protech 3241PTL03 User manual

INSTRUCTION MANUAL
IMPORTANT
Read before us Modell-Nr. 3241PTL03
English (ORIGINAL INSTRUCIONS)
20 METER
RANGE
FINDER

6 7 4 5
1
2 3
f
g h
ba c d e
1
2

1EN
COMPONENT LIST
Display Elements
a Laser “ON”
Length measurement
Display length/area/volume
Area measurement
Volume measurement
Malfunction / service required
Battery symbol
Measurement point (reference)
rear/front
Measurement values
Unit m/ft/inch/’ ‘’
b
c
d
e
f
g
h
The numbering of the product features shown refers to the illustration of the
measuring tool on the graphic page
1. Measuring and on button
Function button
On and Off button
Latch of the battery lid
Battery lid
Laser beam outlet
Reception lens
2.
3.
4.
5.
6.
7.
TECHNICAL DATA
0.2 –40mMeasuring range
±3.0mmMeasuring accuracy(standard deviation)
– 10°C ... +40°COperating temperature
2Laser class
650nm, <1mWLaser type
2 x 1.5 V LR03 (AAA)Batteries
Battery live, approximately
– Individual measurements 5000
75gWeight
110 x 42 x 26.5mmDimensions
Note: The measuring accuracy is ± 2 mm when measuring within 10 m.
The measuring accuracy when measuring over 10 m can be calculated as follows:
± 3mm ± 0.1*(D-10) (D: Measuring distance, Unit: m)

EN 2
GENERAL SAFETY
WARNINGS FOR YOUR
LASER MEASURING
TOOL
WARNING: Read all safety
warnings and all instructions.
Failure to follow the warnings and
instructions may result in serious injury.
Save all warnings and instructions for
future reference.
These lasers do not normally present an optical
hazard although staring at the beam may cause
flash blindness.
Do not stare directly at the laser beam. A hazard
may exist if you deliberately stare into the beam,
please observe all safety rules as follows:
1. Laser radiation, do not stare into beam.
2. The laser shall be used and maintained
in accordance with the manufacturer’s
instructions.
3. Never aim the beam at any person or an object
other than the work piece.
4. The laser beam shall not be deliberately aimed
at another person and shall be prevented from
being directed towards the eye of a person for
longer than 0.25 seconds area.
5. Always ensure the laser beam is aimed at a
sturdy work piece without reflective surfaces,
e.g. wood or rough-coated surfaces are
acceptable. Bright shiny reflective sheet steel or
similar is not suitable for laser applications as
the reflective surface may direct the laser beam
back at the operator.
6. Do not change the laser device with a different
type. The manufacturer or an authorized agent
must carry out repairs.
7. CAUTION: Use of controls or adjustments
other than those specified herein may result in
hazardous radiation exposure.
8. Do not use this product in flammable, explosive,
corrosive environments or near medical
equipment or aircraft.
BATTERY WARNINGS
WARNING
1. Use the recommended type of dry battery,
different type of batteries may cause damage.
Do not expose the battery to an overheating
environment, such as sunlight or fire, which
may explode, cause fire or personal injury.
Do not short-circuit or disassemble the battery,
which may explode, cause fire or personal
injury.
The battery may leak if the device is not
used properly. In case of battery leakage,
carefully remove the liquid with a cloth. Once
contact battery liquid, wash with running
water immediately, and seek medical help
immediately if liquid splashes into eyes.
Do not charge for batteries that are not suitable
for recharging.
Keep the battery away from children because of
the risk of swallowing.
Children are not allowed to use the tool, which is
not a toy.
Remove the batteries to prevent battery leakage
if you do not intend to use the tool for a long
time.
2.
3.
4.
5.
6.
7.
8.
SYMBOL
To reduce the risk of injury, user must
read instruction manual
DO NOT STARE INTO BEAM
LASER RADIATION

3EN
ASSEMBLY
INSERTING/REPLACING THE
BATTERIES
Using alkali-manganese or rechargeable
batteries is recommended for operation of the
measuring tool.
To open the battery lid 5 , press the latch 4 in the
direction of the arrow and remove the battery lid.
Insert the batteries/rechargeable batteries. When
inserting, pay attention to the correct polarity
according to the representation on the inside of
the battery compartment.
Always replace all batteries/rechargeable
batteries at the same time. Do not use different
brands or types of batteries/rechargeable
batteries together.
• Remove the batteries/rechargeable batteries
from the measuring tool when not using it for
longer periods. When storing for longer periods,
the batteries/rechargeable batteries can corrode
and self-discharge.
OPERATION
INITIAL OPERATION
•
Do not leave the switched-on measuring tool
unattended and switch the measuring tool off
after use. Other persons could be blinded by the
laser beam.
Protect the measuring tool against moisture
and direct sun light.
Do not subject the measuring tool to extreme
temperatures or variations in temperature.
As an example, do not leave it in vehicles for
longer periods. In case of large variations in
temperature, allow the measuring tool to adjust
to the ambient temperature before putting it into
operation.
Avoid heavy impact to or falling down of the
measuring tool. After severe exterior effects
to the measuring tool, it is recommended to
carry out an accuracy check each time before
continuing to work.
•
•
•
SWITCHING ON AND OFF
1. Start the laser distance measurer by
pressing the button .
2. Switch it off by pressing and holding down
the button .
1.Start the laser distance measurer by pressing
the button .
2.press and hold the button and then press
button .
Reference
Unit selected

1.Start the laser distance measurer by pressing
the button .
2. Long press the button until the laser is
activated.
3. Direct the laser beam towards the surface you
want tomeasure. The laser distance measurer will
beep during continousmeasurement.
4. Press the button again to stop continuous
measurment.
1.Start the laser distance measurer by pressing the
button .
2.Press and hold the button and then press
button ,the unit will change. Repeat the
operation to select the unit you need.
1.Start the laser distance measurer by pressing
the button .
2.Press the button again to activate the laser.
3.Direct the laser beam towards the surface you
want to measure and press the button again.
The measurement result will be shown on the
display
Note:If you want to clear the last measurment,
press the button .
Continuous measurement
EN 4
Measuring single distance
Note:If you want to clear the measurment, press
the button or . And it will go back to the
function of measuring single distance.

1. Start the laser distance measurer by
pressing the button .
2. Press button two times until th
indicator for Volume measurement
appears on the display.
3. Press the button again to activate
the laser.
4. Direct the laser beam towards the first
target.
5. Press the button again. The first
measurement will be shown on the display.
6. Press the button again to activate
the laser.
How to Calculate Area
1.Start the laser distance measurer by pressing the
button .
2. press button one time until the indicator
for areameasurement appears on the display.
3. Press the button again to ctivate the laser.
4. Direct the laser beam towards the first targer.
5. Press the button again.The first
measurement will beshown on the display
6. Press the button again to activate the laser.
7. Direct the laser beam towards the second target.
8. press the button again.The second
measurement and area result will be shown on
the display.If you want to continue to measure
under this funtion,press the button again.
How to Calculate Volume
5EN

WORKING ADVICE
General Information
The reception lens 7 and the laser beam
outlet 6 must not be covered when taking a
measurement.
The measuring tool must not be moved while
taking a measurement (with the exception of the
continuous measurement function). Therefore,
place the measuring tool, as far as this is
possible, against or on the measuring points.
Measurement takes place at the centre of the
laser beam, even when target surfaces are
sighted at an incline.
INFLUENCE EFFECTS ON THE
MEASURING RANGE
The measuring range depends upon the light
conditions and the reflection properties of the
target surface. For improved visibility of the
laser beam when working outdoors and when
the sunlight is intense, use the laser viewing
glasses(not supplied) and the laser target plate
(not supplied), or shade off the target surface.
INFLUENCE EFFECTS ON THE
MEASURING RESULT
Due to physical effects, faulty measurements
cannot be excluded when measuring on
different surfaces. Included here are:
– transparent surfaces (e.g., glass, water),
– reflecting surfaces (e.g., polished metal,
glass),– porous surfaces (e.g. insulation
materials),
– structured surfaces (e.g., roughcast,
naturalstone).
If required, use the laser target plate (not
supplied) on these surfaces.
Also, air layers with varying temperatures or
indirectly received reflections can affect the
measured value.
MESSAGE CODE
Message
code
Possible
Cause
Remedy
Err10 Battery too
low
Change batteries
Err15 Out of range Measure target
within
the range
Err16 Received
signal too
weak
Use light color
target;
Hold Quick
Measure
more steady
Err18 Background
brightness
too high
Use dark colored
target
Err26
MAINTENANCE AND
SERVICE
MAINTENANCE AND CLEANING
Store and transport the measuring tool
only in the supplied package.
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in
water or other fluids.
Wipe off debris using a moist and soft cloth.
Do not use any cleaning agents or solvents.
Maintain the reception lens 7 in particular,
with the same care as required for eye
glasses or the lens of a camera.
7. Direct the laser beam towards the second
target.
8. Press the button again.The second
measurement will be shown on the display.
9. Press the button again to activate the laser.
10. Direct the laser beam towards the second target.
11. Press the button again.The third
measurement and volume result will be shown
on the display.If you want to continue to
measure under this funtion,
press the button again.
EN 6
One button back to single measuring
Press button to back to single measuring.
Out of display

If the measuring tool should fail despite the care
taken in manufacturing and testing procedures,
repair should be carried out by an authorized
after-sales service centre . Do not open the
measuring tool yourself.
In case of repairs, send in the measuring tool
packed in its package.
AFTER-SALES SERVICE AND
APPLICATION SERVICE
Our after-sales service responds to your
questions concerning maintenance and repair of
your product as well as spare parts.
DISPOSAL
Measuring tools, accessories and packaging
should be sorted for environmental- friendly
recycling.
Do not dispose of measuring tools and batteries/
rechargeable batteries into household waste!
7EN
