Progres Maestro Agronic 4000 User manual

• GPRS modem with cables, connectors and
aluminium for fastening
• For the box: 2 self-tapping screws
• For the antenna connector: 1 tooth lock
washer and 1 nut
• For the aluminium on the motherboard: 2
adhesive clips for the data cable
• GPRS antenna
“Maestro” GPRS/SMS modem
option installation for box model
Agrónic 4000
ASSEMBLY IN BOX FORMAT
Disconnect the controller’s
power supply.
1Remove the 4 screws. 2
Make a hole measuring 6.5
mm in the upper part, as shown in
the image.
Place the antenna connector in
the hole that was made. Position the
tooth-lock washer inside the box.
6
Li the keyboard.
3
Place the modem inside
using the 2 SHR screws that were
provided.
5
4
Tooth-lock
washer Nut
2 SHR screws
2 adhesive clips
GPRS antenna
GPRS modem
Upper part
ITEMS PROVIDED
Manual - Agrónic 4000 · 1

2· Manual - Agrónic 4000
And place the nut on the
outside of the box as shown by the
arrow.
Aix the 2 adhesive clips to the
aluminium on the motherboard.
The antenna should be installed
at an elevated point so it has the
best coverage possible or close to a
window. Do not leave the antenna
cable gathered; extend it fully.
7
10
13
Connect the power cable to
the black H6 cable connector on the
relay board.
Connect the data cable to the
series 1 RS-232 port on the board
and fasten the cable using the clips.
In models with more than 32 outputs, the H6 connector on the relay board is
occupied by the extension cable that runs to the secondary box. In this case,
an adapter is provided to connect the 2 power cables.
8
11
NOTE
To extract the SIM card, press
the yellow button.
Close the controller and
re-insert the 4 screws that were
removed in step 2.
9
12
It is important to connect the antenna cable before powering up the controller and to leave the antenna cable extended to
avoid damaging the modem.

• GPRS modem with cables and compression gland
• To fasten the modem: 2 M3x8 screws, 2 plastic
washers, 2 tooth-lock washers and 2 nuts
• GPRS antenna
“Maestro” GPRS/SMS modem
option installation for built-in model
Agrónic 4000
ASSEMBLY FOR BUILT-IN FORMAT
GPRS antenna
GPRS modem
2 M3 nuts2 tooth-lock
washers
2 plastic
washers
2 M3x8 screws
Manual - Agrónic 4000 · 3
ITEMS PROVIDED
Disconnect the controller’s
power supply.
1Remove the 6 lateral and 2
central screws.
2Separate the keyboard from
the box.
3
In the event that the box did
not come pre-cut, make the 3 holes
shown in the image below.
4
Side to be mechanised
31 mm
45 mm
86 mm
Diameter
3.5 mm
Diameter
22.5 mm
65 mm
35 mm
Place the modem in position
and secure it using the fasteners in
the following order:
6
1 2 3
If you have an adapted box,
break through the hole that has
been cut.
5

R-2323
Polígon Industrial, C/ de la Coma, 2 | 25243 El Palau d’Anglesola | Lleida | España
Tel. [phone] | [email protected] | www.progres.es
Sistemes Electrònics Progrés, S.A.
Insert the cables into the hole
and tighten the compression gland
from both ends.
7Connect the power cable to
the black H6 cable connector on the
relay board or analog input/output
board if you have this option.
8Connect the data cable to
the series 1 RS-232 port on the
motherboard.
9
In models with more than 32 outputs, the cable connector powering the modem will be connected to one of the relay
extension boards.
NOTE
Close the controller and
re-insert the 6 lateral and 2 central
screws that were removed in step
2.
10 It is important to connect the
antenna cable before powering
up the controller and to leave the
antenna cable extended to avoid
damaging the modem.
The antenna should be installed
at an elevated point so it has the
best coverage possible or close to a
window. Do not leave the antenna
cable gathered; extend it fully.
11
