Puretec D20C Series User manual

Freestanding Water Chiller System User Guide
MAINS WATER
D20C Series

2Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
What's Inside
Product Information
Distributor:
Installer:
Phone:
Date Installed:
What's Inside
Puretec Customer Service ................................................................................................. 3
Introduction................................................................................................................................. 3
Specifications ............................................................................................................................. 4
Installation Requirements................................................................................................... 5
Installation................................................................................................................................... 6
Operation & Maintenance................................................................................................... 7
Use Guidelines........................................................................................................................... 7
Electrical Diagram................................................................................................................... 8
Troubleshooting ........................................................................................................................ 8
Warranty....................................................................................................................................... 9
WMTS105
Certicate No. 23291
Pro-Switch Pty Ltd
D20C

3Copyright © Puretec Pty Ltd 2023 D20C Water Chiller System User Guide
Puretec Customer Service
Thank you for purchasing a Puretec Freestanding Water Chiller System. Your system is
a proven performer manufactured from only quality materials and components and will
give years of spring-like water, if maintained properly.
Customer Service Helpline 1300 140 140 (Australia) 0800 130 140 (New Zealand).
Introduction
The Puretec Freestanding Water Chiller System is designed to run economically for many
years, dependent on the initial installation and periodical maintenance.
Flush systems for 10 minutes aer any period of non-use more than 2 days.
The Freestanding Water Chiller System is designed to operate with mains water.
Installation Note: A water dispensing appliance, like any product, has a limited life
and may eventually fail. Also sometimes failure happens early due to unforeseen
circumstances. To avoid possible property damage, this product should be regularly
examined for leakage and/or deterioration and replaced when necessary. A drain pan,
plumbed to an appropriate drain or outfitted with a leak detector, should be used in
those applications where any leakage could cause property damage, and/or the water
supply should be turned off if no one is home/present.
ALL INSTALLATION AND SERVICE WORK SHOULD BE COMPLETED BY
QUALIFIED TRADESPEOPLE. FAULTY OPERATION DUE TO UNQUALIFIED
PERSONS WILL RESULT IN VOIDED WARRANTY COVERAGE.
Puretec Customer Service

4Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Model: D20C D20C-K
Filter Kit: Not Included Yes
Replacement Cartridge: N/A IN142C
Dispensers: Cold Water Only
Faucet: Swan Neck Tap, Bubbler
Function: Cooling
Voltage: 220 - 240V
Frequency: 50 Hz
Cooling Capacity: 20Lph
Input Power: 120W
Upper cover: SS304, Thickness 0.8 mm, rim inside pressed
Shell Housing Material: SS304, Thickness 1 mm
Inlet Connection: 1/4" Tube
Power Cord Length: 2m
Refrigerant: R134a
Cold Tank: 5L, Built-in Evaporator
Adjustable Feet: Yes
Specifications
Specifications
280
1230
170
370
1080
865
Fig. 1 - Dimensions

5Copyright © Puretec Pty Ltd 2023 D20C Water Chiller System User Guide
Installation Requirements
Installation Requirements
The following is a guide but the installer is responsible to comply with any local
regulations that may be applicable to this type of installation.
1. Install near a convenient place to connect to a mains pressure water supply of
drinking water quality and 220 - 240V/50Hz electrical supply.
2. Avoid areas exposed to excessive heat, humidity, rain, saltwater or snow or direct
contact with water spray or splashing.
3. Avoid positions of direct sunlight or solar heat.
4. Install only on flat, level and well supported surfaces.
5. Avoid tilting the machine during installation. If the machine has been tilted
excessively for more than a few minutes during or before installation, leave to
stand for approximately one hour before switching on.
6. Allow an air gap of at 100 mm each side and at the front of the machine.
280
1230
170
370
1080
865
Drain Port: 40 mm DWV Pipe
Fig. 2 - Installation Diagram

6Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Installation
Installation
1. Once positioned and levelled remove the front panel
2. Assemble the carafe filler by inserting the gooseneck outlet into the carafe filler
base that comes installed on the sink. Ensure the gooseneck outlet is pushed in
hard until properly sealed.
3. Connect the 40 mm drain outlet using appropriate 40 mm DWV pipe, fittings and
sealing compound to suit the installation.
4. Connect the inlet water supply to the ¼” tube fitting at the rear of the cabinet and
ensure there is an easily accessible shutoff valve on the water supply line. Fit a
pressure reducing valve to regulate the water pressure if required - max 500 kPa.
5. Switch on the water and check all tubing and fittings for water leaks.
6. Test the dispenser connections by pressing the bubbler button to ensure flow, then
by turning the carafe handle to ensure flow.
7. When new it may take up to 3 minutes to fill the system prior to dispensing water.
8. Connect the power cord to a standard 240V powerpoint and switch on the electrical
supply.
9. Refit the front panel.
10. Allow 1 hour for the water to cool before the water reaches its operational
temperature.
11. To protect the compressor, allow the unit to stand for at least 1 hour aer moving
before switching it back on.
Drain Port
Drain
40 mm DWV Pipe
(not supplied)

7Copyright © Puretec Pty Ltd 2023 D20C Water Chiller System User Guide
Operation & Maintenance
Operation & Maintenance
• Frequently clean the fountain using warm soapy water. Avoid all abrasive and
corrosive cleaning materials.
• Do not pour any waste cleaning water down the drain to avoid blocking the drain
trap.
• If the chiller is not used (e.g. more than 3 days) the power can be switched off to
conserve energy.
• We recommend that the fountain is cleaned aer any period of disuse.
• Keep the area surrounding the fountain clean and dry. In the event of any leakages,
switch off the water and power and call Puretec.
• For models where a filter kit is supplied, Puretec recommends changing the filter
every 6-12 months, when taste and odour return or when you detect a decrease in
flow, whichever comes first.
Use Guidelines
• Use for mains water supply.
• Minimum operating pressure 100 kPa.
• Maximum operating pressure 400* kPa.
• Do not allow exposure to temperatures below 0 °C, protect from freezing.
• Maximum operating temperature 38 °C.
• System must be installed according to local plumbing codes on the cold water line
only.
Caution: Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before the chiller.
* Where line pressure exceeds 400 kPa, an approved pressure limiting device must be
installed (350 kPa limiting valve is recommended for D20C) and must also comply with
Australian & New Zealand Plumbing Standards. (Ref. AS/NZS 3500.1:2021, Clause 3.3.4).

8Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Use Guidelines
Cold Thermostat
Compressor
Fan
Fuse
Fig. 3 - Electrical Diagram
Troubleshooting Guide
In the event of any other breakdown, please call Puretec
Fault Possible Cause Suggested Action
Not cooling. The compressor is not running. Check the power is switched on.
The power is on but not cooling. The thermostat is set too high. Reduce the thermostat
temperature setting.
Water leakage. The pipes or connections are
leaking.
Switch off power, turn off water
and call your service engineer.
Slow water flow.
Low pressure or water leakage. Check connections and inlet
pressure.
Filter cartridge has reached its
max. capacity. Replace filter cartridge.
No water dispenses from the
taps.
Water inlet valve(s) closed or
other blockage.
Open and/or reset the water
inlet valve(s) and check water
supply pipe
Drainage waste blocked. Debris has blocked up the
waste system. Clear the obstruction.

9Copyright © Puretec Pty Ltd 2023 D20C Water Chiller System User Guide
External Filter Kit Installation
D20C-K models include a separate water filter kit. Follow the below installation steps;
1. Select suitable location that is close to the Freestanding Water Chiller System.
Remember to allow access room for changing filters and a suitable place where
water spillage will not cause damage. Location should not be in direct sunlight.
2. Isolate water supply. Uninstall the connections on the cold water line and connect
the tubing, a Smart Tee™ (sold separately) is recommended. Reinstall the previous
connection to the tee valve.
3. Connect a pressure limiting MultiValve (sold separately) to the tee valve with a
length of White Tubing.
6. Install filter cartridge by positioning it in the desired location, marking the position
of fixing hole and fixing with bracket screw. The filter can be mounted horizontally
or vertically. Allow room for the connecting tubes. Ensure flow arrow on the filter
cartridge is in direction of the water flow.
7. Fit tubing into connectors. Allow slack in the tubing.
8. Restore the water supply and check for leaks.
9. When new it may take up to 1 minute to fill the system prior to dispensing water.
Run the system for at least 5 minutes to remove carbon fines. Water may appear
milky, but this is normal and is only tiny air bubbles that will clear aer a short
period.
Fig. 4 - External Filter Kit Installation Diagram
Chiller
Cold Water
Supply
Tee Valve
(sold separately)
MultiValve
(sold separately)
Inline Filter
& Bracket
Tubing
Filter Kit Installation

10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Cartridge Changeout
Replacement cartridge code for D20C-K systems: IN142C
1. Place container under the filter in case of drips.
2. Isolate the water supply and release the water pressure by operating the tap or
bubbler.
3. Disconnect tubing from the cartridge. Discard old cartridge.
4. Remove packaging from the new cartridge. Connect tubing to either end of the
cartridge. Ensure flow arrow on the cartridge is in direction of the water flow.
5. Restore water supply.
4. Check for leaks, rectifying them, if any, before leaving the unit.
Aer installing cartridges flush unit for 5 - 10 minutes.
Cartridge Changeout

11Copyright © Puretec Pty Ltd 2023 D20C Water Chiller System User Guide
Warranty
Warranty
Notes
Puretec water care products are designed, manufactured and supported by Puretec Pty Ltd the name you can
trust for viable and proven water solutions. The complete range of Puretec products are developed, refined, made
to meet and exceed stringent specifications for the worldwide market.
Important: Sales of products are subject to our Terms and Conditions which are available upon request. All
specifications, information and photos are a guide only and are subject to change without notice. Please ring
to confirm details. Warning: For correct operation of this appliance it is essential to observe manufacturer’s
instructions. All installation and service work should be completed by qualified tradespeople. Faulty operation
due to unqualified persons will result in voided warranty coverage. All plumbing must comply with AS 3500.1. All
electrical must comply with AS/NZS3000.
Warranty
Any claim under this warranty must be made within 1 year of the date of purchase of the product. This product
is warranted to be free of defects of material and workmanship for 1 year from the date of purchase. 1 year
warranty is 1 year parts and labour. Excludes cartridges.
Puretec is renowned for its quality and aer-sales support so if you have any issues please call 1300 140 140
(AU) or 0800 130 140 (NZ). To make a warranty claim, contact us directly or the place of original purchase. All
costs relating to a warranty claim must be approved by Puretec prior to any work being carried out.
Puretec will pay your reasonable, direct expenses of claiming under this warranty. You may submit details and
proof of your expense claim to place of purchase for consideration.
The warranty only applies if the product was used and/or installed in accordance with the user guide and/or
installation instructions. This warranty is given in lieu of all other express or implied warranties and manufacturer
shall in no circumstances be held liable for damages consequential or otherwise or delays caused or faulty
manufacturing except as excluded by law.
Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not
incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including
chargeable inspection and labour costs incurred.
Warranty/Australia
This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road, Lonsdale SA 5160, telephone
no. 1300 140 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under law: Our goods come with
guarantees which cannot be excluded under the Australian Consumer Law. You are entitled to replacement or
refund for a major failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Warranty/New Zealand
This warranty is given by Puretec NZ LP, Reg. No 50081773, PO Box 875 Cambridge 3450 NZ, telephone no. 0800
130 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under law: Our goods come with
guarantees which cannot be excluded under the Consumer Guarantees Act. You are entitled to replacement or
refund for a major failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.

Simply scan the QR code or visit
puretecgroup.com/warranty & complete the form.
Register your warranty online within 30 days of your
product purchase.
Terms and conditions apply. Proof of purchase must be retained.
Go to puretecgroup.com for full details.
Simply scan the QR code or visit
puretecgroup.com/warranty
& complete the form.
Register your warranty online within
30 days of your product purchase.
Terms and conditions apply. Proof of purchase must be
retained. Go to puretecgroup.com for full details.
JUN2023
