STATUS™ 24 VOLT
INSTALLATION GUIDE
INST074 Doc 2.00

1
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
CONTENTS
General Information ..........................................................................................2
Status Installation ...............................................................................................3
Operation and Troubleshooting.......................................................................5
Diagram...............................................................................................................6
Limited Commercial Warranty Policy.............................................................7

2
e Status™ system has an easy to interpret LED indicator to inform drivers
and technicians of the current status of a battery. A quick glance at the Status™
Controller assures the driver or technician that the batteries are ready to go,
or alerts the driver that the batteries need maintenance.
GENERAL INFORMATION

3
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
STATUS 24 VOLT INSTALLATION GUIDE
STATUS INSTALLATION
Step 1: Remove the ¾ inch NPT lock
nut. is nut will be used in step 3.
Step 2: Route the Status wires with
the inline fuse holder into the
battery box through a 1.06 inch
hole.
Note: e minimum hole size is 1.06
inches if there is not a pre-drilled
hole in the battery box.
Step 3: Push the Status through the
1.06 inch hole. Slide the ¾ inch
NPT lock nut over the positive
and negative wires and secure it
to the threads on the back of the
Status.

4
Step 5: Connect the wire with the
inline fuse marked battery positive
to the positive post on the battery.
Tighten battery nut.
Step 4: Connect the wire marked
battery negative to the negative
post on the battery. Tighten
battery nut.

5
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
STATUS 24 VOLT INSTALLATION GUIDE
OPERATION AND TROUBLESHOOTING
LED CONDITION ACTION NEEDED
Solid Green Charging mode None
Slow Flashing Green
Batteries in good state
of charge (More than
24.8 volts)
None
Slow Flashing Orange
Batteries in low state of
charge (Voltage below
24.8 volts)
Charge and test
batteries
No LED
Open ciruit from
battery positive and
Status™ or disconnected
ground in battery box
Repair circuit by
repairing the wire or
replacing the fuse

6
DIAGRAM

7
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
STATUS 24 VOLT INSTALLATION GUIDE
LIMITED COMMERCIAL WARRANTY POLICY
Purkeys Fleet Electric, Inc. (hereaer “Purkeys”), warrants each product to be free of defects
in material or workmanship under normal use and service. is warranty is for the benet of
Original Equipment Manufacturers, Dealers, Warehouse Distributors, Fleets, or other End
Users (hereaer “Customers”) and covers products manufactured by Purkeys and sold new to
Customers either directly by Purkeys or by its authorized dealers, distributors, or agents. e
length of the Warranty Period is 36 months.
e warranty period commences on the in-service or install date and is not transferable.
Failure to provide the in-service or install date on the warranty claim form will cause the
warranty period to begin on the date the part was manufactured or date of sale recorded on the
original sales invoice, whichever is earlier.
A completed warranty claim form should accompany all parts submitted to Purkeys for
consideration for repair or replacement under warranty. e submitted claim form should
contain all of the information required. Lack of a properly or fully completed claim form will
result in delay or denial of warranty claim. Claims must be submitted no later than 30 days
aer part is removed.
is warranty does not apply if, in sole judgement of Purkeys, the product has been damaged
or subjected to accident, faulty repair, improper adjustment, improper installation or wiring,
neglect, misuse, or alteration or if the product failure is caused by defects in peripheral vehicle
components or components attached to the Product or failure of a part not manufactured by
Purkeys.
is warranty shall not apply if any Purkeys product is used for a purpose for which it is not
designed or is in any way altered without the specic prior written consent of Purkeys. ANY
Product alleged by a Customer to be defective must be inspected by Purkeys as a part of the
warranty claims process in order to conrm that the part has failed as a result of a defect in
material or workmanship.
Transportation for products and parts submitted to Purkeys for warranty consideration must
be prepaid by Customer. Repaired or replaced products and or components will be returned to
Customer pre-paid by Customer or “freight collect” to the address provided by Customer in the
warranty claim form. No charge will be made for labor or material in eecting such repairs.
e Warranty provided by Purkeys hereunder is specically limited to repair or replacement
of the Product as Purkeys deems most appropriate in its sole discretion. Purkeys neither
assumes nor authorizes any other person to assume on its behalf any other warranty or
liabilities in connection with Purkeys products. e Warranty does not apply to fuses or other
“consumable” or maintenance items which are or may be a part of any Purkeys product.
THIS WARRANTY DOES NOT APPLY TO LOSS OF VEHICLE OR EQUIPMENT, LOSS OF
TIME, INCONVENIENCE, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES.
PURKEYS SPECIFICALLY DISCLAIMS AND SHALL NOT BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES arising out of or from the use of Purkeys products by the
Customer.
THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, INCLUDING
COMMON LAW WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, AND ANY OTHER EXPRESS OR IMPLIED WARRANTIES. ALL
OTHER SUCH WARRANTIES ARE SPECIFICALLY DISCLAIMED.
is Limited Commercial Warranty supersedes all previous Warranty Policies issued by
Purkeys and any of its suppliers.
