Pulse Shower Spas Lanikai PW-91028-1618BRN User manual

Lanikai Shower System
Model #1028-BN, 1028-CH, 1028-MB
PW-91028-1618BRN, PW-91028-1618CP, P W-91028-1618BM
Owner's Manual

Lanikai Shower System Model #1028
Please Read The Following Instructions
COMPLETELY Before Beginning!
Our goal is to ensure your installation goes smoothly and safely. Please read these
instructions carefully and follow recommendations for plumbing and mounting. After
reading instructions, if you determine you do not have the necessary skills and/or tools,
we recommend that a licensed plumbing contractor complete the installation.
If you encounter any problems during installation
PLEASE VISIT CUSTOMER SUPPORT AT
WWW.PULSESHOWERSPAS.COM
Before returning your Shower System to the store
You Will Need The Following Tools
Soft pencil or felt pen to mark tile
4mm & 5mm allen wrench
Safety glasses
Tape measure
Level
Channel locks or adjustable wrench
Drill (preferably cordless)
Masonry drill bit
2

Lanikai Parts Legend
1. Showerhead
2. Shower Arm
3. Shower Arm Riser
4. Set Screws..................3
5. Escutcheon
6. Inlet Fitting
7. Shower pipe
8. Body Jets
9. Handshower Holder
10. Handshower
11. Washer.......................3
12. Hose
13. Diverter Body
14. Diverter Handle
15. Wall Mount
16. Mounting Screws..........2
17. Wall Anchors..................2
18. Allen Wrench
19. Plumber's Tape
20. Glue
21. Nipple Extensions.........2
3

4
Installation Instructions
28”
minimum
28”
minimum
28”
minimum
28”
minimum
New Construction
Make sure distance from water outlet and
mixing valve trim (NOT INCLUDED) is a
minimum 28" or more.
BEFORE YOU BEGIN
Measure the following to ensure
your Lanikai Shower System will
t properly.
Retrot
Remove existing shower arm and shower head.
Make sure distance from water outlet and
mixing valve trim (NOT INCLUDED) is a
minimum 28" or more.

5
Installation Instructions
Step 1
Step 2
12
Screw shower arm riser (3) to shower pipe (7).
Attach shower arm (2) to shower arm riser (3) and
secure. Slide escutcheon (5). Screw showerhead (1) to
shower arm (2) and secure.
[Step 1] Apply a generous amount of PTFE (plumber's)
tape to end of end of nipple.
[Step 2]Screw nipple into tting which old shower arm
was screwed into. Use allen wrench provided to secure.
DO NOT OVERTIGHTEN.
Use nipple extensions as needed.
Step 1
Step 2
3
Mixing valve
(NOT INCLUDED)

6
Step 1
Step 2
Step 3
Step 1
Step 2
Step 3
6
6.1
7
OPTIONAL
CAUTION: Live Plumbing
Step 1: Slide escutcheon (5) back in order to place set
screw (4) later on.
Step 2: Slide diverter body (13) onto wall mount (15).
Step 3: Secure diverter body (13) to wall mount (15) with
set screw (4) provided. Slide back escutcheon (5) to for a
concealed nished look.
Tape
Glue
Back of wall mount
Tape
Glue
Back of wall mount
5
Attach assembled shower to inlet tting (6) and
secure set screw (4) with allen wrench (18) provided.
Apply glue to wall mount (15) as indicated and add
tape (included) to secure to wall. Let glue cure for 48
hours for complete result.
OPTIONAL: If you wish to drill wall mount (15), place
it on marked location and mark holes for drilling. Set
wall anchors (17) in place. You can follow Step 6 to
place the wall mount (15) for easy, steady, installation.
Drill mounting screws (16) into place.
Use level to assure shower pipe is straight and mark
diverter body (13) location.
4
Installation Instructions

7
8 9
Insert washer (11) into the hex end of the handshower
hose (12). Attach hose (12) to handshower outlet located
on the bottom right of the diverter body (13).
Insert washer (11) into the tapered end of the
handshower hose (12) and attach the handshower (10).
Place the tapered end of the hose into the hand
shower holder (9).
Product Fully Assembled
Installation Instructions

Usage
Diverter valve controls the showerhead, handshower, and body
spray function. Turn diverter knob right or left to the desired
setting. The diverter will click into place at each function.
The shower arm height is adjustable by sliding the arm up or
down while holding the shower pipe with your free hand. The
arm also swings freely to the left or right by gently pressing on
the arm or showerhead.
Rotate face of handshower to switch settings and rotate holder
forward or back to adjust angle.
Change the angle of spray by pushing the jet left, right, up, or
down. This system is equipped with PULSE PowerSpray™ body
jets, to turn o top two jets, turn the jet counter clockwise.
Adjust the hand shower height by depressing the button on the
holder and sliding up or down.
Always turn cold water on rst to help prevent any accidental
burning or scalding; especially for children and elderly.
1.8 GPM
MANUFACTURER'S LIFETIME LIMITED WARRANTY
1. Defects Covered; Warranty Period: Pulse Shower Spas, Inc.
(“Pulse”) warrants to the original consumer purchaser who
purchases this shower spa (the “Product”) for use in his or her own
home, that the Product will be free from defects in material and
manufacturing workmanship for as long as the original consumer
purchaser owns that same home. For all other purchasers
(including, but not limited to purchasers for industrial, commercial
and business use), the above warranty will apply for a period of 5
years from the original date of purchase.
2. Remedy: If the Product does not conform to the above
warranty, Pulse, at its option, will repair or replace the Product,
free of charge, or refund your purchase price. For warranty claims,
please visit www.pulseshowerspas.com/index.php/warranty.
Pulse may require that you return the Product to Pulse, shipping
prepaid, in which case Pulse will provide you with a return
materials authorization number (RMA). Pulse may also require
that you provide evidence of the date you purchased the Product.
Pulse will ship a new or repaired Product to you, at the expense of
Pulse, or refund your purchase price. Service labor performed by
you or others in connection with the removal or replacement of
the Product will not be reimbursed by Pulse.
3. Exclusions: Pulse shall not be responsible for failure of
the Product, and the above warranties will not apply, if the
Product fails as a result of improper installation, improper use,
modications or repairs by anyone other than Pulse,
or accident or abuse (including damage during shipment).
4. Warranty on Repairs and Replacements: For consumer
purchasers who purchased the Product for home use, repaired
or replacement Products will continue to be covered under this
warranty for as long as he or she owns that same home. For other
purchasers, repaired or replacement Products will be covered for
the balance of the original warranty period.
5. No Other Warranties; Limitation of Liability: OTHER
THAN THE LIFETIME LIMITED WARRANTY STATED ABOVE,
PULSE DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, TO THE EXTENT PERMITTED BY APPLICABLE LAW.
THE REMEDIES STATED ABOVE ARE YOUR SOLE REMEDIES
IN CONNECTION WITH THIS WARRANTY. IN NO EVENT WILL
PULSE BE LIABLE TO YOU FOR ANY DAMAGES, WHETHER
DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL,
INCLUDING BUT NOT LIMITED TO LOST PROFITS OR BUSINESS
INTERRUPTION, ARISING OUT OF OR RELATING TO THE
PRODUCT OR ITS USE, WHETHER UNDER A CONTRACT,
WARRANTY, TORT, OR ANY OTHER CAUSE OF ACTION, EVEN
IF PULSE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. NOTWITHSTANDING THE TERM OF ANY LIMITED
OR IMPLIED WARRANTY, OR IN THE EVENT THAT ANY LIMITED
WARRANTY FAILS OF ITS ESSENTIAL PURPOSE, IN NO EVENT
WILL PULSE’S ENTIRE LIABILITY EXCEED THE PURCHASE
PRICE OF THE PRODUCT. SOME STATES AND PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS LIMITED
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO
STATE AND PROVINCE TO PROVINCE.
Care and Maintenance
To keep your Shower System looking new, wipe down after each
use with a soft cotton cloth.
Protect your Shower System from hard water stains and mineral
deposits by periodically using an auto spray wax.
Clean using mild liquid soap and a non-abrasive sponge or cloth.
Rinse with clean water.
If the ow rate of your Shower System is less than desired or
reduces over time, ow restrictors located
in the inlet tting can be removed for cleaning. If further
assistance is required please contact customer care on our
website at www.pulseshowerspas.com and we will
be happy to assist you.
Do Not Use Any Kind Of
Chemicals Or Abrasives!
The Lanikai is equipped with Spray Straight™ technology in the
tips of the showerhead and handshower. If the stream becomes
obstructed from mineral deposits, simply rub the soft tips with
your nger to loosen the deposits.
DO NOT use any part of the Lanikai Shower System as a
support device.
PULSE ShowerSpas, Inc. | 297 Anna Street | Watsonville, CA 95076 | 831.724.7300
www.PulseShowerSpas.com
PM-AA-07
