Pullman Holt E1200 Application guide

Save For Future Reference
Replacement Parts List
Portable Tank Extractor
Model E-1200
Vac Motors Replacement Parts
Ref.
No. Part No. Description Qty.
1 B703473 Cord Set 1
2 B703472 Cord Retainer 1
3 B703471 Switch 3
4 B703470 Switch Plate 1
5 B703469 Motor Strap 2
6A B703468 Motor A/C 1
6B B703522 Motor B/C 1
7 B703467 Exh. Hose Adapter 1

Body Replacement Parts
Ref.
No. Part No. Description Qty.
1 B703496 Lid Hinge 1
2 B703495 Lid 1
3 B703494 Lid Gasket 1
4 B703493 Hose Barb 1
5 B703492 Gasket 1
6 B703491 Elbow 1
7 B960941 Dump Valve 1
8 B980227 Gasket 1
Ref.
No. Part No. Description Qty.
9 B980228 Nut 1
10 B703490 Float Cage w/Ball 1
11 B703489 Filter 1
12 B703488 Coupler 1
13 B703487 Latch 1
14 B703486 Elbow 1
15 B703485 Screen 2

Component Parts
Ref.
No. Part No. Description Qty.
1 B703484 Handle 1
2 B703483 Caster 2
3 B703482 Bumper Guard 1
4 B703481 Bumper Insert 1
5 B703480 Filter Screen 1
6 B703479 Close Nipple 1
7 B703478 90° Elbow 1
Ref.
No. Part No. Description Qty.
8 B703477 Hose Barb 2
9 B700144 Hose Barb 1
10 B700144 Hose Barb 1
11 B703476 Pump 1
12 B703475 Spring 1
13 B703474 Wheel 2
14 B703521 Hub Cap 2

10702 N 46th Street •Tampa, FL 33617
[phone] •toll free [phone]
fax [phone] •order entry fax [phone]
www.pullmanholtcorp. com B703607 1/04
WIRING DIAGRAM
2 Vacuum Motors, 1 Pump
WARNING
Any repairs to the electrical system should be preformed by
an Authorized Pullman-Holt Service Center or by a qualified
electrician.
