PulseTech SP-7-OBD-A User manual

The pulsating dc current produced by this product may
interfere with the correct operation of some electronic
devices when the unit is placed near the antenna. In order
to ensure no interference, the circuit box should be placed
away from the antenna.
• Be sure to keep the solar panel clean of dirt and dust so
that it has optimum access to sunlight.
• The circuit box has no moving parts so maintenance is
unnecessary.
• Periodically check to make sure the positive and nega-
tive wires are securely fastened to the battery terminals.
Warranty and Warnings
What Does This Warranty Cover? The warranty covers any defects in workmanship or materials in the circuit
board in the SolarPulse™ product under normal use and service. How Long Does The Coverage Last? This
warranty runs for ten (10) years from the date of purchase. What Will PulseTech Do? PulseTech will, at its
option, replace or repair any defective circuit board with a new or rebuilt circuit board at no charge. What Does
This Warranty Not Cover? This warranty does not cover any parts other than the circuit board. In addition,
PulseTech will not be responsible under this warranty if PulseTech determines that (1) upon examination that
the circuit board failure was (A) caused by misuse, neglect, accident, alteration, or abnormal condition of
operating or handling (including the failure to install the product in accordance with PulseTech’s instructions
and observe the warnings on the product and the instruction manual), or other conditions beyond the control of
PulseTech or (B) damaged in transit to PulseTech, or (2) the owner is not the original purchaser that purchased
the product through an authorized PulseTech dealer or distributer. IN NO EVENT SHALL PULSETECH BE LIABLE
FOR ANY DIRECT, SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, PUNITIVE OR EXEMPLARY DAMAGES,
EXPENSES, LOST SAVINGS OR LOST PROFITS OR ANY OTHER DAMAGES OF ANY KIND FROM ANY BREECH OF
THIS WARRANTY OR OTHERWISE. Some states, provinces or countries do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation may not apply to you. How To Get Service?
Send the product postage prepaid with proof of purchase (sales receipt) within the warranty period to the
authorized reseller where the product was purchased or contact PulseTech directly by calling [phone].
How Does State, Province or Country Law Apply? This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state, province to province or country to country.
THIS WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILI-
TY FOR FITNESS FOR A PARTICULAR PURPOSE.
10-Year Limited Warranty
WARNING
BASIC CLEANING & MAINTENANCE
INSTALLATION MANUAL
For Model SP-7-OBD-A
What SolarPulse Can Do For You
SolarPulse is one of the most effective methods available for charging your
12-volt lead-acid batteries. Besides charging, it also uses our patented Pulse
Technology®to remove and prevent the buildup of lead-sulfate deposits on
your battery plates.
By keeping the plates clean, your battery recharges faster, accepts a full
charge and releases all its stored energy.
The SP-7-OBD-A 7-Watt SolarPulse unit has three components:
• Solar Panel with quick disconnect for easier installation
• Circuit Box housing our exclusive Pulse Technology
• OBD2 connector
Installation is quick and easy. Just follow the steps inside.
WARNING: Because of the possibility of personal injury, always use extreme
caution when working with batteries.
Getting Started
Circuit Box
Quick
Disconnect
Solar Panel
Specifications
Max Charge Current: 450 mA
Maximum Output Voltage: 16.5 V
Solar Panel Dimensions: 10.25" L x 8.85" W x 0.25" H
Circuit Box Dimensions: 3.4" L x 2.4" W x 1.5" H
Main Cable Length: 17'
Box to OBD Connector Length: 3'
Quick Disconnect at Battery
LED Pulse/Charge Indicator
Model Number: SP-7-OBD-A
Part Number: 735X707
OBD2
Connector
Suction Cups

WARNING: Always remove temporary solar panel(s)
before moving the vehicle.
NOTE: For the most effective results, we suggest you install a SP-7
permanently. However, if your vehicle does not allow for a permanent
install, temporary placement of the SP-7-OBD-A will not affect perfor-
mance.
www.pulsetech.net
998XM370 05/20
Push the OBD connector into the OBD port and ensure
it’s secure.
Lay the circuit box on the floor.
Make sure the circuit box’s LED lights up indicating the
solar panel is working at an optimum level. A dimmed
light indicates partial sunlight and you may need to move
the solar panel into direct sunlight for maximum effec-
tiveness.
56
7
Remove the suction cups and solar panel from the box.
Screw a suction cup into each of the four corners of the
solar panel.
Make sure the suction cups are securely attached to
the solar panel, and the bottom of the suction cups are
clean. Mount the solar panel on the inside of the vehicle
windshield where it will have direct access to sunlight.
Let the solar panel cable hang down to the vehicle’s OBD
port.
Connect the quick-disconnect plugs on the solar panel
and circuit box cables.
WARNING: Any solvents that may be harmful to plas-
tic should not be used on or near the unit.
12
34
INSTALLATION INSTRUCTIONS For Model SP-7-OBD-A
