Pulsar ARADIN3 User manual

INSTALLATION GUIDE
ENGLISH
Code: ARADIN3
Name: Enclosure 4U with a DIN-TH35-24xS rail for RACK cabinets
IM ARADIN3
Edition: 1 from 02.07.2014
Supersedes: ---------------
1. Intended use: EN
The enclosure with a DIN rail for RACK cabinets is intended for mounting equipment located inside DIN enclosures, for
RACK 19’’ cabinets. The enclosure features a DIN rail, length: 24x1S. The height of the mounted module cannot exceed
160mm. The enclosure can accommodate max. 24 fuses, 1 S wide. Six M6 screws with cage nuts for mounting in RACK
cabinets are included. The enclosure features a 420x20 mm labeling field. There are cable ducts in the top and bottom
panel of the enclosure, 10 pieces. A holder for a 17Ah/12V battery is included.
2. Specifications:
SPECIFICATIONS
External dimensions
W=
481,5
H=
175
D=
234
[mm
, +/
-
2]
Internal dimensions
W=
445
H=
170
D=
155
Operation temperature range
-
1
0
o
C ÷ +
4
0
o
C
Net/gross weight
3,77
/
4
,
10
[kg]
Materials
sheet metal DC01, 1,0mm thick
rust protection
colour: RAL 9005 BLACK
Enclosure/IP.
IP20
Use
inside
Closing
bolted
Notes
-
the enclosure can accommodate max. 24 fuses, 1 S wide
- the enclosure features a 420x20 mm labeling field
- the enclosure is equipped with 6 M6 screws with cage nuts for
mounting in RACK cabinets and a holder for a 17Ah/12V battery
Declarations
Ro
HS
3. Dimensions:

4. Enclosure:
MANUFACTURER
Pulsar K.Bogusz Sp.j.
Siedlec 150,
32-744 Łapczyca, Poland
Tel. [phone], Fax. [phone]
e-mail: [e-mail], [email protected]
http:// www.pulsar.pl, www.zasilacze.pl
WARRANTY
24 months from the date of purchase.
THE WARRANTY IS VALID only upon presentation of the item’s proof of purchase
