TM-6740 Series Progressive Scan Shutter Cameras
TM-6740 Series Progressive Scan
Shutter Cameras
Operation Manual
1 Introduction
1.1 Product Description
The PULNiX TM-6740 series consists of dual-tap output, high-speed progressive scan CCD cameras.1
The interline-type CCD permits full vertical and horizontal resolution of very high speed shutter images
and applications. The electronic shutter, which has speeds to 1/64,000 sec., can be reset asynchronously
by external pulse control. The frame rate for a full image is 200 fps, with partial scan mode of up to
3200 fps. A 4:3 ratio imager format with uniform square pixels provides superior image definition in
any orientation. On-chip micro lenses provide increased sensitivity.
The TM-6740 has a full dynamic range control function, which can be set at externally selectable look-
up table (LUT) knee slopes to convert 10-bit input to 8-bit output, thereby optimizing the CCD’s full
dynamic range in the normal output signal range. As a dual-tap outputs camera, the TM-6740 has dual-
channel auto-black level balancing2and semi-auto-gain balancing functions. The camera has a dual-tap,
10-bit/8-bit Camera Link output (see Figure 1, “CL (Camera Link) System Configuration,” on page 3).
All the key functions are controlled via a Camera Link serial communication interface.
Applications for the TM-6740 include machine vision, medical imaging, intelligent transportation
systems, high-definition graphics, on-line inspection, gauging, character reading, archiving, and high-
security surveillance.
1. The TM-6740 series consists of TM-6740CL, TMC-6740CL (Camera Link), TM-6740GE, and
TMC-6740GE (gigabit ethernet). Unless otherwise noted, all information contained in this manual
is relevant to all models.
2. Due to the CCD’s structure, auto-black level balancing works with full-image scan modes and ver-
tical partial scan modes. Auto-black level balancing does not work with horizontal partial scan
modes.

Page 2
Introduction
TM-6740 Series Progressive Scan Shutter Cameras
1.2 Features
•Miniaturized and lightweight
The printed circuit boards in the TM-6740 have been arranged based on a new design philosophy.
This creates modular electronics for the camera, giving it flexibility. In addition, the use of
miniature solid-state components results in a compact, lightweight camera that is 50.8mm x
50.8mm x 81.5mm in dimensions, and weighs only 155 grams.
•Imager
The TM-6740 uses a dual-tap progressive-scan interline transfer CCD that has the following
features:
- Resolution of 640 x 480 active pixels for excellent image quality.
- 7.4 x 7.4 µm square pixels for precise dimensional measurement.
- High-speed electronic shutter capability for high dynamic resolution of moving objects that
eliminates the need for a mechanical shutter.
- Progressive-scan CCD eliminates interlace deterioration of image and increases ease of
computer interface.
- High sensitivity and low noise at fast scanning. The CCD has an excellent S/N ratio at the
default setting that is greater than 48dB.
- The CCD has a built-in microlens for increased quantum efficiency.
•Electronic shutter
The TM-6740 has a substrate drain-type shutter mechanism which provides superb pictures at
various speeds without smearing. For more information, please see Section 3.3, “Electronic
Shutter,” on page 13.
•Asynchronous reset
The TM-6740 captures async reset images and provides single-shot video output with single FDV.
This makes it simpler for an ordinary frame grabber to capture the async reset images. The TM-
6740CL’s asynchronous reset is flexible and accepts external horizontal drive (HD) for phase
locking. When the VINIT (5V) pulse is applied to CC1, it resets the camera's scanning and purging
of the CCD.
The TM-6740 has three modes to control the asynchronous reset and shutter speed:
- Async, no shutter. The video signal and FDV are reset by external VINIT.
- Internal shutter speed control. The speed control varies from 1/250 to 1/64,000 sec. The
video signal and FDV starts with internal V reset timing related to shutter speed.
- External VINIT with pulse width. The duration between pulse edges controls the shutter
speed externally.

Page 3
Introduction
TM-6740 Series Progressive Scan Shutter Cameras
•Output
The TM-6740 has a dual tap 10-bit/8-bit Camera Link output. The analog output is
714 mVp-p composite video (75 ohms) on all models.
•Dual-Channel Auto Black Level Balancing and Semi-Auto Gain Balancing
The TM-6740, as a dual-tap output camera, has auto black level balancing and semi-auto gain
balancing functions.
•Integration
The TM-6740 is capable of capturing high-resolution integration images. Its CCD imager can be
exposed for longer than the normal scan timing of 1/200 sec. This integration feature provides extra
sensitivity for applications in dark environments. The progressive scan imager permits a full frame
of resolution in non-interlace format. Integration is achieved by applying INTEG signal to CC2
control of Camera Link or by feeding VINIT pulse width control up to 1 sec of the pulse width in
async pulse width control mode for the frames to be integrated.
•Warranty
Please contact your factory representative for details about the warranty.
1.3 System Configuration
FIGURE 1. CL (Camera Link) System Configuration
Figure 1 below presents a typical system configuration for the Camera Link version.
CAMERA LINK
POWER VIDEO
Computer with
Camera Link™
frame grabber
PD-12P (series)
power supply
Power and
Ext. Sync
26CL-02-26
12P-02S
or
1
2
3
456
9
8
7
11 12
10

Page 4
Installation
TM-6740 Series Progressive Scan Shutter Cameras
2 Installation
The following instructions are provided to help you to set up your camera quickly and easily. We
suggest that you read through these instructions before you unpack and set up your camera system.
2.1 Getting Started
2.1.1 Unpacking Instructions
We recommend that you save the original packing cartons for the cameras and accessories in case you
need to return or exchange an item.
We also recommend that you bench-test any equipment being sent to another location for field
installation to assure that everything is fully operational as a system.
2.1.2 Components List
Please begin by checking your order against the Components List shown below to assure that you have
received everything as ordered, and that nothing has been overlooked in the packing materials. If any
item is missing, please contact your PULNiX representative immediately.
•TM-6740 camera
•Camera-specific data sheet
•Camera-appropriate operation manual (if ordered)
•Dual-tap AccuPiXEL camera-control software
2.1.3 Accessories and Options
Following is a list of additional accessories and options that may be required for your application.
Please check with your PULNiX representative before you install your camera to determine what you
might need.
•PD-12U series power supply
•12P-02S power cable
•26CL-02-26 Camera Link cable
2.2 Camera Setup
2.2.1 Heat Dissipation
The TM-6740 is a compact 640 by 480 camera. Since all the electronics have been packed in a compact
package, the outer case of the camera can become hot due to heat dissipation. For optimal performance,
PULNiX recommends using a cooling fan to set up a positive air flow around the camera and following
the precautions below.

Page 5
Installation
TM-6740 Series Progressive Scan Shutter Cameras
•Mount the camera on a large heat sink (camera bracket) made out of heat-conductive material like
aluminum.
•Make sure the flow of heat from the camera case to the bracket is not blocked by a non-conductive
material like plastic.
•Make sure the camera has enough open space around it to facilitate the free flow of air.
Please contact JAI PULNiX, Inc. at [phone] or send an E-mail to [email protected] if you
have any questions.
2.2.2 Connector Pin Configurations
2.2.2 (a) 12-Pin Connector
The TM-6740 has a 12-pin Hirose connector for power input and
signal integration. Pin #1 is Ground and pin #2 is +12V DC. The
pin-out table is shown below.
TABLE 1. 12-Pin Connector
Pin Description Pin Description
1GND 7NC/VD in*
2 +12V DC 8 Strobe
3 GND (analog) 9 NC/HD in*
4 Video out 10 NC*
*. Option 25-2 TTL inputs on 12-pin
5 GND (digital) 11 NC/Integration Control*
6NC/VINIT in*12 NC
1
2
3
456
9
8
7
11 12
10

Page 6
Installation
TM-6740 Series Progressive Scan Shutter Cameras
2.2.2 (b) Digital I/O Connector
The TM-6740 has a 26-pin connector on the rear panel to output Camera Link data. The connector pin-
out is shown in Table on page 6.
Note: SerTC: Serial To Camera
SerTFG: Serial to Frame Grabber
2.2.2 (c) Analog Output Connector
The TM-6740 has a BNC connector on the rear panel to output analog
video signal (80 MHz).
2.2.3 Camera Link Cable
The 26CL-02-26 cable assembly has been standardized as the Camera Link cable. This cable has a 26-
pin connector on both ends. This is a straight-through cable and the pin-out configuration is shown in
Table on page 6. Contact PULNiX for cable lengths other than 2 meters.
TABLE 2. Connector and Pin-Out Configurations
Camera Link Connector
Pin # Description I/O Pin # Description I/O
1 GND 14 GND
2 Tx OUT 0- Out 15 Tx OUT 0+ Out
3 Tx OUT 1- Out 16 Tx OUT 1+ Out
4 Tx OUT 2- Out 17 Tx OUT 2+ Out
5 Tx CLK OUT - Out 18 Tx CLK OUT+ Out
6 Tx OUT 3- Out 19 Tx OUT 3+ Out
7 SerTC+ In/RXD+ 20 SerTC- In/RXD-
8 SerTFG- Out/TXD- 21 SerTFG+ Out/TXD+
9 CC1- In/VINIT- 22 CC1+ In/VINIT+
10 CC2+ In/INTEG+ 23 CC2- In/INTEG-
11 CC3- In/EX_HD- 24 CC3+ EX_HD+
12 CC4+ In/EX_VD+ 25 CC4- EX_VD-
13 GND 26 GND
1
1426
13

Page 7
Installation
TM-6740 Series Progressive Scan Shutter Cameras
FIGURE 2. 3M Camera Link Cable
Note: For CL versions, serial communication for camera control is done via the Camera Link
connector on the rear panel of the camera.
2.2.4 Power Supplies and Power Cable Setup
2.2.4 (a) Power Supplies
The TM-6740 camera requires 12V DC power that is obtained through the 12-pin connector located on
the rear panel of the camera. PULNiX recommends the following power supplies:
PD-12UU 100-240V AC/12V DC 1.2A universal voltage power supply,
US Plug
PD-12UUP PD-12UU with12-pin connector US plug
PD-12UE PD-12UU European plug
PD-12UEP PD-12UU with 12-pin connector European plug
For users providing power through the 12-pin connector, the PD-12P, PD-12UEP and PD-12UUP
power supplies are available with the 12-pin mating connector already attached to the leads from the
power supply. The PD-12UU and PD-12UE power supplies can be connected to the PULNiX power
cable via a terminal strip or directly.
When wiring the PD-12UU and PD-12UE power supplies directly, please note the following:
•The lead ends must be twisted together and tin-soldered for strength and electrical continuity.
•Shrink tubing or a similar insulator should be used to prevent exposed leads from touching and
shorting.
•The +12V lead is marked with a red stripe or white lettering; be sure not to reverse the leads.
•All connections must be properly insulated to prevent shorting.
26 Position
High Density
Mini D Ribbon
(MDR) Male Plug
Cable
26 Position
High Density
Mini D Ribbon
(MDR) Male Plug
2X
Thumbscrews
2X
Thumbscrews
123
14 15 16
11 12 13
24 25 26
456
17 18 19
789
20 21 22
10
23
123
14 15 16
11 12 13
24 25 26
456
17 18 19
789
20 21 22
10
23

Page 8
Installation
TM-6740 Series Progressive Scan Shutter Cameras
2.2.4 (b) PULNiX Power Cables
If you are using PULNiX power cables such as the 12P-02S, please refer to the 12-pin connector pin-out
diagram below. The cable pin-out diagram is shown in Figure 3 below. The color-coded leads use Gray
for Ground and Yellow for +12V.
FIGURE 3. 12P-02S Interface Cable (optional)
Note: Make sure that the unused leads are not touching and that there is no possibility that
exposed wires could cause the leads to short.
2.2.4 (c) Building Your Own Power Cable
Refer to the 12-pin connector pin-out in Figure 3 on page 8. Connect the Ground lead to pin #1, and the
+12V DC lead to pin #2 of the 12-pin connector. Power must be DC-regulated, and of sufficient current
to properly power the camera.
2.2.4 (d) Attaching the Power Cable to the Connector
The 12-pin connector is keyed and will only fit in one orientation. Follow these directions to properly
attach the power cable to the camera connector:
1. Rotate the connector while applying slight pressure until the keyways line up.
2. Press the connector into place until firmly seated.
3. Plug the power cord into the 100V AC socket. This will power the camera up.
12P-02S Interface Cable
Pin# Lead Color Function Pin# Lead Color Function
1 Gray GND 7 Black coax VD Input*
2 Yellow +12V DC 8 White coax shield Strobe Output
3 Red coax shield AGND 9 White coax HD Input*
4 Red coax Video Out 10 Brown N/C
5 Orange coax shield DGND 11 Blue Integration*
6 Orange coax VINIT Input*
*. Optional OP25-2 TTL inputs on 12-pin connector
12 Black coax shield N/C
HD In (White Coax)
Video Out (Red Coax)
VD In (Black Coax)
Power (Yellow)
+12 V
Analog
Frame Grabber
GND (Gray)
}
Male

Page 9
Installation
TM-6740 Series Progressive Scan Shutter Cameras
2.2.5 Attaching the Analog Video Output
When connecting the TM-6740 to an analog frame grabber, use the BNC connector on the rear panel of
the camera. The input of the monitor should be balanced for 75 ohms termination.
The multi-conductor cable 12P-02S from PULNiX can be used to transmit analog video, power, sync.
signals, and serial communication. The mini coaxial leads in PULNiX multi-conductor cables are
designed for short runs of no longer than 10 feet.
Note: Make sure that no extraneous wires are visible which could cause a short.
2.2.6 Attaching the Camera Lens
The TM-6740 camera accepts 1/3" or larger format size C-mount lenses. To attach the C-mount lens3to
the camera, carefully engage the threads and rotate the lens clockwise until it firmly seats on the
mounting ring. Do not force the lens if it does not seat properly. Please note that some lenses with
extremely long flangebacks may exceed the mounting depth of the camera.
3. C-mount to F-mount and C-mount to K-mount adapters are available for larger format lenses
(35mm). Check with local photography dealers for these lens adapters.

Page 10
Operation
TM-6740 Series Progressive Scan Shutter Cameras
3 Operation
3.1 Camera Rear Panel
3.1.1 Digital I/O Connector (Camera Link)
Refer to Section 2.2.3 on page 6 for information on digital output connectors.
3.1.2 Analog Output Connector
The camera has a BNC connector on the rear panel to output analog video signal.
3.1.3 Power and External Sync Connector
Refer to Section 2.2.2 (b on page 6 for information on the power and external sync. connectors.
3.2 Progressive Scanning
Standard TV-system scanning is 525 lines interlace scanning as specified in the RS-170 protocol. Every
other horizontal line (odd lines and even lines) is scanned at a 60Hz rate per field, and the scanning is
completed with two fields (one frame) at 30Hz rate. Because of the interlace scanning, the vertical
resolution of CCD cameras is limited at 350 TV lines, regardless of the horizontal resolution. When
electronic shutter is applied, the CCD can hold only one field of charge at each exposure. This means
that the vertical resolution of the electronic-shutter camera is only 244 TV lines. The situation is the
same for an HDTV-format camera, since it has interlaced scanning and the vertical resolution of the
shuttered image is 500 lines.
The TM-6740 uses a state-of-the-art progressive scanning interline transfer CCD which scans all lines
sequentially from top to bottom at one frame rate. Like a non-interlace computer screen, it generates a
stable, crisp image without alternating lines and provides full vertical TV resolution of 480 lines. Due to
the TM-6740CL’s extremely high frame rate, however, it will not synchronize to most monitors.
The interline transfer architecture is also important to generate simultaneous shuttering. This is different
from full frame transfer architecture which requires a mechanical shutter or strobe light in order to
freeze the object motion.
CAMERA LINK
POWER VIDEO
1
2
3
456
9
8
7
11 12
10

Page 11
Operation
TM-6740 Series Progressive Scan Shutter Cameras
The TM-6740 outputs the progressive-scanned image with an electronic shutter in thirty-six different
formats. See Table 3 on page 12 for more information.
1. Progressive-scanning digital and analog output
The CCD signal goes through A/D converters 10-bit in, 10-bit/8-bit out. The digital out-
put is available via the Camera Link connector.
The analog output is the same as 75 ohms, 714mV format available from BNC and 12-
pin connector.
2. Full Progressive Scan
Normal scanning mode the TM-6740 is for 640 x 480 pixels. The standard speed with
dual-channel output is 200 frame/sec at the pixel clock of 40 MHz. The progressive scan
reads every line from top to bottom and all lines are exposed with a single electronic
shutter.
FIGURE 4. Full Progressive Scan Mode (A)
3. Partial Scan Mode
By selection, the camera has three partial scan modes: centered 160 lines, centered 224
columns, and centered 224 x 160 area. In partial scan mode at 1000 lines, partial scan’s
frame rate is 28fps. 500 lines is 50 fps, 250 lines is 80 fps.
FIGURE 5. Partial Scan Mode (B, C, and D)
line 1
line 2
n
n+1
224
160
224
160
B DC
Scan Area

Page 12
Operation
TM-6740 Series Progressive Scan Shutter Cameras
4. Binning Mode
The TM-6740 series has horizontal and vertical binning. By selection, the camera has
1x2, 1x4, 2x1, 2x2, 2x4, 4x1, 4x2, and 4x4 binning.
TABLE 3. TM-6740 Scan Mode
Scan Mode
Active Pixels
Vertical
Frequency (Hz)
Horizontal
Frequency
(KHz)
Output Clock
Binning Scan Area
Digital
(MHz)
Analog
(MHz)
No binning
A 640x480 200 100
40 80
B 640x160 540 100
C 224x480 500 250
D 224x160 1250 250
1x2
A 640x240 400 100
B 640x80 1000 100
C 224x240 1000 250
D 224x80 2315 250
1x4
A 640x120 712 100
B 640x40 1596 100
C 224x120 1602 250
D 224x40 3205 250
Binning
r
Σ r·n-(r-i)
i=1
(r=1,2,4;
n=1,2,3,...)
c
Σ c·n-(c-i)
i=1
(c=1,2,4;
n=1,2,3,...)
