progressive automations FLTCON-3 User manual

FLTCON-3
Data Sheet
Wired Remote (Not Included)
8A Per Channel
Input Voltage
Control Type
Output Voltage
Current
Unit Weight 1.55lbs
Warranty 18 Months
Certifications CE, FCC
Size (L x H x W) 11.3" x 1.8" x 3.8"
Number of Channels 3
Feedback Input Hall Effect Sensor
110VAC (Power Cable Included)
24VDC
Duty Cycle 10% (Max. 2 mins on, 18 mins off)

Dimensions
HS M3
11.3"
0.1"
0.3" 3.8"
1.8"
3.7"
3.7"
0.7"
0.7"
0.7"
0.8"
HS M1 AC
M1 M2
M2 M3
Operational Procedure
Once your table lift is installed it is simple to operate. Just use the wired remote for full up/down motion
control. Use the up button to raise the table lift and use the down button to lower it.
You can preset up to 4 positions by following this simple procedure: Use the up/down buttons on the
remote to find your desired height(s), then press “S” followed by a number 1-4., then wait a few seconds
until the height is displayed again. To move to the set position, hold the number button.
Reset Procedure
If the table lift is not functioning properly or the LED screen displays “RST” or “Er1” - “Er13”, please follow
this reset procedure: Unplug the power cord and lifting columns for 30 seconds. Plug the lifting columns
into the control box ensuring a secure connection then plug the power cord back in and continue to the
next step.
If the table lift is raised at all, press and hold the down button on the remote until the lift is fully retracted.
Press and hold the down button for 10 seconds until the LED display reads “ASr”. If you are using a
spare remote without an LED, hold the down button for 10 seconds.
Once “ASr” is displayed on the remote, press and hold the down button until the lifting columns lower,
slightly rise, then stop. Release the button and the table lift is now ready to use.
If the error message persists after the reset procedure, contact us at 1-800-676-6123 or by email at
[email protected].
*If the height difference between the legs exceeds 1.5 inches, stop the reset procedure & contact us.
*lf the handset displays ‘HOT’, let the unit cool down for 20 minutes before starting the reset procedure
again.
