IMPRESTM
Adaptive
Single-Unit Chargers
User Guide
EN LAS BP FRC ID DE
ES
FR IT PR NL RU
简
frontcover.fm Page 1 Tuesday, June 16, 2009 11:49 AM

1
English
TABLE OF CONTENTS
Operational Safety Guidelines ................................. 4
Operating Instructions.............................................. 5
Charging Procedure......................................................5
Initialization .............................................................. 7
Automatic Reconditioning ........................................ 7
Manually Terminating the Reconditioning Process.......8
Manually Initiating the Reconditioning Process ............8
Troubleshooting ....................................................... 9
Service................................................................... 10
Motorola Authorized Transformers ........................ 10
Motorola Authorized Batteries ............................... 11
IMPRES Feature / Benefit Description .................. 11
87H01_AC_IMPRES_SUC.book Page 1 Monday, March 28, 2011 4:47 PM

3
English
IMPORTANT
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This document contains important safety and operating
instructions. Please read these instructions carefully and save
them for future reference.
Before using the battery charger, read all the instructions and
cautionary markings on (1) the charger, (2) the battery, and (3) the
radio using the battery.
1. To reduce risk of injury, charge only the
rechargeable Motorola authorized batteries
listed in Table 4 on page 11. Other batteries
may explode, causing personal injury and
damage.
2. Use of accessories not recommended by Motorola may result
in risk of fire, electric shock, or injury.
3. To reduce risk of damage to the electric plug and cord, pull by
the plug rather than the cord when disconnecting the charger.
4. An extension cord should not be used unless absolutely
necessary. Use of an improper extension cord could result in
risk of fire and electric shock. If an extension cord must be
used, make sure that the cord size is 18 AWG for lengths of
up to 100 feet (30.48 m), and 16 AWG for lengths up to
150 feet (45.72 m).
5. To reduce risk of fire, electric shock, or injury, do not operate
the charger if it has been broken or damaged in any way. Take
it to a qualified Motorola service representative.
!
W A R N I N G
!
87H01_AC_IMPRES_SUC.book Page 3 Monday, March 28, 2011 4:47 PM

4
English
WARNINGS (continued)
6. Do not disassemble the charger – it is not
repairable and replacement parts are not
available. Disassembly of the charger may
result in risk of electric shock or fire.
7. To reduce risk of electric shock, unplug the
charger from the AC outlet before attempting
any maintenance or cleaning.
8. This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
OPERATIONAL SAFETY GUIDELINES
• Turn the radio off when charging the battery.
• This equipment is not suitable for outdoor use. Use only in dry
locations / conditions.
• Connect equipment only to an appropriately fused and wired
supply of the correct voltage (as specified on the product).
• Disconnect from line voltage by removing the power plug from
the outlet.
• The socket outlet to which this equipment is connected should
be close and easily accessible.
• Maximum ambient temperature around the charger must not
exceed 40 °C (104 °F).
• Make sure the cord is located where it will not be stepped on,
tripped over, or subjected to water, damage, or stress.
• Output power from the power supply unit must not exceed the
ratings stated on the product label located on the bottom of the
charger.
!
W A R N I N G
!
87H01_AC_IMPRES_SUC.book Page 4 Monday, March 28, 2011 4:47 PM

5
English
OPERATING INSTRUCTIONS
The IMPRES Adaptive Single-Unit Charger System is a fully
automated battery care system. All a user needs to do is follow
these simple steps:
1. Place the radio / IMPRES battery into the charger.
2. Remove the radio / IMPRES battery when it's fully charged
(LED turns steady GREEN).
The charger’s pocket accommodates either a radio with an
IMPRES battery attached or an IMPRES battery alone. Prior to
charging a radio with an IMPRES battery, turn the radio off.
Batteries charge best at room temperature.
Charging Procedure
1. Plug the charger end of the power supply cord into the power
receptacle located at the back of the charger.
2. Plug the wall receptacle end of the power supply cord into the
appropriate AC outlet. A successful power-up sequence is
indicated by a SINGLE GREEN BLINK on the charger
indicator.
3. Insert an IMPRES battery, or a radio with an IMPRES battery
(with the radio turned off), into the charger’s pocket by:
a. Aligning the groove on each side of the battery with the
corresponding raised rail on each side of the charger
pocket.
b. Pressing the battery toward the rear of the pocket.
c. Sliding the battery into the charger pocket, ensuring
complete contact between the charger and battery
contacts.
87H01_AC_IMPRES_SUC.book Page 5 Monday, March 28, 2011 4:47 PM

6
English
4. To remove a radio or IMPRES battery from the charger, use
two hands to remove a radio or battery from the charger
pocket - one hand to hold and support the charger, and the
other hand to remove the radio or battery.
Once the IMPRES battery is properly seated into the pocket, the
charger indicator illuminates, indicating the charger has
recognized the presence of the battery. Refer to the charging
indicators in Table 1.
Table 1. IMPRES Battery Charging Indicators
Charge Indicator Description
Single Blink Green Charger has successfully powered up.
Steady Red Battery is in rapid charge mode.
Blinking Green Battery has completed rapid charge (> 90 %
available capacity). Battery is in Top-Off
charge (Trickle charge).
Steady Green Battery has completed charging and is fully
charged.
Blinking Orange Battery is recognized by charger but is
waiting to charge. (Either the battery voltage
is too low or the battery temperature is too
low or too high to allow charging. When this
condition is corrected, the battery will
automatically begin charging.)
Blinking Red Battery is unchargeable or not making
proper contact.
Steady Orange (This feature applies to IMPRES batteries
only)
Battery is in recondition or initialization
mode. The length of time the charger
remains in this mode depends upon the
state of charge remaining in the battery
when inserted. (Fully charged batteries
require more time to recondition – 8 to 12
hours or more – than fully discharged
batteries.)
87H01_AC_IMPRES_SUC.book Page 6 Monday, March 28, 2011 4:47 PM

7
English
INITIALIZATION
In order for the features of Motorola IMPRES batteries and the
Adaptive Charging System to be fully available, the data contained
in Motorola IMPRES batteries must be initialized by the charger
the first time it is charged. This process is indicated by a STEADY
ORANGE light on the charger indicator (the same as if the battery
were reconditioning). The process is automatic, includes an initial
reconditioning of the battery, and begins charging upon completion
of this process. This process requires time to initialize the battery,
so the battery should be left in the charger for approximately 12
hours to complete the process. Do not remove the battery from the
charger until the STEADY GREEN light is on.
AUTOMATIC RECONDITIONING
The Motorola IMPRES Adaptive Single-Unit Charger, when used
in conjunction with a Motorola IMPRES battery, has the ability to
determine when it is appropriate to recondition the battery
(required to remove memory issues in IMPRES batteries).
When an IMPRES battery is properly inserted into the charger, the
charger determines if it is appropriate to recondition the battery. If
the battery needs reconditioning, the charger automatically
indicates a STEADY ORANGE. This process may take up to 12
hours to complete, depending upon the state of charge and
capacity rating of the battery when it is inserted.
Blinking Red / Green (This feature applies to IMPRES batteries
only)
Battery has completed charging and is fully
charged. Battery continues to be usable, but
may be nearing the end of its rated service
life.
Table 1. IMPRES Battery Charging Indicators (continued)
Charge Indicator Description
87H01_AC_IMPRES_SUC.book Page 7 Monday, March 28, 2011 4:47 PM

8
English
It is important to note, for this process to be effective, the IMPRES
battery must be allowed to complete the recondition / recharge
process. Leave the battery in the charger until the charger
indicates a STEADY GREEN.
At the completion of the recondition cycle, the charger
automatically recharges the IMPRES battery.
Manually Terminating the Reconditioning Process
At any time during the reconditioning process of a Motorola
IMPRES battery (STEADY ORANGE indication), reconditioning
may be terminated by removing and reinserting the battery back
into the charger within 5 seconds. This causes the charger to
terminate the reconditioning process and begin the charging
process. The charger indicator changes to a STEADY RED. The
charger will attempt to recondition the battery at the next battery
insertion.
Manually Initiating the Reconditioning Process
Within 2 – 1/2 minutes of the initial insertion of an IMPRES battery
(STEADY RED indication), remove and reinsert the battery within
5 seconds to manually force reconditioning to occur. The charger
indicator changes from a STEADY RED to a STEADY ORANGE.
This forces the charger to recondition and automatically recharge
the battery. This is a useful feature to have when IMPRES
batteries have been in storage for several months or longer. Two
or three manual recondition cycles may be required to rejuvenate
the batteries, due to long term storage conditions.
87H01_AC_IMPRES_SUC.book Page 8 Monday, March 28, 2011 4:47 PM

9
English
TROUBLESHOOTING
When troubleshooting, always observe the color of the LED.
Table 2. Troubleshooting
Problem What it means... What to do...
No charger
indication 1a. Charger contact is not being made.
1b. • No power to the
charger.
1a. Check that the radio with
battery, or the battery alone,
is inserted correctly.
1b. • Make sure that the power
cord is securely plugged
into the charger and an
appropriate AC outlet,
and that there is power to
the outlet.
Blinking Red
Indication 2a. Charger contact is not being made.
2b. Battery is not
chargeable.
2a. • Remove the battery from
the charger and replace it
back into the charger.
• Verify that the battery is a
Motorola-authorized
battery listed in Tables 4.
Other batteries may not
charge.
• Remove power from the
battery charger and,
using a clean dry cloth,
clean the gold metal
charging contacts of both
the battery and the
charger.
2b. Replace battery.
Blinking
Orange
Indication
3. Battery is waiting
to charge. The
battery
temperature may
be below 5 °C
(41 °F) or above
40°C (104 °F) or
the battery voltage
may be lower than
the predetermined
threshold level for
rapid charging.
3. When this condition is
corrected, the battery will
begin charging
automatically.
87H01_AC_IMPRES_SUC.book Page 9 Monday, March 28, 2011 4:47 PM

10
English
SERVICE
Adaptive Single-Unit Chargers are not repairable. Order
replacement chargers as necessary from your local Motorola
Sales Representative.
MOTOROLA AUTHORIZED TRANSFORMERS
This charger is designed for use in 90 VAC to 264 VAC, 50 / 60 Hz
applications and uses the following Motorola transformers.
Table 3. Compatible Power Supply Transformers
Charger Power
Supply
Nominal Input
Voltage ±10 %
Line
Frequency
Country
Plug
WPLN4243 None – – –
WPLN4232 2571586S13 110 VAC 50 / 60 Hz US / NA
WPLN4233 2571586S06 230 VAC 50 Hz UK
WPLN4234 2571586S07 220 to 240 VAC 50 Hz Euro
WPLN4235 2571586S08 220 to 240 VAC 50 Hz Australia /
NZ
WPLN4236 2571586S11 220 to 240 VAC 50 Hz Argentina
WPLN4245 2564060M01 220 to 240 VAC 50 Hz China
WPLN4247 2571886T01 90 to 264 VAC 50 / 60 Hz Japan
WPLN4249 2571886T01 90 to 264 VAC 50 / 60 Hz Korea
WPLN4253 2571886T01 90 to 264 VAC 50 / 60 Hz US / NA
WPLN4253B 25012006001 90 to 264 VAC 50 / 60 Hz US / NA
WPLN4254 2571886T01 90 to 264 VAC 50 / 60 Hz UK
WPLN4254B 25012006001 90 to 264 VAC 50 / 60 Hz UK
WPLN4255 2571886T01 90 to 264 VAC 50 / 60 Hz Euro
WPLN4255B 25012006001 90 to 264 VAC 50 / 60 Hz Euro
WPLN4256 2571886T01 90 to 264 VAC 50 / 60 Hz Australia /
NZ
WPLN4257 2571886T01 90 to 264 VAC 50 / 60 Hz Argentina
WPLN4281 2571886T01 90 to 264 VAC 50 / 60 Hz Brazil
87H01_AC_IMPRES_SUC.book Page 10 Monday, March 28, 2011 4:47 PM
