Pure-Pro JA-568 User manual

1
L
JA-568
USER'S Manual
【 】CONTENT
Attention
Components of Electrolysis Water
Ionizer and Its Accessories
Panel Operations and Functions
Generationof Calcium Ionized Water
Replacement of Filter Cartridge
Trouble Shooting Guide
Main Specification
Advantages of Drinking Alkaline
Calcium Ionized Water
Usage of Acidic Ionized Water
Installation of Alternative Switch
1
3
4
5
6
7
8
9
10
11

Before you use the electrolysis water ionizer, please read the
following notices carefully and adhere to them during using it strictly, or it
is possible to damage the machine and your family's health.
1
1
2
3
4
5
6
Do not use turbid water as well
water, underground water or
heavy metal polluted water.
Do not connect any containers or
machines with hot water above 40 C,
lest damage can occur.
0
Do not use aluminum or copper made container for avoiding rust or
discolor.
Do not wash the machine with water directly, and do
not use volatile solvents as alcohol to clean the
machine body. Please wipe it with a soft cloth or
cloth soaked with soap water.
Please replace the filter regularly.
Do not disassemble the machine. Do not block, curve and twist
water inlet/outlet tube. During using the machine, acidic water tube
do not hang high for getting remaining water out of the tube.

7
8
9
10
12
11
13
2
Please prevent the machine from extreme bumping or shaking, avoid
heavy heat ad strong sunlight.
Please pour water into the machine every bay
prior to using it.
Please drink ionized water generated by electrolysis.
As soon as possible. (Under a sealed condition,
period of efficacy of the water is one day in normal
atmosphere temperature, and it is two days in fridge)
Do not use ionized water to breed goldfish or tropical fish, lest
death takes them.
Do not use take medicine with alkaline
ionized water, you should use purified water.
Do not drink acidic water; it is used for
beautifying the face and skin.
Please disconnect the power supply when the machine is not in use
for long period of time.

Operation Panel
Liquid Crystal Display
Alkaline Water Acidic Water
Power Supply Cable
Filter Shell Cover Silver Fiber Activated Carbon
Connectionvalve
12Hose Clip x 2
4Snake Hose x 1
Hanging Fixture x 1
Suction Used to Fix
Water Drain Hose
6
3
PH Testing Liquid
10ml
5
3
1
Water Inlet / Outlet
Hose x 2

When the tap is turned on and water generation
suspends, or stops pressing buttons after pressing
switches, the screen light automatically goes off
after some 1 minute.
00 L
1
2
3
4
5
It indicates water flow volume and water
temperature at present.
1
Alkaline Water/Acidic Water/Purified Water indicator.
3
Filter cartridge life-bar is set at about 6000 liters
water flown through it. Replace filter cartridge
when the bar goes off.
5
Cleaning begins automatically when electrolysis
water generation is closed; the part of the screen
manifests cleaning is on and displays anti-
clockwise rotation. During electrolysis water
generation is open, clockwise rotation is
displayed.
4
Its color corresponds to color acid/alkaline
(PH) values reflect. The speed of screen
bubbles shows electrolysis generation intensity.
2
4
1
00 L
Water Flow Volume
Water Temperature
Replacement/life
(When the light is on,
please press "start" button
to begin intense internal
cleaning; the machine
will begin cleaning
automatically when it's
filled with 60L water)
Cleaning Button
(Filter Cartridge Replacement
Indicator When replacement light
goes on, it indicates the filter's
life is over. Replacement Signal
Reset Button)
(Select different intensity alkaline water
according to different needs)
PurifiedWater Selection Button
Alkaline Water Selection Button
Acidic Water Selection Button
(acidic water)
Introduction of LCD

1.Generation of Alkaline Water: turn the tap on and water
flows into the machine. During puocessing back light goes
on, buzzer beeps 3 times and arrow indicator points toward
Alkaline Press the selection button for the required PH level.
With different press, PH value size varies. Purple colored
back light represents heavy alkaline, blue colored back light
represents everyday drinking alkaline.
2.Generation of purified Water:when the button is pressed,
water flows into the machine. Arrow indicator points toward
purified water, buzzer beeps 3 times; both alkaline water
outlet and acidic water outlet are without electrolysis (green
colored back light goes on ). After the tap is closed for about
1 minute, back light goes off and the everyday drinking
button is automatically triggered on by default.
3.Generation of Alkaline Water: when the button is pressed,
water flows into the machine. Buzzer beeps continuously
(back light becomes red). Arrow indicator points toward
Acidic. Press the selection button for the required PH level.
With different press, PH value size varies. After the tap is
closed for about 1 minute, back light goes off and the veryday
drinking button is automatically triggered on by default.
Notice: every time alkaline calcium ionized water generation has
stopped; comquter in the machine automatically performs internal
cleaning. When done, back light goes off, the machine is in a state of
power saving.
5
Alkaline Water
Purified Water
Acidic Water

1. Detach the cover; unscrew the lid on the second level (spanner is
provided).
2. Take out the inner filter cartridge, aim at the intruded area and place
a new one in.
3. Screw the lid on the second level, put back the cover on the first
level.
Cleaning
Button
Cleaning of filter cartridge
Cleaning
when using 50L water, indicating light goes on, which means to require cleaning. It can be adjusted according to
different water condition in regions. The procedures are as follows:
When waiting, 1.press and hold "purified Water Selection" button for 5 seconds, water flow volume 50L is
revealed on the top left-hand part of the screen. 2.Adjustable range is from 30L to 90L by use of "cleaning" button
or "replacement" button (plus or minus). 3.After range adjustment is over, press "cleaning" button once again, so
the setrp is completed.
Notice: the inner filter cartridge must aim at the
intruded area for the ionizer to work correctly.
Incorrect placement produces warning sound. Please
ensure correct placement for the ionizer to work properly.
ACF Feature activated carbon pores structure
Type of Material: silver fiber coc
onut shell activated carbon
Flowing Rate: 5.0L/Minute
1.When replacement light goes on,
the filter cartridge has exceeded total
water flow volume; it must be
replaced immediately to ensure
electrolysis water quality.
2.After the filter cartridge is replaced,
press and hold Replacement Signal
Reset Button for 3 seconds. When
you hear a long hua sound and
replacement light goes off, release the
button.
6
When intense cleaning light is on,
please turn the tap on, press start
button, cleaning light flickers and
music is played. After cleaning is
done, cleaning light goes off, music
stops, the everyday drinking button
is selected by default.
Replacement
Signal Rest Button
(High-technology long-life coconut shell fiber activated filter cartridge)
Purifying Capacity: take away
salty particle residue
Flowing Volume: about 600L
Remove foul and bad odor
Method for Replacement of Filter Cartridge

7
Phenomenon Reason for problems and handling guideline
Power background
Light mot on or LCD
Displays nothing Ensure power cord is connected to an electrical outlet
Back light is mot on
and nothing get
generation
Displayed when
1.Water pressure too low, the machine does not work correctly, operator
installs additional water pump.
2.Check for correct installation of filter cartridge. The machine does not
work when filter cartridge is misplaced.
Unfold the bent part of the water supply hose.
Ionized water or pure
water comeout dirtily
1.Maybe it is time to replace filter cartridge? (Filter cartridge can be
bought in distribution agencies)
2.Is the tap only half on? Please let more water flow out from the tap.
3.Is water supply line frozen? Defrost the water supply line before using.
Is the indicator light for cleaning required on? Please perform cleaning.
Electrolyzed alkaline
water appears to have
white colored stain
Alkaline ionized water is usually white color after being generated. This
is due to the air bubbles formed as a result of reaction with electrolysis.
It will turn into transparent in a short while and is perfectly safe for
drinking.
1.The white floating object is a crystal formation(the solid form of
calcium) which reaction of Calcium ion and Carbon Dioxide in the air
generates. It is perfectly safe for drinking.
2.The thin layer that can be seen is the solid form of Calcium. Please use
vinegar to clean it.
Container for storing
alkaline water shows
white floating object
or develops thin layer
on its inner wall
Not using the ionizer
for long period of
time
Alkaline water flowing
out from alkaline faucet
becomes slower and
slower
Maybe gradual formation of Calcium crystal in hose blocks the water
outlet, which makes the water flow-out become slower and slower.
Please employ professional to clean inner hose or purchase special filter
cleanser for the ionizer from our company.
Please ensure the power cord is unplugged. Remove water separator and
filter device from the purifier.

Processing rate of water 2./minute:
[In-water pressure is 0.1Mpa(about 1kgf/cm )]
Water Exit Volume 3L/minue:
[In-water pressure is 0.2Mpa(about 2kgf/cm )](estimate)
Electrolysis Capacity Level: Alkaline 3 level; Acidic 1 level
Possible Contnuous Electrolysis Duration:
(Level 1~2) about 1 hours (Level 3) about 30
Plate cleaning automatically performs every time being used.
When intensive cleaning is required after a period of time,
Intense cleaning indicator is on.
Automatic back cleaning when tap water is closed after processing.
2
2
40⊥
8
Power Supply AC:220V/50HZ(customized product)110V/60HZ
About 320W(max)
Nanometer TitaniumAlloys Electrolysis Trough
Power Consumption
Electrolysis Material
In-Water Pressure 1~6.5kg/cm2
Electrolysis Technique Continuous Electrolysis Technique (water volume and
temperature gauge built-in)
Machine Protection
Installation Fuse 10Aand electrical board:2A electrical power overheating
protection installed, transformer temperature protection installed.
Electrolysis
MainMachine
Dimension Height 310mm Width 220mm Depth 125mm℅ ℅
Machine Weight About 4.2kg
Purifier Total water flowing volume: about 6000L5.0L/minute
Purifying capacity: take away salty particle residue
Remove foul and bad odor
Max.Wate Temperature
For Continuous Usage
Power Cable Length About 9 feet

9
Prevent aging:
moisture content of human body cellsreduces with increasing
age. When production andreservation ability of moisture
declines gradually, if continuously, the cells
can bemoistened ever, the speed of aging will slower
downobservably. Alkaline calcium ionized water is justsuitable
for cell sap.
full water is provided
Improve luster and elasticity of the skin:
besidesurine drain, moisture content can evaporate from
theskin. Ifnotsupplied,the skin will become saplessgradually
and wrinkles appear in advance.
Calm emotions:
alkaline calcium ionized water can help eliminate the body's
waste, prevent arteriosclerosis and constipation; it is also helpful
for calming nerve. Anxiety associated with thirsty reflects cells'
fragility and unease.
Maintain relaxation of muscle of urinary bladder:
if water is supplied regularly, there is anappropriate amount of
water reserved in the urinarybladder. If a man's urinary bladder is
often empty or full of urine, the muscle of that hurts easily. Evenif
volume of urine is quite little, there is stillurine drained. Night
urinating with little urine isattributed to aging of muscle of urinary
bladder.
Promote stomach and bowels
peristalsis, arousefeeling of urinating:
first drink a glass of alkalinecalcium ionized water as soon as you
get up, which canawake stomach and bowels, promote their
peristalsisand bring reaction of stomach and colon, shortlyfeeling
of urinating comes.

10
Keep normal body temperature:
adjustment of bodytemperature mainly depends on the
adjustment center inthe below thalamus of the brain. If lack of
water, thebody temperature will rise above normal, which
causesperturbation of function of the below thalamus after along
time.
Prevent gout and arthritis:
uric acid is thebody's metabolized waste. It is mainly drained out
ofthe body by sweat, urine and excrement. If lack ofwater, the
density of uric acid in blood willincrease, and it is piled in the
joints, which can
lead to gout and arthritis and accelerate aging of the
joints. Alkaline calcium ionized water is able toneutralize uric
acid and make it defecated byexcrement and urine.
Prevent kidney calculi:
average people hardly go to
lavatory at night, and volume of urine during 8 hours at night is
little, so the density of urine is generally high when you sleep. If
you drank a glass of 300CC alkaline calcium ionized water before
sleeping, urine would be diluted so as to reduce the possibility of
producing calculi.
Beautifying the face and skin:
it has an effect ofastriction. After washing face, the skin will
become delicate and attractive. It also has good effect whenyou
use it after shaving beard. if adding 2~3 glass ofacidic water to
bathing water, then bathing jar doesnotend to scale, which can
both beautify the entire body and keep the bathing jar clean.
Cleansing to better health:
the water can be usedfor gargling and prevent dermatophytosis.

1
2-layer
screw tooth
2 3 4 5
1 2
11
Way1
If the tap your family uses is
European or American pattern (as
the above picture)
If the water outlet is internal screw
thread (the below picture 1)
1.At first combine 2-layer screw tooth
with the water separator, then screw
them tight (procedure 1,2,3).
2.Unscrew the waver of the tap
(procedure 4).
3.The set of water separator equipped
with the gasket is fixed to the tap, then
screw tight (procedure 5).
According to your own habits, the handle
of the alternative switch can fasten left or
right.
If the water outlet is external screw thread
(as the left picture 2), installation procedures:
unscrew the waver of the tap, then screw the
alternative switch.
If the tap your family uses is
Taiwanese pattern (as the
above picture)
Procedures:
1.First place the installation
ring.
2.Select internal socket ring,
fit over the tap.
3.Use fixtures to fasten.
Lock the alternative switch.
If the water outlet is external screw thread (as
the left picture 2), installation procedures:
unscrew the waver of the tap, then screw the
alternative switch.
Way2
Water SEPARATOR Fix the tap to
the Water SEPARATOR
Unscrew the
water of tap
Combine and screw
the waver of tap
Unscrew the
water of tap Screw the alternative switch
