Proxim Wireless At-a-Glance
Wi-Fi®Mesh Product Portfolio
MeshMax™Series ORiNOCO®Wi-Fi®Mesh Series ORiNOCO®Public Safety Wi-Fi®Mesh Series
Product 3500WM, 3500W, 5054WM, 5054W AP-4000MR(-LR) AP-4000M/AP-4000 AP-4900MR-LR AP-4900M
Description Industry’s first convergence of WiMAX,
Wi-Fi Mesh and Wi-Fi
High-capacity, multiple-use outdoor
Wi-Fi mesh system
Dual-radio enterprise-class indoor AP
with QoS, simultaneous a/b/g support
and enhanced security
High-capacity, outdoor Wi-Fi Mesh
system for Public Safety applications
Dual-radio indoor AP with QoS,
simultaneous a/b/g support and
enhanced security for public safety
Applications • Network operator can deliver
bundle of IPTV, VoIP and Internet
access to subscribers
• Secure and reliable backhaul of
Wi-Fi Mesh traffic
• Security and surveillance
• Metro-area Wi-Fi coverage with
fully redundant wireless backbone
• Mobile wireless networking at edge
of network
• Voice, video and data transmission
with optimal economics
• LAN extension for nomadic access
to corporate network, Internet and
e-mail
• Hotspot
• Guest access to Internet
• Voice, video and data
• Metro-area and mobile Wi-Fi
coverage using 4.9 GHz U.S.
public safety
• Voice, video and data transmission
for mobile public safety vehicles
• Metro-area and mobile Wi-Fi
coverage using 4.9 GHz U.S.
public safety
• Voice, video and data transmission
for mobile public safety vehicles
Environments • Municipal, rural and service provider
broadband networks
• Enterprise campus networks
• Municipal and rural broadband
networks
• Service provider broadband
networks
• Enterprise campus networks
• Enterprises
• Hotspots: retail, hotel, airport
• K-12 and higher education
• Municipal and rural broadband
networks
• Public safety networks including
fire, police and emergency first
responders
• Security and surveillance
• Municipal and rural broadband
networks
• Public safety networks including
fire, police and emergency first
responders
• Security and surveillance
Key Features • Tri-radio design provides WiMAX
backhaul, Wi-Fi Mesh link and Wi-Fi
access in one device
• Simplifies network architecture,
deployment and management
• Significantly reduces TCO with
lowest deployment cost per
square mile
• Dual-radio outdoor access point
• 802.11b/g Wi-Fi access
• ORiNOCO Mesh Creation Protocol
(OMCP) for backhaul at 5 GHz
• Fast handoffs for mobility
• Secure management
• Enterprise class security
• Extended range (-LR Models)
• QoS
• Dual-radio design offers operational
flexibility and high capacity
• User-selectable 802.11a, b or g
operation
• IEEE 802.11i and AES encryption
• QoS for latency-sensitive voice, data
and video applications
• Dual-radio outdoor access point
• 802.11b/g Wi-Fi access
• ORiNOCO Mesh Creation Protocol
(OMCP) for backhaul at 4.9 GHz
• Fast handoffs for mobility
• Secure management
• Enterprise class security
• Extended range
• QoS
• Dual-radio indoor base station
• 802.11b/g Wi-Fi access
• ORiNOCO Mesh Creation Protocol
(OMCP) for backhaul at 4.9 GHz
• Fast handoffs for mobility
• Secure management
• Enterprise class security
• QoS
SPECIFICATIONS
Frequency Band • 3.5 GHz or 5.15-5.85 GHz (WiMAX link)
• 5.15-5.85 GHz (Mesh link)
• 2.4 GHz or 5.15-5.85 GHz (Wi-Fi access)
• 2.4 GHz or 5.15-5.85 GHz for access
• 5.47-5.725 GHz for backhaul
(AP-4000MR)
• 5.745-5.85 GHz for backhaul
(AP-4000MR-LR)
• 2.4 GHz for access
• 5.15-5.85 GHz for backhaul
• 2.4 GHz for access
• 4.9 GHz for backhaul
• 2.4 GHz for access
• 4.9 GHz for backhaul
RF Protocol • 802.16-2004 or WORP (WiMAX)
• 802.11a (Wi-Fi and Mesh)
• 802.11a, 802.11b/g (Wi-Fi)
• 802.11b/g
• 802.11a
• 802.11b/g
• 802.11a
• 802.11b/g
• 802.11a
• 802.11b/g
• 802.11a
Data Rate 25.4 Mbps (3.5 GHz)
54 Mbps (5.15-5.85 GHz and 2.4GHz)
54 Mbps 54 Mbps 54 Mbps 54 Mbps
QoS • 802.16d QoS (WiMAX)
• Draft 802.11e; 802.1p; 802.1q
(Wi-Fi Mesh)
Draft 802.11e; 802.1p; 802.1q Draft 802.11e; 802.1p, 802.1q Draft 802.11e; 802.1p; 802.1q Draft 802.11e; 802.1p; 802.1q
Security • AES (WiMAX)
• 802.11i, AES, TKIP (Wi-Fi Mesh)
• 802.11i
• AES Encryption, TKIP
• 802.11i
• AES Encryption, TKIP
• 802.11i
• AES Encryption, TKIP
• 802.11i
• AES Encryption, TKIP
Form Factors ODU tri-radio device, 3 x
Type-N connectors
ODU dual-radio, 2 x Type-N connectors IDU with external antenna connectors ODU dual-radio, 2 x Type-N connectors IDU with external antenna connectors
For detailed technical specifications, please go to http://www.proxim.com/products/meshmax
©2007 Proxim Wireless Corporation. All rights reserved. Proxim, the Proxim logo and ORiNOCO are registered trademarks and MeshMAX and Tsunami are trademarks of Proxim Wireless Corporation. All other
trademarks mentioned herein are property of their respective owners. Specifications are subject to change without notice. Availability subject to local regulations. *Intent of specifications is to provide a guideline
of the product’s performance, not to provide absolute specifications. Performance results may vary due to environment and implementation.
