Proheat M Series Reference manual

AIR PRESSURE SETTING
RECOMMENDATION
(Diaphragm Compressor Models) for
Sustained High Altitude Operations.
Requirements
Test Procedure
a) Basic Hand Tools.
b) Proheat Remote Start Switch (P/N PK0091).
c) Proheat Digital Manometer Test Gauge (P/N PK0036).
d) Or Proheat Analog Air Pressure Test Gauge (P/N PK0067).
Sustained operation and servicing of the M-Series compressor above
4,000 ft (1219 m) requires the compressor setting be checked and/or
adjusted for proper combustion.
a) Disconnect all harnesses at the PCM.
b) Disconnect the fuel supply line.
c) Loosen and back out the burner head mounting (2) bolts five to
six turns allowing enough room to rotate the burner head 15°
counter-clockwise and remove.
HOUSING SCREWS
TORQUE = 75 IN-LBS
AIR FILTER
POWER
SWITCH INPUT
FUEL INLET
TEMP SENSOR
MOUNTING BOLTS (2)
TORQUE = 100 IN-LBS
Figure A. Burner Head & Blower Housing Removal.
Shock hazard due to high secondary
coil voltage.
WARNING
Copy Part# SB0063, Rev. A, 08/2014 Page 1 of 4
© 2011 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Tel: [phone] Web: www.proheat.com
SERVICE BULLETIN
Before adjusting air pressure, ensure
the Air Compressor filter and Fuel
Nozzle are clean. See service manual
at: www.proheat.com
NOTICE
To avoid the risk of shock and to
ensure that the PROHEAT does not
start, disconnect the Ignition
Module and Fuel Solenoid harness’s
at the PCM.
WARNING

DIAPHRAGM
COMPRESSOR
DIGITAL
MANOMETER
(P/N PK0036)
FLAME
SHIELD
IGNITION
ELECTRODE
ASSEMBLY
DECREASE
PRESSURE
PRESSURE ADJUSTMENT SCREW
PRESSURE
ADJUSTMENT
SCREW
INCREASE
PRESSURE
AIR PRESSURE
MEASURING PORT
d) Remove Ignition Electrode Assembly. Use a flat head screwdriver
to gently pry the electrode assembly out.
e) Remove the Flame Shield. (Rotate to match the mounting square.)
f) Disconnect the Fuel Shut-off Valve and Ignition Module connectors
at the PCM. This ensures that fuel will not spray and/or light
during testing.
g) Remove the plug to the air pressure measurement port.
h) Thread in the Pressure Gauge and torque to 25 in-lbs ±3 in-lbs
(2.8 Nm ±0.3 Nm) as shown in figure B.
i) Connect ONLY the Power Harness and Remote Switch to the PCM.
Figure B. Air Pressure Test. Diaphragm Compressor Model.
j) Switch the PROHEAT on and observe the air pressure after one
minute, and compare to figure C, D or E on page 3 and page 4:
If Air Pressure is outside the recommended setting for your location
please ensure the fuel nozzle and air compressor filter are clean,
then check air pressure again.
k) Adjust the air pressure if necessary by turning the screw as
shown in figure B.
If the pressure cannot be set to the correct setting, rebuild kits
are available. See www.proheat.com for the latest parts manual
SL9167 for more information.
Copy Part# SB0063, Rev. A, 08/2014 Page 2 of 4
© 2011 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Tel: [phone] Web: www.proheat.com
SERVICE BULLETIN
Leaving the Temperature Sensor
disconnected ensures that the burner
head will only run in Cool Down (Purge)
mode for three minutes.
NOTICE
If using PK0067, Analog air pressure
gauge, Calibrate gauge before each
use refer to: www.proheat.com/PDFs/
990614.pdf
NOTICE
Connect power and switch only. DO
NOT connect the temperature sensor.
WARNING

Figure C. M50 Compressor Pressure Altitude Setpoint.
Figure D. M80 Compressor Pressure Altitude Setpoint.
0 1000
(305)
2000
(610)
3000
(914)
4000
(1219)
5000
(1524)
6000
(1829)
7000
(2134)
8000
(2438)
9000
(2743)
10000
(3048)
11000
(3353)
12000
(3658)
13000
(3962)
14000
(4267)
15000
(4572)
Air Pressure PSI (kPa)
Altitude Feet (m)
3.5
(24.1)
4.0
(27.6)
4.5
(31.0)
5.0
(34.5)
5.5
(37.9)
6.0
(41.4)
M50 Compressor Pressure Altitude SetpointM50 Compressor Pressure Altitude Setpoint
ACCEPTABLE RANGEACCEPTABLE RANGE
1.7
(11.7)
1.9
(13.1)
2.1
(14.5)
2.3
(15.9)
2.5
(17.2)
2.7
(18.6)
2.9
(20.0)
01000
(305)
2000
(610)
4000
(1219)
3000
(914)
5000
(1524)
6000
(1829)
7000
(2134)
8000
(2438)
9000
(2743)
10000
(3048)
11000
(3353)
12000
(3658)
ACCEPTABLE RANGEACCEPTABLE RANGE
M80 Compressor Pressure Altitude SetpointM80 Compressor Pressure Altitude Setpoint
Air Pressure PSI (kPa)
Altitude Feet (m)
NOTE: Operation of the M80
above 11,500 feet (3505 m)
is not recommended.
NOTE: Operation of the M80
above 11,500 feet (3505 m)
is not recommended.
Copy Part# SB0063, Rev. A, 08/2014 Page 3 of 4
© 2011 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Tel: [phone] Web: www.proheat.com
SERVICE BULLETIN

l) Turn heater off. Wait until cool down (purge) mode is complete
(approximately 3 minutes).
m) Remove test gauge. Lubricate air measurement port plug O-ring
with diesel fuel and reinstall plug into fuel block. Torque to 25
in-lbs ±3 in-lbs (2.8 Nm ±0.3 Nm). Re-install the Flame Shield,
the Ignition Electrode Assembly and Burner Head onto the Heat
Exchanger. Torque mounting bolts to 100 in-lbs (11.6 Nm ± 1.1 Nm).
n) Connect the Power, Dual Mode Temperature Sensor and Coolant
Pump electrical connections to the heater Burner Head and
reconnect the fuel line.
o) Activate the heater with the remote switch and observe operation
for at least one complete cycle. The heater should run smoothly
with no smoke although there may be some hesitation initially
due to air in the fuel line.
p) Remove the remote switch and re-connect the control
connection.
Figure E. M105/125 Compressor Pressure Altitude Setpoint.
2.0
(13.8)
2.2
(15.2)
2.4
(16.5)
2.6
(17.9)
2.8
(19.3)
3.0
(20.7)
3.2
(22.1)
3.4
(23.4)
3.6
(24.8)
3.8
(26.2)
0 1000
(305)
2000
(610)
3000
(914)
4000
(1219)
5000
(1524)
6000
(1829)
7000
(2134)
8000
(2438)
9000
(2743)
10000
(3048)
11000
(3353)
12000
(3658)
13000
(3962)
14000
(4267)
15000
(4572)
Altitude Feet (m)
Air Pressure PSI (kPa)
ACCEPTABLE RANGEACCEPTABLE RANGE
M105/125 Compressor Pressure Altitude SetpointM105/125 Compressor Pressure Altitude Setpoint
Copy Part# SB0063, Rev. A, 08/2014 Page 4 of 4
© 2011 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Tel: [phone] Web: www.proheat.com
SERVICE BULLETIN
All plugs/harnesses must be rein-
stalled into the Proheat Control
Module (PCM) before heater goes
back into service.
NOTICE
