WaterLogic WL500 - Sparkling User manual

WL500Manual Page23Revision4‐10‐2019
PROGRAMINGMENUANDSELECTIONS

Menu Options BriefDescription
ColdTempSet
3°‐12°C Thecoldtemperaturecanbesetbetween3°Cand12°Cor37°Fand54°F,
dependingonwhichunitsareselected(°Cor°F)intheF/Coption.
37°‐54°F Recommended/DefaultSettingis5°C/41°F.
HotTempSet
70°C‐95°C Thehottemperaturecanbesetbetween70°Cand95°Cor158°Fand
203°F,dependingonwhichunitsareselected(°Cor°F)intheF/Coption.
158°F‐203°F Recommended/DefaultSettingis87°C/189°F.
TempDisplay
Static ThedisplayindicatestheSTATIC(SETPOINT)temperature.Default
Ranging ThedisplayindicatestheACTUALtanktemperature
UVTimer
3minutes TheUVLamp lightseverytimeyoutakeadrinkofcoldwater,andstayson
for3minutes.Recommended/DefaultSettingis3minutes
10minutes TheUVLamp lightseverytimeyoutakeadrinkofcoldwater,andstayson
for10minutes.
Constant TheUVLampstaysonwhenpowerison.NotRecommended
F/C
F TemperaturesaredisplayedindegreesFahrenheit.DefaultisoF
C TemperaturesaredisplayedindegreesCelsius.
Language
English ThedisplaywillreadinEnglish.DefaultisEnglish
Spanish ThedisplaywillreadinSpanish
French,Etc. ThedisplaywillreadinFrench,andmanyothers…
FlowCounter
Liters
(4000‐9000)
DONOTUSE.“NOWATERSUPPLY”Faultwilloccur.UseFiltersTimer
Instead.
Gallons
(1000‐3000)
DONOTUSE.“NOWATERSUPPLY”Faultwilloccur.UseFiltersTimer
Instead.
FiltersTimer
3months TimerforFilters Lifesetat3months.Displays“ChangeFilters”after3
months
6months TimerforFilters Lifesetat6months.Displays“ChangeFilters”after6
months
9months TimerforFilters Lifesetat9months.Displays“ChangeFilters”after9
months
None TimerforFiltersLifeisturnedoff.DefaultisNone
FiltersLife 00DAYS
Indicatesamountofwaterflowed(gal/liters)ordayselapsedsincelast
reset
EnsureFiltersTimerisenabledandFiltersLifeindicatesDAYS
EnergySavingSleepMode On Shutsheaterdown(hotwater)ifnotusedin3hours.–DefaultSleepisON
Off Hotwaterremainspoweredindefinitely.
DefaultSet Cold DefaultsDisplay&DispenseSelectiontoColdafter3seconds. Defaultis
Cold
Sparkling DefaultsDisplay&DispenseSelectiontoSparklingafter3seconds.
Reset OK? ResetstheFilters Lifetozero.ConfirmbyselectingButton3(Hot)toSave
andExit.Thisresetsthetimer.


WL500Manual Page24Revision4‐10‐2019
PROGRAMING‐ACCESSINGPROGRAMMINGMODE



1.

PressButtonsNo.1andNo.2atthesametimeforsevenseconds
until“Password****”appearonthedisplay.








2.
EnterPassword:

AlternatelyPressNo.1andNo.2toenterthepassword

Passwordis:1111

*PressColdSelectionButton(No.1)toenterthepasswordnumber
*PressSparklingSelectionButton(No.2)tomovetothenext
passwordnumber





3.

PressHotSelectionButton(No.3)toenterthe“1111”Password
4.
Afterenteringtheprogrammingmode–Press:

ColdSelectionButton(No.1)toscrollprogrammingoptionsforward

SparklingSelectionButton(No.2)toscrollprogrammingoptionsbackwards


1
2
1
2
PASSWORD ****
3
1111

WL500Manual Page25Revision4‐10‐2019
PROGRAMING–COLDTEMPERATURESETTING








Thecoldtemperaturecanbesetbetween3°Cand12°C(37°Fand54°F)dependingonwhichunitsare
selected(°Cor°F)intheF/Cprogrammingsetting.

Recommended/DefaultTemperatureSetting:5°C(41°F)

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.
Afterenteringtheprogrammingmode–PressColdSelectionButton(No.1)
until“ColdTemp”isdisplayed.

*Note:
PressingColdSelectionButton(No.1)scrollsprogrammingoptionsforward
PressingSparklingSelectionButton(No.2)programmingoptionsbackward
3.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
4.
PressColdSelectionButton(No.1)toincreasetheColdTemperateSetting

PressSparklingSelectionButton(No.2)todecreasetheColdTemperature
Setting.

Recommended/DefaultTemperatureSetting:5°C(41°F)
5.


PressHotSelectionButton(No.3)tosavethetemperaturesettingchosen.
6.
PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Cold Tem
p
Set
3
2
3
4
1

WL500Manual Page26Revision4‐10‐2019
PROGRAMING–HOTTEMPERATURESETTING







 
Thehottemperaturecanbesetbetween70°Cto95°C(158°Fto203°F)dependingonwhichunitsare
selected(°Cor°F)intheF/Cprogrammingsetting.

Recommended/DefaultTemperatureSetting:87°C(189°F)

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.
Afterenteringtheprogrammingmode–PressColdSelectionButton(No.1)
until“HotWater”isdisplayed.

*Note:
PressingColdSelectionButton(No.1)scrollsprogrammingoptionsforward
PressingSparklingSelectionButton(No.2)programmingoptionsbackward
3.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
4.
PressSparklingSelectionButton(No.2)toincreaseordecreasethe
temperaturesetting.

Recommended/DefaultTemperatureSetting:87°C(189°F)
5.


PressHotSelectionButton(No.3)tosavethetemperaturesettingchosen.
6. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Hot Water
3
2
3
4
1

WL500Manual Page27Revision4‐10‐2019
PROGRAMING–TEMPERATUREDISPLAY









Temperaturedisplayisthetemperaturethatthedisplayscreenshows.

Static–DisplaywillalwaysshowtheSTATIC(SETPOINT)temperature–Recommended/Default

Ranging–TheDisplaywillshowthetemperatureofthewaterinthetank.

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.

PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“Static”or“Ranging”

Recommended/DefaultSettingisSTATIC
4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Temp Display
3
2
3
4

WL500Manual Page28Revision4‐10‐2019
PROGRAMING–UVTIMERSETTING








DetermineshowlongtheUVLampstayson.

3minutes–TheUVLampcomesoneverytimeyoutakeaglassofcoldwater,andstaysonfor3
minutes.Recommended/Default

10minutes–TheUVLampcomesoneverytimeyoutakeaglassofcoldwater,andstaysonfor
10minutes.

Constant‐TheUVLampissettobeonallthetime.NotRecommended

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“3minutes”,“10minutes”or
“constant”.

Recommended/DefaultSettingis3Minutes

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.


UV Timer
3
2
3
4

WL500Manual Page29Revision4‐10‐2019
PROGRAMING–TEMPERATUREDISPLAYSETTING










DetermineshowtheDisplayshowsalltemperaturesettingsoptions:

°F‐Fahrenheit–DEFAULTSETTING

°C‐Celsius
1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“Fahrenheit”or“Celcius”

Recommended/DefaultSettingisFahrenheit

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.

°F / °C Set
3
2
3
4

WL500Manual Page30Revision4‐10‐2019
PROGRAMING–LANGUAGEDISPLAYSETTING










Thelanguageshownonthedisplayoptions:

English–Default
French
German
Spanish
*Manyotherlanguages.

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“Fahrenheit”or“Celcius”

Recommended/DefaultSettingisFahrenheit

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.


Language
3
2
3
4

WL500Manual Page31Revision4‐10‐2019
PROGRAMING–FLOWCOUNTER








FlowCounter
Donotusethissetting–itwillresultina“NOWATERSUPPLY”fault.

UsetheFiltersTimerinstead. 




Flow Counter

WL500Manual Page32Revision4‐10‐2019
PROGRAMING–FILTERTIMER









TimerforFiltersLife:

NONE–TimerforFiltersturnedoff–DefaultSetting

3months–Displays“ChangeFilters”after3months

6months–Displays“ChangeFilters”after6months

9months–Displays“ChangeFilters”after9months

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“None,3months,6months
or9months)

Recommended/DefaultSettingisNONE

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Filter Timer
3
2
3
4

WL500Manual Page33Revision4‐10‐2019
PROGRAMING–FILTERLIFE









FilterLifeindicatestheamountofwaterthathasflowed(gallons/liters)ordayselapsedsincelast
reset.

EnsureFilterTimerisenabled,andFiltersLifeindicatesDAYS.

1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3. PressSparklingSelectionButton(No.2)toselect“00DAYS”
4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Filter Life
3
2
3
4

WL500Manual Page34Revision4‐10‐2019
PROGRAMING–ENERGYSAVINGSLEEPMODE










EnergySavingSleepMode

On–EnergySavingSleepModeon.Shutsheardown(hotwater)ifnotusedin3hours.Default
Setting

Off‐Hotwaterremainspoweredindefinitely.
1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“On”or“Off”

Recommended/DefaultSettingisOn

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Slee
p
Mode
3
2
3
4

WL500Manual Page35Revision4‐10‐2019
PROGRAMINGDEFAULTDISPLAYANDDISPENSEPROGRAMMING









 
DefaultsDisplayandDispenseSelectionafter3seconds

Cold‐Default

Sparkling
1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2.


PressHotSelectionButton(No.3)toseewhatthecurrentsettingis.
3.
PressSparklingSelectionButton(No.2)toselect“On”or“Off”

Recommended/DefaultSettingisOn

4.


PressHotSelectionButton(No.3)tosavethesettingchosen.
5. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Default Set
3
2
3
4

WL500Manual Page36Revision4‐10‐2019
PROGRAMING–RESETFILTERSLIFETOZERO










 
ResetstheFilterslifetozero.
1. EntertheProgrammingModein“AccessingProgrammingMode”instructions.
2. PressSparklingSelectionButton(No.2)toselect“OK?”
3.


PressHotSelectionButton(No.3)tosavethesettingchosen.
4. PressExtraHotSelectionButton(No.4)toexitprogrammingmode.



Reset
2
3
4
