ProMinent EXtronic EXBb Series User manual

ProMinent
®
Operating Instructions
Metering Pump ProMinent EXtronic®EXBb
The operating instructions contain changes in the electrical safety parameters.
It replaces all earlier operating instructions.
Please carefully read through these operating instructions in full! Do not discard!
The operator shall be liable for any damage caused by installation or operating errors!
Please enter identcode of the device here!
EXBb ___ ___ ___ ___ ___ ___ ___ ___
Part No. 987094 ProMinent Dosiertechnik GmbH · 69123 Heidelberg · Germany BA EX 014 01/12 EN
0158
BA_EX_014_01_12_EN.p65 31.10.2012, 7:31 Uhr1

ProMinent®
Page 2
Publishing details:
Operating Instructions Metering Pump ProMinent EXtronic®EXBb
© ProMinent Dosiertechnik GmbH, 2003
ProMinent Dosiertechnik GmbH
Im Schuhmachergewann 5-11
69123 Heidelberg
Germany
[email protected]
www.prominent.com
Subject to technical modificatios.
Publishing details
BA_EX_014_01_12_EN.p65 31.10.2012, 7:31 Uhr2

ProMinent®Page 3
Description of Functional Elements
1Drive unit with electronic control and solenoid
2Delivery connection
3End ring
4Liquid end
5Vent valve (only on types 1000 - 0417 NP and PP, refer to identcode on Page 13)
6Socket for bypass hose (only on types 1000 - 0417 NP and PP, refer to identcode on Page 13)
7Intake connection#
8Type identification plate
9Operating/impulse display
10 Inspection window
11 External connection
12 Power connection
13 Mains switch (not for 500 V version)
14 Control for stroke length
15 Locking lever
16 Control knob for stroke rate or pushbutton/pushbutton switch for priming
17 Transparent cover
View of Metering Pump
View of Metering Pump
1
2
3
4
5
6
7
8
9
12
14
15
13
11
16
10
17
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr3

ProMinent®
Page 4
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr4

ProMinent®Page 5
Contents
Contents
View of Metering Pump ......................................................................................................................................................... 3
Description of Functional Elements ............................................................................................................................ 3
Notes for User .............................................................................................................................................................................. 7
Metering Pump Applications............................................................................................................................................. 8
1Safety .................................................................................................................................................................................................. 9
1.1 Notes on Safety ............................................................................................................................................................. 9
1.2 Reference Guidelines/Standards ..................................................................................................................... 9
1.3 Tests and Approvals ................................................................................................................................................... 10
2Design and Function ............................................................................................................................................................ 10
2.1 Functional principle .................................................................................................................................................... 10
2.2 Construction / functional description, diaphragm rupture detector .................................... 10
2.3 Delivery capacity........................................................................................................................................................... 11
2.4 Versions ................................................................................................................................................................................ 12
3Technical Data............................................................................................................................................................................ 13
3.1 Identcode ............................................................................................................................................................................ 13
3.2 Dimensions and Weights ........................................................................................................................................ 14
3.3 Capacity data .................................................................................................................................................................. 15
3.4 Accuracies ......................................................................................................................................................................... 16
3.5 Material Specifications............................................................................................................................................. 16
3.6 Electrical Data ................................................................................................................................................................. 16
3.6.1 Electrical data, control current circuit .......................................................................................... 16
3.6.1.1 for “non-intrinsically safe” version and
“intrinsically safe” version .............................................................................................. 16
3.6.1.2 under “intrinsically safe” version ............................................................................... 17
3.6.2 Electrical data, supply current circuit ........................................................................................... 17
3.6.2.1 for “not intrinsically safe” version ............................................................................. 17
3.6.2.2 for the “intinsically safe” version ............................................................................... 17
3.6.3 Electrical data for the intrinsically safe (optional)
diaphragm rupture indicator ................................................................................................................ 18
3.6.4 Electrical data, details................................................................................................................................. 18
3.7 Mechanical data, cables ......................................................................................................................................... 18
3.8 Ambient conditions ..................................................................................................................................................... 19
4Unpacking ...................................................................................................................................................................................... 19
5Mounting and Installation ................................................................................................................................................ 20
5.1 Installing Metering Pump ....................................................................................................................................... 20
5.2 Installing Hose Lines .................................................................................................................................................. 20
5.2.1 Installing the Intake Line ......................................................................................................................... 21
5.2.2 Installing the Delivery Line .................................................................................................................... 22
5.2.3 Installing the Bypass Vent Line (see fold-out page).......................................................... 22
5.3 Installation Examples, Mechanical/Hydraulic ........................................................................................ 23
5.4 Electrical Installation .................................................................................................................................................. 25
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr5

ProMinent®
Page 6
Contents
6Operation ........................................................................................................................................................................................ 26
6.1 Start-Up ............................................................................................................................................................................... 26
6.2 Determining the Delivery Capacity ................................................................................................................. 27
6.3 Nomograms ...................................................................................................................................................................... 29
6.4 Setting the Delivery Capacity ............................................................................................................................. 37
7Maintenance ................................................................................................................................................................................ 37
8Repairs .............................................................................................................................................................................................. 38
8.1 Replacing working diaphragm / safety diaphragm............................................................................ 38
8.2 Servicing diaphragm rupture detector......................................................................................................... 39
8.3 Replacing separating diaphragm in the diaphragm rupture detector................................. 39
8.4 Checking diaphragm rupture detector ........................................................................................................ 39
9Malfunctions ................................................................................................................................................................................ 40
9.1 Operation/pulse indicator does not light, no stroke movement.............................................. 40
9.2 Pump intake no longer operable despite full stroke movement and venting ............... 40
9.3 Pump no longer meters, although operation/pulse indicator lights ..................................... 40
9.4 Liquid Emerges from end ring ............................................................................................................................ 40
9.5 Pump does not reach high pressures
or no suction despite max. stroke action .................................................................................................. 42
9.6 Diaphragm rupture indicator triggers alarm................................................................................................. 42
10 Used Part Disposal ................................................................................................................................................................ 42
11 Spare parts .................................................................................................................................................................................... 43
Installation data ........................................................................................................................................................................... 46
Guarantee claim for metering pumps ........................................................................................................................ 47
Declaration of Complete Dafety ..................................................................................................................................... 48
EC Declaration of Conformity .......................................................................................................................................... 49
EC Model Certificate ............................................................................................................................................................... 50
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr6

ProMinent®Page 7
Notes for User
Please read the following instructions carefully. They will help you make the best use of this
manual.
The following are highlighted in the text:
•Numbered points
왘Instructions
Operating guidelines:
NOTE
Notes are intended to make your work easier.
and safety instructions:
WARNING
Describes a potentially hazardous situation.
If not avoided may result in fatal or severe injury.
CAUTION
Describes a potentially hazardous situation.
If not avoided, could result in slight or minor injury or damage to property.
IMPORTANT
Describes a potentially damaging situation.
If not avoided may result in damage to property.
Notes for User
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr7

ProMinent®
Page 8
Metering Pump Applications
The ProMinent EXtronic®EXBb is an electronically controlled, explosion-proof diaphragm
metering pump with a short-stroke solenoid.
Liquid media The pump is used for metering liquid media:
•in explosion-threatened workplaces in zone 1, device category II 2 G of explosion group II C
(EXBbG) according to VDE guidelines
• for firedamp-threatened underground excavations in explosion group I, device category
1 M 2 (EXBbM) according to VDE guidelines
•in industrial premises at risk of explosion according to FM and CSA standards
Liquid ends made of various materials cover virtually all applications:
•Polypropylene (PP)
•PVC
•Acrylic
•PTFE-Teflon®
•Stainless steel
Gas-emitting media Self-venting liquid ends made of Acrylic or PVC are available for metering gas-emitting media.
Combustible media
WARNING
For combustible media only use the "SB” dosing head.
IMPORTANT
The pump is not designed to meter gaseous media as well as solids.
Voltages Versions are available for various voltages and frequencies:
230 V, 115 V, 500 V, 100 V und 200 V;
50/60 Hz.
Compatibility The ProMinent EXtronic®EXBb is a continuation of the former EXBa series:
The external dimensions and securing holes are identical and the hydraulic accessories of these
series can be used.
The liquid ends are compatible with the other diaphragm metering pumps, with the exception of
versions „SB _“ and „_ _ M“ (see Identcode page 13).
Metering Pump Applications
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr8

ProMinent®Page 9
Safety
1Safety
1.1 Notes on Safety
WARNING
•Immediately switch off the pump in the case of emergency!
Use the pump power switch or an emergency stop switch in your working environment!
•When installing the metering pump also observe the installation instructions for
devices in explosive areas; for Europe the European operator directive 99/92/EC
(ATEX137) and the ATEX Product Directive 94/9/EC (ATEX 95), implemented in Germany
by the new health and safety legislation!
•When using the metering pump for metering flammable media, observe (in Europe) the
European Operator Guideline 99/92/EC (ATEX 137, previously ATEX118a), implemented
in Germany with the new operating safety directive and the German dangerous
chemicals directive.
•Observe also all relevant standards e.g. DIN EN 60079-10/14 and DIN VDE 60079-11 for
installations in explosion-threatened areas and DIN VDE 0118 for the installation of
electrical equipment in explosion-threatened areas by day.
•Note all national directives which apply to the installation when installing outside
Germany.
CAUTION
•Pumps must be accessible at all times to facilitate operation and maintenance.
Do not obstruct or block access routes!
•Only specially trained and authorized persons are permitted to maintain and repair
metering pumps and their peripheral equipment!
•Always depressurize the liquid end first before carrying out any work on the pump!
•If hazardous or unknown metering media are used, discharge and flush the liquid end
before carrying out any work on the pump!
•Observe the safety data sheets of the metering liquids!
•Always wear protective clothing (goggles, gloves) when handling hazardous or
unknown liquids! This applies in particular to working on the liquid end!
•Assembly of ProMinent® metering pumps with parts not tested and approved by
ProMinent is prohibited and can result in damage to persons and property, for which
no liability will be accepted!
IMPORTANT
•Adjust the stroke length only with the pump running when the load on the stroke length
setting pin is relieved temporarily!
Release the lock before adjusting the stroke length!
•Only use clamping rings and hose sockets suitable for the relevant hose diameter as
well as genuine ProMinent hoses with the specified hose dimensions and wall
thickness, otherwise the stability of the connection cannot be guaranteed!
NOTE
•Avoid reducing the hose sizes!
•Use the next higher pipe cross-section or a pulsation damper for long hose lines and
media with higher viscosity!
1.2 Reference Guidelines/Standards
see EC conformity declaration
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr9

ProMinent®
Page 10
Safety / Design and Function
1.3 Tests and Approvals
Explosions protection The conformity certificate of the DMT-Gesellschaft für Forschung und Prüfung mbH, department
for the safety of electric resources, exploring drifts, can be found in the appendix.
Device type Identification mark Approval
EXBbG II 2G Ex d IIC T6 Gb II 2G c IIC T6 Gb DMT 03 ATEX E 023
EXBbG, intrinsically safe II 2(1)G Ex d [ia Ga] IIC T6 Gb II 2G c IIC T6 Gb DMT 03 ATEX E 023
EXBbM I M2 Ex d I Mb I M2 c I Mb DMT 03 ATEX E 023
ExBbM, intrinsically safe I M2(M1) Ex d [ia Ma] I Mb I M2 c I Mb DMT 03 ATEX E 023
EXBbG Class l, Div.1, Group B, C and D, T6 FMR
EXBbG Class l, Div.1, Group B, C and D, T6 CSA
2Design and Function
You will find the view of the metering pump and the description of the function units on the fold-
out page of the cover.
The metering pump ProMinent EXtronic®consists of the main components
Drive unit (1) With electronic control and solenoid,
power connection (10)
Input “external control” (optional) (11);
Delivery unit End ring (3) with diaphragm which is stabilised by a steel core.
Liquid end (4) with delivery connection (2) and intake connection (7),
on types 1000-0417 NP and PP with bypass hose socket (6) and vent valve (5);
Operator control unit with operating/pulse display (9),
Mains switch (not for 500 V version) (13),
Stroke length control knob (14) with observation window (10),
Locking lever (15),
Control knob for stroke rate or pushbutton/pushbutton switch for priming (16) and
transparent cover (17).
2.1 Functional principle
Metering is based on the pulse burst principle:
A pulse produces a magnetic field around the solenoid,
the solenoid attracts a moving thrust piece,
as a result, the diaphragm displaces the medium in the liquid end via a pressure control valve,
the valve closes on the intake side.
The magnetic field decays on completion of the switch-on pulse,
the thrust piece of the solenoid is reset by a reset spring,
the diaphragm returns to its initial position, thus initiating an intake stroke,
which closes the pressure valve and the media is drawn in on the intake side.
2.2 Construction / functional description diaphragm rupture indicator (optional)
The diaphragm rupture signalling system monitors the leak-tightness of the operating
diaphragm.
The liquid end of EXBb with diaphragm rupture signalling has instead of only one operating
diaphragm an additional diaphragm comprising the operational diaphragm and an additional
safety diaphragm, and is equipped with an intrinsically safe diaphragm rupture sensor (see
figure 1).
BA_EX_014_01_12_EN.p65 31.10.2012, 8:58 Uhr10

ProMinent®Page 11
Design and Function
The safety diaphragm is situated between the top plate and the spacer plate and forms a sealed
interim chamber with the working diaphragm.
Function It serves to monitor ruptures in the working diaphragm and protects the power end from
corrosion and the environment from chemical leaks in the case of diaphragm rupture.
Even after diaphragm rupture, this liquid end can continue to operate in emergency mode at full
working pressure and without leaks until the diaphragm is changed.
fig.: 1
IMPORTANT
If the diaphragm ruptures, an electrical signal is triggered when the system back pressure
reaches approx. 2 bar.
IMPORTANT
Precise pump feed cannot be guaranteed after a working diaphragm rupture.
2.3 Feed rate
The delivery capacity is determined by the stroke length and the stroke frequency (rate).
The stroke length can be steplessly adjusted with the control knob for stroke length (14) during
operation from 100 % to 10 % and then locked. The maximum stroke length is 1.25 mm, 0.63
mm for type EXBb_1000.
A setting of 0 to 110 (120) stroke/min can be set manually with the control knob for stroke
frequency (rate) (16).
At a maximum stroke length and rate and a max. backpressure of 1.5 bar to 25 bar, the
diaphragm-operated metering pumps deliver at a rate of 0.2 l/h to 60 l/h.
1Top plate
2Adapter
3Intermediate bush
4Safety diaphragm
(Backup diaphragm)
5Spacer
6Working diaphragm
7Liquid end
8Locking screw
9Diaphragm rupture indicator
10 Intake line
1
5
2
3
4
10
9
8
7
6
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr11

ProMinent®
Page 12
Design and Function
2.4 Control types
Version “Internal stroke rate setting” (identity code characteristic “Control type”: 0):
The controlling pulse is internally generated, stroke length and stroke rate can be manually
adjusted using the control buttons on the operating panel.
Versions “External contact control” (identity code characteristic “Control type”: 1, 4):
The controlling pulse is externally generated, from potential-free or semiconductor contacts and
fed to the drive unit via the “external control” jack; examples are contact water meter or
DULCOMETER® controls.
Versions “Analog control x - 20 mA”
(Identity code characteristic “Control type”: 2, 3, 5, 6):
An external, analogue signal is fed to the drive unit via the “External control” jack;
the stroke rate changes proportionally according to the 0 .. 20 mA or 4 .. 20 mA signal.
Versions “Internal stroke rate setting with pause function”
(Identity code characteristic “Control type”: 7, 8):
As for version “Internal stroke rate setting”, however there is also the possibility of switching the
metering on and off via an external semiconductor contact or potential-free contact.
NOTE
All control types, that can be controlled via an input, can be supplied with an “External
control” input of “non-intrinsically safe” or “intrinsically safe” type [i, a].
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr12

ProMinent®Page 13
3Technical Data
3.1 Identcode
Technical Data
Viton®is a registered trademark of DuPont Dow Elastomers.
EXBb Series ProMinent EXtronic®Version b
Type of enclosure
GGas-explosion protection, explosion group IIC, device group/category II 2G;
MMining/firedamp, and gas-explosion protection, expl. value I/IIC) device size/category I M2 U. II 2G)
Pump type
1000 1601 1201 0803 1st and 2nd digit: Backpressure [bar]
1002 0308 2501 2502 3rd and 4th digit: Capacity [l/h]
1006 0613 0417 2505
1310 0814 0430 0260
Liquid end material
NP1 Acrylic with vent, Viton®-A O-Ring
NP3 Acrylic with vent, Viton®-B O-Ring
NS3 Acrylic self-degassing, Viton®-B O-Ring
PP1 PP with vent, EPDM O-Ring
PP4 PP without vent/HV, EPDM O-Ring
PS3 PVC self-degassing, Viton®-B O-Ring
SB1 Stainless steel* with internal thread, Rp 1/4 bzw. 1/2 *) Material No. 1.4571
SS1 Stainless steel* with clamping rings PTFE-gasket *) Material No. 1.4571
SSM as SS1, with diaphragm rupture detector
SBM as SB1, with diaphragm rupture detector
SS2 Stainless steel* w. internal thread. 1/4"-NPT, PTFE-gasket *) Material No. 1.4571
TT1 PTFE +25 % carbon, PTFE-gasket
Valve spring
0no valve spring
1with 2 valve springs (1.4571) 0,1 bar
Electrical connection
A230 V 50/60 Hz open End
B115 V 50/60 Hz open End
C200 V 50/60 Hz open End
D100 V 50/60 Hz open End
E500 V 50/60 Hz open End
Control type
0internal stroke rate adjustment
1external contact activation
2analogue activation 0–20 mA
3analogue activation 4–20 mA
4external contact activation [i,a]
5analogue activation 0–20 mA [i,a]
6analogue activation 4–20 mA [i,a]
7internal stroke rate adjustment with pause function
8external stroke rate adjustment with pause function [i,a]
Control variant
0with potentiometer
1with push-button for ma. frequency
2with switch for ma. frequency
Approval/voltage/language
0BVS-Europa/100–500 V/German
1BVS-Europa/100–500 V/English
2FM-USA/100–500 V/English
3CSA-Kanada/100–500 V/English
EXBb ___ ______ ____ ___ ___ ___ ___ ___
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr13

ProMinent®
Page 14
Version ,,NS, PS“ Version ,,SB“
*) Vent valve and bypass only on
Typs 1000 – 0417 NP and PP
10
20
30 40 50 6070
100
1
0
19
0
50
10
20
30
40
60
70
80
90
125
144
G
Technical Data
3.2 Dimensions and Weights
*) see diagram
ProMinent EXtronic® EXBb dimensions in mm
Pump type / material A B C ø D E ø F G
1000,1601, 1201, 0803 NP1 391 136 69 70 6x4 38 229
1002, 0308, 2502, 2505, 1006 NP3 391 136 61 85 8x5 50 237
1310, 0613 391 136 52 100 8x5 66 244
0814, 0417 391 136 52 100 12x9 66 244
0430 381 137 46 135 DN10 117 304
0260 398 142 -16 135 DN15 117 314
1000, 1601, 1201, 0803 PP1 393 136 67 70 6x4 38 236
1002, 0308, 1006 393 136 67 70 8x5 50 236
0613 393 136 57 90 8x5 66 246
0814, 0417 393 136 57 90 12x9 66 246
0430 381 137 46 135 DN10 117 304
0260 398 142 -16 135 DN15 117 314
1002 PP4 389 138 46 85 DN10 50 222
1006 398 145 76 85 DN15 50 222
1310 398 145 76 85 DN15 66 222
0814 398 145 69 100 DN15 66 229
1000, 1601, 1201 TT1 378 134 75 60 6x4 38 223
0803 378 134 70 70 6x4 38 228
1002, 0308, 1006 388 138 42 80 8x5 50 256
0613 388 138 32 95 8x5 66 266
0814, 0417 388 138 32 95 12x9 66 266
0430 388 137 35 135 DN10 117 263
0260 398 142 31 135 DN15 117 268
1000, 1601, 1201 SS1 376 134 84 60 6x5 38 214
0803 376 134 79 70 6x5 38 219
1002, 0308, 2502, 2505, 1006 386 138 48 80 8x7 50 250
1310, 0613 386 138 39 95 8x7 66 259
0814, 0417 386 138 39 95 12x10 66 259
0430 386 137 35 135 DN10 117 263
0260 390 142 28 135 DN15 117 271
1601, 2501 SSM 391 149 84 60 6x5 38 214
1000 SB1 373 134 87 70 Rp 1/4 38 211
1601, 1201, 0803 373 134 79 85 Rp 1/4 38 219
1002, 0308, 2502, 2505, 1006 381 138 56 80 Rp 1/4 50 242
1310, 0613 381 138 48 95 Rp 1/4 66 250
0814, 0417 381 138 48 95 Rp 1/4 66 250
0430 381 138 22 145 Rp 1/4 117 275
0260 383 139 27 145 Rp 1/2 117 279
1601, 2501 SBM 388 149 79 85 Rp 1/4 38 219
fig.: 2
PP=11,5
Nich t unter
Sp annun g
öffnen !
D
NP=13
C
E
BØ 5,8
226
141
306
A
149
F
31
32
93
F
81
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr14

ProMinent®Page 15
Technical Data
Pump type Material Weight
EXBbG EXBbM
1000, 2501,1601, 1201, 0803, 1002, 0308 NP, PP, TT, SS, SB approx. 12/16 kg approx. 26/30 kg
2502, 1006, 0613, 0417 NP, PP, TT, SS, SB approx. 13/17 kg approx. 27/31 kg
2505, 1310, 0814, 0430, 0260 NP, PP, TT, SS, SB approx. 16/20 kg approx. 30/34 kg
3.3 Capacity data
fig.: 2 Pump max. Capacity max. Capacity Stroke rate Connection- Suction Priming Perm. ad-
type at max. at medium size lift* lift** mission pres.
backpressure backpressure ä Ø x i Ø intake side
EXBb bar l/h ml/stroke bar l/h ml/stroke strokes/min mm m Wc m Wc bar
1000 10 0.19 0.27 5 0.27 0.038 120 6x4 1.5 0.5 8.0
2501 SSM 25 1.14 0.16 12 1.4 0.18 120 6x4 5 1.8 8.0
1601 SSM 16 1.31 0.18 8 1.68 0.23 120 6x4 5 1.8 8,0
1601 16 1.00 0.14 8 1.3 0.18 120 6x4 5 1.8 8.0
1201 12 1.70 0.24 6 2.0 0.28 120 6x4 5 2.5 5.5
0803 8 3.70 0.51 4 3.9 0.54 120 6x4 5 2.8 3.0
1002 10 2.30 0.32 5 2.7 0.38 120 8x5 5 1.0 3.0
0308 3 8.60 1.20 1.5 10.3 1.43 120 8x5 5 1.8 1.5
2502 25 2.00 0.28 12 2.4 0.31 120 8x5 5 1.0 8.0
2505 25 4.20 0.64 12 5.3 0.73 110 8x5 5 1.5 3.5
1006 10 6.00 0.83 5 7.2 1.00 120 8x5 5 1.3 3.5
1310 13 10.50 1.59 6 11.9 1.80 110 8x5 5 1.9 2.0
0613 6 13.10 1.82 3 14.9 2.07 120 8x5 5.5 1.9 2.0
0814 8 14.00 2.12 4 15.4 2.33 110 12x9 5 2.0 1.5
0417 3.5 17.40 2.42 2 17.9 2.49 120 12x9 4.5 2.0 1.5
0430 3.5 27.00 4.09 2 29.5 4.7 110 DN10 5 1.8 0.8
0260 1.5 60.00 9.09 - - - 110 DN15 1.5 1.5 0.8
Type 1000
Type 2502, 2505, 1310 only in version NP and SS
Metering pumps for high viscosity media “HV”
EXBb bar l/h ml/stroke bar l/h ml/stroke strokes/min mm m Wc m Wc bar
1002 10 2.30 0.31 5 2.7 0.38 120 DN10 1 - 3.0
1006 10 6.00 0.83 5 7.2 1.00 120 DN15 1.3 - 3.5
1310 10 10.50 1.59 6 11.9 1.80 110 DN15 1.9 - 2.0
0814 8 14.00 2.12 5 15.4 2.33 110 DN15 2 - 1.5
Metering pumps with self-degassing liquid end***
EXBb bar l/h ml/stroke bar l/h ml/stroke strokes/min mm m Wc m Wc bar
1601 16 0.66 0.09 - - - 120 6x4 - 1.8 0.2
1201 12 1.0 0.14 - - - 120 6x4 - 2.0 0.2
0803 8 2.4 0.33 - - - 120 6x4 - 2.8 0.2
1002 10 1.8 0.25 - - - 120 6x4 - 2.0 0.2
*) Suction lift: with intake line filled
**) Priming lift: with intake line not filled
***) The specified performance data are guaranteed minimum values determined with water at room temperature.
1601, 1201, 0803 NS3 383 136 67 * 6x4 38 243
1002 383 136 67 * 6x4 50 243
1601, 1201, 0803 PS3 383 136 67 * 6x4 38 243
1002 383 136 67 * 6x4 50 243
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr15

ProMinent®
Page 16
3.5 Material Specifications
PP1 PP4 PC5 NP1/NP3 NS3 PS3 TT1 SS
Polypropylene Polypropylene PVC Acrylic Acrylic PVC PTFE with Stainless steel
carbon 1.4404
Polypropylene Polypropylene PVC PVC PVC PVC PTFE with Stainless steel
carbon 1.4404
EPDM EPDM FPM-A FPM-A/B FPM-B FPM-B PTFE PTFE
Ceramic — Ceramic Ceramic Ceramic Ceramic Ceramic Ceramic
Duran Ceramic — Duran — — Ceramic 1.4401
Type 1000 with ceramic seat rings in all material versions
PP4 with Hastelloy C valve springs
DEVELOPAN®metering diaphragm with PTFE base in all versions
FPM-A (Viton®-A), FPM-B (Viton®-B) and Duran (laboratory glass) are registered trademarks.
Liquid end
Intake- / delivery
connection
Seals
Balls Ø 6–Ø 12
Balls DN10–DN15
Technical data
3.4 Accuracies
min.: -5 %, max.: not specified
at max. stroke length and max. backpressure,
in all material versions.
Better than ±2 %
under constant conditions and min. 30 % stroke length;
observe following notes:
•All specifications refer to metering measurements with water at 20 °C.
•Constant backpressure, above 1 bar if possible.
•If metering takes place via a free outlet, a pressure retention valve must be used to generate
a backpressure of min. 1.5 bar (refer to the installation examples).
•Wherever possible, lay intake and metering lines with a constant rising gradient.
•If the liquid level of the supply tank is above the pump during operation, admission pressure
will be applied on the intake side; in this case, the backpressure should be so high that there
is a minimum differential pressure of 1.5 bar otherwise a pressure retention valve or a spring-
loaded injection valve with corresponding admission pressure must be used.
NOTE
A pressure retention valve or a spring-loaded injection valve is not an absolutely tight-
closing shut-off element. For this reason, an intake valve which is closed when the
metering pump is at a standstill, must be installed if admission pressure is applied on the
intake side.
3.6 Electrical Data
3.6.1 Electrical data, control current circuit
3.6.1.1 for “non-intrinsically safe” version and “intrinsically safe” version
mA input, identity code feature “control type”: 2, 3, 5*, 6*
Voltage max. 6 V
Current max. 30 mA
Input apparent ohmic resistance, approx. 94 Ω
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr16

ProMinent®Page 17
Technical data
Contact/pause input, identity code feature “control type”: 1, 4*, 7, 8*
Voltage with open contact approx. 5 V
Input resistance approx. 4.7 kΩ
Control using potential-free contact or semiconductor switch:
Residual current max. (contact open): 70 µA
Contact resistance (closed) max.: 10 kΩor
Voltage drop max.: 3 V
Pulse frequency max.: 40 pulses/sec.
Pulse width min.: 10 ms
* For the ensuring of intrinsic-safety, see chapter 3.6.1.2 under "intrinsically safe" version
3.6.1.2 under “intrinsically safe” version
Control circuit Default value of all types “(ia)”,
•Maximum output voltage: U0=7.14 V
•Maximum output current: I0= 5mA
•Maximum output power: P0=23.3 mW
•Internal resistance Ri=4296 Ω
•Maximum external inductance: L0=1H
•Maximum external capacity: C0=13.5 µF
For connection of an intrinsically safe circuit
•Maximum input current: Ii=280 mA
•Maximum input voltage: Ui=30 V
•Maximum input power Pi=2W
•Effective inner self-inductance Li=negligible
•Effective inner capacity Ci=negligible
3.6.2 Electrical data, supply current circuit
3.6.2.1 for “not intrinsically safe” version
Measurement voltage 100,115, 200, 230 and 500 + - 10 % VAC
Maximum current consumption Ieff*1.5 A
Max. peak current during a stroke Ipeak 8 A
Maximum power consumption Pwirk*50 W
* obtained by averaging over several strokes at the maximum stroke rate
3.6.2.2 for the “intinsically safe” version
Supply current circuit Intrinsically safe rated voltage: 100, 115, 200, 230 + - 10%, 500 +6% -10% VAC
Maximum current consumption Ieff*1.5 A
Max. peak current during a stroke Ipeak 8 A
Maximum power consumption Pwirk* 50 W
* obtained by averaging over several strokes at the maximum stroke rate
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr17

ProMinent®
Page 18
3.6.3 Electrical data for the intrinsically safe (optional) diaphragm rupture indicator
Diaphragm rupture detector Type Pepperl+Fuchs, NJ1,5-8GM-N-V1
Nominal voltage 8.2 V (Ri approx. 1 kOhm)
Normal power consumption ≤1mA
Power consumption in the event of a diaphragm rupture ≥3mA
Please observe the Operating Manual and the Type Examination Certificate of the diaphragm
rupture sensor for detailed data and for use in areas at risk of explosion.
3.6.4 Electrical data, details
Pump type 1000, 2501,1601, 1201, 2502, 1006, 0613, 0417, 2505, 1310, 0814, 0430, 0260
0803, 1002, 0308 1002*****
Mains connection (V) 100 115 200 230 500 100 115 200 230 500 100 115 200 230 500
Max. current consumption*** (A) 1.6 1.4 0.7 0.8 0.3 3.0 2.7 1.8 1.8 0.6 4.1 3.6 2.2 2.5 1.1
Effective. current
consumption*** (A) 0.27 0.29 0.14 0.17 0.09 0.70 0.70 0.33 0.41 0.14 0.95 0.84 0.47 0.53 0.25
Mean power consumption (W) 16 16 16 16 16 35 35 35 35 35 47 47 47 47 47
Fuse item 65* value (A)/Type 1.0T 0.63T 0.4T 0.315T 0.319 2.5T 2.0T 1.25T 0.8T 0.63 3.15T 2.5T 1.6T 1.25T 1.25
Value (A)/Type 0.16T 0.16T 0.16T 0.16T - 0.16T 0.16T 0.16T 0.16T - 0.16T 0.16T 0.16T 0.16T -
*special fuse with high switching capacity: only use original fuse
** use only original fuse
*** effective value during a stroke
**** obtained by averaging over several strokes at the maximum stroke rate
*****with material version PP4
Fuse order numbers, see chapter 11
NOTE
Only the effective power consumption is specified on the rating plate
3.7 Mechanical data, cables
Pump type Voltage V Cable Cable type Colour outer Ø mm
EXBbG to 250 power cable H 07 RNF 3G1.5 black 10.0
EXBbG > 250 power cable NSSHÖU 3x1.5 yellow 12.5
EXBbM all power cable NSSHÖU 3x1.5 yellow 14.0
+3x1.5/3E
EXBbG < 60 external/analogue cable Ölflex 110 grey 6.3
EXBbG < 60 external/analogue cable Ölflex EB blue 5.9
EXBbM < 60 external/analogue cable L-YY (zg) Y grey 11.4
EXBb_ 8 diaphragm rupture detector blue
In “FM”- and “CSA” version H07 RNF up to 500 V, the cable aperture has
a 1/2" NPT internal thread for connection to the North American supply system.
Technical data
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr18

ProMinent®Page 19
Technical data / Unpacking
3.8 Ambient conditions
Admissible storage temperature -20 °C to +50 °C
Admissible ambient temperature -20 °C to +45 °C
Admissible chemical temperature -10 °C to +35 °C (in accordance with IEC 335-2-41)
Temperature resistance of material versions
PP NP TT SS
Long term at max. back pressure 50 °C45 °C50 °C50 °C
Max. 15 min at max. 2 bar 100 °C60 °C120 °C120 °C
Climate admissible humidity 92 % non condensing
Behaviour in damp alternating climate DIN IEC 60068-2-78
Enclosure rating IP 65
Sound intensity level ≤70 dB (A), 1 m Abstand
4Unpacking
NOTE
Polystyrene parts are recyclable. They do not belong in the household waste!
왘It is advisable to keep the outside packing complete with the polystyrene parts in order to
be able to return the metering pump in the case of repairs and warranty claims.
왘Compare your delivery note with the packed contents.
왘Check whether the data on the type identification plate (8) of the metering pump agree with
your order data!
왘Should any problems arise, contact your ProMinent dealer or representative. You will find the
addresses on the back page of these operating instructions.
왘Always specify the identity code and the serial number which you will find on the type identi-
fication plate when making any inquiries or ordering spare parts. In this way, the pump type
and material variants can be clearly identified.
Scope of delivery •Metering pump with power cable
•Operating instructions with conformity certificate
•Conformity declaration for Namur-Sensor (only with diaphragm rupture indicator)
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr19

ProMinent®
Page 20
Mounting and Installation
5Mounting and Installation
WARNING
•When installing the metering pump also observe the installation instructions for devices
in explosive areas; for Europe the European operator directive 99/92/EC (ATEX137) and
the ATEX Product Directive 94/9/EC (ATEX 95), implemented in Germany by the new
health and safety legislation!
•When using the metering pump for metering flammable media, observe (in Europe) the
European Operator Guideline 99/92/EC (ATEX 137, previously ATEX118a), implemented
in Germany with the new operating safety directive and the German dangerous chemi-
cals directive.
•Observe valid national regulations when installing the pump abroad!
•Remove all traces of water from the liquid end before starting operation with media
which must not come in contact with water! The metering pump may still have water
residue in the liquid end from the tests carried out at the factory.
5.1 Installing Metering Pump
IMPORTANT
•Secure the pump such that no vibrations can occur.
•Ensure free access to facilitate operation and maintenance.
•The valves of the liquid end must be in vertical position!
왘The metering pump must be secured with screws and washers Ø 6 mm on a horizontal, firm
base.
5.2 Installing Hose Lines
IMPORTANT
•Lay and secure intake and delivery lines such that they cannot chafe.
•Lay intake and delivery lines such that they are free of mechanical stress.
•Arrange all lines such that the pump and liquid end can be removed laterally if required.
•When metering extremely aggressive or hazardous media, a venting facility with return
into the supply tank as well as a shut-off valve must be provided on the delivery and
intake sides.
•Ensure all connections are tight:
only use the clamping rings and hose sockets as specified for the relevant hose
diameter, only use original hoses with specified hose dimensions and wall
thickness.
•Avoid reductions in hose sizes: use the next higher line cross-section for long hose
lines and viscous media or install a compressed air vessel or diaphragm pulsation
damper!
BA_EX_014_01_12_EN.p65 31.10.2012, 7:32 Uhr20
