ProMinent gamma/ L Instruction Manual

ProMinent®
Please read the operating instructions through completely before commissioning this equipment! Do not discard!
Any part which has been subject to misuse is excluded from the warranty!
Part No. 987604 ProMinent Dosiertechnik GmbH •69123 Heidelberg •Germany BA G 015 10/00 GB
Operating Instructions Manual
ProMinent®gamma/ L
Solenoid Dosing Pump
Please affix nameplate here!

ProMinent®
Please fold out this page! È
Printing:
Operating Instructions ProMinent®gamma/ L
© ProMinent Dosiertechnik GmbH, 1999
Address:
ProMinent Dosiertechnik GmbH
Im Schuhmachergewann 5-11
D-69123 Heidelberg
Postfach 101760
D-69007 Heidelberg
[email protected]
www.prominent.de
Subject to technical alteration.
Printing

ProMinent®
Control elements and key functions
Control elements: overview
2
3
4
5
1
910
8
11
12 13
7
6
1 LCD display
2 Stroke length adjusting knob
3 UP key
4 P key
5 DOWN key
6 STOP/START key
7 i key
8 Fault indicator (red)
9 Warning indicator (yellow)
10 Operating indicator (green)
11 “Dosing monitor” terminal
12 “External control” terminal
13 “Float switch” terminal
Key functions
In continuous display mode In settings mode
(operating) (settings)
STOP/START key
STOP
START
Press briefly Stop pump, Stop pump,
start pump start pump
P key
P
Press briefly Start batch (in “batch” operating mode only), Confirm entry- jump to next menu
Cancel error option or continuous display
Press for 2 s Change to settings mode ---
Press for 3 s --- Jump to continuous display
Press for 15 s Load factory settings (calibration) ---
i key
i
Press x1 Toggle between continuous displays Toggle between “change individual digits”
and change a figure"
Press x2 --- For “change individual digits”:
jumps to first digit
Arrow keys UP and DOWN
Press x1 Change directly alterable values Select other settings,
(until “Set” appears) change individual digit or figure
Press simultaneously Prime ---

P
P
PPPP
P
P
P
P
PP
P
PP
P
PP
P
P
P
P
P
P
P
P
P P
P
P
i
STOP
STOP
START
START
edom
Batch
Contact
ManualAnalog
edom
Analog
edom
Manual
edom
Contact
edom
Batch
edoc
enon
1edoc
2edoc
0
99
0
9
0
9
0
tes
hctab
glana
Set
wolf
xua
sserp
bilac
raelc
9
0
9
0
9
0
9
0
6
0
ffo
no
02o
mA
Set
Analog
024
mA
Set
Analog
evruc
Set
Analog
11i
mA
Set
Analog
01i
mA
Set
Analog
12f
Freq.
Set
Analog
02f
Freq.
Set
Analog
11f
Freq.
Set
Analog
01f
Freq.
Set
Analog
91f
Freq.
Set
Analog
01f
Freq.
Set
Analog
91f
Freq.
Set
Analog
01f
Freq.
Set
Analog
92f
Freq.
Set
Analog
92f
Freq.
Set
Analog
02f
Freq.
Set
Analog
02f
Freq.
Set
Analog
91i
mA
Set
Analog
01i
mA
Set
Analog
91i
mA
Set
Analog
01i
mA
Set
Analog
22i
mA
Set
Analog
02i
mA
Set
Analog
92i
mA
Set
Analog
02i
mA
Set
Analog
92i
mA
Set
Analog
02i
mA
Set
Analog
nore
Set
Analog
ffore
Set
Analog
no
ffo
1
0
9
0
9
0
9
0
9
0
1
0
4p
1p
no
ffo
trats 0
6
0
9
0
9
0
9
0
9
0
10000
02451
tinu
tinu
2 s
-----
Set
Analog
Set
Analog
Set
Analog
2
1
002
tctnc no
ffo
9
0
9
0
9
0
9
0
Operating-/Settings Diagram
Continuous
display
Start/stop pump
Change directly alterable values
= Lock (CODE 1)
= Lock (CODE 2)
Prime
Start batch (in"batch" operating mode only)
Cancel error
Check adjustable values
2
1

P
PPP
P
P
P
PP
PP
P
P
i
P
P
P
P
P
P
P
STOP
START
P
PP
P
PP
P
PP
P
P
P
edom
edom
edom
edom
edom
edoc
enon
1edoc
2edoc
0
99
0
9
0
9
0
tes
hctab
Set
glana
wolf
Set
xua
Set
sserp
Set
bilac
Set
raelc
L
N
9
*
Set
Mem
Batch
0
*
Set
Mem
Batch
9
*
Set
Mem
Batch
0
*
Set
Mem
Batch
9
*
Set
Mem
Batch
0
*
Set
Mem
Batch
9
*
Set
Mem
Batch
0
*
Set
Mem
Batch
6
*
Set
Mem
Batch
0
*
Set
Mem
Batch
ffo
Set
Mem
Batch
no
Set
Mem
Batch
02o
024
evruc
11i
01i
12f
02f
11f
01f
91f
01f
91f
01f
92f 92f
02f02f
91i
01i
91i
01i
22i
02i
92i
02i
92i
02i
nore
ffore
no
Set
Flow
ffo
Set
Flow
1
Set
Flow
0
Set
Flow
9
Set
Flow
0
Set
Flow
9
Set
Flow
0
Set
Flow
9
Freq.
Set
Aux
0
Freq.
Set
Aux
9
Freq.
Set
Aux
0
Freq.
Set
Aux
1
Freq.
Set
Aux
0
Freq.
Set
Aux
4p
Set
1p
Set
no
Set
Calib
ffo
Set
Calib
trats
Set
Calib
0
Set
Calib
N
6
LSet
Calib
0
LSet
Calib
9
LSet
Calib
0
LSet
Calib
9
LSet
Calib
0
LSet
Calib
9
LSet
Calib
0
LSet
Calib
9
LSet
Calib
0
LSet
Calib
10000
Set
Mem
Batch
L
02451
Set
Mem
Batch
L
tinu
LSet
tinu
gal
Set
-----
Set
Calib
N
002
PP P
PP
tctnc
Set
no
Set
Mem
Contact
ffo
Set
Mem
Contact
9
Set
Mem
Contact
0
Set
Mem
Contact
9
Set
Mem
Contact
0
Set
Mem
Contact
9
Set
Mem
Contact
0
Set
Mem
Contact
9
Set
Mem
Contact
0
Set
Mem
Contact
P

i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
52
N
*
Mem
Contact
Stop
Operating mode "Analog" 0-20 mA
Stroke rate
Feed rate
Total stroke number
Total litres
(feed quantity)
"External" display
Signal current
Strokes remaining
Batch size/
Litres remaining
Factor
"Mem" appears only when "memory" function activated
Stroke length
Operating mode "Manual"
Continuous display
Operating mode "Contact" with
memory and tansfer factor 5
Operating mode "Batch" with
memory and tansfer factor 5
653
N
Analog
Stop
86321
L
Analog
Stop
txe
Analog
Stop
002
mA
Analog
Stop
56
%
Analog
Stop
56
%
Manual
Stop
56
%
Contact
Stop
56
%
Batch
Stop
081
Freq.
Manual
Stop
081
Freq.
Contact
Stop
653
N
Stop
Contact
081
Freq.
Batch
Stop
653
N
Stop
Batch
057
/hL
Manual
Stop
653
N
Stop
Manual
86321
L
Stop
Contact
86321
L
Stop
Batch
86321
L
Stop
Manual
txe
Stop
Contact
Mem
txe
Stop
Batch
Mem
52
N
*
Mem
Batch
Stop
01000
L
*
Mem
Batch
Stop
*
Mem
Batch
Stop
5
*
Mem
Contact
Stop
005
081
Freq.
Analog
Stop
057
/hL
Analog
Stop
Continuous
display
= UP and/or DOWN arrow keys, directly alterable values

ProMinent®
Table of Contents
Table of Contents
Identcode
General User Guidelines
1 About This Pump ........................................................................................................................................................................ 1
2 Safety .................................................................................................................................................................................................... 1
3 Storage, Transport and Unpacking .......................................................................................................................... 2
4 Device Overview and Control elements .............................................................................................................. 2
4.1 Device overview ............................................................................................................................................................... 2
4.2 Control elements ............................................................................................................................................................. 3
5 Function Description ............................................................................................................................................................. 3
6 Assembly and Installation ................................................................................................................................................. 6
6.1 Assembling dosing pump ........................................................................................................................................ 6
6.2 Assembling tubing ......................................................................................................................................................... 6
6.2.1 Installation for non-self bleeding pumps .................................................................................. 6
6.2.2 Installation of self-bleeding pumps............................................................................................... 8
6.3 Electrical Installation .................................................................................................................................................... 9
6.4 Retrofitting relays ............................................................................................................................................................ 12
7 Settings ............................................................................................................................................................................................... 14
7.1 Check adjustable values ........................................................................................................................................... 15
7.2 Change to settings mode ........................................................................................................................................ 15
7.3 Select operating mode (MODE menu)........................................................................................................... 16
7.4 Settings for operating mode (SET menu) .................................................................................................... 16
7.4.1 Settings for “manual” operating mode ...................................................................................... 16
7.4.2 Settings for “analogue” operating mode (ANALG menu)............................................ 16
7.4.3 Settings for “contact” operating mode (CONTCT menu) ........................................... 18
7.4.4 Settings for “batch” operating mode (BATCH menu) ..................................................... 20
7.5 Settings for programmable functions (SET menu) .............................................................................. 21
7.5.1 Settings for “calibration” function (CALIB menu) .............................................................. 21
7.5.2 Settings for the “pressure levels” function (PRESS menu)........................................ 22
7.5.3 Settings for “auxiliary frequency” function (AUX menu) .............................................. 22
7.5.4 Settings for the “flow” function (FLOW menu) ..................................................................... 23
7.6 Setting code (CODE menu) .................................................................................................................................... 23
7.7 Cancel total stroke number or total litres (CLEAR window) ........................................................ 23
8 Commissioning ............................................................................................................................................................................ 24
8.1 Precision dosing settings ......................................................................................................................................... 25
8.2 Diagrams for setting feed capacity .................................................................................................................. 26
9 Operating ........................................................................................................................................................................................... 26
9.1 Manual operation ............................................................................................................................................................ 26
9.2 Remote control ................................................................................................................................................................. 27
10 Maintenance ................................................................................................................................................................................... 28
11 Repairs ................................................................................................................................................................................................ 28
12 Troubleshooting .......................................................................................................................................................................... 34
13 Decommissioning and Disposal ................................................................................................................................. 35

ProMinent®
Table of Contents
14 Technical Data .............................................................................................................................................................................. 36
14.1 Performance data and weights ........................................................................................................................... 36
14.2 Dosing reproducibility ................................................................................................................................................. 37
14.3 Viscosity ................................................................................................................................................................................. 37
14.4 Materials Data for Liquid ends ............................................................................................................................. 37
14.5 Electrical Data ................................................................................................................................................................... 37
14.6 Ambient conditions ....................................................................................................................................................... 38
14.7 Enclosure rating and safety class ..................................................................................................................... 38
14.8 Compatibility ...................................................................................................................................................................... 38
15 Accessories..................................................................................................................................................................................... 39
Appendix ............................................................................................................................................................................................ 40
gamma/ L Dimensions ............................................................................................................................................................. 40
Exploded diagrams of liquid ends .................................................................................................................................. 44
Feed rate settings diagrams ................................................................................................................................................ 62
EC Declaration of Conformity ............................................................................................................................................ 68
Customer Specification Form ............................................................................................................................................ 69
Guarantee Form............................................................................................................................................................................. 70
Safety Declaration Form ......................................................................................................................................................... 71

ProMinent®
GALA Series gamma/ L, version a
Type Capacity
bar l/h
1000 10 0,74
1601 16 1,1
1602 16 2,1
1005 10 4,4
0708 7 7,1
0413 4 12,3
0220 2 19,0
1605 16 4,1
1008 10 6,8
0713 7 11,0
0420 4 17,1
0232 2 32,0
Material version:
PPE Polypropylene/EPDM
PPB Polypropylene/FPM (Viton®)
PCE PVC/EPDM
PCB PVC/FPM (Viton®)
NPE Acrylic glass/EPDM
NPB Acrylic glass/FPM (Viton®)
TTT PTFE/PTFE
SST Stainless steel 1.4571/PTFE
Liquid end version:
0 Non-bleed, no valve spring, for NP, TT and SS only
1 Non-bleed, with valve spring, for NP, TT and SS only
2 Bleed function, no valve spring for PP, PC, NP, not type 0232
3 Bleed function, no valve spring for PP, PC, NP, not type 0232
9 Self bleed function, for PP, NP, not for type 1000 and 0232
Hydraulic connection:
0 Standard connector as indicated in technical data
5 12/6 hose connector, pressure side only
9 10/4 hose connector, pressure side only
Version:
0 With ProMinent®logo
Power supply:
U 100 - 230 V, ±10 %, 50/60 Hz
Cabel and plug:
A 2 m Euro
B 2 m Swiss
C 2 m Australian
D 2 m USA
Relay:
0 No relay
1 Fault indicating relay, (N/C) changeover relay
3 Fault indicating relay, (N/O) changeover relay
4 As 1 + pacing relay, (1 input each)
5 As 3 + pacing relay, (1 input each)
Accessories:
0 No accessories
1 Foot and dosing valve,, 2 m PVC suction tube,
5 m PE discharge tubing, PP, PC, and NP only
2 As 0 + calibrating cylinder
3 As 1 + calibrating cylinder
Control variants:
0 Manual + external 1:1
1 Manual + external with pulse control
2 Manual + external 1:1 with analogue current
3 Manual + external with pulse control + analoque current
Access code:
0 No access code
1 Access code
Dosing monitoring:
0 Pulse input
1 Input for continuous contact
Pause/level:
0 Pause N/C/level N/C
GALA 1602 PPE 2 0 0 U A 0 0 0 0 0 0
Identcode
Viton®(FPM) is a registered trademark of DuPont Dow Elastomers.
Solenoid Æ70/M70
Solenoid Æ85/M85

ProMinent®
General User Guidelines
Please read through the following user guidelines. Familiarity with these points ensures
optimum use of the operating instructions.
On the fold-out page after the title page you will find the overviews “control elements and key
functions” and “operating/settings diagrams”.
You will find it useful to open out the “control elements and key functions” overview as you read
this instructions manual.
Key points in the text are indicated as follows:
• Enumerated points
SHints
Working guidelines:
GUIDELINES
Guidelines are intended to make your work easier.
Safety guidelines:
WARNING
Describes a potentially dangerous situation. Could result in loss of life or
serious injury if preventative measures are not taken.
CAUTION
Describes a potentially dangerous situation. Could result in lesser injuries or
damage to property if preventative measures are not taken.
TAKE CARE
Describes a potentially threatening situation. Could result in damage to
property if preventative measures are not taken.
The name plate affixed to the title page is identical to that on the gamma/ L pump supplied.
This facilitates matching the correct operating instructions manual to the correct pump.
Please quote the identity code and the serial number, which you will find on the name plate, in
any subsequent correspondence or when ordering spare parts. This will ensure accurate
identification of the pump type and material version.
General User Guidelines

ProMinent®Page 1
About this pump / Safety
1 About This Pump
The pumps in the ProMinent®gamma/ L pump series are microprocessor controlled solenoid
dosing pumps with the following special features:
• The feed rate can be displayed in l/h and/or gal/h, or in strokes/min.
• The stroke rate is continuously adjustable and is displayed in the LCD display.
• Stroke rate adjustment is digitally accurate and is displayed in the LCD display.
• The rated pressure of the gamma/ L can be adapted to individual systems.
• Two pumps can be controlled in different ways via the same standard signal.
• Large, illuminated LCD display
The hydraulic parts of the gamma/ L are identical to those of the Beta®.
2 Safety
Correct use The gamma/ L must be used for liquids only!
The gamma/ L may be used only in compliance with the technical data and specifications given
in the operating instructions!
It is forbidden to use the gamma/ L for any other purpose, or to modify it in any way!
The gamma/ L is not suitable for dosing gases or solids!
The gamma/ L must be used by trained and authorised personnel only!
Safety guidelines
WARNING
•As soon as the gamma/ L is connected to the electricity supply it may
commence pumping!
Avoid leakage of hazardous chemicals in this case!
If this should occur, then press the STOP/START key or disconnect the
gamma/ L from the power supply immediately!
•The gamma/ L cannot be switched to a current-free status! In the event of an
electrical accident, disconnect cable from the mains power supply!
•Disconnect cable from the mains power supply before commencing work on
the gamma/ L!
•Always depressurise liquid end before commencing work on the gamma/ L!
•Empty and rinse out the liquid end before commencing work on the gamma/
L after use with hazardous or unknown chemicals!
•Pumps for radioactive materials may not be returned to ProMinent after use!
CAUTION
•It is not permitted to assemble and install ProMinent®dosing pumps with
non-original parts unless these have been checked and recommended by
ProMinent. It can result in harm to persons and property for which no liability
will be accepted!
•When dosing aggressive materials, check the resistance of the pump
materials (see ProMinent®resistance list in the product catalogue!)
•Observe applicable national directives during installation!
Sound intensity level The sound intensity level is < 70 dB (A) at maximum stroke, maximum stroke rate, maximum
back pressure (water) in accordance with:
DIN EN ISO 3744 (Reproducibility 2 Determining Sound Intensity Level)
PR DIN EN 12639 (Metering Pump Noise Measurement)
DIN 45635-24 (Machine Noise Measurement)

ProMinent®
Page 2
Storage, Transport and Unpacking / Device Overview and Control elements
3 Storage, Transport and Unpacking
Transport and store the gamma/ L in the original packaging!
Protect the packed gamma/ L from moisture and the effects of chemicals!
Environmental conditions for storage and transport:
Storage and transport temperature: –10 bis +50 °C
Humidity: < 92 % relative humidity
Check that the delivery is complete:
Delivery range • Dosing pump with mains lead
• Operating instructions manual with EU conformity declaration
• Accessories if applicable
4 Device Overview and Control elements
When reading this section it is helpful to fold out the overview “Control elements and key
functions”!
4.1 Device overview
3
3.1
a
d
b
f
g
c
3.2
a
e
b
d
c
1 2
1 Control unit
2 Power end
3 Liquid end
Fig. 01
a Backplate
b Liquid end
c Suction valve
d Discharge valve
e Bleed valve
f Coarse/fine bleed valve
g Bypass hose nozzle
Fig. 02 Fig. 03

ProMinent®Page 3
Device Overview and Control elements / Function Description
4.2 Control elements
Please acquaint yourself with the gamma/ L control elements with the help of the “control
elements and key functions” overview!
Indicators The LCD display supports the operation and setting of the gamma/ L with a range of indicators:
Set
Flow
Calib
Mem
ErrorPauseAux
Stop
The indicators are interpreted as follows:
Symbol for P key: The gamma/ L is in settings mode.
Close symbol: In a continuous display: lock (if code has been set).
In settings mode: indicates access to code menu.
Stop: The gamma/ L has been stopped using the STOP/START key.
Pause: The gamma/ L has been stopped using the “pause” function
(external).
Aux: The gamma/ L is pumping at the auxiliary frequency. In AUX
menu: the gamma/ L is in the AUX menu.
Error: A fault has occurred and the pump has been stopped.
Mem: An additional “memory” function has been set in the “contact”
and “batch” operating modes.
In CNTCT or BATCH menus (“mem” flashes): the memory
function can be set
Calib: The gamma/ L is in the CALIB menu.
n a continuous display (“calib” flashes”): more than ± 10 %
deviation of stroke rate from value at the moment of calibration.
Flow: The gamma/ L is in the FLOW menu.
Set: The gamma/ L is in the SET menu.
Command symbol: The number of strokes reached is above the maximum value
(99999) that can be shown in the LCD display
5 Function Description
Function principle Dosing takes place as follows: the dosing diaphragm is forced into the liquid end; the pressure
in the liquid end causes the suction valve to close and the chemical flows out of the liquid end
through the discharge valve. The dosing diaphragm is then forced back out of the liquid end.
The vacuum in the liquid end causes the discharge valve to close and fresh chemical flows into
the suction valve in the liquid end. This concludes one operating cycle.
The dosing diaphragm is driven by an electronically controlled electrical solenoid.
Feed rate The feed rate is determined by the stroke length and the stroke rate.
The stroke length is set between 0 - 100 % using the stroke length adjusting knob. Optimum
dosing reproducibility is achieved by setting the stroke length to between 30 - 100 % (SEK type:
50 - 100 %)!
The stroke rate is set using the arrow keys (not in “analogue” operating mode) to between
0 - 180 strokes/min.
Self-bleed function Pumps with self-bleed function (= SEK types) can operate a prime action even when the
discharge tubing is closed, discharging existing air through a bypass valve. These pumps can
release gas even during operation, irrespective of the actual operating pressure.
An in-built pressure maintenance valve allows accurate dosing even in depressurised states.

ProMinent®
Page 4
Function Description
Operating modes Operating modes are selected using the MODE menu (depending upon identity code, some
operating modes may be absent).
“Analogue” operating mode: (Identity code, control variant: analogue current)
The stroke rate is controlled via an analogue electrical signal via the “external control” terminal.
Signal processing is pre-selected at the controller.
“Manual” operating mode: (Identity code, control variant: manual, standard function)
The stroke rate is controlled manually via the controller.
“Contact” operating mode: (Identity code, control variant: external 1:1 / external with pulse
control)
This operating mode offers the opportunity to make fine adjustments with small increase/
decrease factors. Dosing can be activated by a pulse via the “external control” terminal or by a
semiconductor element. With the “pulse control” option it is possible to pre-set a feed quantity
(batch) or number of strokes (factor 0.01 to 99.99) via the control unit.
“Batch” operating function: (identity code, control variant, external 1:1 / external with pulse
control)
This operating mode offers the option of working with larger transfer factors (up to 65535).
Metering can be triggered by pressing the P key or a pulse from the “external control” terminal
via a contact or semiconductor element. A batching quantity or number of strokes can be pre-
selected via the control unit.
Functions The following functions can be selected using the SET menu:
“Calibrate” function:
The gamma/ L can be operated in all operating modes including in calibrating mode. The
corresponding continuous displays can show the actual feed quantity or the feed rate.
Calibration is maintained within the stroke frequency range 0 - 180 strokes/ min. Calibration is
also maintained when a stroke frequency is altered up to ± 10 %.
“Pressure level” function:
It is possible to set different pressure levels.
“Auxiliary frequency” function:
It is possible to set a stroke rate in the SET menu, which may be activated via the “external
control” terminal. This auxiliary frequency overrides all other pre-set stroke rate frequencies.
“Flow” function:
Stops the gamma/ L when the flow is insufficient. In the SET menu, the number of failed strokes
is entered after which the pump will be turned off.
The following functions are available as standard:
“Float switch” function:
Information on the liquid level in the feed chemical container is transmitted to the gamma/ L.
This option requires the installation of a 2-stage float switch. This is connected to the “float
switch” terminal.
“Pause” function:
The gamma/ L can be stopped by remote control via the “external control” terminal. The “pau-
se” function operates only via the “external control” terminal.
The following functions are activated by keystrokes:
“Stop” function:
The gamma/ L can be stopped by pressing the STOP/START key without disconnecting from
the mains power supply.
.

ProMinent®Page 5
Function Description
“Prime” function:
Priming (short term feed at maximum frequency) is activated by pressing both arrow keys at the
same time.
Optional relay The gamma/ L has two connection options.
“Fault indicating relay” option:
In the event of fault signals, warning signals or float switch activation signals, connects an
electrical circuit to trigger alarm sirens etc. The relay is retrofitted via an aperture in the power
end.
“Fault indicating and pacing relay” option:
Along with the fault indicating relay, the pacing relay produces an electrical impulse for every
stroke. The relay is retrofitted via an aperture in the power end.
Function and error
indicators The operating and error status is shown via the three LEDs and the “error” indicator on the LCD
(see also section 12):
LCD indicator If a fault occurs “error” will appear along with an additional fault warning.
LED indicator Operating indicator (green)
This indicator is lit as long as the gamma/ L is operating correctly.
Warning indicator (yellow)
This warning light appears if the gamma/ L electronics detect a situation that could lead to a
fault, e.g. “liquid levels low 1st stage”.
Warning indicator (red)
This warning light appears if a fault occurs, e.g. “liquid levels low 2nd stage”.
Hierarchy of operating modes, functions and fault statuses
The different operating modes, functions and fault statuses each have a differing effect on
whether and how the gamma/ L functions. These effects are given below:
1. Prime
2. Fault, stop, pause
3. Auxiliary frequency
4. Manual, analogue, contact, batch
to:
1. “Prime” can be activated in any pump status (as long as it is operable)
2. “Fault”, “stop” and “pause” stop all system parts up to “prime”.
3. The stroke rate of the “auxiliary frequency” always overrides the existing operating stroke
rate.

ProMinent®
Page 6
Assembly and Installation
6 Assembly and Installation
WARNING
•The gamma/ L series dosing pumps must be commissioned exactly as
described in the operating instructions manual!
•It is not permitted to assemble and install ProMinent®dosing pumps with
non-original parts unless these have been checked and recommended by
ProMinent.
•Always depressurise tubing before working on the dosing pump. Empty and
rinse out the liquid end!
•Never allow the dosing pump to operate when an discharge tube stop tap is
closed ! It may burst!
•Remove all water from liquid end before commissioning or rinse with a
suitable cleaning agent if using chemicals that should not come into contact
with water!
•Before unscrewing the control unit disconnect the mains lead from the
power supply!
•Observe applicable national directives during installation!
6.1 Assembling dosing pump
TAKE CARE
•The gamma/ L should be fixed in such a way as to prevent vibration!
•Suction and discharge valve must be upright (bleed valve in self-bleed liquid
ends)!
•Ensure free access for operation and maintenance!
Assembling dosing pump The base of the dosing pump must be mounted on a firm, horizontal surface.
6.2 Assembling tubing
6.2.1 Installation for non-self bleeding pumps
CAUTION
•Tubing must be free from stress and kinks when fitted!
•When dosing extremely aggressive or hazardous chemicals it is advisable to
install a bleed valve that feeds back to the container and isolation valves on
the prime and discharge sides.
•In order to ensure connections are fast, use correctly sized clamping rings
and nozzle unions!
•Use only original hoses with specified dimensions and wall-thicknesses!
•Do not exceed maximum permissible priming pressure (see section 14)!
•It is imperative that the maximum permissible operating pressure is not
exceeded (see section 14 and appendix documentation)!
GUIDELINE
The tubing should be attached in such a way as to allow lateral detachment of the
gamma/ L and the liquid end if necessary!

ProMinent®Page 7
Assembly and Installation
PP, PC, NP, TT versions Assembling tubing to plastic valves (see fig. 04)
SCut hose ends straight across
SPush union nut (2) and clamping ring (3) onto hose (1)
SPush the hose end (1) over the nozzle (4) to the stop. Widen if necessary
SMake sure that the O-ring (5) is sitting correctly in the valve (6)
SPlace the hose (1) with the nozzle (4) onto the valve (6)
SClamp the hose connector:
Tighten the union nut (2) while pressing in the hose (1)
SRetighten the hose connector:
Pull the tubing (1) connected to the liquid end briefly and then retighten the union nut (2)
1
2
4
5
6
3
1 Hose
1
2
4
5
3
1 Tube
2 Union nut 2 Union nut ring
3 Clamping ring 3 Rear clamping
4 Nozzle 4 Front clamping ring
5 O-ring 5 Valve
6 Valve
Fig. 04 Fig. 05
SS Version Assembling stainless steel tube connectors to stainless steel valves (see fig. 05)
SPush union nut (2) and clamping rings (3, 4) onto tube (1) leaving approx. 10 mm distance
between them
SPush tube (1) up to the stop in the valve (5)
STighten union nut (2)
SS Version Assembling tubing to stainless steel valves
TAKE CARE
Assemble only PE or PTFE tubing to stainless steel valves!
SInsert an additional support (stainless steel) into PE or PTFE tubing
Installing suction tubing
TAKE CARE
Do not exceed maximum permissible priming pressure on the prime side (see
section 14)!
GUIDELINE
•Make suction tubing as short as possible.
•Suction tubing should be rising in order to prevent air bubbles forming!
•As far as possible use swept bends for bends rather than right angle bends!
•Measure the length and cross section to ensure that the vacuum created by the
priming action does not reach the vaporising pressure of the feed chemical! In
extreme cases excess vacuum on the priming side can cause breaks in the liquid
column or incomplete return stroke!
•Please note: “Priming lift x density of feed chemical £max. priming lift” (in m WG)
Assembly of foot valve SCut the free suction end so that the foot valve hangs just above the container base; for
chemicals with impurities or sedimentation at the bottom, the foot valve should be
positioned well above this layer.

ProMinent®
Page 8
Assembly and Installation
Installing pressure tubing
TAKE CARE
•The discharge tubing should be laid in such a way as to ensure that the
pressure surge of the discharge stroke does not exceed the maximum
operating pressure. As overload protection for the discharge tubing, it is
advisable to fit a relief valve feeding back into the chemical supply container,
e.g. a ProMinent®multifunction valve.
•Check that the length and cross section of the tubing are correct!
6.2.2 Installation of self-bleeding pumps
CAUTION
•Observe all installation and safety guidelines for standard pumps!
•Do not exceed tubing cross section, priming lift, priming pressure or
viscosity of feed chemical!
In addition to the suction and discharge tubing, a bypass tube should be connected. This is
attached to the bleed valve on the upper side of the liquid end (red packing, see fig. 06).
GUIDELINE
The discharge valve is located on the front of the liquid end in the SEK type!
Installation of by-pass tubing
GUIDELINE
When the suction side is primed, at least equal pressure must exist in the bypass
tubing!
The pump can operate when the bypass is primed and the suction side is
depressurised.
SPlace the tube onto the bypass nozzle and/or bleed valve of the self-bleed function liquid
end (recommended: flexible 6x4 PVC hose)
SPush the free end of the tube back into the dosing container
SCut the bypass tube so that it does not enter the feed chemical.
Bleed valve for the bypass tube to the supply
container, 6/4 mm
Discharge valve for discharge tubing to injection
point, 6/4 - 12/9 mm
Suction valve for suction tubing in supply
container, 6/4 - 12/9 mm
Fig. 06

ProMinent®Page 9
Assembly and Installation
6.3 Electrical installation
WARNING
•Installation must be carried out by a trained engineer!
• Disconnect gamma/ L from mains power supply during installation!
•Observe applicable national directives when installing the dosing pumps!
•When connecting with parallel inductive power consumers a switch
contact must be fitted, e.g. relay or contactor!
Connection
to mains power supply Connect the gamma/ L to the mains power supply using the mains lead
Parallel connection to
inductive power consumers If the gamma/ L is connected to the mains in parallel with inductive power consumers
(e.g. solenoid valve, motor) they must be electrically isolated. This will avoid damage caused
by induction and voltage surges when switching off.
SFit individual contacts for the gamma/ L and supply power via auxiliary contactor or relay.
If this is not possible, then:
SConnect a varistor in parallel (order number 710912) or an RC circuit, 0.22 mF/220 W
(order number 710802).
Power element
(in base of pump)
1
PE
L1
N
2
4
5
3
Fig. 07
1 Mains terminal
2 Relay circuit terminal
3 Fuse
4 Solenoid earth lead terminal
5 Solenoid terminal
“External control”
terminal The “external control” terminal is a five pin in-built terminal. It is compatible with the two and
four core cables used previously.
The “auxiliary frequency” function is only available with a five core cable.

ProMinent®
Page 10
Assembly and Installation
gamma/ L configuration Electrical interface for “external contact” - “pause” - “auxiliary frequency”:
• Voltage when contacts open: approx. 5 V
• Input resistance: 10 kW
• Control: voltage free contact (load: 0.5 mA at 5 V),
or: Semiconductor switch (residual voltage < 0.7 V)
• Maximum pulse frequency: 25 pulses/s
• Required pulse duration: ³20 ms
Electrical interface for “external analogue":
• Input load resistance: approx. 120 W
• Maximum current at input: 50 mA
gamma/ L configuration
1
54
2
3
Pin Function 2 core cable 4 core cable 5 core cable
Pin 1 Pause Jumped at pin 4 Brown Brown
Pin 2 External contact Brown White White
Pin 3 External analogue – Blue Blue
Pin 4 Earth White Black Black
Pin 5 Auxiliary frequency – – Grey
Fig. 08
Plug configuration
2
45
1
3
“Pause” function
The gamma/ L is not operating when
• The cable is connected and pins 1 and 4 are free.
The gamma/ L is operating when
• The cable is connected and pins 1 and 4 are connected.
• There is no cable connected (pin 1 is free).
Fig. 09
“Contact” und “Batch” operating modes
One or more discharge strokes are triggered when pin 2 and pin 4 are connected to one another
for at least 20 ms.
Otherwise, pin 1 and pin 4 must be connected.
“Analogue” operating mode
The stroke frequency of the gamma/ L is controlled via an electrical signal. The electrical signal
is applied between pins 3 and 4.
Otherwise, pin 1 and pin 4 must be connected.
“Auxiliary frequency” function
The gamma/ L runs at a pre-set stroke rate when pin 5 and pin 4 are connected to one another.
Otherwise, pin 1 and pin 4 must be connected.
The factory setting for this function is 180 strokes.
GUIDELINE
For function and operating mode hierarchy, see section 5!
