Puredrive Hybrid Series Assembly instructions

Hybrid –5 & 10kWh
Simple installation process
1. Install Solis Hybrid Inverter
2. Position the Battery
3. Connect the DC Power Cables
4. Connect the communication Cables
5. Set up the Solis
6. Switch on the Battery

Install the Solis Hybrid Inverter as per the manufacturers installation guide
1. Install Solis Hybrid Inverter
Hybrid Installer’s Guide

Take the lid off
the battery to
expose the
carrying handles.
Ensure the
selection switch
inside the battery
is set to 0
2. Position the Battery close to the Solis unit
Hybrid Installer’s Guide

Hybrid Installer’s Guide
Connect the cables
supplied with the
Solis Unit to the
battery connection on
the Solis
3a. Connect DC power cables to Solis Unit

Hybrid Installer’s Guide
14/10 mm Lugs
required
3b. Connect DC power cables to Battery

a) For the 10 kWh Hybrid the 2 batteries will need to be
connected to each other. Connect the A battery first, then
the B battery
b) Plug the communication cables between the two off
batteries as shown.
3c. Extra for 10kWh hybrid versions
Hybrid Installer’s Guide

Hybrid Installer’s Guide
You will need a
short RJ45 straight
through patch lead
4. Connect Coms Cable between Solis and Battery

Hybrid Installer’s Guide
Select ‘Puredrive’
option during set
up
5. Follow setup instructions for the Solis

Hybrid Installer’s Guide
Press the plain
button till it
latches
6. Switch on the Battery
Press the power
button till it turns
green
