Projecta INTELLI-RV User manual

INTELLI-RV
500AMP SHUNT MODULE
P/No. PMSHUNT
INSTALLATION GUIDE
Please read this document very carefully to avoid battery monitor
malfunction or re hazards.
The active shunt must be located in a dry environment.
MOUNTING THE MODULE
Do not use mounting screws with countersunk heads.
WARNING
WARNING:
lThe shunt must always be installed into the negative line.
lThe battery negative terminal may only contain one cable, which is the one going
to the shunt. If there are other cables connected to this terminal as well, this may
produce incorrect display readings.
lAlways connect the battery negative terminal to the ‘B-’ stud of the shunt.
Connecting this terminal to the ‘S-’ stud will produce incorrect display readings.
Always disconnect the battery negative cable rst before installation.
Always connect the battery negative cable last when the installation has been
completed.
More information https://www.caravansplus.com.au

2
INSTRUCTIONS
lBattery temperature sensor is optional and should be
attached to the service battery (B1)
lAssembly sequence of nut, washers and cable lug:
Service Battery
positive (to load)
Run cable to INTELLI-RV system
Keep these cables as short as possible!
Supply cable (included)
Active
shunt Battery negative
1A Fuse
12V Service
Battery
+B1
CONNECTION DIAGRAM FOR DUAL BATTERY SETUP
Nut
Spring washer
Washer
Cable lug
CONNECTION DIAGRAM FOR SINGLE BATTERY SETUP
Service battery positive
(to load)
Run cable to INTELLI-RV system
Keep these cables
as short as possible! Battery negative (system ground)
12V, 24V or 48V
Service battery
Starter battery
+B1
+B2
92mm
89mm
46mm
STATUS
NA
NA
NA
NA
NA
P/No. PMSHUNT
Brown & Watson
International Pty. Ltd.
Knoxfield, Victoria 3180
Australia
+B1
Battery 1
+Battery Sensor
B-
Battery
Negative
S-
Load/Charger
Negative
+B2
Starter Battery
COMM
Connect to
INTELLI-RV
GREEN: OK
RED ON: Over Current >500A
STATUS LED
GREEN: OK
Red ON: Over current >500Amp
Note: Starter battery connection optional as the INTELLI-RV already measures the
starter battery voltage.
NA
More information https://www.caravansplus.com.au

3
SETUP VIA THE APP
SET UP VIA LCD
lPress the ‘Light’ button until the setting code is showing on the date time area which means the
monitor is ready for conguration. The ‘PUMP’ button and ‘LOAD’ button can be used to scroll
through the conguration menu.
1Enter setting menu,
Select “Shunt” option
2Select ”Active ”to
enable BM500 shunt
3 Conrm to complete
setup.
1Press and hold “Pump” and “Load” buttons
2Engineering Screen
displays
3Press and hold “Light” button
4Press “Load” button to scroll to “Module”
5Press “Light” to select
6Press “Load” to scroll to “BM”
Silent/Esc Switch
Pump/Up Switch
Light/Enter/Setting Switch
Load/Down Switch
PUMP LOAD
7Press “Light” to select
8Press “Load” to scroll to “01”
9Press “Light” to select
10 Press “Silent”
until you return to
Engineering Screen
11 Press and hold “Pump” and “Load” buttons
to exit engineering mode
12 Shunt set up complete
PUMP LOAD
SILENT
LIGHT
More information https://www.caravansplus.com.au

4
PM300 + PMSHUNT WIRING DIAGRAM
PMLCDC
(4 Pin Wire):
4.5m PMSWEX-2: 2m extension or
PMSWEX-4: 4m extension
PMTEX-2: 2m extension or
PMTEX-4: 4m extension
PMSHEX-5: 5m extension
STARTER BATT +
SERVICE BATT +
STARTER BATT -
SERVICE BATT -
PMLCDC-SY
PMTS: 0.5m
PMSHC: 7m
PMTS: 4.5m
PV IN
Vmp: 17-50V, 30A
PV IN +
PV IN -
PMWS200 or
PMWS400
4
0.5m
2
PMLCD-BT
Cells+DOD BM COM
DC 12V
Starter
battery
More information https://www.caravansplus.com.au

5
NA
NA
NA
NA
NA
P/No.PMSHUNT 500A Current Shunt
+B1
+B2
COMM
PMBEX-2: 2m
extension or
PMBEX-4: 4m
extension
Remote switch
D+ Point
PMSH-V: 1.5m
Service Battery +
PMWS200: 4m
PMBS: 2.5m
PMWS200: 4m
PMWS200: 4m
PMWS200: 4m
PMBS: 0.5m
PMWS200 or
PMWS400
4
PMWS200 or
PMWS400
4
PMWS200 or
PMWS400
4
PM335
1
PMSHUNT
6
PMWEX-4: 4m extension
PMWEX-4: 4m
extension
PMWEX-4: 4m extension PMWEX-4: 4m extension
0.5m
0.5m
0.5m
0.5m
DC 12V
Service
battery
NA
More information https://www.caravansplus.com.au

6
PM400 + PMSHUNT WIRING DIAGRAM
PMLCDC
(4 Pin Wire):
4.5m PMSWEX-2: 2m extension or
PMSWEX-4: 4m extension
PMSWEX-2: 2m extension or
PMSWEX-4: 4m extension
PMTEX-2: 2m extension or
PMTEX-4: 4m extension
PMSHEX-5: 5m extension
STARTER BATT +
SERVICE BATT +
STARTER BATT -
SERVICE BATT -
PMLCDC-SY
PM4Y: 0.5m
PMSHC: 7m
PM4SW10C: 4.5m
PM4SW10C: 4.5m
PM4SW2Y: 0.5m
PV IN
Vmp: 17-50V, 30A
PV IN +
PV IN -
PMWS200 or
PMWS400
4
0.5m
2
PMLCD-BT
3
PM4SW2
PMSWEX-2: 2m extension or
PMSWEX-4: 4m extension
PM4SW2Y: 0.5m
PM4SW2Y: 0.5m
PM4SW2Y: 0.5m
3
PM4SW2
3
PM4SW10
Cells+DOD BM COM
DC 12V
Starter
battery
PMTEX-2:
2m extension or
PMTEX-4:
4m extension
PM4Y: 0.5mPMTS: 4.5m
A
More information https://www.caravansplus.com.au

7
NA
NA
NA
NA
NA
P/No.PMSHUNT 500A Current Shunt
+B1
+B2
COMM
PMBEX-2: 2m
extension or
PMBEX-4: 4m
extension
Remote switch
D+ Point
PMSH-V: 1.5m
Service Battery +
PMWS200: 4m
PMBS: 2.5m
PMWS200: 4m
PMWS200: 4m
PMWS200: 4m
PMBS: 0.5m
PMWS200 or
PMWS400
4
PMWS200 or
PMWS400
4
PMWS200 or
PMWS400
4
PM435
1
PMSHUNT
6
PMWEX-4: 4m extension
PMWEX-4: 4m
extension
PMWEX-4: 4m extension PMWEX-4: 4m extension
0.5m
0.5m
0.5m
0.5m
DC 12V
Service
battery
NA
More information https://www.caravansplus.com.au

8
WARRANTY STATEMENT
