PSB VisionSound VS300 User manual

The VisionSound Series
PSB’s VisionSound Series presents a unique blend of high
performance, dramatic styling and flexible placement options. These
models are the ideal compliment for today’s most sophisticated
video displays.
In spite of their sophisticated style they achieve a sonic performance
without compromise. The VS
300
employs a sophisticated crossover
network with a ‘first of its type’ equalization of the sonic effects
of the rear wall bounce inherent in this type of mounting. All units
are enclosed in rigid aluminum extrusions which are highly durable
and acoustically inert. They use high excursion
4.5
” diameter, wide
suspension woofers and a vented system design to get maximum
bass from minimum dimensions. A carefully contoured “waveguide”
blends seamlessly into the obstruction-free face of the system’s
cabinet optimizing the performance of the
1
” aluminum dome
tweeters.
The VisionSound Series is comprised of two different models, one
which can be applied in three different ways, providing you with a
remarkable number of options.
An optional desktop base turns the VS
300
into a
compact mini tower. The VS
300
comes standard with
a wall mounting bracket and center channel feet.
Depending on the viewing angle the VS
300
can
slide, tilt and swivel to achieve the best possible
sonic performance.
For home theater and serious music listening alike,
demand high impact, accurate ultra-deep bass from
powered subwoofers like the SubSeries
5
i (left) and
SubSeries
1
.
Shown above: VisionSound VS
400
Tower & VS
300
in on-wall, center channel
and desktop confi gurations.

PSB Speakers reserves the right to change specifications or features without notice.
© 2006 PSB Speakers, a division of Lenbrook Industries Limited. PSB is a registered trademark of Lenbrook Industries Limited.
No part of this publication may be reproduced, stored or transmitted in any form whatsoever without the written permission of PSB Speakers.
525 VisionSound Data.
The VisionSound Series - Specifications
Frequency Range
Response
On Axis @ 0°±3dB
On Axis @ 0°±1 1/2dB
LF Cutoff -10dB
Sensitivity
Anechoic Chamber
Typical Listening Room
Impedance
Nominal
Minimum
Input Power
Recommended
Program
Acoustic Design
Tweeter (Nominal)
Woofer (Nominal)
Crossover
Design Type
Size
(W x H x D)
Weight
Net
Shipping
Finish
Features
VisionSound VS400
Tower
(Anechoic Chamber)
59-23,000Hz
65-18,000Hz
43Hz
88dB
90dB
6 Ohms
4 Ohms
(RMS, Clipping <10% Time)
25-250 Watts
180 Watts
1" (25mm)
Aluminum Dome
with Ferrofluid
4 x 4 1/2" (114mm)
Polypropylene Cone
Butyl Rubber Surround
2,200Hz,
LR4
2 1/2 Way Vented
Video Shielded
6 1/3 x 46 x 5 1/3"
110 x 1170 x 135mm
20 lb (9.1kg)/each
35 lb (15.9kg)/pair
Black or Titanium
Cast aluminum weighted base
±
Spectral tilt switch
SonicGuide
™
tweeter mounting
Acoustical match to the VS300
Magnetic Fastening Grille
VisionSound VS300
On-wall/Desktop/Center
68-23,000Hz
75-18,000Hz
52Hz
86dB
88dB
6 Ohms
4 Ohms
(RMS, Clipping <105 Time)
25-100 Watts
70 Watts
1" (25mm)
Aluminum Dome
with Ferrofluid
2 x 4 1/2" (114mm)
Polypropylene Cone
Butyl Rubber Surround
2,200Hz,
LR4
2 1/2 Way Vented
Video Shielded
6 1/3 x 26 1/3 x 5 1/3"
110 x 670 x 135mm
11 lb (5kg)/each
15.7 lb (7.1kg)/each
Black or Titanium
Wall Mountable
Center Channel Feet Included
Desktop Stand Available
Crossover Switch for on-wall
bounce compensation
Magnetic Fastening Grille
The VS
400
is an elegant floor standing speaker that visually
compliments todays most sophisticated video displays and
furniture. With four
4.5
” woofers that provide extremely
powerful bass extension and a
1
” Neodymium dome tweeter, the
VS
400
is a true sonic performer in the PSB tradition.
The VS
300
is designed for on-wall mounting next to flat panel displays.
It contains two
4.5
” woofers and a
1
” Neodymium dome tweeter. Its
vented enclosure is approximately
24
” long.
A unique crossover circuit flattens the frequency response when
mounted on the wall. This is necessary because wall mounting a
speaker causes a rear wall bounce, and a subsequent sonic delay of
the reflected sound creates a broad acoustic depression centered on
400
Hz. This bounce is predictable using computer modeling, making
it possible to develop an exclusive crossover network with corrective
circuitry that precisely fills in the depression and accurately equalizes
the system back to flat. When the speaker is table mounted, a switch on
the rear panel defeats this circuit.
The wall mounting brackets included with the VS
300
are designed for
maximum versatility with a
5
to
6
“ depth to match most wall mounted
LCD and Plasma TVs. The VS
300
’s wall mounting bracket rotates through
a broad range of angles so that it can be aimed inward for best stereo
effect. Utilising the same bracket, with the addition of two feet, the
VS
300
becomes a center channel for placement above or below a TV. An
optional desktop base turns the system into a compact mini tower.
www.psbspeakers.com
1 888 772 0000
(1W (2.83V) @ 1m, IEC-filtered Pink Noise, C-weighted)
