Prorack K340 User manual

,OADSOFADVENTURE
Page 1 of 4
K340 ASSEMBLY AND
FITTING INSTRUCTIONS
Kit contains:
1 x Instructions
4 x Stepped Rubber Pads
4 x Red Plastic Knobs
4 x Plastic Internal Blocks
4 x Grubscrews, M6 x 60mm
1 x Allen Key, 3mm
Rev. B
Remove parts from box & check
Contact your Prorack dealer if any parts are
missing or damaged
Items you will require that are not included:
Tape measure
Important Note:
Whispbar Flush Bar pictured in these instructions, also applicable for Whispbar Through Bar
1. Crossbar Preparation
Remove crossbar and this kit from the•
packaging
Follow step 1-3 of crossbar assembly•
instructions
Remove clamp block by pressing•
backwards
Fit stepped rubber pad (from fitting kit)•
to foot
Press pad firmly onto foot by putting•
thumb pressure on area where pad
spigots engage
Press Here
1.1 1.2
75
kg
Maximum
Whispbar
Load
Rating
When fitted and loaded
correctly

Page 2 of 4
K340 ASSEMBLY AND FITTING INSTRUCTIONS
2.1 2.2
Remove fixpoint covers• Select four M6 x 60mm grubscrews•
and screw them into the centre hole, do
not over tighten
Repeat steps 2.1 - 2.2 for all four•
positions
1.3 1.4
Select plastic internal block and insert•
into foot
Repeat on all four legs•
Push down
2. Positioning Crossbar on Vehicle

Page 3 of 4
K340 ASSEMBLY AND FITTING INSTRUCTIONS
2.3
Adjust crossbar length by clicking legs•
in or out and using the hex screwdriver
provided lock top adjusting screw
Place crossbar foot over grubscrews•
2.4
Select red plastic knob and tighten•
crossbar to grubscrews
2.5
Ensure red plastic knob is in the same•
position as pictured above
Repeat for all four positions•
2.6
Check crossbar feels tight•
Refit covers to leg•

Page 4 of 4
,OADSOFADVENTURE
K340 ASSEMBLY AND FITTING INSTRUCTIONS
Warning Notes
Use these instruction in conjunction with crossbar instructions•
WARNING: Check the Tightness of Screws Regularly
