Protouch prowarm ProTouch V2 User manual

INSTRUCTION MANUAL
& USER GUIDE
Touchscreen Thermostat

Time
Up Arrow
Down Arrow
Mode Selection
Detected Temp
Menu
Touchscreen Thermostat
DISPLAY SYMBOLS
Heat / Event / Floor Sensor

THERMOSTAT DESCRIPTION
The ProWarm Touchscreen thermostat can be used to control your electric floor heating system or water
heating system. It will keep your home at a comfortable temperature whilst minimizing energy use.
THERMOSTAT DESCRIPTION
TECHNICAL SPECIFICATION
Supply voltage: 220-240Vac 50/60Hz
Max load: 16A
Standby power: ＜2W IP rating: IP20
Max wire diameter: 侑2.5mm²
MAIN FUNCTIONS
Open window detection function
Key-lock
Sensor selection
Brightness
Adaptive function
Auto mode
Hold mode
Holiday mode
Frost Mode
Floor temperature limit

Step 1
Separate the panel from the back section: insert a
screwdriver into the two holes under the
thermostat and pry it in the same direction as the
arrow in the picture. It will click and separate
from the back plate.
Step 2
Connect the wires as shown in the wiring
instruction.
NOTE: Thermostat should be mounted in a 35mm deep single gang back box
INSTALLATION AND WIRING INSTRUCTIONS

Step 3
Fix the back section to the single gang
electrical back box with the screws provided
Step 4
Re-install front panel whilst ensuring the pins engage
properly in the circuit board socket.

On/Off
Press the button on the right hand side of the thermostat to turn it on or off.
Note: When frost mode is active, the thermostat will maintain the frost mode temperature when the power is off.
Temporarily override temperature
Press or to temporarily increase or decrease the current temperature. If in AUTO the thermostat will
revert to the automatic schedule at the start-time of the next event.
Mode selection
On the Home Screen, press the key in the Top left hand corner to select the MODE you require.
There are 3 modes:
Auto mode: This is the default mode. The Thermostat will run a set schedule, this can be adjusted to suit
your needs in the Edit Setting section.
Steps:
Press Auto Mode to confirm and this will revert to the home screen.
FUNCTION & USER OPERATION

Manual mode: Thermostat will run with the set temperature continuously until changed.
Steps:
Press Manual Mode to enter temperature setting.
Press or to set the temperature.
Press to confirm and this will revert to the home screen.
Holiday mode: Thermostat will run with the set temperature until the holiday time ends.
Steps:
Press Holiday Mode to enter holiday setting.
Press or to set the days of holiday.
Press to confirm and enter holiday temperature setting.
Press or to set the temperature.
Press to confirm and this will revert back to the home screen.

MENU
On the Home Screen, press the key to enter the Menu. There are 5 parameter settings.
1. Time
The day and clock are set here.
Steps:
Press Time to enter day setting.
Press the day you want to enter hour setting. Press or to set hour
Press to confirm and enter minute setting. Press or to set minute.
Press to confirm and back to Menu. Press to back to the home screen.
2. Key lock
Lock all keys to prevent the settings from being changed.
Lock Steps:
Press Key Lock to enter key lock setting.
Press or to select lock.
Press to confirm and to go back to the home screen.
Unlock steps:
On the home screen, press any key then (in the bottom right corner) will flash 3 times.
Press and hold for 3 seconds to unlock.

3. Brightness
This option allows you to change the brightness of the display
Steps:
Press Brightness to enter brightness setting.
Press to move up/down or touch any part of the line to set the brightness.
Press to confirm and back to Menu.
4. Edit setting
Edit setting can set and change the heating schedule. This only works in AUTO mode, not in Holiday Mode or
Hold Mode. The thermostat runs according to the parameters set within Edit.
Should you wish a time period to turn ‘ON’ set a warm temperature, should you wish the heating to go ‘OFF’
set a low temperature. For example, wake could be set to 25degrees C and Leave (to go off) could be set to
16degrees C.
Steps:
Press Edit Setting to enter days selection. Press the day/s you want to set.
Press to confirm.
Press on the time period you want to set and enter the start time hour setting.
Press or to set start time hour. Press to confirm and enter the start time minute setting.
Press or to set start time minutes. Press to confirm and enter temperature setting.
Press or to set temperature. Press to confirm and to go back to the time periods..
Press to back to the home screen.

5. Advanced Settings
The thermostat provides advanced settings to suit various special situations. These are normally set by
technicians during initial installation.
Steps:
Press Advanced Setting to enter the page of warning.
Press to enter advanced settings.
Press or to switch feature number.
Press the feature to change its parameters.
1. Room Temperature calibration: Calibrate the temperature detected by room sensor.
2. Floor Temperature calibration: Calibrate the temperature detected by floor sensor.
3&4. Frost mode function: If frost mode is on this will protect the property or room from frost.
5. Floor temperature limit: When choose both sensors, you can set the maximum floor temperature value,
system will stop heating if the floor temperature exceed this value.
ADVANCED SETTING
Period parameter table (Default)
Mon - Fri 07:00 22삸08:30 19삸
08:30 22삸
17:00 22삸22:00 19삸
22:00 19삸
17:00 22삸
08:00 22삸
Sat - Sun
Day Wake Leave Return Sleep

Name
Room Temperature Calibration
Floor Temperature Calibration
Frost mode
Frost mode Temperature
Floor Temperature Limit
Switching Differential
Temperature Unit
Sensor Selection
Schedule
Output Delay
Adaptive Function
Open Window
Power Set
Energy Use
Factory Reset
Default value
0°C
0°C
ON
5°C
30°C
1°C
°C
Floor
5+1+1
0 Sec
OFF
OFF
0 W
NO
Ranges
-5°C -- 5°C
-5°C -- 5°C
ON/OFF
5°C -- 15°C
20°C -- 50°C
0.5°C/1°C/2°C/3°C
°C/°F
Room/Floor/Both
5+1+1/7
0S/30S/60S/90S
ON/OFF
ON/OFF
0W -- 3600W
NO/YES
No .
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

TROUBLESHOOTING
Room Sensor Error! : Built-in sensor short-circuit or disconnected.
Floor Sensor Error! : Floor sensor short-circuit or disconnected.
6. Switching Differential: The number of degrees the temperature has to change before the unit switches
on/off. The default is 1 degree so if the temperature is set to 21 degrees the thermostat will
switch on at 20.5 degrees and off at 21.5 degrees. 0.5 degrees either side of 21.
7. Temp unit: °F and °C can be selected.
8: Sensor selection
Room sensor: Run by room sensor. Floor sensor: Run by floor sensor.
Both sensors: Run by room sensor with floor temp limit.
9. Schedule: Select a weekly schedule for the event.
7: each day from Mon to Sun can be set individually.
5+1+1: Mon to Fri have the same events, Sat and Sun can be set individually.
10. Output delay: This option help you avoid inadvertent operation on heating.
11. Adaptive function: After several days of installation and use, Adaptive function ensures that the required
temp has already been reached when the next event begins.
12. Open window: This function only works when room sensor or both sensors is selected. The thermostat
with this function will shut oautomatically for 15 min when the window opens, as it can detect that the
room temp plummets.
13&14. Energy use: This option allows you to enter the various data used to calculate energy use.
15. Factory Reset: All parameters are restored to default values.

DIMENSIONS (mm)
136 15
94

26 60
52
52

WIRING INSTRUCTIONS
Ensure power is disconnected when wiring!
MAX LOAD: 16A
SENSOR
L1N1 N L
FLOOR
SENSOR
POWER
85V-265V
50/60Hz
IP 21
N1 NLL1 S2 COM S1
POWER
FLOOR SENSOR
Suggestion: Please keep the max load around 90% of 16A to prolong the lifetime.

www.prowarm.comSupport: 01268 567019
Touchscreen Thermostat
