ProMinent alpha Series Operating instructions

ProMinent
®
General Operating Instructions
ProMinent®Motor-Driven Metering Pumps
and Hydraulic Accessories
Hydro
Two sets of operating instructions are necessary to ensure safe operation of the metering pumps corresponding to their
intended purpose: The product-specific operating instructions (e.g. for Sigma) and the general operating instructions
for ProMinent® motor-driven metering pumps.
Both are only applicable in conjunction with each other.
Please completely read through these operating instructions first! Do not discard!
The warranty shall be invalidated by damage caused by operating errors!
Part No. 987702 ProMinent Dosiertechnik GmbH · 69123 Heidelberg · Germany BA MOZ 015 05/06 GB
Meta
Makro TZ
Sigma
alpha Vario
Makro/ 5
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr1

ProMinent® ProMinent®
Page 2
Legal notice
Legal notice:
General Operating Instructions for
ProMinent® Motor-Driven Metering Pumps
© ProMinent Dosiertechnik GmbH, 1995
Address:
ProMinent Dosiertechnik GmbH
Im Schuhmachergewann 5-11
69123 Heidelberg
Germany
[email protected]
www.prominent.com
Subject to technical modifications.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr2

ProMinent® ProMinent®Page 3
Table of Contents
Table of Contents
User Information ................................................................................................................................................................................ 4
1Application of Motor-Driven Metering Pumps ............................................................................................. 5
2Safety Notes ................................................................................................................................................................................. 5
3Mounting ......................................................................................................................................................................................... 6
4Installation, hydraulic .......................................................................................................................................................... 7
4.1 Standard Installation .................................................................................................................................................. 8
4.2 Notes on Installation on Intake Side ............................................................................................................. 9
4.3 Notes on Installation on Delivery Side ......................................................................................................... 10
4.4 How not to install pumps ....................................................................................................................................... 12
4.5 Special Notes on Installation............................................................................................................................... 13
5Installation, electrical .......................................................................................................................................................... 15
5.1 Motor ...................................................................................................................................................................................... 15
6Start-Up ............................................................................................................................................................................................ 17
7Maintenance ................................................................................................................................................................................ 18
8Troubleshooting ........................................................................................................................................................................ 18
9Other important considerations for dosing pumps in ex-zones ................................................. 19
9.1 Application in accordance with regulations ............................................................................................ 19
9.2 Safety instructions ....................................................................................................................................................... 19
9.2.1 Safety equipment .......................................................................................................................................... 19
9.2.2 EU declaration of conformity / certification ............................................................................. 19
9.3 Assemble ............................................................................................................................................................................ 19
9.4 Installation, hydraulic................................................................................................................................................. 20
9.5 Installation, electrical ................................................................................................................................................. 21
9.6 Commissioning .............................................................................................................................................................. 21
9.7 Maintenance ..................................................................................................................................................................... 22
9.8 Troubleshooting ............................................................................................................................................................. 23
9.9 Repair..................................................................................................................................................................................... 23
9.10 Decommissioning ......................................................................................................................................................... 23
10 Hydraulic Accessories ........................................................................................................................................................ 24
10.1 Overview and Notes on Accessories ............................................................................................................ 24
10.2 Back pressure valve / relief valve .................................................................................................................... 26
10.3 Pulsation Dampers ...................................................................................................................................................... 26
Appendix.......................................................................................................................................................................................... 28
Warranty Application for Metering Pumps and Accessories ................................................................... 28
Data for Calculating Metering Line .............................................................................................................................. 29
Installing Drawing ...................................................................................................................................................................... 30
Safety declaration form ......................................................................................................................................................... 31
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr3

ProMinent® ProMinent®
Page 4
User Information
Please read through the following user guidelines. Familiarity with these points ensures optimum
use of the operating instructions.
Key points in the text are indicated as follows:
•Enumerated points,
왘Hints
Working Guidelines:
NOTE
Notes on operation.
Safety Guidelines:
WARNING
There is a danger to life or the risk of serious injury if the notes on safety are disregarded!
CAUTION
There is a danger of slight injury and damage to property if the notes on safety are
disregarded!
IMPORTANT
There is a danger of damage to property if the notes on safety are disregarded.
These general operating instructions for motor-driven metering pumps and hydraulic assemblies
apply only in conjunction with the product-related pump operating instructions for e.g. alpha,
Vario, Meta, Sigma, Hydro, Makro/ 5 and Makro TZ motor-driven metering pumps.
User Information
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr4

ProMinent® ProMinent®Page 5
Application of Motor-Driven Metering Pumps / Safety Notes
1 Application of Motor-Driven Metering Pumps
ProMinent®motor-driven metering pumps and accessories are to be used solely for the purpose
of metering liquid media!
In explosion-threatened workplaces in zone 1, device category II 2G of explosion group II C
the pump may not be operated without the corresponding rating plate (and the corresponding
EC conformity declaration) for pumps for explosion-threatened workplaces in accordance with
guideline 94/9/EC of the European guidelines. The explosion group, category and type of
protection shown on the marking must correspond to or exceed the conditions prevailing in the
intended area of application.
All other uses or modifications are prohibited!
Pumps may never be operated in explosion-threatened workplaces without a corresponding
rating plate (and the corresponding EC conformity declaration) for pumps for explosion-
threatened workplaces.
ProMinent® motor-driven metering pumps and accessories are not to be used for the purpose of
metering gasses and solids!
Refer to the relevant product-related operating instructions and product cataloque for the
technical data of the type of motor-driven metering pump used!
Decisive criteria relating to the intended use of the pumps are
•EX-protection of the pump
•Resistance of parts coming in contact with metered medium
•Pressure and temperature of metered medium
2Safety Notes
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
•Immediately switch off the pump in case of emergency! Use the power switch on
the pump or an emergency switch in your immediate operating environment!
•Pumps for radioactive medium must not be shipped through standard channels!
•Observe applicable national regulations for installation abroad!
CAUTION
•Do not obstruct or block access areas!
Pumps must be accessible at all times to facilitate operation and maintenance.
•Only specially trained and authorized persons are permitted to carry out maintenance
and repairs on metering pumps and their periphery!
•Always depressurize the liquid end first before carrying out any work on the pump!
•If hazardous or unknown metering media are used, discharge and flush the liquid end
before carrying out any work on the pump!
•Observe safety specifications for liquid metered media! Corresponding protection and
emergency measures must be implemented prior to initial operation.
•Always wear protective clothing (safety goggles, gloves,...) when handling hazardous or
unknown liquid media! This applies particularly when working on the liquid end!
•Do not use parts which have not been tested and approved by ProMinent for assembly of
ProMinent®motor-driven metering pumps since this can result in damage to persons and
property, for which no liability will be accepted!
•Install safety devices in the system, e.g. overflow valves!
ProMinent®motor-driven pumps are oscillating displacement pumps. Irrespective of
whether the delivery line is closed, e.g. by closing off the delivery line or by closing a valve,
the pressure produced by the pump can reach a multiple of the permissible working
pressure of the system or of the metering pump. This can result in lines bursting with
dangerous consequences particularly in the presence of aggressive or toxic media!
•Piston pumps must always be equipped with a dry-run protection facility to avoid the
pump packing running dry as this may cause overheating and thus premature wear.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr5

ProMinent® ProMinent®
Page 6
Safety Notes / Mounting
IMPORTANT
•Based on state-of-the-art technology, the manufacturer carefully selects the materials
for parts coming into contact with the medium as specified by the customer.
The manufacturer shall not be liable for any damage caused by metering other media
or media which has been modified with regard to its properties (concentration, density,
temperature, additives, impurities etc.).
•Avoid over-feed with positive pressure difference (at least 1 bar) between discharge
and suction sides.
•Only specially trained personnel are permitted to operate the metering pump.
The operator must ensure by applying appropriate accident prevention measures that
operating personnel are not endangered under given operating conditions (pressure,
temperature, aggressivity etc.).
3Mounting
IMPORTANT
•Mount the metering pump upright with the feet on a horizontal base. Refer to the
corresponding data sheets for the dimensions (m) of the securing holes.
DN
fig.1
m
m
•The frame or the foundation for mounting the pump must be designed such as to
ensure the unit is free of vibration and stable.
fig. 2
•Install pump at convenient operating level and mount such that the valves are vertical:
head valve always at top and intake valve always at bottom.
fig. 3
Head valve
Intake valve
Liquid end
f
f
f
•Ensure adequate clearance (f) in area of liquid end as well as intake valve and head
valve so that these parts can be easily removed if required.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr6

ProMinent® ProMinent®Page 7
Mounting / Installation, hydraulic
fig. 4
A
A
•Set up the pump such that the stroke length adjustment, indicator scale A, oil level
indicator, oil filler and drain plugs as well as the valves are easily accessible for
servicing.
fig. 5
DN pipe
DN pump valve
DN pump valve
•Ensure nominal diameters of pipes and installed fittings are the same size or larger
than the nominal diameters of the pump valves (intake and head valves).
4Installation, hydraulic
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
IMPORTANT
•Observe the relevant national directives with regard to installation!
•In order to verify the pressure conditions in the piping system it is recommended to
provide connection options for manometer close to the suction and pressure port.
fig. 6
Pressure
gauge sleeve
Pipe
(delivery line)
Pressure
control valve
Intake valve
Pipe
(intake line)
Pressure
gauge sleeve
•Connect pipes to the pump such that there is no stress or strain whatsoever acting
on the pump, such as offset, weight or expansion of the pipe. Only use a flexible pipe
adapter for connecting steel/stainless steel pipes to plastic pump housings.
fig. 7
Steel/stainless steel
pipe
Flexible pipe adapter
Plastic connecting piece
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr7

ProMinent® ProMinent®
Page 8
Mounting
4.1 Standard Installation
Delivery line
Metering tank
Diagram 8
Metering pump Dirt trap
Metering valve Solenoid valve
Adjustable pressure control valve
PD
Pulsation damper
(Overflow valve)
Foot valve with sieve filter Float valve
Pressure gauge Filler device
Ball check valve Siphon vessel
Shut-off cock valve
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr8

ProMinent® ProMinent®Page 9
Installation, hydraulic
4.2 Notes on Installation on Intake Side
NOTE
Avoid the intake line running empty:
h
fig. 9
•Install foot valve at end of intake line when the pump is higher than the max. liquid level
in the intake tank.
•The calculated size h (see diagram) must not be greater than the specified pump
suction head divided by the density of the delivered medium.
•Use short intake line and avoid thin-walled hoses.
NOTE
Connect intake line to tank slightly above the base of the tank.
IMPORTANT
Provide suitable means for retaining impurities!
Otherwise they can cause faults in the pump and system!
E.g. install a dirt trap (mesh size 100–400 µm depending on medium and type of metering
pump).
fig. 10
NOTE
fig. 11
Install pump with inlet on intake side for gas-emitting media.
NOTE
Intake via siphon line for high-level tanks without connection facilities at base of tank:
fig. 12
•Install filler facility for siphon line (intake line).
•Observe acceleration pressures due to the longer intake line.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr9

ProMinent® ProMinent®
Page 10
fig. 15
Installation, hydraulic
4.3 Notes on Installation on Delivery Side
IMPORTANT
Do not exceed permissible nominal pressure! Otherwise the pump may be damaged!
fig. 13
Provide an overpressure facility if the permissible pressure in the pump head can be
exceeded, e.g. by closing a shut-off element or a blockage in the line:
•Install overflow valve in the delivery line or
•use an overflow valve integrated in the pump housing (depending on type, refer to
data sheet of the type of pump used).
The following points must be observed with regard to the overflow line when using an
overflow valve:
•Route the overflow line with a drop into the supply tank under atmospheric pressure
or into an open runoff channel.
•Connect the overflow line to the intake line, however, only if there is no check valve in
the intake line.
IMPORTANT
Do not use a non-return check valve on the intake side for the overflow return as it may
cause the intake line to tear off.
fig. 14
IMPORTANT
Cut off the return flow from the main line!
Otherwise unwanted mixing in the metering line can occur.
•Install the metering valve at the injection point.
IMPORTANT
Dampen pulsation by installing pulsation dampers if
•low-pulsation delivery flow is required for process reasons;
•acceleration forces have to be reduced due to the geometry of the piping system.
The following can occur if acceleration forces are not dampened
•Fluctuations in delivery, metering faults, pressure surges, valve knocking and wear
as a result of cavitation on the intake and delivery side of the pump.
•Mechanical destruction of pump, leakages and knocking of valves as a result of the
permissible maximum pressure being exceeded on the pump delivery side.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr10

ProMinent® ProMinent®Page 11
Installation, hydraulic
fig. 16
*
PD
Pulsation damper in delivery line
(refer to section 5.3)
fig. 17
*
PD
Pulsation damper for free outlet:
•Install pressure control valve or metering valve at end of metering line.
Pusation damper without trails
(e.g. together with nozzles):
fig. 18
*
PD
•Interlock the solenoid valve electrically with the voltage supply of the metering pump.
* Accumulators without diaphragm: fit a vent valve
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr11

ProMinent® ProMinent®
Page 12
Installation, hydraulic
4.4 How not to install pumps
IMPORTANT
Intake line cannot be bled
fig. 19
•Air pocket in intake line.
Pulsation damper not effective
fig. 20
PD 2
1
•Arrangement of pulsation damper (2) and pressure retension valve (1) incorrect.
fig. 21
Siphon effect
fig. 22
Admission pressure on intake side too high
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr12

ProMinent® ProMinent®Page 13
Installation, hydraulic
4.5 Special Notes on Installation
IMPORTANT
Avoid overloading by positive pressure difference between delivery side and intake side:
fig. 23
•Install end of delivery line higher than the liquid level in the intake tank.
or:
fig. 24
•Install the discharge line outlet of the pump such that its position is higher than the
level of liquid in the chemical storage tank
or:
fig. 25
•Install pressure control valves in the pump delivery line.
IMPORTANT
Ensure constant pressure in the intake line!
Irregular pump flow can occur if the pressure from the take-off line or the intake tank
is transmitted.
fig. 26
•Ensure constant supply height when pump intake is from pressurized lines!
fig. 27
•Ensure constant supply level if intake is from high supply level!
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr13

ProMinent® ProMinent®
Page 14
Installation, hydraulic
fig. 28
•Avoid siphon (suction) effect when metering into a main line under vacuum:
Install pressure control valve (DHV-SR) or metering valve in the metering line!
NOTE
When metering suspensions it is necessary to flush the pump head in order to avoid
deposits forming
•as intermittent flushing or
•flushing after switching off the pump.
IMPORTANT
Switch off metering pump before flushing!
Maximum permissible flushing pressure: 2 bar
Manual flushing device
Flushing water
Flushing device
fig. 29
Automatic flushing device
Flushing water
Timer
autom. flushing device
fig. 30
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr14

ProMinent® ProMinent®Page 15
Installation, hydraulic
5Installation, electrical
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
5.1 Motor
IMPORTANT
•Connect electric motor in accordance with VDE regulations as illustrated in the circuit
diagram provided.
•Check that the mains voltage and frequency agree with the values specified on the
motor ratings plate.
•Provide corresponding motor protection devices in order to protect the motor from
overload (e.g. motor protection switch with thermal overcurrent release).
Fuses are not motor protection devices!
•The specified rated motor output applies at a maximum ambient temperature of 40 °C
and installation altitudes below 1000 m above sea level.
The motor output will be reduced if these values are exceeded (refer to VDE 0530).
•Ensure unobstructed supply of cooling air!
•Installation in wet rooms or in the open:
왘Arrange terminal box such that the cable lead-ins point downwards (can be taken into
account when ordering).
왘Select PG screw glands suitable for the supply line, use reducer if necessary.
Seal cable lead-in well otherwise all other measures will be of little use.
왘Apply sealing compound to PG screw glands and thread of dummy plugs, firmly tighten and
coat once again with sealing compound.
왘Thoroughly clean sealing surfaces of terminal box and terminal box cover before re-
installing.
Seals must be bonded on one side.
After a longer operating period, replace brittle seals by new ones.
Different types of motors are used depending on the application and required output.
ProMinent will send you the motor data sheets for the desired motor versions on request.
Motors connected to three-phase AC network
Three-phase squirrel-cage motor
- circuit circuit
-
L1 L2 L3 L1 L2 L3
W1
U2 V2
V1U1
W2
W1V1U1
U2 V2W2
Low voltage High voltage
fig. 31
Example:
Specified rating 230/400 V
Three-phase network available 400 V:
Correct motor connection Y-circuit
Direction of rotation reversal: Interchange 2 supply lines
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr15

ProMinent® ProMinent®
Page 16
Installation, hydraulic
Pole-changing three-phase AC motor (2 speeds in Dahlander circuit)
When changing over speed with pole selector switch, the star bridge 1U-1V-1W is realized
externally (in switch).
L1 L2 L3
W1
V2 W2
V1 U1
U2
L1 L2 L3
W1V1U1
V2 W2U2
Low speed
High speed
fig. 32
Motors connected to alternating current network
Any three-phase AC motor can be operated in conjunction with a corresponding running
capacitor on the alternating current network. However, care must be taken to ensure that the
starting torque is only approx. 30 % of the rated torque.
Three-phase AC motor with running capacitor (Steinmetz circuit)
L1 N
CB
W1
V2W2
V1U1
U2
fig. 33
Motors with electronic speed adjustment
Refer to the circuit diagram of the control system for connection of the motor if electric motors
are driven by electronic control devices, e.g. three-phase AC motors by frequency converters or
DC motors by thyristor controllers.
External fans
IMPORTANT
For motors with separate cooling fan (identification code feature “R“ or “Z“), a separate
power supply is used for the separate cooling fan!
Actuators/servomotors for stroke length adjustment
Electrical connection of the motors is shown on the enclosed terminal connection diagram and
on the connection diagram provided on the inside of the housing.
IMPORTANT
Stroke length adjustment/control drives must only be operated with the pump running!
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr16

ProMinent® ProMinent®Page 17
Start-Up
6Start-Up
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
IMPORTANT
•Based on state-of-the-art technology, the manufacturer carefully selects the materials
for parts coming in contact with the medium as specified by the customer.
The manufacturer shall not be liable for any damage caused by metering other media
or media which has been modified with regard to its properties (concentration, density,
temperature, additives, impurities etc.).
•Only specially trained personnel are permitted to operate the metering pump.
The operator must ensure by applying appropriate accident prevention measures that
operating personnel are not endangered under given operating conditions (pressure,
temperature, aggressivity etc.).
•Refer to the information provided in the product-specific operating instructions.
•Before starting up, check correct connection of the drive motor as well as the
corresponding additional equipment!
•Check intake and delivery lines for leaks!
•Check whether necessary flushing lines are connected!
•Provide suitable type of safety overflow valves in all delivery lines!
왘Bleed delivery side:
Switch on pump and run at 100 % stroke length until liquid end is full.
Switch off pump.
왘Close bleeder on delivery side.
Pump is now ready for operation.
왘Open shut-off valve in metering line, operate pump.
왘Check cut-in pressure of overflow valve.
왘Check delivery capacity and correct if necessary.
IMPORTANT
•If a compressed air vessel is installed on the delivery side, vent at regular intervals!
•Ensure the correct gas admission pressure (approx. 60–80 % of the mean operating
pressure).
•Observe the information provided in the operating instructions of the frequency
converter if using pumps with speed control.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr17

ProMinent® ProMinent®
Page 18
Maintenance/Troubleshooting
7Maintenance
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
IMPORTANT
•Refer to notes in product-specific operating instructions!
•If metering pumps are sent for repair to the manufacturer or a ProMinent dealer,
clean all parts which come into contact with the medium before shipping.
Essentially, maintenance is restricted to checking the metering capacity and for leaks.
Diaphragm failure:
왘Change diaphragm as described in Section “Diaphragm-type metering unit” in the
product-specific operating instructions.
Impermissibly high leakage from piston-type liquid ends:
왘Replace packing as described in Section “Piston-type metering unit“ and “Notes on packing
seal” in the product-specific operating instructions.
Replace packing as described in Section “Piston-type metering unit” and “Notes on packing
seal” in the product-specific operating instructions. In order to maintain the delivery unit, we
recommend to keep a spare parts kit in stock, consisting of the wearing parts such as
diaphragm or piston packing and the necessary valve parts, balls and seals. We can quote a
spare parts package for your metering system.
8Troubleshooting
WARNING
•Explosion-proof pump only: it is essential that you observe the contents of section 9!
IMPORTANT
Follow instructions in the product’s operating manual!
Fault Cause Corrective measures
No metering pump intake Suction head too high 왘Install pump closer to
(during initial operation) intake tank
Backpressure in metering line 왘Eliminate backpressure
(delivery side) (e.g. via bypass line)
No metering although drive is Stroke setting 0 % 왘Increase stroke length
running (after longer period of ( 씮100 %)
operation) Intake tank empty 왘Top up medium and restart
Gas cushion in intake line and 왘Bleed intake line, check for
liquid end leaks and restart
Metered liquid emerges from Diaphragm defective 왘Replace diaphragm
leakage opening of delivery
unit
Loss of metering capacity Wearing parts in valves 왘Replace wearing parts
(after longer period of defective
operation)
Deposits in valves 왘Clean or replace valve parts
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr18

ProMinent® ProMinent®Page 19
Other important considerations for dosing pumps in ex-zones
9Other important considerations for dosing pumps in ex-zones
9.1 Application in accordance with regulations
•In areas of operation where there is a risk of explosion, the pump may only be operated with
the appropriate nameplate and the corresponding EU declaration of conformity for areas of
operation where there is a risk of explosion in accordance with directive 94/9/EU concordant
with the European directives. The explosion group, category and protection system stated
on the label must be equivalent to or better than the conditions specified in the designated
area of application.
•Any other application or modification is prohibited!
•Pumps which do not have the appropriate nameplate and the corresponding EU declaration
of conformity for areas of operation where there is a risk of explosion may under no
circumstances be operated in areas of operation where there is a risk of explosion.
9.2 Safety instructions
WARNING
•When installing and operating equipment in ex-zones in Europe, you must observe the
European directive 99/92/EU (ATEX 137). In Germany this is incorporated within the
occupational safety regulations and German regulations on hazardous materials.
•You must observe the European standards EN 1127-1, EN 60079-10, EN 60079-14, EN
60079-17 as well as EN 50020 and EN 50039 for intrinsically safe electrical circuits. (In
Germany, these standards are partly covered by VDE 0165 and VDE 0118.)
•For countries outside the EU, you should observe the appropriate national directives.
•Installations in ex-zones must be checked by a “recognised qualified” person. This
particularly applies to intrinsically safe electrical circuits.
•The information detailed below chiefly refers to particular features found in ex-zones. It does
not replace the standard information in the operating instructions manual!
•When cleaning plastic components, you should ensure that no electrostatic charge is
created through excessive friction. - see warning sign
9.2.1 Safety equipment
WARNING
•Please adhere to the following safety instructions for pumps containing non-
conductive components.
ATTENTION
Because of electrostatical flammable
danger, use damp cloth only to wipe
off plastic parts !
9.2.2 EU declaration of conformity / certification
The EU declaration of conformity is attached for the whole pump (also for pumps without
motors).
The EU declarations of conformity, EU design inspection reports and the operating instructions
manuals for the individual components are attached.
9.3 Assemble
No specific notes.
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr19

ProMinent® ProMinent®
Page 20
Other important considerations for dosing pumps in ex-zones
9.4 Installation, hydraulic
WARNING
•Dosing pumps used in ex-zones must be fitted with an appropriate safety relief valve
on the output side of the dosing pump (serves to protect against overheating resulting
from overloading and arcing due to interruption of drive components as a result of
overloading.)
•Piston dosing pumps are designed for use in temperature class T3. The pumps can be
used in T4 if they are fitted with an additional flow controller on the output side (serves
to protect against a rise in temperature resulting from dry running) or with an
appropriate temperature controller.
•Similarly, dosing pumps whose diaphragm is driven hydraulically must be fitted with a
temperature or flow controller for use in T4. (The internal relief valve protects against
overheating in the event of extended operation.) Without this protection, temperature
class T3 is applicable.
•With different temperature classes being available for different components, the
possible application of the entire pump corresponds to the component with the lowest
temperature class.
•Combustible media may only be extracted using stainless steel dosing heads. In
exceptional circumstances, where stainless steel is not available, PTFE with carbon
can also be used. Our TT designs are manufactured from this conductive synthetic
material. The operator should take special care in this instance due to reduced
mechanical stability.
•Piston dosing pumps may not be used for combustible media. Where it is impossible to
avoid the use of piston pumps, additional control measures should be implemented to
ensure the required level of safety. This includes flow controller + piston leakage
controller, and an additional temperature controller on the dosing head for media with
critical friction characteristics.
•Hydraulic diaphragm pumps are perfectly suitable, however it is compulsory to have
those whose construction includes diaphragm-rupture controller Ex “i” and flow
controller.
•Diaphragm pumps with mechanically linked diaphragm, e.g. Zt. MTMa..., TZMa...,
Sigma’s S1Ba..., S2BaHM..., S3Ba: no additional measures are required, although it is
essential to use the construction with diaphragm-rupture indicator, in the Ex “i”
construction.
•Installations in ex-zones must be checked by a “recognised qualified” person.
•The following applies to all dosing pumps when metering combustible media: Start up
and drain only under the supervision of an appropriately qualified person.
•Observe the relevant national directives with regard to installation!
BA_MOZ_015_05_06_GB.p65 24.05.2006, 12:07 Uhr20
