FS1 and FS2) are only mounted
1-1 Upon continuous supply coolant by the coolant supply pump
a. The flow rate of the coolant supply pump shall be greater than the discharge flow rate (max. 20
liters/minute), and smaller than the overflow rate. The overflow rate significantly varies dependent upon
the tubing conditions including the elevation difference between the tank of the HPC system and the
coolant tank of the machine, tubing inclination, and the tubing diameter. The flow rate shall be
determined upon initial operation not to overflow the tank of the HPC system. The most common
method of adjusting the flow rate is installing a valve on the inlet port of the HPC system. (Set the inlet
flow rate based on the discharge volume of the HPC system at zero.)
b. When the FS1 signal is open (normal open), operation of the high-pressure pump of the HPC system shall
be shut off. (Coolant alarm) Operating the high-press pump without coolant significantly reduces the
life cycle of the pump. The interlock circuit shall be configured on the HPC system.
1-2. When controlling the coolant supply pump with a timer
a. Adjust the operation duration of the coolant supply pump between 30 and 80 seconds when the FS1
signal is open (normal open).
Frequently turning on and off the supply pump within a short period may affect the life cycle of the supply
pump. Check the supply flow rate, and adjust the operation duration not to overflow the clean tank of the
HPC system.
If the flow rate of the supply pump is greater than 60 liters/minute, install a valve on the inlet port to
adjust the flow rate.
b. Operation of the high-pressure pump of the HPC system shall be shut off when the FS1 signal is
open (normal open), and the coolant supply pump operates, but the FS1 signal is not closed (normal
close) after 10 to 15 seconds. (Coolant alarm)
Operating the high-press pump without coolant significantly reduces the life cycle of the pump. The
interlock circuit shall be configured on the HPC system.
6-2. When all of the standard and the optional level switches (FS1, FS2, FS3 and FS4) are mounted
a. When the FS3 signal is open (normal open), use this signal as the on-signal of the supply pump.
b. When the FS4 signal is closed (normal close), use this signal as the off-signal of the supply pump.
c. When the FS1 signal is open (normal open), operation of the high-pressure pump of the HPC
system shall be shut off. (Coolant alarm)
Operating the high-press pump without coolant significantly reduces the life cycle of the pump. The
interlock circuit shall be configured on the HPC system.
Controlling the filter replacement alarm (FS2)
1. When the FS2 signal is switched from being closed (normal close) to being open (normal open), use this
signal as the filter replacement alarm signal.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 16
<Electric circuit diagram (MS Con't)>
< Electric circuit diagram (Harting Con't)>

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 17
6-3. System Mounted with Control Box
* The system with the standard specifications is not indicated otherwise.
1) Power lamp: Lights when the main power is supplied.
2) Supply pump lamp: Lights when the coolant supply pump operates.
- The pump operates on upon the coolant level is Mid or Low. The pump does not operate at Hi level.
3) Hi P/S Pump Lamp: Lights when the high-pressure pump operates.
- The pump operates when receiving the cycle start signal in the automatic mode, or when
pressing the button in the manual mode.
- The pump does not operate at low level of the coolant.
4) NPR AL Lamp: Lights when the phase main power is inversed.
- Refer to Section 7 in Chapter 7.
5) MCT EMG: Lights when the HPC system is shut off upon emergency.
- High-pressure discharge is terminated.
6) EMG: Lights when the pressing the emergency button on the coolant unit.
- All the functions are terminated, alarm light lights, and the buzzer sounds.
7) Supply Pump O/L Lamp: Lights when there takes over-current on the coolant supply pump.
- Remove the cause, then press Reset button.
8) HI P/S Pump O/L Lamp: Lights when over-current takes place on the high-pressure pump.
- Remove the cause, then press Reset button.
9) Level HI Lamp: Light when the level is Hi in the tank.
10) Level Mid Lamp: Light when the level is Mid in the tank.

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 18
11) Level Low AL Lamp: Light when the level is Low in the tank.
- When this lamp lights, the high-pressure does not operate.
12) Filter Change Lamp (Full Option): Signals replacement of contaminated filter after automatically
switching off the filter.
- When the filter is not replaced within the designated period with a 24-hour timer, the filter
alarm takes place, and operation of the system is shut down. (User sets the period. The factory
default is 16 hours.)
13) Filter AL: Signals replacement of contaminated filter.
- Standard: After replacing the filter, open the drain valve of the dirty tank to remove the coolant,
and then close the vale again. Otherwise, the system does not operate, or no alarm does
not place even if the filter is contaminated again. (Stress is caused to the machine.)
- Full Option: Replace the filter, and the rotate switch 20. (in either direction; A-> B, or B-> A)
Reset Play 5 lights, the coolant in the dirty tank is automatically removed, and the
tank closes after certain period. The mode is switched to the automatic filter
switching preparation mode. Refer to description in 12) above.
14) SOL1: Lamp indicating operation of solenoid valve 1.
15) SOL2: Lamp indicating operation of solenoid valve 2.
16) EMG S/W: Switch shutting down operation of the HPC system.
All the functions are terminated, the red alarm light lights, and the buzzer sounds.
17) Manual/Auto Select S/W: Switch for switching between the automatic operation and the manual
operation.
- In the automatic mode, the system operates in accordance with the signals of the system
(e.g., system ready and cycle start). Use this mode for processing work.
- In the manual mode, the system operates only when pressing the button on the pump
I ndependent from the signals of the system.
Use this mode for repairing or resetting the machine.
18) Hi Pressure Pump: The pump is available in the manual mode. The pump operates while pressing
the button.
- The pump does not operated when any other alarm takes place.
19) Supply pump: The pump is available in the manual mode. The coolant supply pump operates
while pressing the button.
- The pump does not operate even when pressing the button if the level is Hi.
20) Buzzer On/Off: When an alarm takes place on the machine, the red lamp lights and the buzzer
sounds on Call Light.
- Press this button to silence the buzzer only after checking the alarm.
- Return the switch to ON position after resetting the alarm. Otherwise, the buzzer does not
sound upon subsequent alarm.
21) SOL3: Lamp indicating operation of solenoid valve 3.
22) SOL4: Lamp indicating operation of solenoid valve 4.
23) Level Low AL Reset

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 19
6-4. Operation Sequence Chart of System Mounted with Full Options
* Indicating upon normal operation and thereafter
Filter 1,2
사용
Automatic drain
from dirty tank
Filter Reset
A↔B
Replacing
filter
1 & 2 by
operator
Automatic switch standby
for filter 1 & 2
Filter AL
System operation
shutdown
Filter change lamp
extinguishing
Filter 1,2
clogged
Automatically switching
to filter 2 & 1
Filter
Change

--------------------------------------------------------------------------------------------------------------------------------
REV.20161107 V5.0E PFMF Series Installation & Operation Manual 20
Chapter 7 Trial Run
Cautions for first trial run:
1. The level of the coolant in the coolant tank of the system body shall sufficiently high for operation of
the HPC system.
2. All the shutoff valves installed on the coolant supply line shall be kept open.
The high-pressure discharge tubing shall not be blocked.
3. All the connections on the tubing shall securely be tightened.
4. Fully turn the adjusting bold of the pressure control valve in the vicinity of the high-pressure discharge
outlet in counterclockwise direction to reduce the spring pressure inside the valve to minimize the
pressure discharged from the pump during the trial run.
(Refer to Chapter 7.)
5. The filter shall be installed inside the HPC system. At least one of the valves on the inlet line (filter 1
and filter 2) shall be kept open. The valve on the high-pressure shall be kept open.
6. The level of the coolant inside the clean tank shall be kept at sufficient height. (1/3 to 2/3 of the tank)
7. Temporarily run the high-pressure pump (two to three seconds) to check the rotation direction.If the pump
rotates in wrong direction, switch two phases from U, V and W.
8. Make sure the high-pressure pump normally operates, and
high-pressure discharge is made normal.
9. Check the coolant supplied into the clean tank for any
overflow or low level to cause an alarm.
10. Check the system for any abnormal noise.
Check the coolant for unstable flow.
11. If there is air lock on the high-pressure discharge tubing,
the pump may not operate normally.
Caution: The needle of the discharge pressure gauge shall steadily move. If the needle jerks or trembles,
there is a large volume of air in the coolant. (Check the coolant supply system for normal operation.)
Chapter 8 Pressure Setting and Operation of Pressure Control Valve
The pressure control valve is a safety valve to prevent pressure exceeding the standard value on the HPC
system. The pressure setting of PFMF 000-00 shall not exceed (Refer to Table 1) in any case.
How to adjust the pressure setting on the pressure control valve:
1. Make sure that the power to the HPC system and "M" code on the machine are kept OFF.
2. Remove the hose tubing from the high-pressure discharge
tubing, and insert the orifice for measuring pressure
supplied together with the HPC system in the discharge
tubing. (Refer to the figure on the right.)
3. Loosen the locking nut.
U V W
U V W
Discharge
port
Orifice
Adapter
Hi Pressure
Hose
