Profoto Air USB User manual

Forotherlanguagesvisit:
www.profoto.com/support
User guide
AirUSB

Air USB
2
www.profoto.com

Air USB
3
www.profoto.com
Congratulations on your new
Profoto product!
Regardless ifyou chose a new flash or a new light-shaping tool,know
thatalmosthalfacentury’sworthofexperiencewasputintoitsmaking.
If the years have taught us one thing, it is to never neglect a single
detail. We only put our name on a product in which we have the
fullest confidence. Before shipping, every one of our products pass
an extensive and strict testing program. Unless it complies with the
specified performance,qualityand safety,it is a no-go.
Asaresult,weareconfidentthatyournewProfotoproductwillstaywith
youforyears and help you growas a photographer.
But getting the product is only the beginning of that journey. Using
it for light shaping is the real adventure. That is why we take pride in
providing you with such a wide assortment of light-shaping tools,
allowingyou to shape the light in anyway you can imagine.
The almost infinite possibilities might seem bewildering at first, but
we’re certain you will soon get the hang ofit.
I encourageyou to sign up for ournewsletteror visit Profoto stories,
www.profoto.com/profoto-stories,to learn more about shaping
light from photographers who are sharing theirstories about how
Profoto Light ShapingTools help them create outstanding images.
EnjoyyourProfoto product!
ConnyDufgran,founder

Air USB
4
www.profoto.com
General safety instructions
SAFETY PRECAUTIONS!
Do not operate the equipment before studying the instruction manual and the accompanying safety
information. Make sure that Profoto Safety Instructions always accompany the equipment! Profoto
products are intended for professional use! Generators,lamp heads and accessories are intendedfor
indoorphotographic useonly.Do notplaceoruse the equipmentwhereit can be exposedtomoisture,
extremeelectromagneticfields,orin areaswithflammable gasesordust!Donotexposetheequipment
to dripping or splashing. Do not place any objects filled with liquids, such as vases, on or near the
equipment. Do not expose the equipment to rapid temperature changes in humid conditions as this
could lead to condensation water in the unit.Do not connect this equipment to flash equipment from
otherbrands.Donot useflash headswithout suppliedprotectiveglass coversorprotectivegrids.Glass
coversmustbe changediftheyhavebecomevisiblydamaged tosuch anextentthattheireffectiveness
is impaired,for example by cracks or deep scratches.Lamps must be changed if they are damaged
or thermally deformed. When placing a lamp into the holder ensure not to touch the bulb with bare
hands.Equipment must onlybe serviced,modified or repaired by authorized and competent service
personnel! Warning - The terminals marked with the flash symbol are hazardous when live.
WARNING – Electrical Shock – High Voltage!
Mainspoweredgeneratorsshallalwaysbe connectedtoamains socketoutletwithaprotectiveearthing
connection!Onlyuse Profoto extensioncables! Do notopen ordisassemblegeneratorsorlamp heads!
Equipmentoperateswith highvoltage.Generatorcapacitors areelectricallychargedfora considerable
length of time after being turned off. Do not touch modeling lamps or flash tubes when mounting an
umbrella metal shaft in its reflector hole.Disconnect the lamp head cable between the generator and
lamphead whenchangingthe modelinglamporflash tube!The mainsplugorappliancecouplerisused
as disconnect device.The disconnect device shall remain readily operable.Batteries (battery pack or
batteries installed) shall not be exposed to excessive heat such as direct sunlight,fire,or the like.
Caution – Burn Hazard – Hot Parts!
Donot touchhotpartswithbarefingers!Modelinglamps,flashtubesandcertainmetalpartsemitstrong
heat when used! Do not point modeling lamps orflash tubes too close to people.All lamps may on rare
occasionsexplodeand throwout hot particles!Makesurethattheratedvoltage forthe modeling lamp
corresponds with the technical data in the user guide regarding the power supply!
NOTICE – Equipment Overheating Risk
Removetransportcapfromlampheadbeforeuse! Donot obstructventilationbyplacing filters,diffusing materials,
etc.overinletsandoutlets oftheequipmentventilationordirectlyoverglass covers,modeling lampsorflashtubes!
Note about RF!
This equipment makes use of the radio spectrum and emits radio frequency energy. Proper care
should be taken when the device is integrated in systems.Make sure that all specifications within this
documentarefollowed,especiallythose concerningoperatingtemperatureandsupplyvoltagerange.
Make sure the device is operated according to local regulations.The frequency spectrum this device
is using is shared with otherusers.Interference cannot be ruled out.
Final Disposal
Equipment contains electrical and electronic components that could be harmful to the environment.
Equipment may be returned to Profoto distributors free of charge for recycling according to WEEE.
Followlocallegal requirementsforseparatedisposalofwaste,forinstanceWEEEdirectiveforelectrical
and electronic equipment on the European market,when product life has ended!

Air USB
5
www.profoto.com
Table of Contents
General safety instructions.............................................................................................4
About Profoto Air USB......................................................................................................6
About Profoto Studio 3....................................................................................................6
General notes on wireless operation with Profoto Air............................................ 7
Technical data.....................................................................................................................8
Profoto Air USB.................................................................................................8
Regulatory information ....................................................................................................9

Air USB
6
www.profoto.com
About Profoto Air USB
Control the shoot wirelessly from your laptop! The Profoto Air USB
dongleis allyouneedtotakewirelesscontrolofyourProfotoAirflashes
from yourMac or PC.Profoto AirUSB is the perfect match forProfoto
Studio 3.
• Plugs into anyMAC orPC with a USB“Type A”connection.
• Provides wireless operation with the latest versions of Profoto
Studio 3.
• Open frequency band (2.4 GHz),approved for worldwide use.
• Operating range of up to 100 m / 330ft.
• Small and easyto use.
About Profoto Studio 3
Profoto Studio 3 is a simpleyet powerful software tool that allowsyou
to control your Profoto lighting equipment directly from the desktop
of your computer. Go to www.profoto.com to read more about the
features and find out which Profoto flashes that are supported. Here
you can also download the latest versions for MAC and PC free of
charge.

Air USB
7
www.profoto.com
General notes on wireless operation with
Profoto Air
TheProfotoAirUSBchannels[1-8]useeightspecificfrequenciesinthe
2.4GHzbandandhavean operatingrangeofup to100meters(330ft).
Thefrequenciesareevenlydistributedovertheentirefrequencyband.
Since each channel uses a different radio frequency, it maximizes the
possibility to find a channel not interfered by other photographers
using ProfotoAir,WLAN/Bluetooth devices orotherradio equipment
operating on the 2.4 GHz frequency band. To ensure best wireless
performance follow these simple guidelines:
• Keep cables and cords away from antennas (The antenna is built
into the Profoto AirUSB dongle.Use the supplied extension cable
to ensure afree dongle position).
• Make sure there is at least 1 meter (3.3 feet) distance between the
closest flash and theAir USB.
• Maintain line ofsight between the ProfotoAir USB and theflashes
wheneverpossible.
• When hiding the flash from view,try to not hide it behind oragainst
metal orwater-filled objects as this will affect the radio range.

Air USB
8
www.profoto.com
Technical data
ProfotoAirUSB
Specifications
Frequencyband 2.4 GHz
Separate radio channels 8
Range Up to 100 m (330 ft)
Antenna type Integrated
Computerconnection USB 2.0Type Aplug
Measurements
Dimensions 70 x 20 x 22 mm (2.7 x 0.8 x 0.8 in)
Weight 20 g (0.7 oz)
Alldataareto beconsideredasnominal andProfotoreservestheright
make changeswithout further notice.

Air USB
9
www.profoto.com
Regulatory information
World-wideUsageofRadioSpectrum
TheProfotoAirUSB operatesonthelicense-free2.4GHzISM bandfor
SRD (Short Range Devices). This band may be used in most parts of
the world.Regional restrictions mayapply.
Note: Refer to national regulations for the region where the Profoto Air USB shall be operated and make sure
that they are followed.
UnitesStatesandCanada
F.C.C.andindustryCanada
Compliance Statement (Part 15.19) This device complies with Part 15
of FCC rules and RSS-210 of IndustryCanada.Operation is subject to
the following two conditions:
1. this device maynot cause harmful interference and,
2. this device must accept any interference received, including
interference that maycause undesired operation.
Warning(Part15.21)
Changesormodifications not expresslyapprovedbythepartyresponsibleforcompliance couldvoidthe user’s
authority to operate the equipment.
Ce dispositif est conforme aux normes RSS-210 d’Industrie Canada.
L’utilisation de ce dispositif est autorisée seulement aux conditions
suivantes :
1. il ne doit pas produire de brouillage et
2. l’utilisateur du dispositif doit être prêt à accepter tout brouillage
radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
Theterm‘IC’beforethecertification/registrationnumberonlysignifies
that the Industry Canada technical specifications were met.
Les lettres ‘IC’ n’ont aucune autre signification ni aucun autre but
que d’identifier ce qui suit comme le numéro de certification/
d’enregistrement d’Industrie Canada.

Air USB
10
www.profoto.com
ProfotoAB
Transmitter/ Receiver
MODEL: ProfotoAir USB 2.4 GHz
Type: PCA5105-0000
FCC ID:W4G-RMI
IC: 8167A-RMI
Product ofSweden
Japan
Themodule hasbeengrantedmodularapprovalforsaleandoperation
inJapan.
特定無線設備の種類
Classification ofspecified radio equipment:
Article 2,Clause 1,Item 19
2.4 GHzWide Band LowPowerData Communication
上記のとおり、電波法第38条の 24第1項の規定に基づく認証を行っ
たものであることを証する。
This is to certify that the above-mentioned certification bytype has
been granted in accordance with the provisions ofArticle 38-24,
Paragraph 1 of the Radio Law.
R 202WW08109202
R 202WW08109203
R 202WW08109204
Taiwan
The device has been approved by NCC
注意! 依據低功率電波輻射性電機管理辦法 第十二條經型式認證合格之低
功率射頻電機,非經許可,公司、商號或使用者均 不得擅自變更頻率、加大
功率或變更原設計之特性及功能。
第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發
現有干 擾現象時,應立即停用,並改善至無干擾時方得繼續使用。前項合
法通信,指依 電信規定作業之無線電信。低功率射頻電機須忍受合法通
信或工業、科學及醫療 用電波輻射性電機設備之干擾。

Air USB
11
www.profoto.com
