Tubing connection diagram
Installation diagram
08 Change filters
Change membrane
Operation regulation
FAQ
13 How UV works
Maintenance checking list
Memo
Thank you very much for selecting
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.
Pure-Pro Water Corp.
Memo
Doublestar
Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

01
PURE-PRO REVERSE OSMOSIS SYSTEM
14
PURE-PRO REVERSE OSMOSIS SYSTEM
Introduction of Double Star
¨
¨
Double Star- Chic Countertop RO System
Features & Specifications
As a smart and chic countertop RO system, Double Star is especially designed for
homes, offices, restaurants, and shops use. It is the most delightful RO system
invention of 21 century. This revolutionarily new PurePro compact system is easy
to use and install as an under sink type or a countertop one. With superior quality
of reverse osmosis, ultraviolet and carbon filtration to put refreshing, clean water
at your fingertips.
Moreover, without tools, no mess, and no technician, the individual sanitary
quick-change cartridges make it easier to maintain.
Maintenance checking list
Date
Filters
1st stage 2nd stage 3rd stage 4th stage 5th stage 6th stage
Production: 80 GPD / 300 LPD
3.2 gallons NSF standard water storage tank
Safety approval: tuv (en60950) & ce mark
With a transformer, available in 110volt, 220volt or 240volt (50/60hz)
Input in ac 110volt, 220volt or 240volt (50/60hz); output in dc24v
Operation pressure: 10 -100 psi
UV stainless steel. 1 gallon per minute / 3.8 liters per minute flow rate
Automatic shut-off valve
Flow restrictor, stainless steel check valve
Long reach attractive faucet
Feed water connector & deliver valve
Drain saddle valve
Quick-connect fitting
Four color coded 1/4 inch tubing for system connection
Completely assembled & water leaking testing
100% factory tested and sterilized ready for installation.
Water storage tank: 4.5gallons / 17 liters
Dimensions: (cm) 35 (l) x 35(w) x 15 (h) - system
(cm)28(l)x35(w)x28(h)-tank
Weight: 10 kg - system
4kg-tank
Max. inlet water temperature: 46
Suitable for: countertop / under sink
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

Reverse osmosis was originally designed to make sea water drinkable for the
navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore
size much smaller than bacteria virus, or the cryptosporidium parasite. When
functioning properly it will remove all microorganisms from tap water and produce
sterile water. Reverse osmosis is the reversal of the natural flow of osmosis. In a
water purification system, the goal is not to dilute the salt solution, but to
separate the pure water from the salt and other contaminants. When the natural
osmotic flow is reversed, water from the salt solution is forced to pass through the
membrane in the opposite direction by application of pressure-thus the term
REVERSE OSMOSIS. Through this process, we are able to produce pure water
by screening out the salts and other contaminants.
13
PURE-PRO REVERSE OSMOSIS SYSTEM
02
PURE-PRO REVERSE OSMOSIS SYSTEM
What is reverse osmosis
Reverse Osmosis
Pressure
Membrane
Water flow
How UV works
Using UV radiation in this manner to purify water is popular among Europeans
who have known about it for decades. It's used in the United States started in the
early 1990s and is becoming more prevalent especially with outbreaks of drinking
water contamination by microorganisms. The UV purification system
incorporates a lamp of suitable size and wattage to generate light of the proper
wavelength with an electronic ballast to operate it. The electronic ballast plays an
important role in how much UV the lamp generates. Dosage is a function of UV
wavelength, intensity and time. Light intensity from the lamp is proportional to the
electric current flowing through it, and is also affected by the frequency at which
it's operated. Both of these parameters are controlled by the electronic ballast.
Since many water purification systems are portable, they sometimes require
power supplied from a battery rather that the typical AC source, i.e.,220 -volt
outlet. The electronic ballast must be able to accommodate applications with this
requirement. Some of the other features users might expect from the electronic
ballast are small physical size, long life and high efficiency.
At least one line of electronic ballasts can help meet these requirements. It can
operate a wide variety of germicidal lamps from a number of different power
supply voltages including both AC and DC (battery) sources. Many models are
compact in size and can be easily incorporated into most designs. Probably one
of the most attractive features of the product line is that nearly any model can be
customized for a specific lamp to generate different levels of UV radiation. In
some cases, new or specialty lamps require new ballast designs. In these
instances, engineers can often create designs that meet or exceed customer
needs. UV irradiation is becoming a more viable and economical means of water
purification when used in conjunction with other methods.
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
1. Take out the UV sterilizer from the box as shown in the picture.
2. Connect the wire to both ends of UV lamp. 3. Tight up the UV cap.
Install UV lamp :
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

03
PURE-PRO REVERSE OSMOSIS SYSTEM
12
PURE-PRO REVERSE OSMOSIS SYSTEM
T.D.S
Components & Other selections
European ceramic faucet 3.2G water storage tank Housing wrench
Deliver-valve Water supply connector Drain saddle
Tank ball shut-off valve Four color coded 1/4 inch
tubing for system connection
¨Other selections
¨Components
TDS meter
Q: What is the guarantee on the Pure-Pro system ?
Q: What factors affect the quantity and the quality of the water production?
Pressure
Temperature
Total Dissolved Solids (TDS)
Membrane
Q: Can the Pure-Pro system be connected to an extra faucet?
The Pure-Pro System (excluding filters) is guaranteed for 1 year for material
and workmanship. All defective parts will be replaced free within the first year
under natural breakdown. The membrane has one year pro-rated guarantee.
There are four major variables to consider:
1. -The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSI is ideal.
2. -76 F is the ideal water temperature for R.O. 40 F water will
cause the production of R.O. water to fall to half of that at 76 F. The maximum
water temperature recommended is 85 F.
3. -The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4. -Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
Pure-Pro system includes RE1812-70 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
It only takes a 1/4" tee and tubing to run the water to a refrigerator or a extra
faucet. Some families run Pure-Pro system to all of their bathrooms.
0 0
0
0
Q: What is the maintenance schedule for the Pure-Pro System ?
The three pre-filter cartridges should be changed every 6 months. The 5 micron
sediment cartridge filter is the first one; the second is a carbon cartridge filter,
and the third one is a 1 micron sediment filters. (some systems comes with the
Extruded carbon filter.) Failure to change the cartridge every 6 months may
cause chlorine to destroy the membrane.
FAQ
Color Tester
GOOD
BAD
TEST
Mini TDS
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

11
PURE-PRO REVERSE OSMOSIS SYSTEM
04
PURE-PRO REVERSE OSMOSIS SYSTEM
Cartridge Filters
A.With everything connected, turn on the water check for leaks.
B.Make sure the storage tank shut-off valve is "OFF". Open the sink
top faucet.
C.Within a few minutes (up to 15) the water will start to run from the
faucet slowly.
D.Let the water run for at least 30 minutes. This flushes the carbon
filters on first time use.
E.After initial flushing, open the shut-off valve on the tank and close
the sink top faucet.
F.Tank will now full of water (usually 2 to 3 hours) after the tank has
filled. Open the sink top faucet and drain all water until the storage
tank is empty and there is only a small flow from the sink top
faucet.*** DO NOT USE FIRST TANK OF WATER.***
G.Close the sink top faucet. The system is now ready for use.
H.Change filters regularly every 6 to 12 months and have the
membrane checked annually.
Caution
1.Do not use hot water (over 45 C)!
2.Do not freeze the machine!
3.Switch off electricity and water source if away for more than 5 days,
and drain out pure water.
0
Operation regulation
Service Life
6 Months
4 Years
1 Year
Stage 1
Stage3
Stage 2
Inline Activated
Carbon Filter
Stage 4
Flimtec
Memmbrane
Stage 5
Post Carbon Filter
Cartridge Filters Filter Description
6 Months
6 Months
This 1micron sediment filter is made by Dupont Anti-
Bacteria. High capacity filter removes dusts, particles and
rusts, 99.70% anti-bacterial, comply with FDA test
standard. Use 100% pure PP fine fiber. Product series
have been passed the test in accordance with the filtering
effect test of ANSI-NSF standard 42 - particulate reduction
class II-V of U.S.A. Service Life: 1500GAL
This granular activated carbon filter is composed of
high-performance activated carbon that removes free
chlorine, odor, organic contaminants, pesticides, and
chemicals that contributed to taste and odor.
Service Life: 1500GAL
Filmtec (Dow Chemical)membranes, maker of the
world's most advanced reverse osmosis membranes.
High rejection membrane with the capacity of
producing 80 gallons per day. Eliminates up to
99.9% of most chemicals, dissolved solids, metals,
bacteria, and viruses. Service Life: 10000GAL
This post carbon filter is designed to improve taste.
It removes any residual impurities and odors and
provides a finer conditioning of pure water.
Service Life: 3000GAL
Inline 1 Micron
Sediment Filter
1 Year
Stage 6 Ultraviolet light (UV), a natural part of the sunlight is
widely accepted as a reliable, efficient & environmentally
friendly solution for water disinfection. This UV lamp
utilize the application of particularly efficient UV radiator
with a 254nm wave length to cause immediate death for
organisms and wipe out their ability to survive and
reproduce. 99.99% Destruction Of Bacteria And Viruses.
UVC-LIGHTING
ULTRAVIOLET WATER STERILIZER
Ultraviolet
Water Sterilizer
Inline Activated
Carbon Filter
This granular activated carbon filter is composed of
high-performance activated carbon that removes free
chlorine, odor, organic contaminants, pesticides, and
chemicals that contributed to taste and odor.
Service Life: 1500GAL
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

4Let the water run for at least 30
minutes. This flushes the carbon
filters on first time use.
05
PURE-PRO REVERSE OSMOSIS SYSTEM
10
PURE-PRO REVERSE OSMOSIS SYSTEM
Tank Faucet In PutDrain
3Switch on water tank.
Operation regulation
2Turn on water source.
To RO system
The parts of Doublestar
RO membrane housing
Post carbon filter
Flow restrictor 300ml
The 1st stage housing
The 2nd stage housing
The 3rd stage housing
UVC-LIGHTING
ULTRAVIOLET WATER STERILIZER
UV water sterilizer
Auto shut-off valve
To the tank
To the faucet
In put
Drain
1Plug in electricity.
Front part
Reverse part
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

Tank Faucet In PutDrain
06
PURE-PRO REVERSE OSMOSIS SYSTEM
09
PURE-PRO REVERSE OSMOSIS SYSTEM
Tubing connection diagram
Faucet
Tank
Drain
Input water
CONNECTING THE COLOR TUBING:
A. Connect the WHITE tubing to the water supply connector.
B. Connect the BLUE tubing to the sink top faucet.
C. Connect the BLACK tubing to the drain saddle.
D. Connect the RED tubing to the storage tank.
A
B
C
D
PRO
RE
NG WATE R SYSTEM
3Squeeze the quick connector jaco
fitting and pull the tube out.
4Remove the membrane housing
cap anticlockwise.
O
5Remove the membrane by a pincer.
6Install the membrane by carefully
pushing the spigot end into the
socket at the far end of the housing
until completely in.
Change membrane
To RO system
1Unplug electricity. 2Turn off water source. 3Switch off water tank.
(Reverse part)
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM

PURE-PRO REVERSE OSMOSIS SYSTEM
07 08
PURE-PRO REVERSE OSMOSIS SYSTEM
Input water : Install water tank :
1.Remove the membrane housing cap.
2.Replace the membrane.
To RO system
Deliver valve
To faucet
To water source pipe
Install European ceramic faucet : Install drain saddle :
Assemble membrane :
Hand tighten plastic
shut-off valve to tank.
Then connect color
tubing.
Drill a 1/4" hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Installation diagram
6Tight up the jaco fitting after
changing the filter. Push the tube
bank into the quick connector jaco
fitting.
7Drain out 1 Gallon of water to
purify replacement filters.
Change filters
5Squeeze the quick connector jaco
fitting and pull the tube out. Loose
the jaco fitting from the filter.
Then replace the filter.
3Switch off water tank.
1Turn off water source.
To RO system
UVC-LIGHTING
ULTRAVIOLET WATER STERILIZER
PRO
P
URE
DRINKING WATER SYSTEM
1Unplug electricity.
Double Star- Chic Countertop RO System Double Star- Chic Countertop RO System
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
