Propello Nectar User manual

6, Sarat Chatterjee road
Kolkata - 700 089, Toll Free No.: 1800 121 0600
Email: [email protected]
www.propello.in
CIN: U74900WB2009PTC137818
USER MANUAL FOR

Contents
About Crystal/Nectar RO 2
Table of Chemical Constituent 3
Principle of Osmosis and Reverse Osmosis 4
Salient Features 5
How does Crystal/Nectar RO works 6
Installation and Usage 7
Problems, Check Points and Solutions 8
System Warranty 9
Technical Specifications 10
Warranty Card 11-12
Innovations
for happiness

The Table below gives an insight on how chemical impurities can impact your health
Total Hardness asCaCO3 200 Encrustation in water supplying
mg/L, max structure and adverse effects on
domestic use
Total dissolved solids 500 Beyond this palatability decreases
and may cause gastro intestinal
irritation
Iron (Fe) mg/L, max 0.3 Beyond this limit taste,
appearance are affected, has
adverse effect on domestic uses
and water supplying structures.
It also promotes iron bacteria
Chlorides (Cl) mg/L, max 250 Beyond this limit taste corrosion
and palatability are affected
Nitrate (NO3), mg/L, max 45 Beyond this methaemoglobinemia
takes place
Fluoride (F) mg/L, max 1 Fluoride should be kept as low as
possible. High luoride may cause
uorosis
Mercury (Hg) mg/L, max 0.001 Beyond this limit the water
becomes toxic
Arsenic (As) mg/L, max 0.01 Beyond this limit the water
becomes toxic
Lead (Pb) mg/L, max 0.01 Beyond this limit the water
becomes toxic
Chemical
Constituent
Requirement (Acceptable
limit)1510500-2012 Drinking
water specification
Undesirable effect outside
the desirable limit
Table of Chemical Constituent
Congratulations and a warm welcome to the World of Propello Water
Purification Systems.
The Crystal/Nectar RO is a result of our constant endeavor to provide
100% Pure and Healthy drinking water.
The Crystal/Nectar RO water purifier uses Reverse Osmosis Technology
to remove all kinds of impurities, Chemicals and Micro-organisms. This
technology also removes the hardness of water. The Crystal Alkaline RO
helps to improve PH level.
The Crystal Alkaline purifier uses Alkaline Cartridge to maintain the
necessary amount of minerals in the water .With the use of RO Technology
and other filtration stages the Crystal Alkaline RO water purifier ensures
that you get the purest drinking water.
On the other hand Nectar RO has Copper Cartridge which ensures the
goodness of copper, calcium and magnesium in water.
Here's wishing you and your family a happier and healthier life.
With Warm Regards,
Propello Family
3

• Suitable for mounting or counter-top installation.
• Purification by RO and UV Technology.
• 10 litre storage tank capacity.
• External SMPS Adaptor for water protection
• RO membrane fused inside membrane housing to prevent tampering.
• Push-fit components for leak-proof & maintenance free performance.
• Fully automatic operation with auto-on and auto-off.
• ABS construction for corrosion-free lifespan.
• Equally suitable for water from all sources
• Crystal/Nectar Reverse Osmosis System provides close to 100% removal of
almost all unwanted and harmful substances
• LPS prevents the pump from dry running in case the overhead tank is empty
• Automatic Water Level Sensor controls the water level automatically and shuts off
the pump when the storage tank is full
RO Technology
Unique RO Technology membrane removes excess TDS, blocks dissolved impurities and
chemical contaminants, while retaining essential minerals in the drinking water.
Alkaline Cartridge/Copper Cartridge:
• Make the water nutrient, by providing essential minerals.
• It provides healing effects and improves health immunity
• Enhance the taste of water.
• It balances the pH level of your drinking water.
• Helps to maintain Calcium & magnesium in the water besides enchancing copper ions.
• It helps in protecting the storage tank water from external bacterial contamination. .
Total Protection:
Eliminates tough new age contaminants like lead, pesticides and heavy metals from water.
It also ensures that water is free from disease-causing bacteria, virus and protozoa.
Large Storage Capacity:
It comes with a 10-litre in-built storage tank. Thereby ensuring purified water on tap, all the
time.
Salient Features
5
What is Osmosis?
In living cells movement of liquids takes place through
a semi-permeable membrane separating solutions of
different concentrations. Passage of water from weak
solution to through a semi permeable membrane is
called osmosis. Osmosis is a vital mechanism in the
transport of fluids in living organisms, for example,
uptake of water from the earth and also transport of
water between cells in case of plants.
Principle of Osmosis and Reverse Osmosis
What is Reverse Osmosis?
Reverse Osmosis (RO) is when osmosis is reversed by
applying external pressure to the more concentrated
(polluted side). The water is forced through a synthetic
semi permeable membrane that allows only water
(H20) molecules. When pressure is applied to the
concentrated solution, the water passes through the
membrane and the rest is left behind, to be drained
out. In the Reverse Osmosis System, water is pushed
under high pressure through a very fine membrane of
pore size 0.0001 micron. So the water that comes
through the membrane filter is free from total dissolved
solids, hardness, micro-organisms, chemicals, other
metal contaminants, particles and VOC.

7
The 8 stages Crystal/Nectar RO are as follows:
Stage Component Function
1 Iron filter Helps in remove dissolved iron from water
2 Pre-filter yarn removes suspended impurities likr dirt mud,
polypropylene rust, sand etc.
3 Pre-carbon Filter Silver Removes excess chlorine, bad odour, colour,
impregnated Activated bad taste and organic impurities
Carbon
4 Sediment Filter Melt Removes fine particles such asdirt, dust,
blown Yarn mud and sand
polypropylene
5 Reverse Osmosis Membrane Removes TDS, hardness, luoride,
Thin Film Composite (TFC) pesticides, VOC, heavy metals like lead,
0.0001 micron mercury, cadmium & Arsenic etc.
Removes micro-organisms like bacteria,
viruses and protozoan cysts.
6 Alkaline Cartridge/ • Make the water nutrient, by providing
Copper Cartridge essential minerals.
• It provides healing effects and improves
health immunity.
• Enhance the taste of water.
• It balances the pH level and copper ions
of your drinking water.
• It helps in protecting the storage tank
water from external bacterial
contamination.
7 UF Keeps the water sparkling clean
8 TDS Controller Helps to maintain TDS of output water
How does Crystal/Nectar RO works
Can be used for:
Watering plants.
Cannot be used for:
Cleaning utensils, daily household cleaning, washing clothes and drinking
purpose
Check points before calling our Service Department
Before you panic and call our service department, here are some simple
steps to be followed. Most times you’ll find that one or a combination of
these will solve the problem/s. When these steps at your end fail then
immediately call our helpline/service department and we will take up your
case on priority.
Thank You.
Installation and Usage
Install it in a dry ventilated place
• Keep it away from direct sunlight or below freezing temperatures.
Connect it only to cold tap water.
• Filters can be damaged if connected to hot tap water.
• Make sure that the tap water pressure is max. 2.0 kg/cm2. If the tap
water pressure you receive is higher than the maximum specified, the
use of a pressure reducing valve is recommended. The above
accessory is available with our company at an additional cost.
• If not, water might fow back into the purifier.
• Make sure that the purifier is installed within the distance of 1m (max)
from the tap water supply.
• This purifiers for 230V only so make sure that you connect to a 230V
power outlet.
• Do not install the purifier in a place where rainwater could leak into it
(Outdoor etc.).
Water is a rapidly depleting source. It is our moral responsibility to
ensure that water is recycled as much as possible.
The water fushed :

9
Problem Check Points Solutions
Water tastes bad 1. Is the storage tank clean? If not then dispose off the tank water
and clean the tank
2. Have you kept the purified If yes, then dispose off water
water in the tank too long? and clean the tank.
3. Is it time to change filters? Call our service department to
change filters.
Too much or too little water 1. Is the tap water valve closed? Open the tap water valve.
is being purified 2. Is the tap water temperature too low? If so, the amount of purified
water will be reduced.
3. Filters may be clogged or damaged. Call our service department and
change filters.
4. Pump or SV has failed. Call Service department to
rectify/change
Water doesn't come out. 1. Is there water in the tank? Check the storage tank.
If tap water is not supplied,
2. Is tap water supplied? close the tap water valve.
3. Is the tap water valve closed? Open the tap water valve.
4. Not sure what is wrong. Call our service department.
Water is leaking 1. Is water coming out of the After checking the inside of the
top cover or the purifier? product, close the tap water valve,
unplug the power cord and call our
service department.
Problems, Check Points and Solutions
Warranty is the responsibility of the company.
This product is warranted for one year from the date of sale against all defects except
plastic components, rubber and their assembly there of. In the event of any complaint,
please contact your dealer or the nearest company service center.
Toll free number 1800 121 0600
This warranty is valid only when...
• The application has not been opened or tampered with, by any unauthorized person.
• The unit is brought to and taken from the service center at the customer's cost and risk.
• The guarantee card or cash memo duly signed by the authorised dealer are presented
with the complaint.
• The application has been installed, used and maintained in accordance with the
instruction manual
This warranty does not apply for...
• Damage due to chipping peeling, plating, and denting.
• Breakage or damage to components of Bakelite, urea, ABS, SAN and such plastic
material, rubber parts and cord.
• The items that are subject to normal wear and tear due to operations.
• Damage resulting from accidents, mishandling or negligence on part of customer.
System Warranty

11
MODEL NAME
PURIFYING TECHNOLOGY
APPLICABLE TDS RANGE IN INPUT WATER
INSTALLATION TYPE
PURIFIED WATER FLOW RATE
STORAGE TANK CAPACITY
TDS REDUCTION
% WATER RECOVERY
NET WEIGHT
OPERATING INPUT
RO MEMBRANE
MEMBRANE TYPE
BOOSTER PUMP VOLTAGE
INPUT WATER TEMPERATURE
INPUT WATER CHLORINE
INPUT WATER IRON
INPUT WATER TURBIDITY
CRYSTAL
REVERSE OSMOSIS (RO)
WITH ALKALINE ENRICH
TECHNOLOGY
UPTO 1500 mg/L
TABLE TOP AND
WALL MOUNTING
10 L/hr
10 LITERS (approx)
90% (approx)
27% (approx.)
9 KGS (approx)
VOLTAGE 230V AC/50HZ
75 GPD
THIN FILM COMPOSITE RO
24V DC
5 DEGREE C –45 DEGREE C
0.2 mg/L (max)
0.3 mg/L (max)
15 NTU (max)
NECTAR
REVERSE OSMOSIS (RO)
WITH COPPER ION
TECHNOLOGY
UPTO 1500 mg/L
TABLE TOP AND
WALL MOUNTING
10 L/hr
10 LITERS (approx)
90% (approx)
27% (approx.)
9 KGS (approx)
VOLTAGE 230V AC/50HZ
75 GPD
THIN FILM COMPOSITE RO
24V DC
5 DEGREE C –45 DEGREE C
0.2 mg/L (max)
0.3 mg/L (max)
15 NTU (max)
Note:
* Technical Specifications are subject to change without prior notice.
* Flow rate and other parameters depend on the input water pressure and condition of the filters.
Technical Specifications
WARRANTY CARD
Name of Customer:
Contact No: (R) (M)
Postal Address:
Date of invoice: Date of installation:
Model No: Unit No:
Membrane No: Pump No:
Dealer Stamp & Sign:
Signature of sales person Customer signature

Dear Customer,
Congratulations! You have become a proud owner of Propello Water Purifier, the model mentioned
below is covered under warranty against all manufacturing defects for a period of 12 months from the
date of purchases subject to the conditions mentioned overleaf.
Model:
SI No.:
Bill No.:
Purchasing Dealer's Name with signature & seal:
Warranty Terms & Conditions
The goods are warranted against all manufacturing defects for a period of 12 months from the date of
purchase subject to the following conditions:
A. The warranty does not cover items that are subject to normal wear and tear due to operations.
B. Defective purifier with valid warranty card and original bill to be produced to the authorized service
franchise or service dealer by the customer's own cost during working hours.
C. This warranty does not cover defects as result of accident/ damage due to transit or misuse.
D. This warranty is not applicable if the damage is a result of attractions, unauthorized repairs,
tampering or alteration of any part, unauthorized installation or damages caused as a result of natural
calamity, riots or any unnatural circumstances.
E. Consumable items will not be covered under warranty.
F. This warranty is valid only when it bears the signature and stamp of the authorized dealer.
G. The defective item or component will be replaced / repaired at the sole discretion of Propello
Innovations Pvt. Ltd. And the replaced parts will be the property of Propello Innovations Pvt. Ltd.
H. This product is intended for domestic use and not for commercial use. The purified water is intended
for drinking purpose only and any other use such as bathing, washing etc. will lead to cancellation of
warranty.
I. All disputes are subject to Kolkata jurisdiction.
J. The machine has a limited purifying capacity designed only for drinking purposes the warranty will not
to be valid purified water used for other purposes.
Customer's Signature
WARRANTY CARD
Welcome to
Propello family
