iiNet TGIINet-1 User manual

Technicolor modem TGIINet-1
Quick Setup Guide
i
i
n
e
t
.
n
e
t
.
a
u
/
n
b
n
i
i
n
e
t
.
n
e
t
.
a
u
/
n
b
n
i
i
n
e
t
.
n
e
t
.
a
u
/
n
b
n
i
i
n
e
t
.
n
e
t
.
a
u
/
n
b
n

This guide will tell you everything you need
to know about setting up your home network
including internet, WiFi and Netphone (VoIP).
Welcome

Welcome
What are you setting up today?
You’ll need to plug in a little differently depending
on which type of internet service you have.
ADSL or VDSL Broadband
See page 6
Naked broadband
See page 10
NBN Fibre
See page 12
Netphone
See page 20
Need some
WiFi tips?
To customise your default WiFi
network name and password, turn
to page 16.
For tips on how to connect to the
WiFi, see page 22.

4
Get to know your modem’s ports
DSL
For use with
xDSL or Naked
broadband only
Phone
Plug in a handset
to use with a
Netphone service
or Home Phone
PSTN
For use with Home
Phone services
(xDSL only)
USB 1 and 2
Plug in a USB drive
to share files via
home network
or a 3G modem
to route mobile
broadband as WiFi
Ethernet 1-4
Connect
computers or
laptops with an
Ethernet cable
WAN
For use with NBN
Fibre or other
fibre services
Power port
Power button
Reset button
Hold for 5-8
seconds to factory
reset

5
Get to know your modem’s lights
Status
Orange - booting up
Red - Offline
Green - Online
Flashing orange -
Upgrade in progress
Wireless
Green - WiFi is on
Flashing - WiFi booting
up/WiFi activity
WPS
Flashing orange - WPS
connection in progress
Green - Connection
successful
Red - Connection failed
Phone
Green - Netphone enabled
Flashing - Call in progress
Wireless button
Turn WiFi broadcasting
on/off
WAN
Green - DSL or WAN port
connection
Flashing - Connection
activity
Internet
Green - Internet
connection
Red - Connection failed
Flashing - Connection
activity
Ethernet
Green - Ethernet
connection
Flashing - Connection
activity

6
Phone socket
Ethernet Cable
Power Button
Power Cable
Power Socket
Plugging in for ADSL and VDSL
ADSL
LINE
PHONE
Line Filter
You only need to use the line filter if you have ADSL and
you need to plug the modem and a handset for Home
Phone into the same wall socket
Phone Cable
(optional)
Phone Cable
Line Filter
Cable
Phone Handset
Handset for
Netphone
(optional)
Plug into your
computer’s
Ethernet Port
(optional)

7
1. Take the grey-tipped phone cable and plug it into the grey DSL port on the back of your modem.
2. The other end of the cable may be plugged directly into the phone socket on the wall OR into the ADSL port
on the line filter if you need to share the phone socket with a Home Phone.
3. Plug the black power supply cable into the modem’s Power port and an available power outlet. Turn the
modem on using the Power button.
4. You can connect WiFi enabled computers, tablets or smartphones to your modem’s WiFi network using the
details on the Default Wireless Settings card found in the box.
5. Alternatively, use the yellow-tipped Ethernet cable to connect a computer’s Ethernet port to any of the
yellow LAN ports.
6. Let your modem rest for 10-15 minutes. In most cases it will retrieve your settings and get online
automatically. Try viewing a website – if it works, you can skip to page 16.
If you were unable to view a website, ADSL users should follow the advice on the next page.
VDSL users (typically former TransACT customers) should see page 9.
Plugging in for ADSL and VDSL

8
Manual settings for ADSL or Naked broadband
1. On your connected computer or WiFi device, open your web
browser and go to http://10.1.1.1
2. Log in with the default username and password, which are
both admin.
3. The Setup Wizard should run; if not, simply click Setup Wizard
on the dashboard. Enter the following details:
WAN Interfaces: ADSL
WAN Type: PPP over Ethernet
Username: Your broadband username
(include any “@domain.com.au”)
Password: Your broadband password (case sensitive)
VPI Number: 8
VCI Number: 35
4. If you have iiNet Netphone (VoIP), enter your VoIP details on
the next page, otherwise click “I don’t have VoIP”. You can set
up VoIP from other providers later with the steps on page 20.
5. Click Next, and then turn to page 16 to continue with the WiFi
setup.
3
4

9
Manual settings for VDSL broadband
1. On your connected computer or WiFi device, open your web
browser and go to http://10.1.1.1
2. Log in with the default username and password, which are
both admin.
3. The Setup Wizard should run; if not, simply click Setup Wizard
on the dashboard. Enter the following details:
WAN Interfaces: VDSL
WAN Type: PPP over Ethernet
Username: Your broadband username
(include any “@domain.com.au”)
Password: Your broadband password (case sensitive)
4. If you have iiNet Netphone (VoIP), enter your VoIP details on
the next page, otherwise click “I don’t have VoIP”. You can set
up VoIP from other providers later with the steps on page 20.
5. Click Next, and then turn to page 16 to continue with the WiFi
setup.
3
4

10
Plugging in for Naked broadband
Power Cable
Plug into your
computer’s
Ethernet Port
(optional)
Phone socket
Ethernet Cable
Power Button
Phone Cable
Power Socket
Handset for
Netphone
(optional)

11
Plugging in for Naked broadband
1. Take the grey-tipped phone cable and plug it into the grey DSL port on the back of your modem.
2. Plug the other end of the cable directly into the phone socket on the wall. Do not use the line filter.
3. Plug the black power supply cable into the modem’s Power port and an available power outlet. Turn the
modem on using the Power button.
4. You can connect WiFi enabled computers, tablets or smartphones to your modem’s WiFi network using the
details on the Default Wireless Settings card found in the box.
5. Alternatively, use the yellow-tipped Ethernet cable to connect a computer’s Ethernet port to any of the
yellow LAN ports.
6. Let your modem rest for 10-15 minutes. It should retrieve your settings and get online automatically. Try
viewing a website – if it works, you can skip to page 16.
If you were unable to view a website, don’t panic. Just follow the steps on page 8.

12
Plugging in for NBN or Fibre
Smart wiring
Some newer homes have internal smart wiring, allowing your NBN Connection Box to be plugged into a
patch panel in one room, and your modem to be plugged into the corresponding port on a patch panel
in another room.
NBN Connection
Box / Fibre Unit
Ethernet Cable
Power Button
Power Cable
Ethernet Cable
Power Socket
Plug into your
computer’s
Ethernet Port
(optional)
Handset for
Netphone
(optional)

13
Plugging in for NBN or Fibre
1. Take the red-tipped Ethernet cable and plug it into the red WAN port on the back of your modem.
2. Plug the other end of the cable directly into the active UNI-D port on your NBN Connection Box or fibre
unit. This is typically UNI-D1. If this doesn’t work and you don’t know which one to use, please contact us
using the details on the back cover of this guide.
3. Plug the black power supply cable into the modem’s Power port and an available power outlet. Turn the
modem on using the Power button.
4. You can connect WiFi enabled computers, tablets or smartphones to your modem’s WiFi network using the
details on the Default Wireless Settings card found in the box.
5. Alternatively, use the yellow-tipped Ethernet cable to connect a computer’s Ethernet port to any of the
yellow LAN ports.
6. Let your modem rest for 5-10 minutes. It should retrieve your settings and get online automatically. Try
viewing a website – if it works, you can skip to page 16.
If you were unable to view a website, simply follow the steps on the next page.

14
Manual settings for NBN or Fibre
1. On your connected computer or WiFi device, open your web
browser and go to http://10.1.1.1
2. Log in with the default username and password, which are
both admin.
3. The Setup Wizard should run; if not, simply click Setup Wizard
on the dashboard. Enter the following details:
WAN Interfaces: Ethernet
WAN Type: Dynamic IP Address*
*Note: South Brisbane, Places Victoria and some OptiComm
Fibre services will need WAN Type PPP over Ethernet instead.
You will also need to enter your broadband username and
password.
4. If you have iiNet Netphone (VoIP), enter your VoIP details on
the next page, otherwise click “I don’t have VoIP”. You can set
up VoIP from other providers later with the steps on page
20.
5. Click Next, and then turn to page 16 to continue with the WiFi
setup.
3
4

15

16
WiFi settings
Your modem can broadcast your internet as a wireless signal for your WiFi enabled computers, tablets and
smartphones to connect to.
1. Your modem already has a default WiFi network set up on it. You’ll find the network name and password on
the base of your modem, as well as your Default Wireless Settings card.
2. We recommend leaving the default WiFi settings unchanged - after connecting once, your device will
remember the settings for you. Connection advice can be found on page 22.
3. If you want, you can change the WiFi settings during steps 3 and 4 of the Setup Wizard, or by clicking the
Wireless option on the http://10.1.1.1 dashboard.
4. Wireless 2.4GHz (WiFi) must be turned ON to broadcast WiFi. If you turn SSID Broadcast off, your network
name will not be visible to WiFi devices and you’ll have to enter it manually when connecting a device.

17
WiFi settings
IMPORTANT
It’s good to love your neighbour, but not enough to give them free WiFi! You should always
set a password for your WiFi network and only share it with people you trust.
5. Change your SSID Broadcast name as desired. This is the name of your WiFi network that you’ll need to
connect to.
6. Security Key Type should be set to WPA+WPA2 PSK. You can then change your Security Key (WiFi
password) as desired.

18
Router Security settings
Step 5 of the Setup Wizard allows you to change the username
and password used to log in on the http://10.1.1.1 page. This can be
handy if you have tenants or meddling teens and you don’t want
them to change your modem settings.
Default username: admin
Default password: admin
To keep the defaults, simply retype “admin” in all the text boxes.
If you do set a custom username and/or password, you should
write it down and keep it somewhere safe.
TIP
If you ever forget your custom login details, you
can factory reset the modem to return it to the
default “admin” settings. However, you will also
lose all other custom settings, so you’ll need to set
up your modem again.

19
All done!
Your modem should now be online, allowing you to access websites
and all the other joys of the internet.
If you have a Netphone (VoIP) service, please see page 20 for setup
instructions.
If you can’t view websites or you have any other trouble, please
contact our friendly Support Team using the information on the
back cover of this guide.

20
Setting up VoIP
If you didn’t set up VoIP in the Setup Wizard or you have a third party VoIP provider, please use these instructions.
1. On your connected computer or WiFi device, log in at http://10.1.1.1. The default username and password are
both admin.
2. Click Telephony on the dashboard. On the Global page, underneath SIP Network, click the Edit button to the
right of the existing SIP Network entry. Edit to the following settings:
SIP Domain: Your VoIP provider’s SIP domain*
Primary Registrar: Your VoIP provider’s SIP server*
Primary RegistrarPort: 5060
Primary Proxy: Your VoIP provider’s SIP server*
Primary ProxyPort: 5060
Expire time: 3600
*You’ll find a list of iiNet Group VoIP settings on the next page. If your VoIP provider isn’t listed, please check their
website for their VoIP settings.
