Wall Mounted Products

The Compact Termination Box MK 2 is designed for use in residential and business applications for the termination

of up to four optical fibres. The wall box enables the termination of a customer drop cable onto SC/UPC or SC/APC

type pigtails and adapters. It can also be used as a splice point between two cables. The unit is supplied with a

fixing bracket for mounting directly onto a wall or onto a DIN rail. The unit can be supplied with pigtails and

adapters pre-installed, and can also be supplied o a reel with a length of cable pre-installed. Pigtails supplied are

G657A1 fibre (others available on request) and adapters are fitted with a protection shutter.

Features and Benefits

• Compact & attractive design for interior wall mounting.

• Cables can enter unit from rear, bottom, top, right hand side or left hand

side.

• Supplied with a bracket for wall mounting or mounting directly onto a DIN

Rail.

• G657A1 fibre pigtails supplied as standard. All fibres are positively

managed to maintain a 20mm minimum bend radius.

• Flip tray to allow access to connectorised tails and cable entry.

• Removable cover for easy access. The cover contains a cut out for a label

to be inserted and a further transparent cover is supplied to fit over the

label.

• Supplied with a security screw to prevent unauthorised access.

• Unit manufactured from fire resistant UL94-V0 rated material.

• Patchcords exit unit on bottom face and are protected by the use of

shuttered adapters.

• Standard colour is white RAL9016. Other colours are available on request.

• Can be supplied on a reel with a pre-installed stub of cable for direct

mounting without the need to open the box. Contact Prysmian for further

information.

Prysmian Part Numbers: See Table Below

Compact Termination Box MK2

Part Numbers

SC/UPC SC/AP C

Empt y

1 Pig t ail & 1 A dap t er XCP SC01127 XCP SC01128

2 Pigtails & 2 Adapters XCP SC01129 XCP SC01130

3 Pigtails & 3 Adapters XCP SC01131 XCP SC01132

4 Pigtails & 4 Adapters XCP SC01133 XCP SC01134

Co nnecto r Type

X C P S C 0 113 5

Kit Contents

•1xBase

•1xCover

• 1 x Splice Tray

• 1 x Wall or DIN Rail Fixing Bracket

• N x Pigtails (See part numbers)

• N x Adapters (See part numbers)

• 1 x Cover Fixing Screw

• 1 x Label Cover

• 1 x Blank Label

•2xCableTies

•1xInstallationGuide

• 2 x Fixing Screws

• 2 x Wall Plugs

Note: Splice protectors are not

supplied. Splice protectors can be

ordered separately. See additional

items.

Additional Items

• Splice Protectors

• Adapters

• Pigtails

• Security Screwdriver (tool)

www.prysmiangroup.com

WM044, Issue 06, May 2012

Page 2 of 3

Wall Mounted Products

•Number of input cable ports: 2 bottom, 1 rear, 1 top, 1 left, 1 right

•Maximum input cable diameter: 6mm

•Maximum Capacity: 4 Fibres

•Maximum no. of customer feeds: 4 Patchcords

•Required space envelope (mm): (l) 83 x (w) 100 x (d) 27

•Operating temperature: -20oC to + 50oC (5 to 95% RH)

•Material: FR ABS

•Colour: White RAL9016

•Testing:-

•Optical: Tested 1310,1550 & 1625nm

•Transportation: FT/RD/RESA/09/11/213 – 3.3

•Installation: FT/RD/RESA/09/11/213 – 3.4

•Climatic Storage: FT/RD/RESA/09/11/213 – 3.8

•Impact: FT/RD/RESA/09/11/213 – 3.8

•Cover Resistance: FT/RD/RESA/09/11/213 – 3.10

•Tensile: FT/RD/RESA/09/11/213 – 3.12

•Torsion: FT/RD/RESA/09/11/213 – 3.13

•Insertion Loss: FT/RD/RESA/09/11/213 – 3.14

•Climatic Testing: FT/RD/RESA/09/11/213 – 3.15

Logistics

Technical Data

• Packing Dimensions (mm): (l) 100 x (w) 115 x (d) 40

•PackedWeight(kg): 0.10

•Netweight(kg): 0.08

• Installation Instructions included

Pigtail Technical Data

Pigtails are supplied with either xx/UPC or xx/APC connectors.

xx/UPC connectors can be used in cases where xx/PC or xx/SPC connectors are required.

For technical data on the pigtails supplied refer to Prysmian data sheet AC003

www.prysmiangroup.com

WM044, Issue 06, May 2012

Page 3 of 3

Wall Mounted Products

Additional Items

Splice protectors are used to protect the fibre splice. They are 2.2mm in

diameter and 45mm in length.

Prysmian Part No. - XPESC00053 (pack of 50)

- XKTSC00050 (pack of 12)

Heatshrink Splice Protectors

Mechanical Splices are used to splice fibres together without the need of a fusion

splicing machine. They are 4mm wide x 4mm tall and 40mm in length. An

assembly tool and splice holder is required for installation. See Prysmian data

sheet AC007 for further information on mechanical splices.

Prysmian Part No. – XKTSC00121 (pack of 50)

Mechanical Splices

The Security Screw Driver is used for installation / re-entering of the Box.

Prysmian Part No. – XCPSC00669

Installation Tools

Security Screw Driver
