Prothelis Greta User manual
Manual
Prothelis AG
March 8, 2021
Important Note
PROTHELIS SAYS THANK YOU!
We are delighted that you have chosen to purchase an area tracker from Prothelis and thank you for
the confidence you have shown in us.
1 Important Note
Please note that area requires approximately 24 hours after activation to achieve optimum functionality. The activation
process is indicated by a flashing LED light after the tracker has been connected to the power supply. Before the activation
process starts, the battery requires a minimum level of charge. This may take up to 20 minutes.
2
Package contents
2 Package contents
•area (Tracker)
• USB cable
–We recommend a 5V 2A mains plug (not included), which is suitable for mains voltages from 100 to 240V.
• PTEholder
–The holder is used to attach the tracker and can be used universally, e.g. on a dog collar, belt etc..
3 Activating area
1. Go to https://myprothelis.de/activate and create a user account.
2. Register your tracker and choose a service package for the desired period.
3. Connect the tracker to the power supply.
The tracker flashes and should not be removed from the power supply until the activation process has been completed.
Once the tracker has been activated, it stops flashing and is ready to use.
While trying to register within the network for the first time the tracker flashes in blue light. If the network registration was
successful, the device updates the firmware, if necessary, which is indicated by a blinking white light.
During the whole process, the tracker also charges the battery, as it is connected to the power supply. While the tracker
is charging the LED shows an animated green, and when the battery is charged a constant green light.
INFO
The service package is needed to use area and the 24h messaging service.
4 Installing the app
Download the free Prothelis app from the App Store or Play Store, or scan in the QR code below.
Sign in to your account.
The tracker is now ready for use.
The web app is available here: https://myprothelis.de
3
Using your tracker
App Store (iOS) Play Store (Android)
Table 1: Mobile App QR Codes
5 Using your tracker
Once successfully activated you can use your tracker straight away. Your tracker’s current position and battery status
can now be seen in the Prothelis app.
If you have any other questions or suggestions regarding our products, please contact us at: [email protected]
5.1 Charging your tracker’s battery
Connect the tracker to the power supply. The tracker starts the charging process automatically.
The charging process is indicated by an animated green light on the tracker. Once the charging process is complete,
the light changes to a constant green.
The Prothelis app informs you when the battery is low. The tracker also indicates this with a flashing red light.
6 SAFETY INFORMATION
Before you begin using the tracker you must please read through this safety information.
It includes important information that guarantees the tracker is used correctly.
6.1 General
The tracker and its accessories can only be used properly if you are familiar with the operating instructions and with the
safety information and terms of use. Being familiar with this will protect you and your environment against hazards.
In addition to the mandatory requirements contained in this safety information, please also exercise the care that is
typically required when using electrical appliances in traffic situations. Please contact us if you have any concerns
regarding the safety information. We will be happy to help you. Any use of the tracker and its accessories other than
for the intended use is prohibited. Any claims for damages against Prothelis GmbH that are caused by use other than
for the intended use are excluded. All the specifications and information have been compiled taking the current state of
technology and engineering development standards into account.
6.2 First steps
Remove all the elements from the packaging and check that everything is present. All products are subject to a restrictive
quality control. Nevertheless, please check that the elements (in particular the cable) are intact. Sources of danger are,
4
6.3 Safe storage
for example, cracks in the cable insulation. Only activate the tracker and its accessories with the help of the quick start
guide or the operating instructions.
The tracker and accessories are not intended for people (in particular children) who cannot assess the implications of
electronic and technical features and can therefore not handle them. Children in particular cannot assess the potential
hazards, such as swallowing or improper use. The same care must be taken with animals and pets. The tracker may
only be charged in an ambient temperature of 0 °C to 45 °C. Otherwise the battery could be damaged.
6.3 Safe storage
The tracker and accessories must be stored in such a way that they are out of reach of the aforementioned people or
animals and pets. The tracker has been developed for use in temperatures ranging from 20 °C to 60 °C. Please always
ensure that the tracker is not exposed to any heat sources that exceed the aforementioned temperature. Otherwise it
may overheat and in extreme cases lead to the battery and tracker being damaged, with serious consequences such
as smoke or fire. Please refrain from having the tracker or accessories engraved. This could lead to anything from an
impairment of functionality to a complete breakdown of the tracker, as well as potential hazards such as overheating.
6.4 Attaching the tracker safely
The cable and charger must be protected from moisture. Always ensure that nobody but you has access to the charger
and cable. Heavy mechanical strain or constant, unusually strong vibrations must be avoided. Please always ensure
that the tracker is attached safely to the object being tracked.
• Always ensure that the tracker is attached to the object being tracked in such a way that it is not exposed to any
excessive heat. (Tracker is attached under a vehicle’s bonnet).
• The tracker and accessories must not be attached and stored in or near heating and gas equipment or similar.
• When attaching the tracker to motorised and nonmotorised modes of transport always ensure that it is not attached
in a place that could impair steering or functionality.
• When transporting (heavy) goods the tracker must be attached in such a way that there is no chance of it being
deformed as a result of a long journey.
• The permanent use of the tracker in and around transmitters (radar systems, transmission masts and similar) may
lead to interference and impair the tracker’s mode of operation.
• Interference can occur with objects which contain magnetic strips or chips (credit, debit or similar payment and
identification cards). In extreme cases, this can lead to damage to the tracker or to the object itself. Try to keep
the tracker as far away from such objects as possible.
6.5 Damage
It is prohibited to use the tracker and its accessories if it can no longer be used in the way it was intended (cracks in
tracker‘s casing, no visual indicators displayed when placed in charger, charging cable damaged, or similar). Please
contact us or one of our licensed partner companies.
6.6 Battery/Waste disposal
Under the EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), electrical and electronic items
may not be disposed of together with household waste. Consumers must hand over any waste equipment that cannot
be used any more to a separate collection point. By doing this it is ensured that waste equipment is properly recovered
and recycled, preventing any negative impact on the environment. The same applies to batteries in accordance with
5
Declaration of conformity
the Battery Ordinance (BattV). It is prohibited to dispose of them in the household waste. Used batteries/ rechargeable
batteries may be returned free of charge to collection points in your community.
Never try to remove the battery from the device!
7 Declaration of conformity
Prothelis AG hereby declares that the GPS tracking device area (article no. 09054802) complies with the essential
requirements and other relevant provisions of Directive 2014/53/EU. The complete text of the Declaration of conformity
can be downloaded from the following website:
https://prothelis.de/conformity
8 Warranty
The statutory warranty period applies in each case.
9 Technical Specifications
9.1 Location Method
• GNSS (Global Navigation Satellite System)
• GSM (Global System for Mobile Communications)
9.2 Connection
• GPRS
9.3 Protection Class
• IP 67
9.4 GNSS Receiver
• GPS + GLONASS
• Accuracy: <2.5 m (CEP)
9.5 GSM Module
• GSM 900 33dBm (2W)
• GSM 1800 30dBm (1W)
9.6 SIM Card
• Embedded SIM (integrated)
6
9.7 User Interface
9.7 User Interface
• Status LED
• Mobile app
• Web app for PC
9.8 Accumulator
• Intelligent power management
• 630 mAh LiPo accu
• Chargeable via USB
• Lasts up to 10 days during active usage
9.9 Temperature
• Charge: 0 °C to +45 °C
• Usage: Use in ambient temperatures from 20 °C to +60 °C
9.10 Inertial Navigation System (3Axis Sensor)
• Accelerometer
9.11 Parameter
• Height: 26 mm
• Width: 30 mm
• Length: 65 mm
• Weight: 38 g (+/ 2 g)
7
