Pulse Shower Spas Nirvana 1070-CH User manual

Nirvana Shower System
Model #1070-CH
PW-91070-8225CP
Owner's Manual
All images shown are for illustration purposes.
Actual product may vary due to prodcut enhancement.
D
r
i
l
l
-
l
e
s
s

2
Nirvana Shower System/PW-91070-8225CP
Please Read The Following Instructions
COMPLETELY Before Beginning!
Our goal is to ensure your installation goes smoothly and safely. Please read these
instructions carefully and follow recommendations for plumbing and mounting. After
reading instructions, if you determine you do not have the necessary skills and/or tools,
we recommend that a licensed plumbing contractor complete the installation.
If you encounter any problems during installation
PLEASE VISIT CUSTOMER SUPPORT AT
WWW.PULSESHOWERSPAS.COM
Before returning your shower system to the store
You Will Need The Following Tools
Soft pencil or felt pen to mark tile
Allen wrench
Safety glasses
Phillips screwdriver
Channel locks or adjustable wrench
Plumber's Tape
Drill (Preferably cordless)

Parts Legend
1. Set Screws
2. Shower System
3. Showerhead
4. Mirror
5. Handshower
6. Handshower Holder
7. Handshower Hose
8. Loofa Hose
9. Shelf
10. Allen Wrench
11. Shelf Screw
12. Wall Mount
13. Mounting Screws
14. Wall Anchors
15. Stainless Steel Gasket
16. Glue
17. Plumber's Tape
18. Washer
19. Loofa Glove
20. Soap Dispenser
21. Diverter
22. Soap Control Handle
3

4
Installation Instructions
28”
minimum
28”
minimum
28”
minimum
1
2
Make sure distance from water outlet and mixing valve trim
(NOT INCLUDED) is a minimum 28" or more.
Remove existing showerhead from shower arm
Remove any remnants of old plumber's tape and ush out
shower pipe.
BEFORE YOU BEGIN
Measure the following to ensure
your shower system will t properly.
Measure

5
Glue
Back of
handheld
holder
Glue
Back of
handheld
holder
Installation Instructions
Glue
Back of
wall mount
Glue
Back of
wall mount
3 5
4 6
Loofa assembly: Connect loofa (19) and loofa hose (8) to shower
system (2).
Shelf assembly:Use allen wrench(10) and shelf screw(11) to assemble
the shelf (9) onto the shower system (2).
Insert washer (18) and screw shower system (2) onto shower arm.
Insert washer (18) and screw showerhead (3) to shower system (2).
Glue handshower holder (6) onto wall, let cure for 24 hours.
Place mirror (4) onto shower system (2) and secure.
Insert washer (18) into the hex end of the handshower hose (7).
Attach hose to handshower outlet located on the bottom of the diverter (21).
Insert washer (18) into the tapered end of the handshower hose (7)
and attach the handshower (5).
Place the tapered end of the hose into the handshower holder (6).
Measure to conrm correct positioning of wall mount (12).
Drill less option: Glue wall mount onto wall, let cure for 24 hours.
Drill Option: Drill wall anchors (14) into place. Drill wall mount (12)
using stainless steel gaskets (15) and mounting screws (13).
Handshower holder is
tapered. Assure larger
opening is upright.

6
Max soap
OFF
USAGE:
SOAP DIVERTER INSTRUCTIONS:
Use soap diverter to control amount of soap on
the loofa.
Use existing shower valve to turn water on/o and
adjust temperature.
Always turn cold water on rst to help prevent any
accidental burning or scalding; especially for children
and elderly.
Use diverter to choose desired function. Switch
between showerhead, handshower, or loofa.
Use mirror slider to slide mirror up and down part of the
shower system
When using the loofa, make sure you have enough soap
in the soap dispenser. Rell soap dispenser at the top.
DO NOT use any part of the shower system as a
support device.
Installation Instructions
Max soap
OFF
Product fully assembled
7
Insert soap here
Mirror Slider
Soap level window

7
MANUFACTURER'S LIFETIME LIMITED WARRANTY
1. Defects Covered; Warranty Period: Pulse Shower Spas,
Inc. (“Pulse”) warrants to the original consumer purchaser
who purchases this shower spa (the “Product”) for use in
his or her own home, that the Product will be free from
defects in material and manufacturing workmanship for as
long as the original consumer purchaser owns that same
home. For all other purchasers (including, but not limited
to purchasers for industrial, commercial and business use),
the above warranty will apply for a period of 5 years from
the original date of purchase.
2. Remedy: If the Product does not conform to the above
warranty, Pulse, at its option, will repair or replace the
Product, free of charge, or refund your purchase price. For
warranty claims, please visit www.pulseshowerspas.com/
index.php/warranty. Pulse may require that you return the
Product to Pulse, shipping prepaid, in which case Pulse will
provide you with a return materials authorization number
(RMA). Pulse may also require that you provide evidence
of the date you purchased the Product. Pulse will ship a
new or repaired Product to you, at the expense of Pulse,
or refund your purchase price. Service labor performed
by you or others in connection with the removal or
replacement of the Product will not be reimbursed
by Pulse.
3. Exclusions: Pulse shall not be responsible for failure of
the Product, and the above warranties will not apply, if the
Product fails as a result of improper installation, improper
use, modications or repairs by anyone other than Pulse,
or accident or abuse (including damage during shipment).
4. Warranty on Repairs and Replacements: For consumer
purchasers who purchased the Product for home use,
repaired or replacement Products will continue to be
covered under this warranty for as long as he or she
owns that same home. For other purchasers, repaired or
replacement Products will be covered for the balance of
the original warranty period.
5. No Other Warranties; Limitation of Liability: OTHER
THAN THE LIFETIME LIMITED WARRANTY STATED
ABOVE, PULSE DISCLAIMS ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, TO THE EXTENT PERMITTED
BY APPLICABLE LAW. THE REMEDIES STATED ABOVE
ARE YOUR SOLE REMEDIES IN CONNECTION WITH THIS
WARRANTY. IN NO EVENT WILL PULSE BE LIABLE TO
YOU FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL, INCLUDING
BUT NOT LIMITED TO LOST PROFITS OR BUSINESS
INTERRUPTION, ARISING OUT OF OR RELATING TO THE
PRODUCT OR ITS USE, WHETHER UNDER A CONTRACT,
WARRANTY, TORT, OR ANY OTHER CAUSE OF ACTION,
EVEN IF PULSE HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. NOTWITHSTANDING THE TERM
OF ANY LIMITED OR IMPLIED WARRANTY, OR IN THE
EVENT THAT ANY LIMITED WARRANTY FAILS OF ITS
ESSENTIAL PURPOSE, IN NO EVENT WILL PULSE’S
ENTIRE LIABILITY EXCEED THE PURCHASE PRICE OF
THE PRODUCT. SOME STATES AND PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE AND PROVINCE
TO PROVINCE.
Care and Maintenance
To keep your shower system looking new, wipe down after each use with a soft cotton cloth.
Protect your tub ller from hard water stains and mineral deposits by periodically using an auto spray wax.
Clean using mild liquid soap and a non-abrasive sponge or cloth. Rinse with clean water.
Do Not Use Any Kind Of
Chemicals Or Abrasives!

PULSE ShowerSpas, Inc. | 297 Anna Street | Watsonville, CA 95076 | 831.724.7300
www.PulseShowerSpas.com
PM-AA-02
NOTES
