Purafil PuraShield MINI User manual

User Manual
MINI MOLECULAR CAR
AIR FILTRATION UNIT

Product Features
Product Functions
Product Specifications
Content
Your Air Purifier
Usage
Filter Replacement
Warranty
Contact Information
Trouble Shooting Guideline
Product Introduction
Operation Instructions
Safety Precautions

Product Introduction
Thank you very much for choosing this product. The PuraShield Mini vehicle mounted air
purifier adopts a multi-layer purification technology unique to our company. With the Mini,
wherever you go with your vehicle, you will be provided with cleaner air and a healthier
environment.
The PuraShield Mini uses a multi-layer filtration approach for added protection with multiple
unique layers of filtration technologies and UV light integrated into one. It can effectively
remove PM 2.5 particulates, smoke, dust, target viruses and bacteria, and odorous gases.
The filter uses multiple technology layers to eliminate 99.9% of target viruses and bacteria*.
The PuraWard Filter is protected by an embedded micro-technology containing an EPA
registered antimicrobial additive using copper and silver ions to combat many bacteria
and viruses†. Developed and manufactured in the USA, our patented§molecular filtration
media removes aerosols carrying viruses from the air, safely oxidizing the molecules.
With streamlined appearance, this product is easy to use, and highly adaptable with a simple
plug-and-play design and two operating speeds. Power the unit with an included USB power
cable.

Safety Precautions
Please keep the manual at hand for
easy access.
Read the manual carefully before
use.
To use properly, please read and
follow the following notes and
warnings.
When in use, mounting site should not block the airbag or driving activities for
safety reasons.
To prevent damage caused by electronic components’ short-circuit, do not let water
or other liquid or flammable detergent into the product.
To prevent damage caused by electronic components’ short-circuit, do not use
water or other liquid or flammable detergent to clean the product.
Danger
Warnings
A 12V DC USB power cable (included) is required for this unit. Any other power supply
may cause harm or damage.
Unauthorized modification or repairs are not allowed.
Do not place metal pieces such as pins, or any other foreign objects inside the air
inlet/outlet, or it may cause damage or at the risk of electric shock.
If the cord is damaged, to avoid danger, please send the product to us or local
service center for replacement.
Please turn off and unplug the product during filter replacement, cleaning, or
moving.
When connected with non-Purafil 12V power adapter, there is no guarantee that
the product will work properly or free from harm or damage.
Do not touch the cord with wet hands.
Do not use near any flammable or explosive materials.
Do not use in highly humid environment, such as bathroom.

Please keep the manual at hand for
easy access.
Read the manual carefully before
use.
To use properly, please read and
follow the following notes and
warnings.
Safety Precautions
Do not place the product in any area that may obstruct driving activities or disturb safety
protection, or any other areas that may cause danger.
When use in car, do not place the product in any area that may block the driver’s view,
or obstruct driving activities.
Please only use in dry areas in the car. Please keep the product dry, and any use in highly
humid environment is not allowed.
Do no use near any heat source, heated areas, flammables or explosives, or in direct
sunlight.
Please ensure the plug is well suited into the socket.
If the plug, the socket, or the appliance is damaged, or the unit doesn’t operate properly,
do not use.
Do not touch the cord with wet hands.
Please make sure the power socket is in accordance with product requirements.
To comply with safe driving, actions such as switching on/off the power, plug-in/out are not
recommended.
To avoid accidents, please keep the product away from children and pets.
When in use, do not cover the air inlet/outlet, and please do not put fingers or any other
objects in the inlet/outlet.
Only the filters specifically made for the PuraShield Mini can be used with this product; avoid
using other filter brands.
When repair is needed, please send the product to Purafil’s designated service
representatives, and do not use any unauthorized parts.
No water shall be allowed to enter the product during cleaning.
Please do not pour any liquid or spray any aerosol to this appliance or its filters.
To ensure proper functioning, it is recommended to replace the filter every six
months. To maintain working efficiency, please check and replace filters on a regular
basis, the frequency should base on surrounding environment and actual usage.
Washing is not allowed for PuraShield Mini Portable Air Purifier filters.
Ensure the product is unplugged before replacing filters.
Notice

Your Air Purifier
Upper Case
Touch Button
Indicating Light
Air Outlet
Car's Anti-slip Pad
Buckle Strap
Multiple-effect
Filter Cartridge
Air Inlet
Filter Cover
To obtain a full support from Purafil, please register your product.
Before setup and use, please read this user manual thoroughly and keep it in a safe place for future
reference.
Strap
Thank you for selecting this Purafil product!
USB Power Cable

Product Features
Patented§Multi-layer
Filter Technology
Two fan speed settings: High and Low
Touch button design realized easy operation.
Operation status indicators clearly indicating the operation mode.
High quality high speed DC motor in use, featuring low noise, large quantity of air flow and
highly energy efficient.
Multiple usage: the product can be placed on anti-slip pad above the car instrument panel or
armrest; it can also be fixed to the back of the headrest using straps included with the product.
Multi-layer composite filter is an innovated structure with multiple patented filtration technologies
and UV light integrated into one. It can effectively remove PM 2.5 particulates, smoke, dust, target
viruses and bacteria, and odorous gases. The filter uses multiple technology layers to eliminate
99.9% of target viruses and bacteria*. The PuraWard Filter is protected by an embedded
micro-technology containing an EPA registered antimicrobial additive using copper and silver
ions to combat many bacteria and viruses†. Developed and manufactured in the USA, our
patented§molecular filtration media removes aerosols carrying viruses from the air, safely
oxidizing the molecules.

Developed and manufactured in the USA, our patented molecular filtration media removes aerosols
carrying viruses from the air, safely oxidizing the molecules, while removing toxic and harmful gases.
Product Functions
Molecular Filtration Media:
A high efficiency filter protected by an embedded micro-technology containing an EPA registered antimicrobial
additive using copper and silver ions to combat many bacteria and viruses. PuraWard has been successfully
applied to air filters and respiratory masks approved by the FDA.
PuraWard Filter:
Virus Reduction Rate Time
H1N1 99.91% 5 Min.
H7N9 99.98% 5 Min.
FILTER IS PROTECTED FROM VIRUSES AND BACTERIA:
Bacteria Reduction Rate Time
S. Aureus 99.95% 1 Hr
E. coli 99.96% 1 Hr
PURASHIELD MINI TESTED TO REMOVE*
VIRUSES
H1N1 Influenza A
MS2
Percent
99.99%
99.99%
Percent
99.9%
BACTERIA
Staph Albus
*Laboratory testing shows 99.9% reduction of H1N1, MS2, and Staph Albus in 2 hours. Test reports are available on request.
† Filter protected by an EPA-registered antimicrobial additive. . §Patent number US 9,370,763 B2

Usage
Mounting position A
For initial use, please put straps
through the buckle strap on the back
of the product.
Mount the product on the back of
the seat.
Plug the power cord into the product.
Insert the other end of the power cord
into a USB port or a cigar lighter
adapter (not inlcuded).
Place the power cord in a hidden
place, or places where driving
activities will not be disturbed.
Touch the power switch lightly to turn
on/off the product. By pressing it
multiple times, the following status can
be adjusted: high speed low speed,
turn off.
1.
4. 5. 6.
2. 3.

Touch the power switch lightly to turn
on/off the product. By pressing it
multiple times, the following status can
be adjusted: high speed low speed
turn off.
6.
Place the anti-slip pad on to the car
instrument panel.
1. Plug the power cord into the product. 2.
Insert the other end of the power cord
into a USB port or a cigar lighter
adapter (not inlcuded).
4. Place the power cord in a hidden
place, or places where driving
activities will not be disturbed.
5.
Place the product on the pad.
3.
Usage
Mounting position B

Filter Replacement
Control Panel
Functions
Please ensure the plug and socket insert well and firmly.
Never use this product if it has a damaged cord or plug, if the unit is damaged or it is
not operating properly.
Do not touch the cord with wet hands.
Please insert the plug of the MINI Car Air Purifier into a USB port
or a cigar lighter adapter (not inlcuded).
Unplug the power cord from the unit,
and place the unit on a firm surface.
2.
Touch the Power switch until the
indicator is off to shut down the unit.
1. Press the filter cover and pull to open
the filter.
3.
Pull the filter handle, take out used
filters.
4. Push the filter handle, install new filter. 5. Put on the back cover; press the filter
cover firmly with hands until it closes.
6.
Filter Replacement:

Shall the product pictures be different from the actual product,
the actual product prevails.
Product Specifications
Manufacturer declaration:
Operation Standard:
Product Model CPUM-MINI
Parameter
Noise <50dB
Clean Air Volume 4 m3/h
Filter CPUM-MINI-CART
Nominal Voltage DC12V
Nominal Power 3.9 W
Weight 860 g
Unit Size 200x142x60 mm
Specification
PuraShield Mini Air Filtration Unit

Common Problems Cause and Solution
Failure to Turn On
Fan Operation Failure
Touch button has no reaction
Replaced Filter Mismatch
Major Air Quantity Decrease
Check if the power cord is connected properly .
Check if there is any objects blocking the inlet/outlet of the appliance.
Check the filter condition, if it is too dirty change a new one.
Check if the power cord has any short-circuit.
After checking, if the touch button still does not work, please contact
our hotline.
Check if the type number on the filter is CPUM-MINI-CART
Portable Air Purifier.
Ensure the filter is well suited in the filter slot.
Ensure there is no foreign objects blocking the opening of the filter.
Remove the plastic package when replacing filters.
Check and ensure there is no objects blocking the air inlet/outlet.
Check the filter condition. If it is too dirty, replace the filter..
Ensure the plug is plugged into the USB Port.
Ensure the car is powered up.
Verify if the power cord is well connected.
Check if the plug is well connected and conducting well.
Ensure the unit is turned on.
Trouble Shooting Guideline
When your PuraShield Mini has the following problems, please unplug the unit first; the measures listed
below can be taken, or contact the nearby customer service centers established by our company for
assistance.

Purafil, Inc. 2654 Weaver Way, Doraville, GA 30340, USA
Phone: [phone] Website: www.purafil.com
Contact Information

Dealer (Purchase Location)
Contact No.
Model Product Code
Contact No.
Address
Purchase Date
Post Code
User Name
Address
Post Code
cut along the dot line
Warranty
To register your device online, visit:
https://www.purafil.com/purashield-registration/

cut along the dot line
Instructions for After Sale Service
1.
2.
3.
4.
Visit https://www.purafil.com/purashield-registration/ to register your device.
Purafil offers a two year warranty free of charge
(product appearance and consumable items are not included)
since the purchase date. The date of purchase is subject to effective
purchase receipts；
Service will be provided by completing the online warranty form or
warranty card and presenting effective purchase receipts. The warranty form
and purchase receipt need to be presented when requesting a service under
warranty.
The warranty does not cover the following circumstances:
：
Purafil reserves the rights of modification and interpretation of the above
terms and conditions.
（1）
（2）
（3）
Any damage caused by human factors including using the
appliance under improper operating conditions, operating without
following the User Manual, and improper storage etc.
Unauthorized disassembly, maintenance, modification conducted
by the user or an unauthorized third party; failure to provide a
warranty card or effective receipts.
The appliance is damaged due to improper transposition or other
irresistible incidence (such as flood, fire, thunderstrike and
earthquake etc.) after the purchase.
Manufacturer:
2654 Weaver Way, Doraville, GA 30340, USA
Phone: [phone] USA: [phone]
Purafil, Inc.
