Pulse Shower Spas Malibu ShowerSpa 1043-SSB User manual

Malibu ShowerSpa
Model #1043-SSB
PW-91043-2125BSS
Owner's Manual

2
Malibu ShowerSpa Model #1043-SSB / PW-91043-2125BSS
Please Read The Following Instructions
COMPLETELY Before Beginning!
Our goal is to ensure your installation goes smoothly and safely. Please read these
instructions carefully and follow recommendations for plumbing and mounting. After
reading instructions, if you determine you do not have the necessary skills and/or tools,
we recommend that a licensed plumbing contractor complete the installation.
If you encounter any problems during installation
PLEASE VISIT CUSTOMER SUPPORT AT
WWW.PULSESHOWERSPAS.COM
Before returning your ShowerSpa to the store
You Will Need The Following Tools
Soft pencil or felt pen to mark tile
Allen wrench (supplied)
Safety glasses
Tape measure
Level
Reciprocating saw w/ metal cutting blade (Sawzall®)
Channel locks or adjustable wrench
Drill (preferably cordless)
¼" Masonry drill bit

3
Dimensions
11.42 in. - 290 mm
35.43 in. - 900 mm
57.08 in. - 1450 mm
17.71 in. - 450 mm
6.3 in. -
160 mm
7.87 in. -
200 mm
2.75 in. -
70 mm
0.59 in. -
15 mm
0.60 in. -
15.2 mm 0.78 in. -
19.8 mm
100°

4
Parts Legend
1. ShowerSpa
2. Screw............................4
3. Mounting Bracket......2
4. Wall Anchor.................4
5. 90° Elbow/Supply Line
6. Rubber Washer......................3
7. Nut
8. Washer
9. Handshower Holder
10. Handshower Hose
11. Handshower
12. Flow Restrictor..................3
2x
Flow Restrictor Placement:
•2.5/1.8 gpm restrictor inside the showerhead
•2.5/1.8 gpm restrictor in the diverter outlet to the body jet
•2.5/1.8 gpm restrictor with check valve built-in in the
handshower holder

5
Assembly
After Unpacking Your ShowerSpa, Some Assembly Is Required Prior To Installation
Handshower Holder Assembly
1. Insert handshower holder (9) into hole located on side of ShowerSpa and secure with washer (8) and nut (7).
2. Secure nut (7) with adjustable wrench if needed.
3. Attach supply line (5) with rubber washer (6) installed to the handshower holder (9). Securely tighten to ensure no leaks.
Do not overtighten.
After ShowerSpa Is Mounted To The Wall
Connect The Handshower
1. Insert washer (6) into hexagon shaped end of handshower hose (10) and attach to threaded outlet of handshower holder (9)..
Do not over-tighten.
2. Insert silicone washer (6) into tapered end of handshower hose (10) and attach to handshower (11). Insert handshower into holder (9).

6
nstallation
New Construction or Extensive Remodel –New Finished Wall Surface
1. Prior to sheetrock, stub-out ½" hot and cold supply lines
beyond nished wall surface, 4" on center. For best results,
attach 90° brass ttings (available at most hardware stores) to
the stub-outs maintaining ¼" – ½" of space between the tting
and nished wall. The open end of the 90° brass ttings should
point down so the supply lines attach parallel to the wall. 1
2. For a person 5'8" – 6'2" we recommend the stub-outs be either
28" or 38" above nished oor.
2
3. Before installation, make certain that water is COMPLETELY
TURNED OFF to both hot & cold supply lines of shower.
4a. Mark location of holes for the mounts, making sure holes are
plumb. For a person 5'8" – 6'2", we recommend placing the top
hole of the upper mount at approx. 57" above nished oor.
3
4b. Determine location for the lower mount. Measure the distance
between indents on the bottom edges of the two brackets on
back of ShowerSpa. Using this distance, measure down from
the top hole in upper mount to get the location of the top hole
in lower mount.
4c. Use the mounts to mark only one of the lower holes in each
mount, whichever is most convenient.
5. Before drilling holes, make certain that connecting to stub-outs
DOES NOT INTERFERE with backside of ShowerSpa and it is
ush with nished wall at desired mounting height.
2
6. Drill ¼" holes through wall surface using a masonry bit. Drill
slowly through wall surface to avoid cracking and chipping.
Insert anchors and securely screw brackets to wall. Before
connecting hot and cold supply lines, hang the ShowerSpa on
wall, check the height and make sure the ShowerSpa is ush
against wall with a secure t.
7. Connect hot and cold water supply lines to stub-outs—DO NOT
OVERTIGHTEN. Before mounting the ShowerSpa, check ttings
to make sure they are secure. Turn on water and check for
leaks. When ttings are leak-free, mount ShowerSpa on wall.
8. OPTIONAL—Seal around body of ShowerSpa with a bead of
silicone. DO NOT SEAL BOTTOM.
Retrot – Existing Shower Replacement
NOTE—In a remodel in which you are not replacing the nished wall surface (tile, or backing material) it is advisable to purchase a PULSE
ShowerSpa model that covers the location of your existing valve assembly—either single handle or two-handle type. If your PULSE
ShowerSpa model does not cover this area, you will need to either choose another PULSE ShowerSpa model that does or make necessary
repairs with appropriate materials (i.e. wallboard, tile, berglass, etc).
1. TURN OFF WATER SUPPLY TO SHOWER. Typically there is a
gate valve where the water main enters the house. Turning the
water valve o at hot water tank does not turn o cold water
supply line.
2. Make certain water is completely turned o to both hot & cold
supply lines of shower. Turn shower valve on, both hot and cold,
to VERIFY WATER SUPPLY IS OFF. Open a sink faucet in the
bathroom in which you are installing the ShowerSpa to relieve
any pressure and help adequately drain shower supply lines.
3. Remove handle(s) and trim cover(s) of your existing shower
valve, exposing valve body in wall.
4. Locate hot and cold supply lines entering valve. Using a
reciprocating saw with sharp metal saw blade, cut existing
valve out, preserving threads of the supply lines entering valve.
You should also cut the riser within wall supplying the existing
showerhead. Carefully twist and remove valve.
5. Unscrew old showerhead from shower arm, then unscrew
shower arm from wall.
6. Water lines must be extended to the outside of wall cavity, 4"
on center. For best results, attach 90° brass ttings (available
at most hardware stores) to the stub-outs maintaining ¼"– ½"
of space between the tting and nished wall. The open end
of the 90° brass ttings should point down so the supply lines
attach parallel to the wall.
1
7a. Mark location of holes for the mounts, making sure holes are
plumb. For a person 5'8" – 6'2", we recommend placing the top
hole of the upper mount at approx. 57" above nished oor.
3
7b. Determine location for the lower mount. Measure the distance
between indents on the bottom edges of the two brackets on
back of ShowerSpa. Using this distance, measure down from
the top hole in upper mount to get the location of the top hole
in lower mount.
7c. Use the mounts to mark only one of the lower holes in each
mount, whichever is most convenient.
8. Before drilling holes, make certain that connecting to stub-outs
DOES NOT INTERFERE with backside of ShowerSpa and it is
ush with nished wall at desired mounting height.
2
9. Drill ¼" holes through wall surface using a masonry bit. Drill
slowly through wall surface to avoid cracking and chipping.
Insert anchors and securely screw brackets to wall. Before
connecting hot and cold supply lines, hang ShowerSpa on wall,
check the height and make sure ShowerSpa is ush against the
wall with a secure t.
10. Connect hot and cold water supply lines to stub-outs—
DO NOT OVERTIGHTEN. Before mounting the ShowerSpa,
check ttings to make sure they are secure. Turn on water and
check for leaks. When ttings are leak-free, mount ShowerSpa
on wall.
11. OPTIONAL—Seal around body of ShowerSpa with a bead of
silicone. DO NOT SEAL BOTTOM.
1 Additional ttings or longer supply lines may be necessary depending on your specic situation.
2The desired mounting height of ShowerSpa determines, or is determined by location of the ½" stub-outs.
3The mounting height can vary depending on several factors (i.e. location of supply lines, interference from ShowerSpa plumbing, old valve access area,
personal preference, etc.)

7
Usage
Pressure Balance Mixing Valve
This ShowerSpa is equipped with a cUPC® pressure balance mixing valve to adjust water ow and temperature.
The valve automatically adjusts to changes in water pressure (i.e. someone ushes a toilet), keep ing your tem-
perature constant and preventing accidental scalding. To turn on the ShowerSpa simply raise the handle until the
desired ow rate is achieved. Rotate to the right to decrease temperature and rotate to the left to
increase temperature.
Brass Diverter
This ShowerSpa oers independent control of each function - showerhead, handshower, and/or body jets. Water
pressure can be directed to a single function or split between the dierent functions via the three diverter control
handles.
Body Jets
There are two single-function jets with silicone tips for rub clean, Spray-Straight™ performance.
Handshower
The brass handshower has a sleek wand-shaped design that delivers a satisfying power-spray pattern with a
stainless steel stretch hose.
Turning Shower ON/OFF
The on/o of the shower should be controlled by the on/o of the valve. It is not recommended to leave the valve
in the on position and rely on the diverters to turn the water o.
Care and Maintenance
Always blot dry any water from the surface of your ShowerSpa. To protect your ShowerSpa from hard water
stains and mineral deposits, use an auto spray wax periodically and wipe down your ShowerSpa after each use.
Allowing water to evaporate on the surface can lead to a buildup of mineral deposits. Cleaning with a damp,
nonabrasive sponge and drying with a clean soft cloth should help keep your ShowerSpa looking beautiful.
REMEMBER
NEVER use any abrasives or harsh cleaners!
Clean with mild soap and water ONLY!
To keep your ShowerSpa in pristine condition,
DRY AFTER EACH USE!

Manufacturer’s Lifetime Limited Warranty
1. Defects Covered; Warranty Period. Pulse Shower Spas,
Inc. (“Pulse”) warrants to the original consumer purchaser
who purchases this shower spa (the “Product”) for use in his
or her own home, that the Product will be free from defects
in material and manufacturing workmanship for as long as
the original consumer purchaser owns that same home. For
all other purchasers (including, but not limited to purchasers
for industrial, commercial and business use), the above
warranty will apply for a period of 5 years from the original
date of purchase.
2. Remedy. If the Product does not conform to the
above warranty, Pulse, at its option, will repair or
replace the Product, free of charge, or refund your
purchase price. For warranty claims, please visit
www.pulseshowerspas.com/index.php/warranty. Pulse
may require that you return the Product to Pulse, shipping
prepaid, in which case Pulse will provide you with a return
materials authorization number (RMA). Pulse may also
require that you provide evidence of the date you purchased
the Product. Pulse will ship a new or repaired Product to
you, at the expense of Pulse, or refund your purchase price.
Service labor performed by you or others in connection
with the removal or replacement of the Product will not be
reimbursed by Pulse.
3. Exclusions. Pulse shall not be responsible for failure of
the Product, and the above warranties will not apply, if the
Product fails as a result of improper installation, improper
use, modications or repairs by anyone other than Pulse, or
accident or abuse (including damage during shipment).
4. Warranty on Repairs and Replacements. For consumer
purchasers who purchased the Product for home use,
repaired or replacement Products will continue to be
covered under this warranty for as long as he or she
owns that same home. For other purchasers, repaired or
replacement Products will be covered for the balance of
the original warranty period.
5. No Other Warranties; Limitation of Liability. OTHER
THAN THE LIFETIME LIMITED WARRANTY STATED
ABOVE, PULSE DISCLAIMS ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, TO THE EXTENT PERMITTED
BY APPLICABLE LAW. THE REMEDIES STATED ABOVE
ARE YOUR SOLE REMEDIES IN CONNECTION WITH THIS
WARRANTY. IN NO EVENT WILL PULSE BE LIABLE TO
YOU FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL, INCLUDING
BUT NOT LIMITED TO LOST PROFITS OR BUSINESS
INTERRUPTION, ARISING OUT OF OR RELATING TO THE
PRODUCT OR ITS USE, WHETHER UNDER A CONTRACT,
WARRANTY, TORT, OR ANY OTHER CAUSE OF ACTION,
EVEN IF PULSE HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. NOTWITHSTANDING THE TERM OF
ANY LIMITED OR IMPLIED WARRANTY, OR IN THE EVENT
THAT ANY LIMITED WARRANTY FAILS OF ITS ESSENTIAL
PURPOSE, IN NO EVENT WILL PULSE’S ENTIRE LIABILITY
EXCEED THE PURCHASE PRICE OF THE PRODUCT. SOME
STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES SO THE ABOVE LIMITATIONS OR EXCLUSIONS
MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE AND
PROVINCE TO PROVINCE.
PULSE ShowerSpas, Inc. | 297 Anna Street | Watsonville, CA 95076 | 831.724.7300
www.PulseShowerSpas.com
PULSE20-REV. D
