Propur Inline connect fs10 Quick start guide

INLINE CONNECT FS10

Under Counter Water Filter System with

ProMax™ FULL SPECTRUM™ Filter Technology

Installation & Use Instructions

Package Contents

Filter housing, 2-3/4”port x 3/8” brass (lead free)

compression fittings installed in housing,

mounting bracket attached to housing, ProMax™

FULL SPECTRUM™ filter cartridge installed in

housing, 30” x 3/8” compression fitting flex hose and

filter cartridge replacement wrench

Tools and Hardware Required

Adjustable wrench, screwdriver, Teflon tape,

4 - screws for mounting bracket to cabinet, 1/2“ drill bit

when using optional faucet

System Specifications

•Overall height from bottom of housing to top of

bracket is 18.5”. Diameter is 7.25”

•Type of installation: Under counter – Inline or with

optional separate faucet - for cold water use ONLY

•Space Requirement: System requires minimum of 2”

below sump(housing) for filter replacement

•Maximum Working Pressure: 860 Kpa (125 psig)

NOTE: Should your water pressure exceed 80 psig,

install a pressure reducing valve before installing the

system

•Minimum Working Pressure: 137 Kpa (20 psig)

•Minimum Working Temperature: 5° C (41° F)

•Maximum Working Temperature: 38° C (100° F)

•Recommended Flow Rate: 0.2 – 1.0 gpm

•Contaminant Reduction: Refer to Lab Reports

•Filter Life Expectancy: Up to 1 year with inline

installation and up to 2 years with separate faucet

installation

•Replacement filter: PM-FS10-RF

1. Face Plate

2. Large Rubber Washer

3. Small Rubber Washer

4. Plastic Washer

5. Star washer

6. Steel nut

7. Quick connect fitting

8. 3/8” tubing

STANDARD INLINE SYSTEM

OPTIONAL SEPARATE

FAUCET KIT

Designed to fit under sink or in basement. Do NOT install where the temperature could fall below

freezing as damage could result. No power required. For use with cold potable water only.

READ COMPLETELY BEFORE INSTALLING OR USE.

SHOULD YOU HAVE QUESTIONS ABOUT INSTALLING YOUR PROPUR SYSTEM, PLEASE CONTACT TECHNICAL SUPPORT

AT 800-544-3533 X27 OR EMAIL [email protected] FOR ASSISTANCE.

CAUTION: Before beginning the installation, turn OFF the cold water supply under your sink or your house supply at the meter.

Open the cold water faucet to release any water pressure.

WARNING: Do not use water source that is microbiologically unsafe or of unknown quality without adequate disinfection before or

after the system. For specific health requirements, consult your healthcare professional.

Check and comply with any installation state or local codes that may apply.

Pr pur

WATER

PURIFICATION

SYSTEMS

T-Valve included. Shown in OPEN position

Install Filter Housing – see diagram A on page 3

1. Select a suitable location for the filter housing under the sink.

NOTE: Location should be reasonably accessible for filter replacement. When mounting housing to cabinet, leave a

minimum 2” space below sump/filter housing for removal of sump for maintenance and filter replacement and orientate to

match the desired flow direction.

DO NOT INSTALL where temperatures fall below freezing as damage to the system will occur.

NOTE: The flow arrow and IN/OUT are embossed on the top of the black plastic housing head. DO NOT reverse.

NOTE: Filter cartridge is pre-installed at the factory.

WARNING: Be sure to turn off your water supply or manual shut off valve for your cold water before proceeding with the

installation. If your plumbing does not include a manual shut off valve at the sink, we recommend one be installed before

proceeding.

2. Secure the bracket attached to the filter housing assembly to the side of the sink cabinet in the desired location.

Depending on your installation, use appropriate fasteners not supplied with your system. Be sure to securely mount the

housing using the 4 mounting holes as it will be heavy when full of water.

3. Remove existing flex hose connection at the cold water shut off valve and attach to the OUT side of your filter. Filter

housing requires a 3/8” compression fitting on the end of your existing flex hose.

4. Using the flex hose included with your system, attach one end to the IN side of the filter housing and the other end

to the manual shut off valve. The flex hose requires a 3/8” compression fitting.

MAKE SURE FITTINGS ARE TIGHTENED SECURELY. DO NOT OVER-TIGHTENED.

GO TO STEP 3.0 – START-UP to complete the installation.

2.0 Inline Installation With Separate Faucet (Optional Kit) –

See diagram B on page 3 for Optional Faucet

Begin installation by following steps 1 & 2 in section 1.0 above. Then continue with 2.0 below.

1. Disconnect existing flex hose connected to your manual cold water shut off valve or cold water supply.

2. Install the T-valve (included) as shown in Diagram B on page 3. Requires 3/8” compression fitting size.

3. Re-connect existing flex hose to the outflow side of the T-valve. Other end should remain connected to existing faucet.

4. Prepare a piece of 3/8” plastic tubing (included) to fit between the quick connect push fitting on the T-valve and the

IN side on the water filter housing - ADD additional 1-1/2” to tubing length as tubing will travel about 3/4” into each

fitting to seat properly.

5. Insert one end of plastic tubing into the quick connect on the T-valve - press in firmly.

6. With other end of tubing, remove nut and compression washer from filter housing. Slide nut first onto tubing, then slide

compression washer onto tubing. Insert tubing firmly into brass fitting (lead free) on housing. Slide compression washer

and nut onto threads and begin to tighten nut using wrench. Tighten securely. DO NOT over tighten.

7. Select a suitable location for the drinking water faucet as close to the sink as possible allowing convenient space

under the sink for assembly. The spout of the faucet should be able to reach the sink. A 2” flat area is required

to mount the faucet. Check for clearance, then drill the sink top with a 1/2” bit to accommodate the faucet inlet pipe.

8. See Optional Faucet details and diagram on page 1 for installation on the faucet through the sink top.

9. Remove the plastic quick connect adaptor, the brass nut and the lock washer from the inlet pipe.

10 .Insert the faucet stem through the sink top to seat the rubber washer.

11. Replace the lock washer and brass nut and tighten firmly with a wrench.

12. Attach the plastic quick connect to the threaded stem of the faucet using Teflon tape (not supplied)

13. Prepare a piece of 3/8” plastic tubing (included) to fit between the quick connect push fitting on the faucet and the

OUT side on the water filter housing - ADD additional 1-1/2” to tubing length as tubing will travel about 3/4” into each

fitting to seat properly. Insert end of plastic tubing into the quick connect push in fitting on faucet. Press firmly.

14. With other end of tubing, remove nut and compression washer from filter housing. Slide nut first onto tubing, then slide

compression washer onto tubing. Insert tubing firmly into brass fitting (lead free) on housing. Slide compression

washer and nut onto threads and begin to tighten nut using wrench. Tighten securely. DO NOT over tighten.

GO TO STEP 3.0 – START-UP to complete the installation.

1.0 Standard Inline Installation

1. Slowly turn on your water supply or manual shut off valve.

2. Check for leaks before proceeding

3. Press the RED button on top of the black housing head to allow trapped air out of the system.

4. Slowly turn on your cold water faucet.

5. Water should start flowing out of faucet.

6. Allow water to flow for a few minutes to flush out the system before using the water. Some residual particles may be

expelled during this flushing process. This is normal.

7. Your system is now ready for use.

3.0 START-UP

Minimum 2” space needed between bottom

of filter housing and base of cabinet

A. Existing manual cold water shut off valve.

If there’s not an existing valve, we recommend

one be installed.

B. Braided flex hose with 3/8” compression

fittings (included) attaches to IN side on

housing and outflow of manual shut off valve

C. Filter housing/sump

D. Existing braided flex hose attaches to OUT

on filter housing and cold water faucet

YOUR INSTALLATION MAY REQUIRE ADDITIONAL

HARDWARE NOT INCLUDED WITH THE SYSTEM.

DIAGRAM A

Minimum 2” space needed between bottom

of filter housing and base of cabinet

DIAGRAM B

A. Manual cold water shut off valve.

If there’s not an existing valve, we recommend

one be installed.

B. Shutoff T-valve for filter system (included)

3/8” male and female compression fitting with

3/8” quick connect for tubing

Handle shown in OPEN position

C. Filter housing/sump

D. Plastic tubing

YOUR INSTALLATION MAY REQUIRE ADDITIONAL

HARDWARE NOT INCLUDED WITH THE SYSTEM. 3

3.0 How To Replace The FS-10 Filter Cartridge

1. Turn off the water supply or manual water shut off valve. Turn on faucet to release water and pressure.

2. Press the RED button on top of the black housing head to release any remaining pressure in the filter housing.

3. Using the supplied wrench ONLY, slowly unscrew the filter housing sump by turning counterclockwise until removed.

4. Drain water from filter housing/sump over sink and remove old filter cartridge by gently pulling it out

from the housing and discard. Make sure inside of sump is clean. OK to wash with warm, soapy

water and rinse well.

5. Insert new filter cartridge into housing. Make sure cartridge end with washer is installed facing

upward in housing.

6. Lubricate the O-ring and sump threads with food grade silicone grease.

7. Using the supplied wrench ONLY, screw housing/sump back onto filter head clockwise securely.

Hand tighten, firmly, being careful not to cross thread. DO NOT over tighten.

8. Slowly turn on water supply or manual water shut off valve.

9. Open the cold water faucet downstream to release any air.

10. Turn off faucet and press RED button on top of the black housing head to allow any trapped air out

of the system.

11. Slowly turn on your cold water faucet. Water should start flowing out of faucet.

12. Check for any leaks.

13. Allow water to flow for a few minutes to flush out the system before using the water. Some residual

particles may be expelled during this flushing process. This is normal.

14. Your system is now ready for use.

1. How do I know when to replace my filter cartridge?

PROPUR™ LIMITED WARRANTY

Lincoln-Remi Group, LLC d/b/a Propur (“PP”) sells its products with the intent that they are free from defects. PP warrants to the original retail purchaser/con-

sumer when purchased from an authorized PropurTM dealer, that its products will be free of defects in material and workmanship under normal use for the

following periods beginning on the date of purchase: 2 year limited warranty on PropurTM Inline Connect FS10 series components excluding the filter element,

one (1) year for ProMaxTM FS10 filter element. PP will replace or repair any product, at its sole discretion, during the Warranty Period. Any damage caused by

misuse or abuse; accident; improper installation; dropped product; failure to provide recommended maintenance; transportation damage; neglect; environmental

conditions; or any other conditions whatsoever that are beyond the control of PP are excluded from this warranty. This express limited warranty shall be the sole

and exclusive warranty. ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES

OF MERCHANTABILITY, FITNESS OR FITNESS FOR ANY PARTICULAR PURPOSE OR ANY OTHER POTENTIAL OBLIGATION ON THE PART OF PP

WITH RESPECT TO PRODUCTS SOLD BY PP ARE DISCLAIMED. EXCEPT FOR ANY EXPRESS WARRANTIES, ALL PROPUR PRODUCTS ARE SOLD

“AS-IS”. PP shall not be held liable for any incidental, consequential or special damages of any sort whatsoever. The liability of PP is limited to the original retail

purchaser and to the repair or replacement of defective parts during the Warranty Period. No refunds will be given at any time. The liability of PP terminates

upon the expiration of the Warranty Period or transfer of product ownership. To obtain warranty service on your Propur product, mail the product with your dated

sales receipt as proof of purchase, postpaid, to the following address: Propur, 1200 Benstein Rd, Commerce Twp, MI 48390. NO C.O.D’s This warranty provides

you with specific legal rights. You may have additional rights which may vary from country to country. Because of individual country laws and regulations, some

of the above limitations and exclusions may not apply to you.

Attention CA, IA and WI Consumers In compliance with state law for CA, IA and WI, Propur™ water filtration products are sold and shipped to residents of these

states without any health related performance claims except for aesthetics including chlorine reduction, and improvement with taste, odor and sediment.
