Pronto PP18 User manual

!
!
!
!
!
Manual of PP18
(450Mbps 5.8G Outdoor CPE)
!
!
!
!
!
!
!!!!!!!!
This is the manual of 450Mbps 5.8G outdoor CPE, which will approximate guide
you how to set and apply the outdoor CPE, it provide a convenient graphical
interface for network construction and maintenance person, as well as a user
through a simple and accurate operation, and configuration management of the
CPE.
!
!
!
!
!
!
!
!
!
!
!

!
I. Connection and Power Supply
I. Port Connection and power supply
Instruction of different port：
!
!
!
!
P1. CPE Port Connection
Please use a power supply of 12V DC adapter or 24V POE adapter, WAN / LAN port
is the PoE Port.
!
Reset:
There are two ways to reset the CPE:
1. CPE Manage page: Click “Management”, then “Save/Reload Settings”, then click
“Reset Settings” to finish the CPE Reset.
!
P2. CPE Reset
Pay Attention
Pls make sure the CPE’s power supply is normal, or the CPE will be damaged and
can’t rebootz

2. Press the Reset Button on CPE more than 15 seconds, then release, the device
will reboot and restore to factory settings
!
The connection way of CPE, PoE Router:
!
!
!
!
!
!
!
!
!
P3. Connection diagram of CPE and PoE Router
!
!
II. Login
1. Connect the CPE with computer as P2 picture
2. Configure the PC’s local connection IP address as 192.168.1.X (X is number
from 2 to 254), subnet mask is 255.255.255.0, follow P4 and P5 to finish.
!
P4. Setting of computer’s IP addresses P5. Setting of computer’s IP address!
Pay Attention
Incorrect Connection or the use power adapter and PoE adapter not from our
factory, the CPE will be damaged

3. Input 192.168.1.1 into IE browser, then pop up the login page, the default login
user name: Admin, Passwords: pronto, please do following P5
!
P6. Login
After login, then P6 Device Status will be showed:
!
P7. Device Status
There are four operation mode showed on this page:
Gateway mode, Repeater Mode, AP Mode and WISP Mode;
And the default operation mode is Wireless AP.

!
III. Quickly Configure CPE
!
Gateway Mode:
Click “Gateway Mode” under following picture and choose the right WAN access
type, then input the right SSID, Channel, key as like.
!
!
P8. Gateway Mode
WiFi Repeater and Station operation configuration
Login the Web management page, click “Repeater Mode”, then “Scan AP”
P9. Repeater Mode

Select the AP’s SSID want to bridge, take test-3200-5G for example, Select AP
!
!
P10. Select AP
!
Input the AP’s key, and apply changes, then the outdoor CPE in WiFi repeater.
!
!
P11. Repeater Mode
!
Instruction
If your computer can’t pop up this window, pls check your IE explorer and see whether it is blocked
already. And if this CPE can’t scan any SSID, pls check if there are 5G wireless signal.

!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
AP Mode
Plug and Play to transmit wireless signal for wireless end users form wired
networking. In this part, user can mark the AP’s location and name for easy
problem checking. Then can change SSID, Key, Channel as request.
!
P12. AP Mode
!
WISP
In this operation mode, user should confirm the WAN access type at first, then set
the SSID, key, Channel as request.
!
P13. WIPS Mode

Advanced Settings:
I. System Status
Click “Advance Settings”, will show system status, such as firmware version, build
time, System uptime...
!
P14. System Status
!
Click 5.8GHz Wireless Status, will show CPE’s WLAN Status, Signal Strength,
SSID...
!
P15. 5.8GHz Wireless Status
!

!
If want to check LAN status, please check following picture
!
P16. LAN Status
!
II. Operation Mode:
Set operation mode manually, choose the right operation mode, then apply
changes. The function of this part will be same as Quick Setup step.
!
P17. Operation Mode
III. 5.8GHz Repeater:
In this part, main function is WiFi repeater, bridge exist wireless AP, then set
security as you like.
!
P18. 5.8G Repeater

IV. 5.8G Wireless:
In this part, users can managed the CPE’s SSID, password, channel, bandwidth,
security method, firewall, virtual AP.......
!
P19. 5.8GHz Basic info
How to set 5.8G Virtual AP, please take 1,2,3,4,5 steps
!
P20. 5.8GHz Virtual AP

!
How to allow/deny the end user list to access into this CPE.
!
P21. 5.8GHz Access Control
!
!
P22. 5.8GHz Advanced
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
IV.Network Setting
LAN Interface Setup mainly showed as follow:
!
P23. Network Setting

!
V. Management
In this part, user can set Time zone, show Log info, upgrade firmware, change
login user name and password.
!
P25. Management
VI.Upgrade Firmware
Pls click Upgrade Firmware, then browse and choose the firmware should upgrade,
then click upgrade to upgrade the firmware.
!
P26. Firmware Upgrade
After finish firmware upgrade, please click Save/Reload Settings, then reset
settings to default.
!
After that, the firmware upgrade is finished.

!
VII. Share Internet and Obtain IP address automatically
Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server
address automatically as following picture showed. The computer will obtain the
IP address from router or base station to get Internet.
!
!
!
Trouble Shooting:
!
F1: The Failure phenomenon and solution
Failure phenomenon
Solution
SYS Indicator off
Please make sure the PoE module connection is
right. POE Port connect with CPE, LAN port
connect with computer
Can’t scan the wireless AP
Scan it several times more；
Make sure there are 5G signal existed.
Reset the CPE, scan it again after CPE restart；

!
Failure phenomenon
Solution
Can’t land to CPE through
Web page
Please check the IP address of computer and
CPE to see whether they are in same
networking segment, The method is click
“start”-“Run” input “cmd”，ping 192.168.1.1 to
test the CPE connectivity.
Reset CPE and load it again;
Please make sure the IP address 192.168.1.1 is
not occupied by other device in CPE’s
networking;
Check computer and cable problem,
recommend to use 10/100M UTP unshielded
cable;
Clean up Arp binding from “Start”-“Run” input
“cmd” arp –d
Clean the IE Brower’s temporary files and
Cache file。
CPE can’t connect with AP
（the status display
unconnected）
Try to scan the available wireless networking
again；
Make sure the CPE’s wireless standard
（11b/g/n, 5.8G）is correct；
The Security and passwords are matched
between CPE and AP；
The signal strength of AP is too weak to
connect, should be more than -75dBm；
The connection of CPE and
AP is success, but the
computer can’t share
internet
Please Check the computer’s IP address and
DNS setting. If it is dynamin, set the network
card as automatically obtain. If it is static IP,
Please contact with ISP for correct IP address
and DNS address.
How to Reset CPE
Press the “Reset” button more than 15 seconds
after power on. The CPE will restore factory
default after the CPE restart.
