1. To assure proper installation measure the voltage on each phase and insure the correct device is installed.
2. Turn off power to circuit where surge protector is to be installed.
3. Mount device so as to keep conductor length as short as possible. Cut wires to length and connect to circuit per wiring diagram below
avoiding sharp bends or looping.
4. Reinstall covers, restore power and conrm diagnostic LED is Illuminated.
H1-75-04N Installation Instructions
Surge Protection Device 120/240 Volt AC Type 1
120/240 Vac Installation Diagram
Disconnect
120 Vac Installation Diagram
Service Panel
240V ac
120V ac
120V ac
Black Black
Line 1 Line
Ground* Ground*
Line 2 Neutral
Green Green
Black Black
120V ac
Diagnostic Operation Device Ratings
LED On = System Protected
LED Off = Replace Device
Normal Voltage Per Leg
Max. Discharge Current (Imax)
Max. Operating Voltage (MCOV)Per Leg
Nipple mount to enclosure for type one installation
120 Vac
75 kA
150 Vac
*All surge protection devices require good ground
connection for effective operation
Installation Instructions
Ground
Black
Black Green
Ground
Green
Black
Neutral

www.pspproducts.com Phone: [phone] [email protected] Fax: [phone]
PSP Products Inc. - 8535 Phoenix Drive, Manassas, VA 20110
2
H1-75-04N Installation Instructions
Surge Protector Lifetime Warranty
$50,000 Connected Equipment Warranty
Call 800-648-6802 to request a claim form
PSP Products Inc. Warrants our surge protector model H175-04N to be free from defects in material and
workmanship for the lifetime of the original purchaser. We will repair or replace any defective unit returned to us
under the terms of this warranty. Warranty registrations cards must be completed and returned to us within 10
days of installation. The following exclusions apply.
Units damage as a result of direct or close proximity lighting strikes, sustained over voltages,
improper installation, abuse or acts of god.
Under the terms of this warranty PSP Products Inc. Will repair or replace any motor or electro mechanical
component of the connected HVAC system that is damaged as a result of a surge passing through our device. We
will pay up to $1,000.00 per occurrence with a $50,000 lifetime maximum. We reserve the right to repair/replace
the damaged equipment or pay fair market value of the equipment at the time damage occurs.
The surge protector must show signs of surge damage and not operating outside of its labeled specications.
The surge protector must be returned to PSP Products at the purchasers expense with any claims for damage.
Damages resulting from sustained over voltages, direct or close proximity lighting strikes, improperly grounded
or installed devices, acts and acts of god are excluded from this warranty.
All claims must be made within 14 days of the surge occurrence.
